Artecta Meteor-120RGB User manual

LED technology
THE ART OF LIGHTING
A0620125 Meteor-120RGB
Underwater Pool Light
Operating Instructions
Underwater Pool Light
UNDERWATER RATED

CONTENTS
Preface....................................................................................................................................................... 2
Precautions ................................................................................................................................................ 2
Features ..................................................................................................................................................... 3
Components and Connectors ..................................................................................................................... 3
Installation .................................................................................................................................................. 4
Controls....................................................................................................................................................... 5
Appearance................................................................................................................................................. 6
Technical Specifications.............................................................................................................................. 6
Declaration of conformaty............................................................................................................................ 7
PREFACE
The METEOR 120-RGB series of a compact ultra-thin underwater pool light with built-in driver is designed to
use the latest LED lighting technology.
The surface-mount designed casing enable very simple installation on the flat surface without any surface
preparation during construction and the max. diameter of the hole through the wall is 8 mm.
The METEOR 120-RGB with 316T stainless steel casings is available with RGB colors with 12 highpower
LEDs.
The multi-color RGB version allows changing of the color of lighting manually or automatically through the
complete rainbow spectrum.
The most advanced electronic design with built-in microprocessor enables network connection and simple
control of complete group of lights with dimming.
2
PRECAUTIONS
The underwater pool light has to be installed and used in accordance with the instructions of this manual
only.
The power supply has to be disconnected before installation.
The underwater pool light is recomended to be installed around 0.2 m below the water line for the best
illumination and to avoid over-heating.
The optical window must be clear and not covered by any kind of isolating or other material.
The optical window has to be cleaned with a mild soap or detergent and lukewarm water by using a soft
cloth or sponge. Do not use abrasive or highly alkaline cleaners.
Never scrape with razor blades or other sharp instruments. Benzene, leaded gasoline, acetone or carbon
tetrachloride should never be used.
Do turn power off immediately and refer servicing to qualified service personnel if the underwater pool light
does not operate normally following the operating instructions.

3
119
9
8
APPEARANCE
Red: Powersupply DC+
Black: Powersupply DC-
Orange: Pulse Control +
Brown: Pulse Control GND
1
2
4
3
High grade polycarbonate glass optical window
Stainless Steel
316L stainless steel 316L
Fixing Screws
5m 4-Pole Multicable
FEATURES
Innovative DesignS
tainless Steel Ultra-Thin Casing
12 Power LEDs Design
White, Red, Blue, Green or Multi-Color RGB Lighting
High Grade Polycarbonate Glass Optical Window
Vacuum Metalized Reflector
Remote Control
Digital Dimming
Polarity Protection
Transient Protection
Thermal Protection
Wide Range Power Supply
Low Power Consumption
Simple Installation
Optional accessories for different pools installations
(1) Optical window
High-grade polycarbonate glass optical window.
(2) Underwater pool light casing
Stainless steel casing with fixing holes and cable gland.
(3) Cable
The 4-pole multi-core cable to connect the 12-24Vdc power supply and optional remote control or
switch.
(4) Fixing screw
The fixing screws to fix the underwater pool light on the wall.

Wall
Screw 5.5X38
Sealing Grooves (2X)
Sealing
INSTALLATION
The underwater light kit consists of the following components:
Underwater Light METEOR 120-RGB
4 x fixing screw 5.5x38 with wallplugs
Operating Instructions
The METEOR 120 has to be installed on a flat surface on the pool wall under water line.
Do not try to install the underwater pool light while the pool is filled with water.
When the installation is finished briefly test the underwater light prior to fill the pool with water.
The installation have to be realized by a qualified personnel.
Note:
Avoid using the underwater pool light out of the water for more than 2 minutes.
The underwater pool light is protected by a temperature sensor against over-heating.
When the temperature of the underwater pool light exceeds 85°C the underwater pool light
is automatically switched off.
Wall preparation
The underwater pool light is recommended to be installed around 0.2 m below the waterline for the best
illumination and to avoid over-heating.
To fix the underwater pool light with screws 5.5x38 the diameter of holes drilled into the wall has to be 8 mm.
The diameter of the hole for cable gland drilled through the wall has to be 8 mm.
Sealing
Before inserting the cable with gland through the hole the sealant has to be used into the grooves, around the
four fixing holes and around the gland in the rear surface of the underwater pool light.
The sealant can be on silicon basis but the best solution is two-component polymer sealant.
Fixing
The underwater light has to be fixed with four screws 5.5x38 with wallplugs.
Note:
Do not overtighten the screws as this can result in underwater pool light damage.
4

