Argo Symphony User manual

11
V 09/20
This product is only suitable for correctly-insulated
environments or for occasional use.
OPERATING INSTRUCTIONS
Read the instructions carefully before operating the appliance or carrying out maintenance
operations.
Observe all the safety instructions; failure to observe the instructions may lead to accidents and/or
damage. Keep these instructions in a safe place for future reference.
GENERAL SAFETY INFORMATION
DIGITAL CERAMIC FAN HEATER
EN

12
V 09/20
Use this fan heater only as outlined in this manual. Any other use
not recommended by the manufacturer may cause fire, electric
shock or injury to persons.
Make sure that the type of mains power complies with the electrical
requirements of the fan heater (220-240 V~/50 Hz).
This appliance can be used by children of at least 8 years of age
and by people with reduced physical, sensory or mental abilities, or
who lack sufficient experience or the necessary knowledge,
provided that they are supervised or have been instructed on how
to use the appliance safely and understand the hazards related to
its use.
Children must not be allowed to play with the appliance.
Cleaning and maintenance operations normally carried out by the
user must not be performed by unsupervised children.
This product is not a toy.
Children under the age of 3 must be kept away unless
continuously supervised.
Children between the ages of 3 and 8 only need to switch the
appliance on / off as long as it has been placed or installed in its
normal operating position and that they receive supervision or
instructions regarding the safe use of the appliance and
understand the dangers.
Children between the ages of 3 and 8 must not plug in, adjust or
clean the appliance or perform maintenance by the user.
WARNING: Certain parts of this product may become very hot
and cause burns. Special care should be taken when children
and vulnerable people are nearby.
To avoid the risk of accidentally resetting the thermal protection,
this appliance must not be powered through an external switching
device, such as a timer, or connected to a circuit that is switched
on and off by the utility.
WARNING: do not use the fan heater with a controller or any
other device that activates the appliance automatically, as
there may be a risk of fire if the fan heater is covered or
incorrectly positioned.
Do not restrict the air inlet and outlet grilles.
The appliance heats up significantly when running and can cause
burns. Avoid unprotected contact with the hot surface.

13
V 09/20
Keep flammable materials, such as furniture, cushions, blankets,
paper, cloths, curtains and similar items at least 1 m away from the
front, sides and back of the appliance.
Disconnect the mains power when the appliance is not in use or
during cleaning.
Avoid using the fan heater in dusty environments or in the
presence of flammable vapours (e.g. in workshops or garages).
Do not place anything on the product; avoid placing wet garments
on the fan heater.
Use the heater in a well-ventilated area.
Avoid placing fingers or foreign objects in the air inlet/outlet grilles,
as this may lead to electric shock or fire and may damage the
appliance.
To avoid the risk of fire, do not block the grilles or tamper with
them in any way while the fan heater is in use.
Do not use the appliance if the power cable or plug are
damaged. If the power supply cable is damaged, it must be
replaced by the manufacturer or its technical assistance service or
in any case by a person with similar qualifications, in order to
prevent any risk.
Do not use the fan heater if it has fallen from a certain height or if it
has been damaged in any way. Contact a service centre to check
the fan heater or make any necessary electrical or mechanical
repairs.
The most common cause of overheating is the build-up of dust in
the appliance. Remove accumulated dust by removing the plug
and cleaning the grilles using a vacuum cleaner.
Do not use any abrasive products to clean the appliance. Clean it
using a damp cloth (not wet) rinsed with soapy water. Remove the
plug from the socket before performing any maintenance.
To disconnect the fan heater, turn the switch to OFF and remove
the plug from the socket. Pull on the plug only. Do not pull on the
cable when turning off the fan heater.
Do not place any objects on the cable and also avoid bending the
cable.
Using extension leads is not recommended as they may overheat
and cause a fire hazard. Never use a single extension lead to
operate multiple appliances.

14
V 09/20
Do not immerse the power cable, plug or any other part of the
appliance in water or other liquids.
Do not touch the plug with wet hands.
Do not place the fan heater above or near another heat source.
WARNING: AVOID COVERING THE FAN HEATER TO PREVENT
IT FROM OVERHEATING.
The symbol below signals this warning:
The fan heater may cause the risk of fire if, while operating, it is
covered or comes into contact with flammable material including
curtains, drapery, blankets, etc. KEEP THE FAN HEATER AWAY
FROM THESE MATERIALS.
Do not connect the fan heater to the power supply until it has been
correctly assembled or positioned.
Do not run the cable under carpets. Do not cover the cable with
blankets, carpets or similar materials. Place the cable away from
busy areas and where it cannot accidentally be pulled out.
Do not operate the fan heater in close proximity to bathtubs,
showers, washbasins or pools.
Do not position the fan heater in the bathroom.
The heating appliance must not be placed immediately below a
power outlet.
Do not operate the appliance outdoors.
Upon initial start-up, the fan heater may emit a slight, harmless
smell. This smell is a normal effect of the initial heating up of the
internal heating elements, and should not recur subsequently.
WARNING:
THE ON/OFF SWITCH IS NOT THE ONLY METHOD OF
DISCONNECTING THE MAINS POWER.
ALWAYS UNPLUG THE APPLIANCE DURING MAINTENANCE
OPERATIONS, WHEN MOVING IT OR WHILE IT IS NOT IN USE.
A fan heater contains parts that generate electrical arcs and
sparks. It must not be used in potentially dangerous areas such as
those subject to the risk of fire or explosion, or areas filled with
chemical substances or humidity.
Do not use the appliance on soft surfaces such as beds, where the
grilles may get covered. Always rest the fan heater on a flat and

