ASSEMBLY AND OPERATION INSTRUCTIONS
ELECTRIC WATER HEATER

2 / EN
GENERAL SAFETY INSTRUCTIONS
1. Read the instructions and warning in this manual carefully, they
contain important information regarding safe installation, use
and maintenance.
This manual is an integral part of the product. Hand it on to the
next user/owner in case of change of property.
2. The manufacturer shall not liable for any injury to people, animals or
damage to property caused by improper, incorrect or unreasonable
use or failure to follow the instructions reported in this publication.
3. Installation and maintenance must be performed by professionally
qualified personnel as specified in the relative paragraphs.
Only use original spare parts. Failure to observe the above instruc-
tions can compromise the safety of the appliance and relieves the
manufacturer of any liability for the consequences.
4. DO NOT leave the packaging materials (staples, plastic bags, ex-
panded polystyrene, etc.) within the reach of children they can
cause serious injury.
5. The appliance may not be used by persons under 8 years of age,
with reduced physical, sensory or mental capacity, or lacking the
requisite experience and familiarity, unless under supervision or
following instruction in the safe use of the appliance and the haz-
ards attendant on such use. DO NOT permit children to play with
the appliance. User cleaning and maintenance may not be done
by unsupervised children.
6. DO NOT touch the appliance when barefoot or if any part of your
body is wet.
7. Before using the device and after routine or extraordinary mainte-
nance, we recommend filling the appliance’s tank with water and
draining it completely to remove any residual impurities.
8. If the appliance is equipped with a power cord, the latter may only
be replaced by an authorised service centre or professional tech-
nician.
9. It is mandatory to screw o the water inlet pipe of the unit a safety
valve in accordance with national regulations. In countries which
have enacted EN 1487, the safety group must be calibrated to a
maximum pressure of 1487 MPa (0,7 bar) and include at least a cock,

3 / EN
check valve and control, safety valve and hydraulic load cutout.
10. Do not tamper with the overpressure safety device (valve or safety
group), if supplied together with the appliance; trip it from time to
time to ensure that it is not jammed and to remove any scale de-
posits.
11. It is normal water drips from the overpressure safety device when
the appliance is heating. For this reason, the drain must be con-
nected, always left open to the atmosphere, with a drainage pipe
installed in a continuous downward slope and in a place free of ice.
12. Make sure you drain the appliance and disconnect it from the pow-
er grid when it is out of service in an area subject to subzero tem-
peratures.
13. Water heated to over 50 °C can cause immediate serious burns if
delivered directly to the taps. Children, disabled persons and the
aged are particularly at risk. We recommend installing a thermostat-
ic mixer valve on the water delivery line, marked with a red collar.
14. Do not leave flammable materials in contact with or in the vicinity of
the appliance.
15. Do not place anything under the water heater which may be dam-
aged by a leak.

4 / EN
Symbol Meaning
Failure to observe this warning can result in injury, which may even be fatal in certain circumstances
Failure to observe this warning can result in damage or injury, even serious in certain circumstances,
to property, plants and animals
Observe the product’s general and specific safety instructions.
GENERAL SAFETY STANDARDS
Ref. Warning Risk Symbol
1
Do not open the appliance or
remove from its installation
Electrocution hazard due to the presence
of live electrical equipment Personal injury
- burns caused by overheated components
and wounds caused by sharp edges
2
Do not start or stop the appliance by inserting/
pulling the power plug Electrocution hazard due to damage to the power cord, its plug or the socket
3
Do not damage the power cord Electrocution hazard due to bare live wires
4
Do not leave objects on the appliance
Personal injury due to objects falling o the
appliance as a result of vibration
Damage to the appliance or other property
due to objects falling o the appliance as a
result of vibration
5
Do not climb onto the appliance
Personal injury due to falling o the appli-
ance
Damage to the appliance or other property
due to the appliance itself detaching from
its mounting
6
Do not clean the appliance without having first
switched it o, pulled its power plug or shut
o its power switch
Electrocution hazard due to the presence
of live electrical equipment
7
Install the appliance to a solid wall which is
not subject to vibration
Danger of the appliance falling o the
wall due to structural collapse, or noisy
operation
8
Make the electrical hookup with cables of
adequate cross-section Danger of fire due to overheating of under- sized electrical wires
9
Restore all safety and control functions after
working on the appliance and check that they
are operational before returning it to service
Damage or blocking of the appliance due
to improper control
10
Drain all components containing hot water,
using the bleed cocks, before handling them Danger of burns
11
Descale the system as given in the product's
“safety sheet”; when doing so, ventilate the
room, wear safety clothing, make sure not to
mix products, and protect the appliance itself
and any adjacent objects
Personal injury due to contact of the skin
and eyes with acid, inhalation or ingestion
of noxious chemicals
Damage to the appliance and adjacent
objects due to corrosion by acid
12
Do not use insecticides, solvents or aggres-
sive detergents to clean the appliance Damage to plastic and painted parts and assemblies

