The New Cooking
Collection 2009

Ariston’s philosophy is simple: to be
part of everyday life, taking Care of you,
offering you appliances with unmatched
Style thanks to their clean, refined lines,
making your home attractive, elegant
and welcoming.
And your life will be better too, thanks
to Quality products that work safely and
offer highest Performance to meet your
every need.
So you can work, stay at home and live
your life without giving them a thought:
you can spend your time savouring your
most precious moments.
Welcome to Ariston.
Our Ideas,
Your Home
The new Ariston Cooking Range
Style for living
2 3
Ovens......................................................7
Hobs.....................................................12
Rangehoods..........................................17
Upright Cookers...................................19
Coffee Machine.....................................21
Specifications.......................................22

4
Openspace
Openspace
5
More room
for flexibility
With the same external
dimensions as a 60cm oven,
and a standard built-in
space, the Openspace oven
offers 20% extra capacity
with its 70 litres of greater
versatility. It offers the
option of cooking on 4
shelves at the same time
or cooking large quantities
which would not necessarily
be possible in a traditional
oven.
Divide The Space To Multiply It.
Openspace’s most innovative feature is the insulating divider that
separates the whole Extra Large cavity into 2 different-sized spaces:
SMALL SPACE – Approximately 20 litres, equipped with a revolutionary
Fast Cooking system and grill function
MAIN SPACE – Approximately 48 litres, with its Universal cooking
functions that allow the preparation of any kind of dish.
The 2 spaces, Small & Main, offer unimaginable versatility. They can be
used simultaneously to prepare a complete dinner in a shorter time, or
separately, just using the space required for your particular needs.
When they are used together, cooking temperatures can be regulated
between 50°C and 250°C with a difference of as much as 100°C
between the 2 compartments. This makes it possible to cook very
different dishes, also safe in the knowledge that smells and flavours will
not mix.
Openspace is the only one on the market to offer the maximum
in flexibility.
Bread Program
The aroma of hot oven-baked bread is an
experience that evokes the flavours of bygone
days. Today, you can experience this directly at home
thanks to the new Bread function. The oven sets
the various cooking phases by establishing time and
temperature with an excellent result every time.
10'
•Cold Oven at start ›No pre-heating (time saving)
•First phase › 2°raising (optimisation)
•Second phase › 3° raising + inside cooking
•Third phase › outside browning
Yo u can put the dough into the cold oven because the electronics can
manage the heating elements for short periods of time (no burning risk).
2°raising
End cooking
20' 30' 40' 50'
45'
50°
120°
220°
210°
3°raising
Inside Cooking
200°
100°
Cold Oven
Pizza Program
It is possible to cook at home an amazing
pizza as made in a wood-burning oven:
perfect internal and external cooking in only
30 min.
PROGRAMS & FUNCTIONS
Thanks to the Extra Large Space, Openspace offers 10 cooking functions: 6 of which
are universal and suitable for any type of cooking, while the remaining 4 are automatic
programs which can be used to achieve perfect results for any recipe.
Automatic Programs:
200°
100°
25 minutes
•Cold Oven at start ›No pre-heating (time saving)
•First phase › colouring
•Second phase › internal cooking
3 minutes
Colouring
180°
Temperature
raising Recovery
End cooking
Cold Oven
SMALL, MAIN, DOUBLE OR EXTRA LARGE?
EXTRA LARGE CAVITY:
To cook 4 levels at the same time or
very large items.
DOUBLE SPACE*:
It makes possible to cook 2 different
dishes at the same time.
MAIN SPACE*:
To cook up to 3 levels.
SMALL SPACE*:
For cooking or heating up food more quickly.
*Applies to OS 99 DPIX only.
