Artesyn MVME7616E Series Quick start guide

MVME7616E Transition Module
Installation and Use
P/N: 6806800A43F
May 2016

© Copyright 2016 Artesyn Embedded Technologies, Inc.
All rights reserved.
Trademarks
Artesyn Embedded Technologies, Artesyn and the Artesyn Embedded Technologies logo are trademarks and service marks of
Artesyn Embedded Technologies, Inc. All other names and logos referred to are trade names, trademarks, or registered trademarks
of their respective owners. © 2015 Artesyn Embedded Technologies, Inc. All rights reserved. For full legal terms and conditions,
please visit www.artesyn.com/legal.
Notice
While reasonable efforts have been made to assure the accuracy of this document, Artesyn assumes no liability resulting from any
omissions in this document, or from the use of the information obtained therein. Artesyn reserves the right to revise this document
and to make changes from time to time in the content hereof without obligation of Artesyn to notify any person of such revision or
changes.
Electronic versions of this material may be read online, downloaded for personal use, or referenced in another document as a URL to
an Artesyn website. The text itself may not be published commercially in print or electronic form, edited, translated, or otherwise
altered without the permission of Artesyn.
It is possible that this publication may contain reference to or information about Artesyn products (machines and programs),
programming, or services that are not available in your country. Such references or information must not be construed to mean that
Artesyn intends to announce such Artesyn products, programming, or services in your country.
Limited and Restricted Rights Legend
If the documentation contained herein is supplied, directly or indirectly, to the U.S. Government, the following notice shall apply
unless otherwise agreed to in writing by Artesyn.
Use, duplication, or disclosure by the Government is subject to restrictions as set forth in subparagraph (b)(3) of the Rights in
Technical Data clause at DFARS 252.227-7013 (Nov. 1995) and of the Rights in Noncommercial Computer Software and
Documentation clause at DFARS 252.227-7014 (Jun. 1995).
Contact Address
Artesyn Embedded Technologies Artesyn Embedded Technologies
Marketing Communications Lilienthalstr. 17-19
2900 S. Diablo Way, Suite 190 85579 Neubiberg/Munich
Tempe, Arizona 85282 Germany

Contents
MVME7616E Transition Module Installation and Use (6806800A43F) 3
About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.3 General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.4 Serial Port Interface Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.5 P2 Adapter Boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
1.6 Three-row P2 Adapter (MVME761-001) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1.7 Five-Row P2 Adapter (MVME761-011) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
1.8 Connectors and Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
1.9 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
1.10 Cooling Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
1.11 FCC Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2 Hardware Preparation and Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.2 Unpacking the Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.3 Installing the Serial Interface Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.4 Installing the Transition Module and P2 Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3 Functional Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.2 Circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.3 P2 Signal Multiplexing (P2MX) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
3.4 Serial Interface Module Circuitry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
3.5 COM1 and COM2 Asynchronous Serial Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
3.6 Asynchronous/Synchronous Serial Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
4 Connector Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4.2 P2 Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
4.3 Asynchronous Serial Port Connectors (J5/J6) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Contents

MVME7616E Transition Module Installation and Use (6806800A43F)
Contents
4
Contents
Contents
4.4 Asynchronous/Synchronous serial Port connectors (J7/J8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.5 Parallel I/O Port Connector (J4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4.6 Ethernet Connector (J9) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
4.7 P2 Adapter Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
4.7.1 3-Row P2 Adapter (J2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
4.7.2 3-Row P2 Adapter (J3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
4.7.3 5-Row P2 adapter (J1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
4.7.4 PMC I/O, 5-Row P2 Adapter (J3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
4.7.5 5-Row P2 adapter (J4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

List of Tables
MVME7616E Transition Module Installation and Use (6806800A43F) 5
Table 1-1 SIM Part Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Table 1-2 MVME761 Transition Module Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Table 1-3 3-Row P2 Adapter Connectors (MVME761-001) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Table 1-4 5-Row P2 Adapter Connectors (MVME761-011) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Table 1-5 Transition Module Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Table 1-6 MVME761-0x1 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Table 3-1 P2 signal multiplexing sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Table 4-1 P2 Connector Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Table 4-2 COM1 and COM2 Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Table 4-3 Serial Port 3 Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Table 4-4 Serial Port 4 Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Table 4-5 Parallel I/O Connector Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Table 4-6 10Base-T/100Base-TX Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Table 4-7 8-bit SCSI Connector (3-Row P2 adapter) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Table 4-8 VME Connector (3-Row P2 adapter) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Table 4-9 16-bit SCSI Connector (5-Row P2 adapter) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Table 4-10 PMC I/O Connector (5-Row P2 adapter) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Table 4-11 VME Connector (3-Row P2 adapter) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

