Argonaut M7 Smart Touch Install/Operation Guide
Welcome
Thank you for your recent purchase of the Argonaut M7 monitor. You represent a wise and rapidly growing group of boaters that recognize the smartest way to equip
your boat for now and the future! We use smartphones in all facets of our lives and Argonaut is proud to be the first company in history to offer you practical control
of your personal device in the marine environment. As marine apps become increasingly more powerful, your M7 will prove to be one of your most indispensible
boating tools!
Package Contents
The following items are included within your M7 packaging:
1.) M7 Monitor.
2.) Bezel Back Cover Frame With Mounting Screws.
3.) Flush Mount Oversize Bezel Back Cover Frame.
4.) Flush Mount Frame Edge Face Cover.
5.) RAM Mount Arm Kit With Mounting Screws.
6.) Miracast HDMI Screen Mirroring Dongle.
7.) 12 Volt DC-DC Converter For Miracast.
8.) Micro Female To Standard Female USB Adapter.
9.) HDMI Female To Female Coupler.
10.) 6’ Female BNC Composite Video Cable.
11.) Velcro Strap (To Attach BNC To RAM Base).
Mounting
The M7 can be conveniently flush or pedestal mounted. Flush Mounting: Refer to the attached mounting template and instructions. RAM Mounting:Attach the
diamond shaped mounting ball plate to the back of the M7 using screws with lock washers. Take care to tighten just snug, not over tighten. Attach the circular
mounting ball plate to your desired location. Attach the adjustable arm to the circular and diamond shaped mounting plates. Adjust the display angle as desired.
Note: As an added precaution to avoid accidental detachment, secure the adjustable clamp with cable wrap or bungee cord.
Wiring
Power: The M7 monitor is designed for 12 Volt power input. NOTE: DO NOT CONNECT DIRECTLY TO A 24 VOLT POWER SOURCE AS THIS WILL DAMAGE
THE DISPLAY AND VOID YOUR WARRANTY. If you need to connect directly to a 24 volt system, please consult with your dealer or Argonaut and we can supply
you with an optional 24 volt DC-DC converter. PLEASE MAKE SURE TO AVOID IMPROPER CROSSING WIRES (POSITIVE TO NEGATIVE) AS THIS CAN
DAMAGE THE DISPLAY ELECTRONICS.
HDMI: Place the HDMI cable end in a dry location. We recommend this location to be ventilated to avoid overheating the Miracast dongle or your phone during hot
operational conditions. Attach the Actiontec Miracast dongle to the HDMI cable using the supplied HDMI coupler. Connect the Miracast DC-DC converter to 12 volt
power. Note that this part is provided to supply power for the Miracast dongle not your phone. If desired, you can also power the Miracast with a standard 5 volt
micro USB charger.
HDMI/Miracast Parts Disconnected HDMI/Miracast Parts Connected
Actiontec Miracast Setup: The Miracast provides a live streaming image directly from your phone to the M7. We recommend placement of this part next to your
phone for best performance. Please follow the Miracast setup instructions.
Micro USB: This connector should also be placed in close proximity to the Miracast as described above. Please note that the specially designed USB cable not only
communicates with your M7 but also provides phone charging via the M7’s built in phone charging circuitry.
BNC VIDEO: This connector allows direct connection to a camera or video source if desired. Note that a velcro retaining strap is provided to secure this short
connector to the RAM mount bolt hole if desired.
41665 Date Street ●Murrieta ● California, 92562 ●Tel [phone] ●Fax [phone] ● [e-mail]

Complete Wiring. Note: 12V Power Ready To Be Connected Directly Or By Cigarette Adapter (Not Included)
Required Apps To Load
The M7 has been designed to work with a great variety of Android smartphones. In order to operate properly, certain apps may be needed on your device. We
recommend the following apps, some of which may or may not be needed:
Multi-action Home Button: Replaces hardware Home Button with onscreen Home Button:
https://play.google.com/store/apps/details?id=com.home.button.bottom
Brightness Control & Dimmer: Dims phone screen to reduce power consumption and heat:
https://play.google.com/store/apps/details?id=net.humblegames.brightnesscontroldimmer
Stay Alive!: Prevents phone from timing out and sleep mode for continuous operation: https://play.google.com/store/apps/details?id=com.synetics.stay.alive
Screen Rotation Controller: Allows phone to be set in landscape mode for optimal screen view on the M7:
https://play.google.com/store/apps/details?id=com.dp.applockorientation
ZenUI Launcher-Theme,Wallpaper: May be required for certain phones to reconfigure desktop for proper viewing:
https://play.google.com/store/apps/details?id=com.asus.launcher
KK Launcher: An additional choice to reconfigure desktop for proper viewing. Our preference is the ZenUI launcher for simplicity over KK Launcher:
https://play.google.com/store/apps/details?id=com.kk.launcher
System Startup
1.) Once properly wired as described above, and connected to power, you will then see the Miracast active screen image on the M7 display showing river
stones. NOTE: IF YOU DO NOT SEE AN IMAGE ON THE M7 SCREEN, CONFIRM BLUE LED ON MIRACAST IS ON. ALSO CONFIRM M7 LED IS ON.
IF SO, PRESS THE M7 POWER BUTTON AND THE IMAGE SHOULD APPEAR.
2.) Activate settings on your phone to enable Miracast. Depending on your phone this will be listed as either “Quick connect”, “Screen Mirroring”, “Casting” or
other. This will then display your phones’ screen image on the M7 display. If you do not see the image, refer to your phone manufacturer’s specific
Miracast or screen mirroring instructions.
3.) Confirm touch screen operation by touching screen. Upon doing so, you will see a “TOUCH ACTIVATION” message and after a momentary lapse, the
touch screen will now control your phone.
Please note that after the M7 is powered on, you can remove or reconnect your phone at any time without any delayed operation.
Button Panel Control
The side mounted button panel allows convenient control over monitor settings, signal input and brightness. From top to bottom, functions are as follows:
1.) LED: This indicator light remains green when connected to power and turns red when connected to input.
2.) Power Button: Powers screen on/off.
3.) Menu: Opens on screen display menu for monitor control settings.
4.) Up Button: Allows movement to up menu item (s)
5.) Down Button: Allows movement to down menu item (s)
6.) Exit/Signal Select: Allows Menu exit/close. Is also a hot key to change input signal from HDMI to Video.
7.) Brightness Control Gradient: Allows brightness control to maximum at top and minimum at bottom. Note that LED brightness automatically dims according
to your screen brightness to avoid a bright LED during night operation.
Basic Operation
After proper startup, the M7 will remain in phone charging mode until you touch the touch screen. Upon doing so, a screen message will appear notifying you
“ACTIVATING TOUCH” whereby the touch screen is fully operational and controlling your phone. Note that the touch mode remains active for 3 minutes upon which
it automatically switches back to charge mode. For more detailed instructions,
Please refer to the Support tab at www.argonaut.mobi.
Maintenance & Care
When not in use for extended periods of time we recommend turning off power to both the M7 and Miracast dongle. For cleaning the display, do not use harsh
chemicals or Windex glass cleaner. We recommend cleaning with fresh clean water (distilled is ideal) and a clean soft terry or micro fiber cloth. Do not allow salt
water residue to remain on the glass as it may damage the antireflective optics.