60
60
+20%
220¡
180¡
60
60
+20%
220¡
180¡
60
60
+20%
220¡
180¡
60
60
+20%
220¡
180¡

Openspace
OS 99 DPIX
60cm Experience Line Extra Large Oven
70 Lt of capacity: 20% increase in internal space•
4 ovens in 1:•
a) 4 simultaneously cooking in the EXTRA LARGE oven (70 Lt)
b) Cooking in the upper SMALL oven (20 Lt)
c) Cooking in the lower MAIN oven (48 Lt)
d) Simultaneously cooking in the upper SMALL oven & lower
MAIN oven ( 20 + 48 Lt)
10 cooking functions in the EXTRA LARGE oven: 4 automatic•
programs + 6 universal functions.
2 functions in the SMALL oven: Fast Cooking & Grill•
Universal functions in main oven•
Fast Clean – Pyrolytic self-cleaning function•
Integrated ventilation system•
4 oven glass doors•
Glass inner door•
Divider•
Grey cavity•
2 halogen lights•
Electronic regulation timing and temperature•
Recipe book and quick guide provided•
Anti-touch Stainless Steel – Easy to Clean•
MADE IN
ITALY
New - Coming Soon!
Barbeque
The top heating element and the rotisserie
spit (where present) are activated.
The high and direct temperature of the grill is
recommended for food which requires a high
surface temperature. Good for food that needs a
higher cooking temperature, such as steaks and
hamburgers.
Low Temperature
This function allows preserving the original
properties and flavours of the food.
3 low temperature programs:
40°C: Defrosting, raising, yoghurt.
65°C: Reheat, dry and keep warm.
90°C: Rapid low temperature – to preserve the
nutrients and tenderness.
Multilevel Cooking
All heating elements and the fan are
activated. Since the heat remains constant
throughout the oven, the air cooks and browns food
in a uniform manner. Thanks to this function; it is
possible to cook simultaneously up to 4 levels at the
same time.
Gratin
The top heating element, rotisserie spit
(where present) and the fan will be
activated. During part of the cycle, the circular
heating element is also activated. This combination
of features increases the effectiveness of the uni-
directional thermal radiation provided by the heating
elements through the forced circulation of the air
throughout the oven. This helps to prevent food
from burning on the surface and allows the heat to
penetrate right into the food.
76
Meat Program
This cycle is set for cooking each kind of
meat in the most appropriate way. This
automatic program consists of 3 phases: external
colouring, internal cooking and “recovery” –
where the temperature decreases slowly and
the combined action of the heating elements and
the cooling fan control the humidity. The level
of cooking can be regulated according to all
different tastes, with the possibility to change
duration to have the “well-done”, “medium” or
“rare” result.
Pastries Program
This cycle is set for the cooking of
traditional cakes, doughnuts and pies.
10'
•Cold Oven at start › No pre-heating (time saving)
•First phase › colouring
•Second phase › internal part cooking
•Cake: the cycle is set for the cooking of traditional cakes, like doughnut and pies.
End cooking
temperatu re
raising
Cold Oven
20' 30' 40' 50'
190°
Colouring
200°
100°
Recovery/internal cooking
With humidity level control,
for a not aggressive
and more delicate cooking
Recovery: temperature decreases
slowly and the combined action of the
heating elements and the cooling fan
control the humidity.
Universal Programs: OS 89 CIX
60cm Experience Line Extra Large Oven
70 Lt of capacity: 20% increase in internal space•
4 simultaneously cooking in the EXTRA LARGE oven (70 Lt)•
10 cooking functions in the EXTRA LARGE oven: 4 automatic•
programs + 6 universal functions.
Self-cleaning catalytic liners•
Integrated ventilation system•
3 oven glass doors•
Glass inner door•
Grey cavity•
Electronic regulation timing and temperature•
Anti-touch Stainless Steel – Easy to Clean•
MADE IN
ITALY
Largest European 60cm
Oven In The Market

Experience Line
9
FZ 51 IX
60cm Experience Line Oven
5 cooking functions: Traditional, Multi-cooking, Top Oven,•
Grill & Gratin.