MVME7616E Transition Module Installation and Use (6806800A43F)
6
List of Tables

List of Figures
MVME7616E Transition Module Installation and Use (6806800A43F) 7
Figure 1-1 RTM Front Panel and Components Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Figure 1-2 Three Row P2 Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Figure 1-3 Five Row P2 Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figure 2-1 Serial Port Interface Jumper Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Figure 2-2 SIM Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Figure 2-3 Installing the SIM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Figure 2-4 Chassis Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Figure 3-1 Transition Module Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Figure 3-2 3-Row DIN Backplane P2 Adapter Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Figure 3-3 5-Row DIN Backplane P2 Adapter Block Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Figure 3-4 Multiplex Signal Timing Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Figure 3-5 EIA-574 DTE Port Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Figure 3-6 EIA232-DCE Configuration Port 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Figure 3-7 EIA232-DCE Configuration Port 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Figure 3-8 EIA232-DTE Configuration Port 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Figure 3-9 EIA232-DTE Configuration Port 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

MVME7616E Transition Module Installation and Use (6806800A43F)
8
List of Figures

MVME7616E Transition Module Installation and Use (6806800A43F) 9
About this Manual
Overview of Contents
This manual is divided into the following chapters and appendices:
Chapter 1, General Information, on page 13
Chapter 2, Hardware Preparation and Installation, on page 21
Chapter 3, Functional Description, on page 27
Chapter 4, Connector Pin Assignments, on page 41
MVME7616E Transition Module Installation and Use provides general information, hardware
preparation, installation instructions and support information for the MVME7616E-001 and
MVME7616E-011 Transition Modules. These transition modules are used as the interface
between the variants of the MVME51005E and MVME55006E Single Board Computers. A P2
adapter module and cable are supplied with the MVME7616E. The MVME7616E will hereafter
be referred to as the MVME761.
As of the printing date of this manual, these I/O module models are available:
Model Number Description
MVME7616E-001
MVME7616E-011
3-Row Rear Transition Module and P2 Adaptor
5-Row Rear Transition Module and P2 Adaptor
MVME761P26E-001
MVME761P2-6E011
3-Row, P2 Adapter Module Only
5-Row, P2 Adapter Module Only
Related Product
MVME51005E
MVME51105E
MVME Series MVME51005E Single Board Computer
MVME55006E MVME Series MVME55006E Single Board Computer
IPMC7616E-001
IPMC7616E-002
Multifunction rear I/O PMC module; Ultra-Wide SCSI, one parallel port,
three asynchronous and one synchronous/asynchronous serial port
SIM232DCE5E
SIM232DTE5E
EIA232-DCE serial interface module
EIA232-DTE serial interface module

MVME7616E Transition Module Installation and Use (6806800A43F)
About this Manual
10
About this Manual
Abbreviations
This document uses the following abbreviations:
Abbreviation Description
CFM Cubic Feet per Minute
DCE Data Communications Equipment
DIN Deutsches Insitut für Normung eV
DTE Data Terminal Equipment
EMI Electro-Magnetic Interference
ESD Electro-Static Discharge
FCC Federal Communications Commission
GND Ground
IC Integrated Circuit
IEEE Institute of Electrical and Electronics Engineers
PMC PCI Mezzanine Card
RF Radio Frequency
RTM Rear Transition Module
SCSI Small Computer System Interface
SIM Serial Interface Module
VME Versamodule Eurocard

About this Manual
MVME7616E Transition Module Installation and Use (6806800A43F) 11
Conventions
The following table describes the conventions used throughout this manual.
Notation Description
0x00000000 Typical notation for hexadecimal numbers (digits are
0 through F), for example used for addresses and
offsets
0b0000 Same for binary numbers (digits are 0 and 1)
bold Used to emphasize a word
Screen Used for on-screen output and code related elements
or commands in body text
Courier + Bold Used to characterize user input and to separate it
from system output
Reference Used for references and for table and figure
descriptions
File > Exit Notation for selecting a submenu
<text> Notation for variables and keys
[text] Notation for software buttons to click on the screen
and parameter description
... Repeated item for example node 1, node 2, ..., node
12
.
.
.
Omission of information from example/command
that is not necessary at the time being
.. Ranges, for example: 0..4 means one of the integers
0,1,2,3, and 4 (used in registers)
| Logical OR

MVME7616E Transition Module Installation and Use (6806800A43F)
About this Manual
12
About this Manual
Summary of Changes
This manual has been revised and replaces all prior editions.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury
Indicates a hazardous situation which, if not avoided,
may result in minor or moderate injury
Indicates a property damage message
No danger encountered. Pay attention to important
information
Notation Description
Part Number Publication Date Description
6806800A43F May 2016 Removed Declaration of Conformity.
6806800A43E February 2016 Added Declaration of Conformity in
Chapter 1, General Information on page 21.
6806800A43D April 2015 Re-branded to Artesyn template.
6806800A43C July 2009 Updated Table 1-6
6806800A43B August 2008 Updated to Emerson style.
6806800A43A June 2006 First edition.