15
V 09/20
stable surface when it is running, so as to prevent it from toppling
over. Arrange the cable so that neither the fan heater or other
objects can be on top of it.
Always unplug the appliance when it is not in use.
Turn the appliance off if unattended, in order to prevent accidents.
 In the event of any anomalies (abnormal noise or a strange smell),
immediately turn off the appliance; do not attempt to repair it but
take it to your local service centre.
DESCRIPTION OF PARTS
1. Soft touch control panel
2. LED display
3. Front panel
4. Hot air outlet
g
rille
5. Air intake grille with filter
6. On/off switch
7. Handle and remote control-holder
CONTROL PANEL DISPLAY and REMOTE CONTROL
REMOTE CONTROL
Front view Rear view
1
2
3
4
5
6
7
ON/OFF button
ON/OFF LED
+ / -
ECO LED Low power LED
(1500W)
High power LED
(2500W) TEMPERATURE &
TIMER button
High/low power
button
ECO button

16
V 09/20
Use Lithium/Manganese button cells, model no. CR2032 -3 V, conforming to Battery Directive no. 2006/66/EC and
amendment Directive 2013/56/EC (supplied with the remote control).
HOW TO INSERT / REMOVE THE REMOTE CONTROL BATTERIES (refer to the diagram below)
Open the battery cover at the back of the remote control (press the back and pull the flap). Insert the battery into the slot,
making sure you respect the polarities. Put the cover back onto the remote control.
WARNINGS FOR BATTERIES
Batteries must not be exposed to heat sources such as fire, sun or similar sources;
Remove the batteries if they start to heat up or you know you will not use the appliance for a long time
- the batteries must be installed correctly in the appropriate battery compartment;
- when you remove the batteries because they are damaged or at the end of their life, dispose of them according to the
national regulations in force and indicated below.
- In case of battery fluid leak, remove all batteries, avoiding the leaked liquid from coming into contact with skin or clothes. If
liquid from the battery comes into contact with skin or clothing, wash the skin with water immediately. Before inserting new
batteries, carefully clean the battery compartment with a paper towel, or follow the battery manufacturer's recommendations
for cleaning.
●Warning Danger of explosion if battery is replaced with an incorrect type. Use and replace only batteries with the same
size and type
Improper use of batteries can cause liquid leakage, overheating or explosion.
This liquid is corrosive and can be toxic. It can cause skin and eye burns, and is harmful to ingest.
To reduce the risk of injury:
●Keep batteries out of the reach of children.
●Do not heat, open, puncture, cut or throw batteries into fire.
●Do not mix old and new batteries or batteries of different types
●Do not leave metal objects that can come into contact with the battery terminals and therefore can heat up and / or cause
burns.
TIRA
PREMI
Inserimento pila
INFORMATION FOR THE CORRECT DISPOSAL OF BATTERIES IN ACCORDANCE WITH EUROPEAN DIRECTIVE
2006/66/EC and amendment Directive 2013/56/EC
Replace batteries when they are depleted. At the end of their life, batteries must be disposed of separately from unsorted
waste. They must be taken to designated recycling centres or returned to a retailer providing this service. Separate disposal of
batteries prevents potential negative effects on the environment and human health due to inadequate disposal, and also allows
their constituent materials to be recovered and recycled, resulting in significant savings in terms of energy and resources. In
order to highlight the obligation regarding separate disposal, the battery carries the crossed-out dustbin symbol. Illegal disposal
of the product by the user may lead to administrative sanctions being applied as per current regulations.