Integrated ventilation system•
2 oven glass doors•
Glass inner door•
Minute minder•
Anti-touch Stainless Steel – Easy to Clean•
58 Lt net oven capacity•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed: 2400W,•
Maximum current absorbed: 10 A
Fast Clean
Fast Clean is an automatic
self-cleaning cycle, which uses
a 500°C pyrolysis process to destroy
any cooking grease or sugar residues
left on the inner walls. The process
is completely safe and has a power
consumption of less than 2.8 kW:
the cost of an espresso! Fast Clean
ovens have quadruple glass doors,
an automatic door lock and a forced
ventilation system that ensures perfect
heat insulation.
FZ 891 P.1IX
60cm Experience Line Oven
8 cooking functions: Traditional, Multi-cooking, Barbeque,•
Gratin, Pizza, Baking, Fast Cooking & Proving.
Fast Clean – Pyrolytic self-cleaning function•
Integrated ventilation system•
4 oven glass doors•
Glass inner door•
Electronic Display•
Telescopic guides•
Grey cavity•
Anti-touch Stainless Steel – Easy to Clean•
56 Lt net oven capacity•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed: 2800W,•
Maximum current absorbed: 11.7 A
8
Clean
Inner door in glass:
The inner door of the Experience
Line oven is made out of one single
piece of very high quality glass that is
resistant to temperature shocks and
high temperatures. The glass inner
door is a very elegant and functional
solution that, thanks to the total
absence of junctions, also offers a
large surface where you can place
your oven trays and pans.
Anti-touch
All Experience ovens are anti-
touch that means the stainless steel
cleaning will no longer be a problem!
Grey cavity
The grey-coloured interior makes
the oven clearer. It gives maximum
visibility and better control during all
stages of cooking without the need to
open the oven.
Integrated ventilation
system:
The integrated ventilation system
guarantees a real heat insulation
keeping at a safe temperature either
the door or the knobs. It also avoids
damage on your kitchen cabinets
through the automatic fan system that
reduces the oven external walls tem-
perature.
Experience Line
F 73 C.2IX
60cm Experience Line Oven
6 cooking functions: Traditional, Multi-cooking, Barbeque,•
Gratin, Pizza & Baking.
Self-cleaning catalytic liners•
Integrated ventilation system•
2 oven glass doors•
Glass inner door•
Telescopic guides•
Digital Timer•
Rotisserie•
Anti-touch Stainless Steel – Easy to Clean•
58 Lt net oven capacity•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed: 2800W,•
Maximum current absorbed: 11.7 A
MADE IN ITALY
Clean

Hobs
11
Hobs
A cooking philosophy
translated in a range:
professional recipes have
finally found a space for
expression at home.
If you love cooking in an innovative and
sophisticated way, matching flavours and
ingredients, then the new Ariston hobs
have been designed for you.
Power
The exclusive Triple Ring burner takes full
advantage of a uniform power distribution
and guarantees quick and even cooking.
The innovative flame distribution allows
you to have an excellent heat distribution
under the pan.
75cm wide cook tops a
new dimension with 25%
more working space.
Whether planning from new or replacing
your old cook top, now there is a hob
choice with more workspace and more
options. The 75cm hobs will fit into a
standard 60cm hob cut-out, so updating
to more space, flexibility and burner
power is simply a matter of specifying an
Ariston 75cm hob.
Control
The new double crown
double regulation allows
you to cook better and
in less time, achieving
maximum flexibility and
efficiency. The flame can
be regulated separately
on each crown. It is now
possible to achieve the
most delicate heat (1.5
MJ/h) for gentle cooking
to the most powerful
flames (19 MJ/h) where
an intense heat is
required.
Versatile
The double face burners is made up by
two burners that can be rotated and
used simultaneously. It is suitable for
rectangular baking tins, griddle plate or
large pans.
