Argox PI-1030 User manual

Portable data terminal
User’s Manual
PI-1030/PI-1230
V1.1-12-07-2017

i
Regulatory Compliance
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
-Consult the dealer or an experienced radio/ TV technician for
help.

ii
CAUTION:
Any changes or modifications not expressly approved by the grantee of
this device could void the user's authority to operate the equipment.
RF EXPOSURE WARNING:
The equipment complies with FCC RF exposure limits set forth for an
uncontrolled environment.
The equipment must not be co-located or operating in conjunction with
any other antenna or transmitter.
FCC ID:NBF-PI-1X30
CAUTION: EXPLOSION HAZARD
Do not disassemble, short circuit, heat the battery or dispose of in fire. Store battery
pack in a proper place. Do not expose to temperature above 60℃/140℉. Use
specified charger only. Please dispose of the used batteries following the rules or
laws issued by the local government.
警告：電池若未妥善處理，可能會導致爆炸。

iii
請勿拆卸電池，或用火銷毀電池。請將電池放置於兒童拿不到的地方。
請使用專用充電器充電，並請依照當地政府或法律規定妥善處理廢棄
電池。
經型式認證合格之低功率射頻電機, 非經許可,公司, 商號或使用者
均不得擅自變更頻率,加大功率或變更原設計之特性及功能
低功率射頻電機之使用不得影響飛航影響安全及干擾合法通
信, 經發現有干擾現象時,應立即停用,並改善至無干擾時方得繼續
使用
前項合法通信,指一電信法規定作業之無線電通信低功率射頻電
機需忍受合法通信或工業,科學及醫療用電波輻射性電機設備之
干擾

Release Note
i
Release Note
Version
Date Note
V1.0 02/22 2017 Initial release
V1.1 07/12 2017 Add Appendix A for reference

ii
Content
1 Introduction .......................................................................... 1
1.1 Unpacking ................................................................. 2
1.2 Understand your terminal ........................................ 4
1.2.1 Terminal ........................................................ 4
1.2.2 Holder(Option) .............................................. 5
1.3 Indicators .................................................................. 6
1.3.1 LED ................................................................ 6
1.3.2 Buzzer ............................................................ 8
1.3.3 Vibration ....................................................... 8
1.4 Keypad ...................................................................... 9
1.5 Power source .......................................................... 14
1.5.1 Inserting or replacing battery ..................... 15
1.5.2 Charge the battery ...................................... 18
2 Get started .......................................................................... 20
2.1 Set up your terminal ............................................... 20
2.2 User interface ......................................................... 21
2.3 Connection ............................................................. 23
2.3.1 Remote link connection .......................................... 24
2.4 Attach the hand strap ............................................. 27
3 Controls and settings .......................................................... 29
3.1 User Menu .............................................................. 29
3.1.1 Run Program ............................................... 30
3.1.2 Remote Link ................................................ 30
3.1.3 Scanner(HID) ............................................... 31

iii
3.1.4 Information ................................................. 32
3.2 System Menu .......................................................... 33
3.2.1 Remote Link ................................................ 33
3.2.2 Disk info ...................................................... 33
3.2.3 Timer setting ............................................... 34
3.2.4 Environment ............................................... 35
3.2.5 Test .............................................................. 36
3.2.6 System info .................................................. 38
3.3 Supervisor Menu .................................................... 39
3.3.1 Remote Link ................................................ 40
3.3.2 Format disk ................................................. 43
3.3.3 Setting ......................................................... 44
3.3.4 Information ................................................. 49
4 Applications ........................................................................ 50
5 Troubleshooting.................................................................. 51
5.1 Hardware issues ...................................................... 51
5.2 Communication issues ............................................ 52
5.3 Barcode scanning issues ......................................... 53
6 Specifications ...................................................................... 54
Appendix A .............................................................................. 58

1 Introduction Unpacking
1
1 Introduction
PI series is a lightweight, portable data terminal (PDT)
for data capture and collection. This manual will help
you to get to know PI series and utilize it well.
Features
￭ Scratch-resistant keypad Coated with PC
(polycarbonate), the letters and numbers on the keys
won’t wear off between uses.
￭ Battery cover open detection When the switch of
the battery cover is up, the system automatically
saves your files and shut down.
￭ Large flash memory PI series offers more flash
memory than the rivals on the same level. The
standard is 20 MB, and the optional is 60 MB.
￭ Wi-Fi connectivity You can exchange data over a
Wi-Fi network.(PI-1030)
￭ Backup battery The backup battery gives you
additional 15 minutes to finish your job if the primary
batteries wear out.

1 Introduction Unpacking
2
1.1 Unpacking
Make sure all of the following items are included in your
package.
PI series Quick Start Guide
USB Cable
or
RS-232 Cable with USB
power cord
Holder(Option) Hand Strap

1 Introduction Unpacking
3
Plug and Power Supply (Option)
When you receive your terminal, open the package
immediately and inspect for shipping damage. If you
discover any damage, contact the shipping company and
file a claim. Argox is not responsible for any damage
incurred during shipping. Save all package materials for
the shipping company to inspect.
Note If any item is missing, please contact your
local dealer.
