Artecta A0320073 User manual

Par 46 Tracklight - Warm on Dim
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Product code: A0320073
USER MANUAL
ENGLISH
V1

1
Par 46 Tracklight - Warm on Dim
Product code: A0320073
Preface
Thank you for purchasing this Artecta product.
The purpose of this user manual is to provide instructions for the correct and safe use of this product.
Keep the user manual for future reference as it is an integral part of the product. The user manual shall be
stored at an easily accessible location.
This user manual contains information concerning:
●Safety instructions
●Intended and non-intended use of the device
●Installation and operation of the device
●Maintenance procedures
●Troubleshooting
●Transport, storage and disposal of the device
Non-observance of the instructions in this user manual may result in serious injuries and damage of
property.
©2021 Artecta. All rights reserved.
No part of this document may be copied, published or otherwise reproduced without the prior written
consent of Highlite International.
Design and product specifications are subject to change without prior notice.
For the latest version of this document or other language versions, please visit our website
www.highlite.com or contact us at [e-mail].
Highlite International and its authorized service providers are not liable for any injury, damage, direct or
indirect loss, consequential or economic loss or any other loss arising from the use of, or inability to use or
reliance on the information contained in this document.

2
Par 46 Tracklight - Warm on Dim
Product code: A0320073
Table of contents
1. Introduction..........................................................................................................................................................3
Before Using the Product ..................................................................................................................................3
Intended Use .......................................................................................................................................................3
LEDs Lifespan .......................................................................................................................................................3
Text Conventions ................................................................................................................................................3
Symbols and Signal Words................................................................................................................................4
Symbols on the Information Label ..................................................................................................................4
2. Safety ....................................................................................................................................................................4
Warnings and Safety Instructions ....................................................................................................................5
Requirements for the User.................................................................................................................................6
3. Description of the Device...................................................................................................................................7
Front View ............................................................................................................................................................7
Dimensions...........................................................................................................................................................7
Product Specifications ......................................................................................................................................8
4. Installation and Deinstallation ...........................................................................................................................9
Safety Instructions...............................................................................................................................................9
Personal Protective Equipment .......................................................................................................................9
Installation Site Requirements ..........................................................................................................................9
Mounting..............................................................................................................................................................9
Dismounting.......................................................................................................................................................11
Direction Adjustment .......................................................................................................................................12
Color Frame.......................................................................................................................................................12
Connecting to Power Supply.........................................................................................................................12
5. Troubleshooting .................................................................................................................................................13
6. Maintenance .....................................................................................................................................................13
Safety Instructions for Maintenance.............................................................................................................13
Preventive Maintenance................................................................................................................................13
Basic Cleaning Instructions .......................................................................................................................13
Corrective Maintenance................................................................................................................................14
7. Transportation and Storage..............................................................................................................................14
Instructions for Transportation ........................................................................................................................14
Storage...............................................................................................................................................................14
8. Disposal ..............................................................................................................................................................14
9. Approval.............................................................................................................................................................14

3
Par 46 Tracklight - Warm on Dim
Product code: A0320073
1. Introduction
Before Using the Product
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your
Highlite International dealer.
Your shipment includes:
●Artecta Par 46 Tracklight –Warm on
Dim (including track adapter)
●Color frame (installed)
●User manual
Fig. 01
Intended Use
This device is intended for professional use as an architectural light spot. It is suitable for indoor installation
in shops, exhibition halls, showrooms and similar venues. This device is not suitable for households.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
LEDs Lifespan
The light output of the LEDs gradually decreases over time (lumen depreciation). High operating
temperatures contribute to this process. You can extend the lifespan of the LEDs by providing adequate
ventilation and operating the LEDs at the lowest possible brightness.
Text Conventions
Throughout the user manual the following text conventions are used:
●References: References to chapters and parts of the device are in bold lettering, for example:
“Refer to 2. Safety”, “turn the adjustment handle (05)”
●Notes: Note: (in bold lettering) is followed by useful information or tips

4
Par 46 Tracklight - Warm on Dim
Product code: A0320073
Symbols and Signal Words
Safety notes and warnings are indicated throughout the user manual by safety signs.
Always follow the instructions provided in this user manual.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in
death or serious injury.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
Attention
Indicates important information for the correct operation and use of the
product.
Important
Read and observe the instructions in this document.
Electrical hazard
Provides important information about the disposal of this product.
Symbols on the Information Label
This product is provided with an information label. The information label is located on the mounting
bracket.
The information label contains the following symbols:
This device is designed for indoor use.
This device falls under IEC protection class I.
This device shall not be treated as household waste.
2. Safety
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.