MB 91 IX
90cm Maxi Oven
DN 62 X
60cm Experience Line Double Oven
Main Oven – 7 cooking functions: Traditional, Circulaire•
Roasting, Grill, Pastries, Slow Cook, Fan & Defrosting
Second Oven – 2 cooking functions: Traditional & Grill•
Integrated ventilation system•
3 oven glass doors•
Glass inner door•
Digital Timer•
Self-cleaning catalytic liners•
Net oven capacity: 65 Lt (Main oven), 35 Lt (Second oven)•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed: 5100 W,•
Maximum current absorbed: 21.25 A
New - Coming Soon!
MADE IN
ITALY
10
Maxi & Double Oven
MADE IN
ITALY
7 cooking functions: Traditional, Lower Heating Element, Upper Heating Element, Grill, Gratin, Pastries & Multi-level.•
Integrated ventilation system•
3 oven glass doors•
Rotisserie•
Electronic Start / End of cooking Timer•
68 Lt net oven capacity•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed:•
3100W, Maximum current absorbed: 13.4 A

13
75cm Hobs
12
90cm Hobs
MADE IN ITALY
MADE IN ITALY
MADE IN ITALY
MADE IN ITALY
MADE IN ITALY
* All 75cm hobs will fit into a standard 60cm cut-out dimension.
* All 75cm hobs will fit into a standard 60cm cut-out dimension.
Dual Wok Burners
19MJ/h
The Superior Burner
PH 941 MSTV
90cm Multi-function Hob
4 gas burners:•
Left Rear (Semi-fast) – 6 MJ/h, Right Rear (Auxiliary) – 3.3 MJ/h,
Left Front (Triple Ring) – 15 MJ/h, Right Front (Fast) – 9 MJ/h
Special cooking surface: Dual oval ceramic plate – 1000 + 800 W•
1 hand electronic ignition•
Flame failure gas cut-off system•
3 enamelled grids•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed: 1800 W,•
Maximum current absorbed: 7.5 A
PH 941 MSTB GH
90cm Multi-function Hob
4 gas burners:•
Left Rear (Semi-fast) – 6 MJ/h, Right Rear (Auxiliary) – 3.3 MJ/h,
Left Front (Triple Ring) – 15 MJ/h, Right Front (Fast) – 9 MJ/h
Special cooking surface: 1 Griddle Plate – 900 W•
1 hand electronic ignition•
Flame failure gas cut-off system•
3 cast iron grids•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed: 900 W,•
Maximum current absorbed: 3.75 A
PH 960 MST GH
90cm Gas Hob
6 gas burners including:•
Left Rear (Semi-fast) – 6 MJ/h,
Right Rear (Auxiliary) – 3.3 MJ/h,
Left Middle (Triple Ring) – 15 MJ/h,
Right Middle (Fast) – 9 MJ/h,
Left Front (Double Face) – 5 MJ/h,
Right Front (Double Face) – 5 MJ/h
1 hand electronic ignition•
Flame failure gas cut-off system•
4 cast iron grids•
PH 741 RQO GH
75cm Multi-function Hob
3 gas burners:•
Left Middle (Double Ring Double Regulation) – 1.5 MJ/h to 19 MJ/h
Right Rear (Semi-Fast) – 6 MJ/h
Left Front (Auxiliary) – 3.3 MJ/h
1 dual oval ceramic plate: 1100 + 900 W•
1 hand electronic ignition•