5 / EN
LEGIONELLA BACTERIA
Legionella are small rod shaped bacteria which are a natural constituent of all fresh waters. Legionaries’
disease is a pneumonia infection caused by inhaling of Legionella species. Long periods of water stag-
nation should be avoided; it means the water heater should be used or flushed at least weekly.
The European standard CEN/TR 16355 gives recommendations for good practice concerning the pre-
vention of Legionella growth in drinking water installations but existing national regulations remain in
force.
DESCRIPTION OF WATER HEATER
(see figure 7)
F) LED
A) Cap
M) Adjustment knob
B) Water intake pipe
C) Water outlet pipe
TECHNICAL CHARACTERISTICS
For the technical specifications, refer to the nameplate (the nameplate is located next to the water in-
take/outlet pipes).
TABLE 1 - PRODUCT INFORMATION
Model 10L
Oversink
10L
Undersink
15L
Oversink
15L
Undersink
30L
Oversink
Weight when empty kg 6.6 6.6 7.4 7.4
12.8
Wattage W 1500
Heating Time [∆T = 50°C] minutes 23 23 35 35 90
Heat Dispersion kWh/24hours 0.51 0.62* 0.56 0.69* 0.68
This appliance is conforming with the standard SANS 151 and with the electrical safety standards SANS
60335-1 and SANS 60335-2-21
* Declared Energy Performance have been achieved by using the hydraulic adaptors supplied with
the Water Heater

6 / EN
INSTALLING NORMS (for the installer)
CAUTION: Observe all general warnings and safety standards listed at the beginning
of this text in full; all such instructions are obligatory.
The appliance must be installed and commissioned by a qualified technician in accordance with estab-
lished regulations and local health and safety regulations.
We recommend installing the appliance as close as possible to the delivery points to minimise heat loss
along the pipes. Local regulations may provide for restrictions on installation in bathrooms; observe any
regulatory minimum distances. The range of water heaters includes models set up to be assembled
above or below the point of use (sink, basin or shower). The models intended to be assembled under
the point of use are called “undersink”. To facilitate maintenance, make sure there is a clearance of at
least 50 cm inside the enclosure for access to the electrical equipment. Fix the supplied bracket to the
wall with screws and dowels of adequate size for the type of wall. Hook the water heater to the bracket
and pull down to make sure it is secured.
HYDRAULIC CONNECTION
The INSTALLATION of the appliance must strictly comply with SANS 10254 code of practice, a copy of
which is obtainable from the South African Bureau of Standards. Installation, maintenance and repairs to
the appliance not complying with the SANS 10254 code of practice will invalidate the Warranty.
If you decide to install mixer units (taps or shower), purge the pipes of any potentially damaging impuri-
ties first. The appliance must not be supplied with water of hardness less than 12°F, nor with especially
hard water (greater than 25°F); we recommend installing a water softener, properly calibrated and con-
trolled - do not allow the residual hardness to fall below 15°F. Before using the appliance, we recommend
filling its tank with water and draining it completely so as to remove any residual impurities.
Specific taps must be used for this type of installation and the connection must be implemented as
shown in the diagram in Fig. 1. With this solution, the water heater can work at any mains pressure and
no type of tap must be connected on the outlet pipe, which acts as a vent.
We reccomend that all exposed metal pipes must be lagged.
The hydraulic adaptors, which are delivered with the product, must be installed on the thread connection
with a sealing.
ELECTRICAL CONNECTION
Before performing any operations, disconnect the appliance from the electricity mains using the
external switch.
1. Electrical installation must comply with SANS 10142 – Electrical code for wiring of premises and should
be tested by the local electricity authority. The fixed wiring must incorporate a means of disconnecting
from the main supply having a separation of at least3 mm in all poles.
2. Check the circuit breaker on the distribution board is the correct amperage for the unit.
3. Check that all electrical connections are secure. with a sealing.
!WARNING! THIS APPLIANCE MUST BE EARTHED.
4. Replace electrical cover and ensure geyser is full of water before switching on electricity, even for
testing purposes.
5. Fixed wiring must incorporate a means of disconnecting from the main supply, having a separation of
at least 3 mm in a pole.

