Argo CREOLA Q3 User manual

V 09/16
7
CREOLA Q3
OPERATING INSTRUCTIONS
Read the instructions carefully before installing and operating the appliance or performing
maintenance operations. Observe all the safety instructions; failure to observe the instructions may
cause accidents and/or damages. Store these instructions for future reference.
QUARTZ HEATER
EN

V 09/16
8
GENERAL SAFETY INFORMATION
Use this heater only as outlined in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock or
injury to people.
Ensure that the mains power complies with the voltage specified on
the fan heater data plate (220-240V~50Hz).
This appliance can be used by children aged from 8 years and
above and people with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a
safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
This product is not a toy. Children of less than 3 years should be
kept away unless continuously supervised.
Children aged from 3 and less than 8 years shall only switch on/off
the appliance provided that it has been placed or installed in its
intended normal operating position and they have been given
instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children aged from 3 years and
les than 8 years shall not plug in, regulate and clean the appliance
or perform user maintenance.
CAUTION - Some parts of this product can become very hot
and cause burns. Particular attention has to be given where
children and vulnerable people are present.
WARNING: In order to avoid hazard due to inadvertent resetting of
the thermal cut-out, this appliance must not be supplied through and
external switching device, such as a timer, or connected to a circuit
that is regularly switched on and off by the utility.
WARNING: do not use the fan heater with a controller or any
other external device that activates the appliance

V 09/16
9
automatically, as there may be a risk of fire if the fan heater is
covered or incorrectly positioned.
Do not restrict the air inlet and outlet grilles.
The appliance heats up slightly when in use. In order to avoid burns,
do not let bare skin touch hot surfaces.
Ensure that all objects are at least 1 meter from the front and sides
of the appliance.
Disconnect the mains power when the appliance is not used or for
cleaning operations.
Avoid using the heater in dusty environments or in the presence of
inflammable vapors (e.g. in workshops or garages) or paint vapors.
Do not place anything on the appliance, do not use the appliance to
dry clothing.
Use the appliance in a well-ventilated area.
Avoid placing fingers or foreign objects in the air inlet/outlet grilles,
as this may lead to electric shock or fire and may damage the
appliance.
To avoid the risk of fire, do not block the grilles or tamper with them
in any way while the heater operates.
Do not use the appliance if the cord or plug are damaged. If the
power supply cord is damaged, it must be replaced by the
manufacturer, dealer or a similarly qualified person so as to avoid
any safety risks.
Do not operate the appliance if it has fallen from a height or has
suffered damage in any way. Contact qualified technical personnel
to examine the appliance or perform any electrical or mechanical
repairs.
The most common cause of overheating is the build-up of dust in
the appliance. Remove dust deposits by unplugging the appliance
and cleaning the air outlets and grilles with the aid of a vacuum
cleaner.

V 09/16
10
Do not use abrasive detergents for cleaning this appliance. Clean
the appliance with the aid of a damp (not wet) cloth rinsed in hot
soapy water. Always remove the plug from the mains socket before
cleaning.
To disconnect the fan heater, push the switch to OFF and remove
the plug from the socket. Pull on the plug only. Avoid pulling on the
cord when disconnecting the heater.
Do not place any objects on the cord and do not bend it.
It is not advisable to use extension cords, as these may overheat
and cause the risk of fire. Do not use a single extension cord to
operate multiple appliances.
Do not immerse the cord, plug or any other element of the appliance
in water or other liquids.
Do not touch the plug with wet hands.
Do not place the fan heater above or near another heat source.
WARNING: AVOID COVERING THE FAN HEATER TO PREVENT IT
FROM OVERHEATING.
The symbol below signals the above warning:
The heater may cause the risk of fire if, while in operation, is
covered by or comes into contact with inflammable material
including curtains, drapery, blankets, etc. KEEP THE HEATER
AWAY FROM THESE MATERIALS.
Do not connect the appliance to the mains power before it has been
properly assembled and positioned.
Do not run the cord under carpets. Do not cover the cord with
blankets, carpets or similar materials. Place the cord far away from
busy areas or where it cannot be accidentally pulled-out.
Do not operate the fan heater in close proximity to bathtubs,
showers, washbasins or pools.
Do not position the fan heater below a socket outlet.
Do not operate the appliance outdoors.