Flame failure gas cut-off system•
2 cast iron grids•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed: 2000 W,•
Maximum current absorbed: 8.3 A
PH 750 RT GH
75cm Gas Hob
4 gas burners:•
Left (Double Ring Double Regulation) – 1.5 MJ/h to 19 MJ/h
Right (Triple Ring) – 15 MJ/h
Rear (Semi-Fast) – 6 MJ/h
Front (Auxiliary) – 3.3 MJ/h
1 hand electronic ignition•
Flame failure gas cut-off system•
3 cast iron grids•

KZT 7424 DOF
70cm Ceramic Hob
4 radiant heat zones:•
Left rear (Double Ring – 210 / 140mm) – 2200 / 1000 W
Right rear (145mm) – 1200 W, Left front (145 mm) – 1200 W
Right front (Oval – 145x250mm) – 1800 / 1000 W
12 power levels•
Touch control•
Time controlled heat zones•
Residual heat indicators•
Child safety feature•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed: 6400 W,•
Maximum current absorbed: 26.7 A
MADE IN ITALY
MADE IN ITALY
NRA 640 B
60cm Ceramic Hob
4 radiant heat zones:•
Left rear (210mm) – 2300 W, Right rear (160mm) – 1400 W
Left front (145mm) – 1200 W, Right front (180mm) – 1800 W
9 power levels•
Touch control•
Residual heat indicators•
Child safety feature•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed: 6700 W,•
Maximum current absorbed: 27.9 A
15
Ceramic Hobs
14
60cm Hobs
NRO 841 OX
80cm Ceramic Hob
4 radiant heat zones:•
Left (Oval – 170x260mm) – 2400 / 1000 W
Middle (180mm) – 1800 W
Right rear (230mm) – 2300 W
Right front (145mm) – 1200 W
9 power levels•
Touch control•
Residual heat indicators•
Child safety feature•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed: 7700 W,•
Maximum current absorbed: 32.1 A
MADE IN ITALY
PZ 640 T GH
60cm Experience Line Gas Hob
4 gas burners:•
Left (Fast) – 9 MJ/h, Right (Triple Ring) – 15 MJ/h
Rear (Auxiliary) – 3.3 MJ/h, Front (Semi-Fast) – 6 MJ/h
1 hand electronic ignition•
Flame failure gas cut-off system•
3 cast iron grids•
MADE IN ITALY
PF 640 EST
60cm Gas Hob
4 gas burners:•
Left rear (Semi-Fast) – 6 MJ/h, Right rear (Auxiliary) – 3.3 MJ/h
Left front (Triple Ring) – 15 MJ/h, Right front (Fast) – 9 MJ/h
1 hand electronic ignition•
Flame failure gas cut-off system•
2 enamelled grids•
MADE IN ITALY
PH 640 MT
60cm Gas Hob
4 gas burners:•
Left (Fast) – 9 MJ/h, Right (Triple Ring) – 15 MJ/h
Rear (Auxiliary) – 3.3 MJ/h, Front (Semi-Fast) – 6 MJ/h
1 hand electronic ignition•
3 enamelled grids•
* Also available: PH 640 MST with flame failure gas cut-off system
MADE IN ITALY

MADE IN
ITALY
RHB 9 / RHB 8
90cm / 80cm Canopy Hood
Maximum extraction rate: 1034 m3/h•
High performance centrifugal motor•
Stainless steel•
2 X 20 W halogen lights•
3 speed settings•
3 self-supporting aluminium filters for RHB 9; 2 filters for•
RHB 8.