5
Par 46 Tracklight - Warm on Dim
Product code: A0320073
Warnings and Safety Instructions
DANGER
Danger for children
For adult use only. The device must be installed beyond the reach of children.
●Do not leave various parts of the packaging (plastic bags, polystyrene foam, nails, etc.) within
children’s reach. Packaging material is a potential source of danger for children.
DANGER
Electric shock caused by dangerous voltage inside
There are areas within the device where dangerous touch voltage may be present.
●Do not open the device or remove any covers.
●Do not operate the device if the covers or the housing is open. Before operation, check if the
housing is firmly closed and all screws are tightly fastened.
●Disconnect the device from electrical power supply before service and maintenance.
DANGER
Electric shock caused by short-circuit
This device falls under IEC protection class I.
●Make sure that the device is electrically connected to ground (earth). Connect the device only to a
track system with ground (earth) connection.
●Do not cover the ground (earth) connection.
●Do not bypass the thermostatic switch or fuses.
●For replacement use fuses of the same type and rating only.
●Do not modify, bend, mechanically strain, put pressure on, pull or heat up the interconnecting power
cable.
●Make sure that the interconnecting power cable is not crimped or damaged. Examine the power
cable periodically for any defects.
●Do not immerse the device in water or other liquids. Do not install the device in a location where
flooding may occur.
Attention
Power supply
Before connecting the device to the power supply, make sure that the current, voltage and frequency
match the input voltage, current and frequency specified on the information label on the device.
Attention
General safety
●Do not shake the device. Avoid brute force when installing or operating the device.
●If the device fails to work properly, discontinue the use immediately.

6
Par 46 Tracklight - Warm on Dim
Product code: A0320073
Attention
This device shall be used only for the purposes it is designed for.
This device is intended for professional use as an architectural light spot. It is suitable for indoor installation
in shops, exhibition halls, showrooms and similar venues.
●This device is not suitable for households.
●This device does not contain user-serviceable parts. Unauthorized modifications to the device will
render the warranty void. Such modifications may result in injuries and material damage.
Attention
Before use, examine the device visually for any defects.
Make sure that:
●There are no deformations on housings, fixations and installation points.
●The lens is not cracked or damaged.
●The interconnecting power cable is not damaged and does not show any material fatigue.
Attention
Do not expose the device to conditions that exceed the rated IP class conditions.
This device is IP20 rated. IP (Ingress Protection) 20 class provides protection against solid objects greater
than 12 mm, such as fingers, and no protection against harmful ingress of water.
Requirements for the User
This product may be used by ordinary persons. Maintenance may be carried by ordinary persons.
Installation and service shall be carried out only by instructed or skilled persons. Contact your Highlite
dealer for more information.
Instructed persons have been instructed and trained by a skilled person, or are supervised by a skilled
person, for specific tasks and work activities associated with the installation, service and maintenance of
this product, so that they can identify risks and take precautions to avoid them.
Skilled persons have training or experience, which enables them to recognize risks and to avoid hazards
associated with the installation, service and maintenance of this product.
Ordinary persons are all persons other than instructed persons and skilled persons. Ordinary persons
include not only users of the product but also any other persons that may have access to the device or
who may be in the vicinity of the device.

7
Par 46 Tracklight - Warm on Dim
Product code: A0320073
3. Description of the Device
The Artecta Par 46 Tracklight –Warm on Dim is a compact spot suitable for indoor venues. It features a
warm-on-dim technology which mimics the dimming curve of a traditional tungsten lamp. At 100 %
output the color temperature is 2700 K and at 5 % –1800 K. The high CRI and the lack of UV radiation
make it a good solution for clothing shops and galleries. The device is delivered with a color frame.
The device is equipped with a 3-phase track adapter. The 3-phase track adapter is compatible with the
Artecta 3-phase track systems and with the most 3-phase tracks available on the market.
Front View
01) Track adapter
02) Track lock
03) Circuit selector (OFF, 1, 2 and 3)
04) Interconnecting cable
05) Ground connection
06) Mounting bracket
07) Adjustment screw
08) 3 x Color frame holders
09) Color frame
10) Color frame clip
Fig. 02
Dimensions
Fig. 03