V 09/16
11
Upon initial start-up, the fan heater may emit a slight, harmless
smell. This smell is a normal effect of the initial heating up of the
internal heating elements, and should not recur later on.
WARNING: DO NOT DEPEND ON THE ON/OFF BUTTON
SWITCH AS THE SOLE MEANS OF DISCONNECTING POWER.
WHEN SERVICING OR MOVING THE HEATER, ALWAYS
UNPLUG THE POWER CORD.
A heater has hot and arcing or sparkling parts inside. It must not be
used in potentially dangerous locations such as flammable,
explosive, chemical-laden or wet atmosphere.
Do not place the heater on soft surfaces, like a bed, where openings
may become blocked. Always place the heater on a stable, flat,
level surface when operating, to avoid the chance of the heater
overturning. Locate the power cord so the heater or other objects
are not resting on it.
Always unplug the heater when not in use.
In order to avoid accidents turn unit off if unattended.
In the event of any problems (abnormal noise or a strange smell)
switch off the appliance immediately, do not
attempt to repair it and take it to your local after sales service.
DESCRIPTION OF PARTS
1. Heat Element
2. Side Panel
3. Double Rocker Switches
4. Fireguard
5. Reflector
6. Auto cut-off switch

V 09/16
12
HOW TO USE THE FAN HEATER
Put the fan heater vertically on a flat and stable surface.
Connect the power cord to a suitable electric socket (230V~/50Hz).
The product has 3 quartz elements.
The device has two switches that allow different settings. The heating element quartz turn red.
Switch 1: 500W (I) heater on
Switch 2: 500W (II) +500W (III) heaters on
Switch 1 + 2 : All heaters on
SPECIAL FEATURES
The Motion Off Detection Feature will cut the power if the unit falls over in any direction or is lift (such
as if you move it to another part of the room). The Tip-Over Switch will cut the power if the unit is
knocked over forward or backward (for example, if a pet accidentally tips it over). Both are controlled
by the Tip Over Switch on the bottom of the unit. Do not attempt to defeat this safety feature.
Be sure the Switches are in the OFF position before plugging the unit in. Plug in to an AC outlet
and switch on the appropriate quartz elements. Switch off the appliance if not used.
The appliance can be moved to the other place by lift up the handle at the back side.
MAINTENANCE AND STORAGE
ALWAYS UNPLUG THE APPLIANCE BEFORE CLEANING OR MAINTENANCE.
IMPORTANT: DO NOT SUBMERGE THE CERAMIC FAN HEATER IN WATER
Cleaning the outside surface of the appliance
Turn the switch off and unplug before carrying out any maintenance work or moving the appliance.
Use a soft cloth to remove any dust from the fan heater.
If the fan heater is excessively dirty, use a soft cloth moistened with water and a mild detergent at a temperature lower than
50°C. Let the fan heater dry completely before use.
Do not use corrosive detergents or solvents such as petrol. Do not wash the appliance with water. Do not use oils, chemical
substances or other items to clean that may damage the surface.
Use a vacuum cleaner to remove dust from the air inlet/outlet grilles.
STORAGE
If the appliance is not used for prolonged periods, it must be stored together with this manual in its original packaging, in a
cool and dry place.
INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN ACCORDANCE WITH THE EUROPEAN DIRECTIVE
2012/19/EU
At the end of its working life this equipment must not be disposed of as an household waste. It must be taken to special local
community waste collection centres or to a dealer providing this service. Disposing of electrical and electronic equipment
separately avoids possible negative effects on the environment and human health deriving from an inappropriate disposal and
enables its components to be recovered and recycled to obtain significant savings in energy and resources. In order to
underline the duty to dispose of this equipment separately, the product is marked with a crossed-out dustbin.