Diameter of air outlet: 150 mm•
Ducted or re-circulating installation•
•
•
•
•
•
•
•
•
MADE IN
ITALY
RHE 9
90cm Canopy Hood
Maximum extraction rate: 796 m3/h•
Stainless steel•
2 X 20 W halogen lights•
3 speed settings•
3 self-supporting aluminium filters•
Diameter of air outlet: 150 mm•
Ducted or re-circulating installation•
90cm Canopy Hood
•
Stainless steel
•
•
•
•
•
•
17
Rangehoods
16
Induction Hobs
MADE IN
ITALY
NIC 641 B
60cm Induction Hob
4 induction zones:•
Left rear – 1400 W, Right rear – 2200 / 3000 (with booster)
Left front – 2200 W, Right front – 1400 W
9 power levels•
Booster•
Touch control•
Time controlled heat zones•
Bevelled•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed: 7200 W,•
Maximum current absorbed: 30 A
•
•
•
•
•
•
•
MADE IN ITALY

CPDO 110 X
110cm Professional Upright Cooker
5 gas burners:•
Left rear (Semi-fast) – 6 MJ/h, Right rear (Semi-fast) – 6 MJ/h
Left front (Auxiliary) – 3.3 MJ/h, Right front (Fast) – 9 MJ/h
Middle (Double Ring Double Regulation) – 1.5 MJ/h to 19 MJ/h
1 hand electronic ignition•
Flame failure gas cut-off system•
3 cast iron grids•
Main Oven – 8 electric cooking functions: Fan oven, Traditional,•
Roast Meat, Roast Chicken, Rising, Cake Cycle (Auto), Bread
Cycle (Auto) & Fish
Second Oven – 4 electric cooking functions: Traditional, Pastry,•
Mini Grill, Maxi Grill
Self-cleaning catalytic liners•
Telescopic guides•
Integrated ventilation system•
3 oven glass doors•
Digital Timer•
Dish Warming Drawer•
Net oven capacity: 68 Lt (Main oven), 36 Lt (Second oven)•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed: 5300 W,•
Maximum current absorbed: 22.1 A
MADE IN ITALY
Dimensions (W x D x H) mm: 1100 X 625 X 900
New - Coming Soon!
19
Upright Cookers
18
Rangehoods
CP 059 MDX
90cm Professional Upright Cooker
5 gas burners:•
Left rear (Semi-fast) – 6 MJ/h, Right rear (Auxiliary) – 3.3 MJ/h
Left front (Semi-fast) – 6 MJ/h, Right front (Fast) – 9 MJ/h
Middle (Double Ring Double Regulation) – 1.5 MJ/h to 19 MJ/h
1 hand electronic ignition•
Flame failure gas cut-off system•
3 cast iron grids•
8 electric cooking functions: Traditional, Multi-cooking, Barbeque,•
Gratin, Pizza, Baking, Grill (Rotisserie) & Defrosting
Self-cleaning catalytic liners•
Integrated ventilation system•
2 oven glass doors•
Electronic start / end cooking•
Rotisserie•
68 Lt net oven capacity•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed: 3105 W,•
Maximum current absorbed: 12.9 A
MADE IN ITALY
SL 19.1 P / SL 16.1 P
90cm / 60cm Slim Line Rangehood
Maximum extraction rate: 460 m3/h•
Available in stainless steel or white•
3 speed settings•
2 X 20 W halogen lights•
3 self-supporting aluminium filters for SL 19.1 P; 2 filters•
for SL 16.1 P.
Diameter of air outlet: 120 mm•
Ducted or re-circulating installation•
•
•
•
for SL 16.1 P.
•
•
ARS 91 / ARS 61
90cm / 60cm Slide-out Rangehood
Maximum extraction rate: 500 m3/h•
3 speed settings•
2 X 40 W halogen lights•
1 self-supporting aluminium filter•
Ducted or re-circulating installation•
Also available: ARS6B – with 385 m3/h extraction capacity•
& 2 speed settings.
•
•
•
•
AGM.1 IX
Undermount Hood
Maximum extraction rate: 650 m3/h•
3 speed settings•
2 X 20 W halogen lights•
1 self-supporting aluminium filter•
Diameter of air outlet: 120 mm•
Ducted or re-circulating installation•
18
•
•
•
•

Experience Line Automatic Coffee Machine
The new Ariston Coffee Machine, completely in stainless steel with Graphic Touch control on the front,
matches the Experience ovens perfectly. It is easy to use and clean, completely electronic, and offers
the possibility to program three different types of coffee, different both in size and density. Thanks to
apposite taste, you can even regulate the creaminess. It can also be used to heat milk, to prepare tea
water or to make great cappuccinos.