7 / EN
MAINTENANCE REGULATIONS (for competent person)
CAUTION: Observe all general warnings and safety standards listed at the beginning
of this text in full; all such instructions are obligatory.
NOTE: Elements burn through commissioning without water and burnouts due to loose connections are
not covered by the Warranty.
For greater safety, have qualified personnel carry out a careful inspection of the electrical system, ensur-
ing it complies with the applicable norms in force, because the appliance manufacturer will not be held
responsible for any damage caused by the lack of earthing of the system or for faults in the electricity
supply.
Check that the system is suitable for the maximum power absorbed by the water heater (please refer
to the data plate) and that the cross-section of the electrical connection cables is suitable and complies
with current laws. The use of multiplugs, extensions or adaptors is strictly prohibited. It is strictly forbid-
den to use the piping from the plumbing, heating and gas systems for the appliance earthing connection.
If the appliance is supplied with a power supply cable and the latter should need replacing, use a cable
featuring the same characteristics (type H05VV-F 3x1.5 mm², 8.5 mm in diameter) and compliant with
SANS 60227-5. The supply cable (type H05 VV-F 3x1.5 mm²) is to be inserted in the proper hole situated
in the back of the appliance and slide it until it reaches terminal of the thermostat, then lock single cables
by mean of the insulation base. To disconnect the unit from the electrical supply use a bipolar, switch
conforming to local (contact opening at least 3 mm, better if equipped with fuses).
The appliance must be earthed and the earth cable (which must be yellow-green and longer than that
of the phases it is fixed to the terminal marked by the symbol . Block the power supply cord on the
small cap using the special wire clamp provided.
Before usage, make sure that the supply voltage is in compliance with the rated values of the ap-
pliance. If the appliance is not supplied with a power supply cable, use a flexible cable (type H05VVF
3X1.5mm2, 8.5 mm) in diameter compliant with the applicable norms in force, if the applianche is sup-
plied with a cable clamp.
Startup and commissioning
Before powering up the appliance, fill the heater with mains water.
To do so, open the mains cock and the hot water tap until all the air has been vented from the
boiler. Check for leaks from the flanges, tighten down the fittings (not too much!) if necessary
(A fig. 4). Power up using the switch and in models with no switch, power up by turning the
adjustment knob clockwise
Maintenance work may only be done by qualified technicians (in possession of the regulatory requi-
sites). Before requesting for the Technical Assistance to intervene for a suspected fault, check that this
is not caused by a temporary lack of water supply or power failure.
Draining the appliance
Make sure to drain the appliance when it is out of service or in an area subject to subzero
temperatures.
To drain the appliance, proceed as follows:
- permanently disconnect it from its power supply;
- open the hot water tap (sink or bath tub).

