Arrow T59 User manual

SAFETY INSTRUCTIONS
• Always be cautious of potential hazards such as electrical wiring,
slippery footing, damp or wet conditions, etc.
• Make sure you know what you are fastening — look for hidden
hazards.
• Keep work area clean. Cluttered areas and benches invite accidents.
• Keep children away. All visitors should be kept a safe distance from
work area.
• Store idle tools. When not in use, tools should be stored in high or
locked-up place — out of reach of children.
• Use safety glasses.
• Do not overreach. Keep proper footing and balance at all times.
• Maintain tools with care. Follow instructions with care.
• For service, use only approved service centers.
• Use only original parts provided by the supplier.
• Stay alert — watch what you are doing. Use common sense.
• Do not staple into electrical wires. Be cautious of wires that may be
hidden from view. Disconnect circu its.
.oNtraP
21
21X
5922
5923
5924
25
26
5927
27a
28
29
29a
30X
30a
31
32
33
40
POSTAGE AND HANDLING EXTRA
Prices subject to change without notice.
T59™
GUN TACKER

OPERATING INSTRUCTIONS
TO LOAD
1. Remove pusher rod from machine.
2. Insert strip of staples.
3. Replace pusher rod.
STAPLE PENETRATION
For best penetration with any gun tacker, raise the
rear of the gun slightly off the work and bear down
on the front end to prevent recoil when operating.
The power spring on the T59 will drive well into
all ordinary woods.
T59™
1/4" x 1/4"
6mm x 6mm
1/4" x 5/16"
6mm x 8mm
5/16" x 5/16"
8mm x 8mm
TO CLEAN STAPLE CHANNEL
1. Remove pusher rod A.
2. Remove screw and nut from hole B.
3. Pull down entire inside frame for complete cleaning.
How to determine staple shortage for rell.
1. Press latch to release pusher rod.
2. Lightly push rod forward until it stops. Visible projected part of rod indicates amount
of staples remaining in track.