CP 859 MDX
80cm Professional Upright Cooker
5 gas burners:•
Left rear (Semi-fast) – 6 MJ/h, Right rear (Auxiliary) – 3.3 MJ/h,
Left front (Semi-fast) – 6 MJ/h, Right front (Fast) – 9 MJ/h,
Middle (Triple Ring) – 15 MJ/h
1 hand electronic ignition•
Flame failure gas cut-off system•
3 cast iron grids•
8 electric cooking functions: Traditional, Multi-cooking, Barbeque,•
Gratin, Pizza, Baking, Grill (Rotisserie) & Defrosting
Self-cleaning catalytic liners•
Integrated ventilation system•
2 oven glass doors•
Electronic start / end cooking•
Rotisserie•
68 Lt net oven capacity•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed: 3105 W,•
Maximum current absorbed: 12.9 A
MADE IN ITALY
21
Upright Cookers/Coffee Machine
Upright Cookers
Experience Line Automatic Coffee Machine
CP 0V9 MDX
90cm Professional Freestanding Cooker
4 radiant heat zones:•
Left rear (Oval: 170X260mm) – 2500 / 1000 W,
Right rear (145mm) – 1200 W,
Left front (145mm) – 1200 W,
Right front (Double Ring: 210 / 140mm) – 2000 / 1000 W
Residual heat indicators•
8 electric cooking functions: Traditional, Multi-cooking,•
Barbeque, Gratin, Pizza, Baking, Grill (Rotisserie) & Defrosting
Self-cleaning catalytic liners•
Integrated ventilation system•
2 oven glass doors•
Electronic start / end cooking•
Rotisserie•
68 Lt net oven capacity•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed: 10,000 W,•
Maximum current absorbed: 41.7 A
MADE IN ITALY
CX 67 SP6X
60cm Upright Cooker
5 gas burners:•
Left rear (Double Face) – 5 MJ/h, Middle rear (Double Face) –
5 MJ/h, Right Rear (Double Face) – 5 MJ/h, Left Front (Triple
Ring) – 15 MJ/h, Right Front (Auxiliary) – 3.3 MJ/h
1 hand electronic ignition•
Flame failure gas cut-off system•
Square flat wire support grids•
7 electric cooking functions: Traditional, Baking, Fast Cooking,•
Multi-cooking, Pizza, Grill, Gratin
Self-cleaning catalytic liners•
Integrated ventilation system•
2 oven glass doors•
Electronic start / end cooking•
56 Lt net oven capacity•
Voltage: 240 V ~ 50 Hz, Maximum power absorbed: 3000 W,•
Maximum current absorbed: 12.5 A
MADE IN ITALY
20
MCA 16
Digital display•
Touch controls•
3 functions: Coffee, Hot Water, Steam•
3 coffee types: Short, Normal, Long•
Coffee grinder regulator•
Crème brewing system•
Anti-touch: stainless steel easy to clean•

7j^ai"^cHeZX^[^XVi^dch
(. 6g^h^iEinA^b^iZYVgZcdigZhedch^WaZ[dgVcnZggdghdgdb^hh^dch#E^XijgZh!heZX^[^XVi^dchVcY Y^bZch^dch
VgZ[dg^aajhigVi^dcejgedhZhdcanVcYVgZhjW_ZXiidX]Vc\Zl^i]djicdi ^XZ#
3768@ID>C9:M
8+,HE
28
CX 67 SP
CX 67 SP6X MCA 16
7j^ai"^cHeZX^[^XVi^dch
(' 6g^h^iEinA^b^iZYVgZcdigZhedch^WaZ[dgVcnZggdghdgdb^hh^dch#E^XijgZh!heZX^[^XVi^dchVcYY^bZch^dch
VgZ[dg^aajhigVi^dcejgedhZhdcanVcYVgZhjW_ZXiidX]Vc\Zl^i]djicdi ^XZ#
3768@ID>C9:M
6GH.&
6GH+&
22
7j^ai"^cHeZX^[^XVi^dch
(& 6g^h^iEinA^b^iZYVgZcdigZhedch^WaZ[dgVcnZggdghdgdb^hh^dch#E^XijgZh!heZX^[^XVi^dchVcY Y^bZch^dch
VgZ[dg^aajhigVi^dcejgedhZhdcanVcYVgZhjW_ZXiidX]Vc\Zl^i]dji cdi^XZ#
3768@ID>C9:M
G=:.