5
METEOR 120-RGB
wire color
FUNCTION
Red + DC Power Supply
Black GND Power Supply
Orange + Control
Brown GND Control
Remote control connection
To control the mode of lighting the simple key-switch (not included) has to be used and connected to
the CONTROL wires by the 2-pole signal cable (not included).
CONTROLS
Remote control has to be used to turn-on and turn-off the underwater
pool light and to control the mode of lighting and luminosity.
The multi-color underwater pool light can be controlled by using the
key-switch.
When the light is turned-off the color or mode of lighting can be
changed sequentially by pressing the momentary switch for 2
seconds:
METEOR 120-RGB
Sequence of lighting
Custom Color
Full RGB
Cool White
Bluish White
Red
Green
Blue
Rainbow Color Spectrum
5
230V AC
Puls-dim
controller
LED 12-24V
Power-
Supply
Earthing
The underwater pool light has to be earthed by using a pre-tinned green wire with a yellow stripe a
minimum of 8 AWG (8.36 mm2). The wire has to be connected to the underwater pool light by the
help of one fixing screw 5.5x38.
Connection
The power supply has to be connected through the main switch (not included) with correct polarity
and protected by a fuse (not included). The power supply voltage has to be from 10 - 30Vdc.
Note:
The power supply has to be switched off before installation.
The underwater light has to be connected as described in the table below:

TECHNICAL SPECIFICATIONS
Power supply: 12 – 24 Vdc,
max. 1.4A@12 Vdc
max. 650 mA@24 Vdc
Advised Powersupply @12Vdc: PLN-60 (A9900351)
Advised Powersupply @24Vdc: PLN-60 (A9900361)
Lens angle: 60°
Optical window: High-grade
polycarbonate glass
Luminous flux: 1300 Lm
White color temperature: 3.000K
Operating temperature: -10°C - +50°C
Casing: Stainless steel (316L)
Protection: IP68
Dimensions: Ø119 x 9 mm
Weight: 0.6 kg
Design and specifications subject to change without notice.
6
Turning on /off
Press the key-switch momentary.
Changing the color or mode of lighting
When the light is turned-off press the key-switch for 2 seconds.
Setting the Custom Color
At the selected Rainbow Color Spectrum mode press the key-switch momentary to turn the light off.
After that press the key-switch for 5 seconds or until the light is switched to the selected color and
then the Custom Color is set and selected.
Dimming
When the light is turned-on press the key-switch until the desired illumination is achieved. By another
pressing of the key-switch the luminosity will increase to the maximum illumination.
Set default
Press the key switch for min. 40 seconds or until the light is turned off.
Synchronization
When more than one multi-color underwater pool light is connected to the system the optional
Synchronization Unit LSU08 is recommended to synchronize the colors of lighting at the Rainbow
Color Spectrum mode of lighting. On the other case the colors of all installed lights would not be the
same after few minutes or hours of operation in the Rainbow Color Spectrum mode.
If the multi-color light is used only with one of the fixed color of lighting the synchronization is not
necessary.
Highlite international BV
Vestastraat 2
NL 6468 EX Kerkrade
The Netherlands
ARTECTA Division
Phone: [phone]
Fax: [phone]
E-Mail: [email protected]

Name
Address
Highlite International BV
Vestastraat 2
6468EX Kerkrade
Supplier Details
Product Name
Ordercode
The Netherlands
Meteor-120 RGB
Product Details
Trade Name
A0620125
Artecta
1 EMC Di i 2004/108/EC
Applicable Standards Details
1. EMC Directives : 2004/108/EC
EN 55015: 2006+A1: 2007
EN 61547: 1995+A1: 2000+A2: 2009
EN 61547: 2009
2. Low Voltage Directives : 2006/95/EC
EN 60598-1: 2004+A1: 2006
Supplementary Information
The conformity to above standards is verified by Astel d.o.o..
Supplementary information
I hereby declare under our sole responsibility
that the product mentioned above to which this
declaration relates complies with the above mentioned
s t a n d a r d s a n d D i r e c t i v e s
Name Issued Date
Declaration
S. ildiz April 22, 2011
s t a n d a r d s a n d D i r e c t i v e s
Signature of representative
Highlite International BV.
Vestastraat 2, 6468 EX Kerkrade,
The Netherlands
DECLARATION OF CONFORMATY
7