8 / EN
Replacing parts
Disconnect the appliance from its power supply.
Remove the enclosure to access the electrical equipment.
To work on the thermostat, extract it from its mount and disconnect it from its power supply.
To work on the heating element and anode, first drain the appliance.
Use only original spare parts
Scheduled maintenance
The heating element (R fig. 5) should be descaled every two years to ensure it works properly.
If you do not wish to use a liquid descaler, you can simply break o the deposit, taking care not to dam-
age the heating element’s cladding. The magnesium anode (N fig. 5) must be replaced every two years;
however, the anode should be checked every year if the water is corrosive or chloride rich. To replace
it, remove the heating element and unscrew it from its bracket.
After routine or extraordinary maintenance, we recommend filling its tank with water and draining it
completely so as to remove any residual impurities.
Use only original spare parts supplied by the manufacturer’s authorised service centres.
Reactivating the two-pole cutout
If the water overheats excessively, a thermal cutout (CEI-EN compliant) trips to cut the electrical power
supply to the heating element (both phases); contact the Service Centre if this occurs.
USER INSTRUCTIONS
CAUTION: Observe all general warnings and safety standards listed at the beginning
of this text in full; all such instructions are obligatory.
Recommendations
- Do not place anything under the water heater which may be damaged by a leak.
- If the water is not used for a long time:
 ➤shut o power to the appliance by setting the external switch to “OFF”;
 ➤close the water circuit cocks.
- Water heated to over 50°C can cause immediate serious burns or even death. Children, disabled
persons and the aged are particularly at risk of burns.
Do not attempt to service or repair the appliance.
Operation, setting the operating temperature
Start up
Power up by turning the adjustment knob clockwise. The indicator lamp only remains on when heating
up. The thermostat will automatically disconnect the resistance when the preset operating temperature
is reached.
Setting the operating temperature
On models with external regulation, the water temperature can be set with the knob (M fig. 6) connected
to the thermostat, as indicated on the device itself.

9 / EN
USEFUL HINTS
If the water delivery is cold, have the following checked:
- is there power to the thermostat and terminal block?
- are the heating elements working?
If the water is boiling hot (steam is coming out of the taps)
Shut o electrical power to the appliance and have the following checked:
- thermostat;
- the amount of scale on the boiler and heating element.
If the hot water delivery is insucient, have the following checked:
- the mains water pressure;
- the condition of the deflector on the cold water intake pipe;
- the condition of the hot water pipe;
- the electrical equipment.
NEVER ATTEMPT TO REPAIR THE APPLIANCE YOURSELF - ALWAYS HAVE THIS DONE BY A
QUALIFIED TECHNICIAN.
The indicated data and specifications are not binding; the manufacturer reserves the right to modify
them at his own discretion notification or replacement.
HYDRAULIC FITTINGS

10 / EN

11 / EN

12 / EN
7
43
5
F
A
A
N
R
6T
M
A
M
F
C B

13 / EN
WARRANTY
To be retained
Ariston Thermo South Africa (Pty) Ltd
294 Barolong St., Icon Park, Sunderland Ridge, South Africa
T: ([phone] - Web: http://www.ariston.com/en-za
Mr.
Address
ZIP Town
Model
Serial N.
Years Tank Warranty Date of purchase
1. Ariston Warranty against corrosion (leaking) the
inner tank of this water heater for the period
specified on the forehead of this certificate.
2. Heating element and thermostat will be War-
ranty for two years
3. Other parts, such as: gaskets, probe lamp,
flange, security valve, will be warrantee for one
year.
4. Magnesium anode (where applicable) is not
covered by any Warranty in virtue of its nature
of consumable material.
5. Furthermore this Warranty will not cover: trans-
portation and handling damages; damages oc-
curred because of wrong installation, transpor-
tation and installation expenses arising from
eventual faulty units. This Warranty is invalid
unless the unit is properly used and regularly
maintained as set out in the installation manual.
6. The Warranty period will begin on the date of
purchase reported on the receipt/invoice re-
leased by the dealer upon selling the unit.
7. It is therefore required, in order to exercise
one’s right to the eventual claim, to keep the
following: receipt/invoice proving the date of
purchase; this certificate duly filled-up.
8. This Warranty provides the free replacement of
the defective component or of the whole unit in
case the above defects
9. Ariston will not be held responsible for any dam-
age, direct or indirect, to people, animals, prop-
erties in the house due to the non observance
of the instructions contained in the installation
manual of the relevant unit.
10.In case of claim, the unit MUST remain installed.
Contact the Ariston Service Call Centre at 087
943 7470. Proof of purchase/installation needs
to be supplied.
5 years

14 / EN

15 / EN

420010753802 - 07/2020
Ariston Thermo SpA
Viale Aristide Merloni 45
60044 Fabriano (AN) Italy
Telefono 0732 6011 - Fax [phone]
[email protected]
www.aristonthermo.com
Ariston Thermo South Africa (Pty) Ltd
294 Barolong St. Icon Business Park
Sunderland Ridge
South Africa
([phone]
[email protected]
www.aristonthermo.com