21
RHE 9 ARS 91/ARS 61 AGM.1X
NRO 841
KZT 7424 DO F
7j^ai"^cHeZX^[^XVi^dch
'% 6g^h^iEinA^b^iZYVgZcdigZhedch^WaZ[dgVcnZggdghdgdb^hh^dch#E^XijgZh!heZX^[^XVi^dchVcY Y^bZch^dch
VgZ[dg^aajhigVi^dcejgedhZhdcanVcYVgZhjW_ZXiidX]Vc\Zl^i]dji cdi^XZ#
3768@ID>C9:M
@DI,)')>D7>
@DI,&()9D
@7I+&')>D 7>
@OI+&')>9 ;
16
KZT 6124 ID F
NRA 640 B NIC 641
22
Specifications
23
Specifications
60cm Ovens
PH 9 Hobs
PF 6 Hobs
MB 91
PH 7 Hobs
DN 62
PH 6 Hobs
SL 19.1 SL 16.1
7j^ai"^cHeZX^[^XVi^dch
.6g^h^iEinA^b^iZYVgZcdigZhedch^WaZ[dgVcnZggdghdgdb^hh^dch#E^XijgZh!heZX^[^XVi^dchVcY Y^bZch^dch
VgZ[dg^aajhigVi^dcejgedhZhdcanVcYVgZhjW_ZXiidX]Vc\Zl^i]dji cdi^XZ#
3768@ID>C9:M
B7.&
6
PZ 6 Hobs
7j^ai"^cHeZX^[^XVi^dch
(% 6g^h^iEinA^b^iZYVgZcdigZhedch^WaZ[dgVcnZggdghdgdb^hh^dch#E^XijgZh!heZX^[^XVi^dchVcY Y^bZch^dch
VgZ[dg^aajhigVi^dcejgedhZhdcanVcYVgZhjW_ZXiidX]Vc\Zl^i]djicdi ^XZ#
3768@ID>C9:M
G=7.
G=7-
20
RHB 9/RHB 8
7j^ai"^cHeZX^[^XVi^dch
(+ 6g^h^iEinA^b^iZYVgZcdigZhedch^WaZ[dgVcnZggdghdgdb^hh^dch#E^XijgZh!heZX^[^XVi^dchVcY Y^bZch^dch
VgZ[dg^aajhigVi^dcejgedhZhdcanVcYVgZhjW_ZXiidX]Vc\Zl^i]dji cdi^XZ#
3768@ID>C9:M
8E%*.B9
CP 0V9 MX
25
CP 059 MD/CP 0V9 MX/CP 859 MT
Arisit Pty Limited are not responsible for any errors or omissions. Pictures, specifications and dimensions are for illustration purposes only and are subject
to change without notice.

All Ariston products carry a "Total Peace of Mind" 2 year warranty.
ARISIT PTY LIMITED (Australia)
ABN 23 091 515 294
40-44 Mark Anthony Drive
Dandenong South VIC 3175
Phone: Sales: 1300 762 219 - Service: 1300 815 589
Fax: Sales & Service [phone]
Email: [email protected]
ARISIT PTY LIMITED (New Zealand)
1A Howe Street Newton, Auckland 1145
PO Box 68-140 Newton, Auckland 1145
Phone: [phone] - Fax: [phone]
Email: [email protected].nz
SPD-JUNE 2009