8
Par 46 Tracklight - Warm on Dim
Product code: A0320073
Product Specifications
Model:
Par 46 Tracklight –Warm on Dim
Electrical:
Input voltage:
100–240 V AC, 50/60 Hz
Power consumption:
29 W (at full output)
PFC:
0,97
Physical:
Dimensions:
300 x 196 x 330 mm (L x W x H) (with the track adapter)
Weight:
1,47 kg (with the track adapter)
Track adapter:
Power connection:
220–250 V, 10 A
F max:
100 N
Phases:
3
Optics:
Light source:
28 W LED
Dimmer:
External, TRIAC type
Beam angle:
60°
Luminous flux:
1800 lm
CCT minimum:
1800 K
CCT maximum:
2700 K
CRI:
>95
Construction:
Housing:
Extruded aluminum
Color:
Black
IP rating:
IP20
Cooling:
Natural convection
Thermal:
Maximum ambient temperature ta:
40 °C
Minimum ambient temperature:
-5 °C
Minimum distance:
Minimum distance from flammable surfaces:
0,5 m
Minimum distance to lighted object:
0,5 m

9
Par 46 Tracklight - Warm on Dim
Product code: A0320073
4. Installation and Deinstallation
Safety Instructions
WARNING
Incorrect installation and deinstallation can cause serious injuries and damage of
property.
Installation and deinstallation of the device must be carried out only by instructed or skilled persons.
Follow all applicable European, national and local safety regulations concerning electrical installations in
buildings and working at heights.
Before installing or deinstalling the device make sure that the track system is disconnected from power
supply.
Personal Protective Equipment
During installation and deinstallation wear personal protective equipment in compliance with the
national and site-specific regulations.
Installation Site Requirements
●The device can be used only indoors.
●The device can be mounted only to a 3-phase track system.
●The minimum distance to other objects must be bigger than 0,5 m.
●The maximum ambient temperature ta= 40 °C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 40 °C
Mounting
The device can be mounted only to a 3-phase track system.
CAUTION
Restrict the access under the work area during mounting.
To mount the device, follow the steps below:
01) Disconnect the track system from the power supply.
02) Make sure that the circuit selector (03) is in OFF position and the track lock (02) is in unlocked
position, as shown in Fig. 04.
03) Align the flange of the track adapter (01) with the track, as shown in Fig. 05.
Fig. 04
Fig. 05

10
Par 46 Tracklight - Warm on Dim
Product code: A0320073
04) Insert the track adapter (01) in the track and push it until it snaps into place.
05) Turn the track lock (02) clockwise to lock the device in the track, as shown in Fig. 07.
Fig. 06
Fig. 07
06) Select the circuit with the circuit selector (03). You can select 1-, 2- and 3-phase circuit, as shown in
Fig. 08.
Attention
Do not slide the track adapter in the track to adjust the position of the device (see Fig. 09). This can
damage the connectors. Remove the device from the track and install it at the new place. For more
information on how to remove the device from the track, refer to 4.5. Dismounting on page 11.
Fig. 08
Fig. 09

11
Par 46 Tracklight - Warm on Dim
Product code: A0320073
Dismounting
CAUTION
Restrict the access under the work area during dismounting.
To dismount the device, follow the steps below:
01) Disconnect the track system from the power
supply.
02) Let the device cool down before dismounting.
03) Set the circuit selector (03) in OFF position, as
shown in Fig. 10.
Fig. 10
04) Turn the track lock (02) counterclockwise to unlock the device (see Fig. 11).
05) Pull the track adapter (01) from the track (see Fig. 12).
Fig. 11
Fig. 12