17
V 09/20
HOW TO USE THE FAN HEATER
Place the fan heater in a vertical position on a flat and stable surface. Connect the power cable to a suitable electric
socket (220-240V~/50Hz). Use the handle to move the appliance.
SWITCHING ON/OFF
Put the on/off button (on the rear) in the “I” position. When the appliance emits a “beep”, this means that the fan heater is
ready for use and enters stand-by mode. Press the button on the control panel or on the remote control to switch it on.
To switch off the fan heater, press the button again, let the unit cool down for about 30 seconds and switch the button
on the rear to “0” to turn the fan heater off.
Total
Press the button on the control panel or on the remote control to select the low (1500W) or high (2500W) heating
function. The LED in low function and in high function, will appear on the display.
TIMER
When the fan heater is operating, press the button on the control panel or on the remote control to set the timer. The
LED indicator will start flashing, press the + or - buttons on the control panel or on the remote control to select the switch-
off timer (1-12 h). When the set timer expires, the fan heater switches to stand-by mode.
TEMPERATURE REGULATION
The temperature can be regulated via the remote control or the control panel; press the button, on the display the
LED will flash, use the + e – buttons until you reach the desired temperature. Press the button again to exit the
temperature regulation settings.
ECO – CONTINUOUS MODE
When the unit is operating, press the “ECO” button to activate the Eco mode: the matching LED will light on the display.
In this mode the heating power is adjusted automatically,
- When the room temperature is lower than the set temperature by a maximum of 2°C, the fan heater will operate at
low power (1500W).
- When the room temperature is lower than the set temperature by more than 2°C, the fan heater will operate at high
power (2500W).
- When the room temperature is equal to the set temperature, the fan heater goes into stand-by mode and switches
back on when the room temperature drops by at least 2°C.
When the unit is operating, press the + button until the display shows “- -” to set the “CONTINUOUS” mode. In
CONTINUOUS mode, the fan heater operates without interruption for maximum 12 hours, before switching to stand-by
mode. If you want to activate this function, press the ECO button or the button twice and “-” to set the temperature.
Memory function: The unit memorises the settings even after it has switched off to stand-by mode.
Energy saving function: after 1 minute of operation, the brightness of the display is reduced by 1/3.
The appliance is equipped with an anti-tipping device which interrupts operation when the product is tilted. Do not
position the appliance on its side or upside down.
CAUTION: ALWAYS UNPLUG THE APPLIANCE BEFORE CLEANING OR MAINTENANCE OPERATIONS.
IMPORTANT: DO NOT IMMERSE THE CERAMIC FAN HEATER IN WATER
Cleaning the outside surface of the appliance
Use a soft cloth to remove any dust from the fan heater.
If the fan heater is excessively dirty, use a soft cloth dampened with water and neutral detergent at a temperature below
50°C. Leave the fan heater to dry completely before using it again.
Do not use corrosive detergents or solvents such as petrol. Do not wash the appliance with water. When cleaning the
appliance, do not use oils, chemical substances or other items that may damage the surface.
Use a vacuum cleaner to remove dust from the air inlet/outlet grilles.
STORAGE
If the appliance is not used for prolonged periods, it must be stored together with this manual in its original packaging, in a
cool and dry place.
MAINTENANCE AND STORAGE

18
V 09/20
INFORMATION REQUIREMENTS FOR ELECTRIC LOCAL SPACE HEATERS
Table 2 - Annex II - Ecodesign requirements - Requirements for product information -
COMMISSION REGULATION (EU) 2015/1188 of 28 April 2015 implementing Directive 2009/125/EC of the European
Parliament and of the Council with regard to ecodesign requirements for local space heaters
Model identifier(s): SYMPHONY
Item Symbol Value unit Item unit
Heat output Type of heat input, for electric storage local space
heaters only (select one)
Nominal heat output Pnom 2,5 kW manual heat charge control, with integrated
thermostat
[no]
Minimum heat output
(indicative)
Pmin 1,5 kW manual heat charge control with room
and/or outdoor temperature feedback
[no]
Maximum continuous
heat output
Pmax,c 2,5 kW electronic heat charge control with room
and/or outdoor temperature feedback
[no]
Auxiliary electricity
consumption
fan assisted heat output [no]
At nominal heat output elmax NA kW Type of heat output/room temperature control (select
one)
At minimum heat output elmin NA kW single stage heat output and no room
temperature control
[no]
In standby mode elsb 0 kW Two or more manual stages, no room
temperature control
[no]
with mechanic thermostat room temperature
control
[no]
with electronic room temperature control [yes]
electronic room temperature control plus
day timer
[no]
electronic room temperature control plus
week timer
[no]
Other control options (multiple selections possible)
room temperature control, with presence
detection
[no]
room temperature control, with open
window detection
[no]
with distance control option [no]
with adaptive start control [no]
with working time limitation [no]
with black bulb sensor [no]
Contact details : ARGOCLIMA SPA - Via A. Varo,35 - Alfianello (BS) - ITALY -
www.argoclima.com
The seasonal space heating energy efficiency of all local space heaters except commercial
local space heaters, ηS(%)
37

19
V 09/20
INFORMATION ON THE CORRECT DISPOSAL OF THE PRODUCT pursuant to Art. 26 of (Italian) Legislative Decree no. 49
of 14/03/14, “IMPLEMENTATION OF DIRECTIVE 2012/19/EU ON WASTE ELECTRICAL AND ELECTRONIC EQUIPMENT”
At the end of its useful life, this appliance must not be disposed of together with household waste. We call your attention to the
crucial role played by the consumer in the reuse, recycling and other forms of recovery of such waste.
The dismantled appliance, with its components collected separately, must be delivered to the local waste disposal facility or
returned to the dealer free of charge when purchasing a new equivalent appliance.
Sorted disposal of electric and electronic equipment prevents potentially negative consequences on the environment and human
health due to improper waste disposal, and also allows the constituent materials to be recovered and recycled, with significant
savings in terms of energy and resources.
In order to highlight the obligation regarding separate disposal of these devices, the appliance carries the crossed-out wheeled bin
symbol.
www.argoclima.com