12
Par 46 Tracklight - Warm on Dim
Product code: A0320073
Direction Adjustment
To adjust the angle of the device and the direction of the beam, follow the steps below:
01) Pivot the device around the track adapter (01) to adjust the direction of the beam (see Fig. 13).
02) Turn the adjustment screw (07)counterclockwise to release it.
03) Tilt the device at the desired angle (see Fig. 14).
04) Turn the adjustment screw (07) clockwise to tighten it. Make sure that the device cannot move freely
after the adjustment screw (07) is tightened.
Fig. 13
Fig. 14
Color Frame
The Par 46 Tracklight –Warm on Dim is delivered with the color frame installed. You can insert a color gel
or a diffusion filter into the color frame. To remove the color frame, follow the steps below:
01) Press the color frame clip (10) and at the same time remove the color frame (09) from the color
frame holders (08)(see Fig. 15 and Fig. 16).
Fig. 15
Fig. 16
02) Insert a color gel or a diffusion filter into the color frame.
03) Press the color frame clip (10) and at the same time insert the color frame (09) into the color frame
holders (08).
04) Release the color frame clip (10) to lock the color frame in position.
Make sure that the color frame is locked in position with the color frame clip before using the device.
Connecting to Power Supply
This device is suitable for mounting only to a 3-phase track system. The device is connected to power
supply when it is mounted to the track system.
Before installing or deinstalling the device make sure that the track system is disconnected from power
supply.

13
Par 46 Tracklight - Warm on Dim
Product code: A0320073
5. Troubleshooting
This troubleshooting guide contains solutions to problems which can be carried out by an ordinary
person. The device does not contain user-serviceable parts.
Unauthorized modifications to the device will render the warranty void. Such modifications may result in
injuries and material damage.
Refer servicing to instructed or skilled persons. Contact your Highlite International dealer in case the
solution is not described in the table.
Problem
Probable cause(s)
Solution
The device does not
function
No power to the device
●Check if the track system is connected
to the power supply
Main fuse is blown
●Disconnect the device and contact
your Highlite International dealer
LEDs are damaged
●Disconnect the device and contact
your Highlite International dealer
No light or LEDs cut
out intermittently
The power supply settings do not
match local AC voltage and
frequency
●Disconnect the device. Check the
settings and correct, if necessary
6. Maintenance
Safety Instructions for Maintenance
DANGER
Electric shock caused by dangerous voltage inside
Disconnect power supply before servicing or cleaning.
Preventive Maintenance
Attention
Before use, examine the device visually for any defects.
Make sure that:
●All screws used for installing the device or parts of the device are tightly fastened and are not
corroded.
●There are no deformations on housings, fixations and installation points.
●The lens is not cracked or damaged.
●The interconnecting power cable is not damaged and does not show any material fatigue.
Basic Cleaning Instructions
The external lens of the device must be cleaned periodically in order to optimize the light output. The
cleaning schedule depends on the conditions at the site where the device is installed. When smoke or
fog machines are used at the site, the device will need more frequent cleaning. On the other hand, if the
device is installed in a well-ventilated area, it will need less frequent cleaning. To establish a cleaning
schedule, examine the device at regular intervals during the first 100 hours of operation.

14
Par 46 Tracklight - Warm on Dim
Product code: A0320073
To clean the device, follow the steps below:
Disconnect the device from the electrical power supply.
Allow the device to cool down for at least 15 minutes.
03) Remove the dust collected on the external surface with dry compressed air and a soft brush.
04) Clean the lens with a damp cloth.
05) Dry the lens carefully with a lint-free cloth.
Attention
●Do not immerse the device in liquid.
●Do not use alcohol or solvents.
Corrective Maintenance
The device does not contain user-serviceable parts. Do not open the device and do not modify the
device.
Refer repairs and servicing to instructed or skilled persons. Contact your Highlite International dealer for
more information.
7. Transportation and Storage
Instructions for Transportation
●Use the original packaging to transport the device, if possible.
●Always observe the handling instructions printed on the outer carton box, for example: “Handle with
care”, “This side up”, “Fragile”.
Storage
●Clean the device before storing. Follow the cleaning instructions in chapter 6.2.1. Basic Cleaning
Instructions on pages 13–14.
●Store the device in the original packaging, if possible.
8. Disposal
Correct disposal of this product
Waste Electrical and Electronic Equipment
This symbol on the product, its packaging or documents indicates that the product
shall not be treated as household waste. Dispose of this product by handing it to the
respective collection point for recycling of electrical and electronic equipment. This is
to avoid environmental damage or personal injury due to uncontrolled waste
disposal. For more detailed information about recycling of this product contact the
local authorities or the authorized dealer.
9. Approval
Check the respective product page on the website of Highlite International
(www.highlite.com) for an available declaration of conformity.

©2021 Artecta