Chapter 1
MVME7616E Transition Module Installation and Use (6806800A43F) 13
General Information
1.1 Overview
This manual provides general information, hardware preparation, installation instructions, and
a functional description for the MVME761-001 and MVME761-011 Transition Modules.
The MVME761-0x1Transition Module provides the interface between the MVME5100 or
MVME5500
Single Board Computer VMEmodules and various peripheral devices. This module provides
industry standard connectors to simplify customer cable requirements for the serial port,
printer, and Ethernet signals.
1.2 Features
The features of the MVME761-0x1 Transition Module include:
Industry-standard connectors for these interfaces:
– Two EIA-574 asynchronous serial ports (DTE)
– Two asynchronous/synchronous serial ports, configured for EIA-232-D (DCE or DTE)
– One parallel port (IEEE Standard 1284-I compliant)
– 10Base-T/100Base-TX Ethernet
Two 60-pin Serial Interface Module (SIM) connectors for configuring the
asynchronous/synchronous serial ports
Single-width board
Electro-Magnetic Interference (EMI) and Electro-Static Discharge (ESD) protection
1.3 General Description
The MVME761-0x1 Transition Module provides the interface between the standard Ethernet,
parallel port, and the serial port connectors on a variety of single board computers. All port I/O
controllers reside on the host VMEmodules. The MVME761 transition module Ethernet and
parallel port circuitry is passive. The serial port circuitry provides multiplexing and buffering
functions (refer to P2 Signal Multiplexing (P2MX) on page 29). The multiplexing function is
transparent to the user.

General Information
MVME7616E Transition Module Installation and Use (6806800A43F)
14
Both MVME761-0x1 models use the same transition module. The MVME761-001 comes with
a P2 adapter that connects to a 3-row DIN chassis backplane. The MVME761-011 comes with a
P2 adapter that connects to a 5-row DIN chassis backplane.
Figure 1-1 shows the MVME761 transition module component layout and the front panel. See
Table 1-2 for a list of the front panel port connectors.
Figure 1-1 RTM Front Panel and Components Side

General Information
MVME7616E Transition Module Installation and Use (6806800A43F) 15
1.4 Serial Port Interface Modules
You may configure the asynchronous/synchronous serial ports (ports 3 and 4) to the
appropriate interface by installing a Serial Interface Module (SIM). A SIM is a small “plug-in”
printed circuit board that converts the TTL-level synchronous or asynchronous port signals to
industry standard voltage levels used by the ports. The SIM contains the receiver and
transmitter circuits for converting the input and output signals of the host VMEmodule to the
appropriate serial data communication protocol.
The SIMs for the MVME761 are listed in the following table.
Additional SIMs may be released. Please see your Artesyn representative for a complete list of
SIMS that are available for the MVME761-0x1.
1.5 P2 Adapter Boards
The P2 adapters route the asynchronous and synchronous port, printer port, and Ethernet
signals to the MVME761 transition module.
Table 1-1 SIM Part Numbers
Interface Model Number Part Number
EIA-232-D DCE SIM232DCE5E 01-W3876B11A
EIA-232-D DTE SIM232DTE5E 01-W3877B11A

General Information
MVME7616E Transition Module Installation and Use (6806800A43F)
16
1.6 Three-row P2 Adapter (MVME761-001)
The P2 adapter for the MVME761-001 mounts onto a 3-row, 96-pin P2 backplane connector.
The 50-pin male connector, J2, carries the 8-bit SCSI signals from the host VMEmodules. To run
SCSI devices, you may install an additional transition module that is equipped with a SCSI port,
such as the MVME712B.
This P2 adapter, and the cable for connecting to the MVME761 transition module, can be
ordered separately as model MVME761P2-001.
Figure 1-2 Three Row P2 Adapter
C
B
A
2
1
J1
J2
1933 9610
J3
2
1
1
64
63
50
49
++
R1
C1
U1
9
25
17
CR1
R2
C2 C3
C4
C5
U2
C6
C7
P1
C
B
A
132

General Information
MVME7616E Transition Module Installation and Use (6806800A43F) 17
1.7 Five-Row P2 Adapter (MVME761-011)
The P2 adapter for the MVME761-011 mounts onto a 5-row, 160-pin P2 backplane connector.
The 68- pin female connector, J1, carries 16-bit SCSI signals from the host VMEmodules. It also
has a 64-pin male connector, J3, for PMC I/O.
This P2 adapter, and the cable for connecting to the MVME761 transition module, can be
ordered separately as model MVME761P2-011.
1.8 Connectors and Cables
The connectors on the MVME761 transition module and the P2 adapters are listed in the
following tables. The port connectors are located on the front panel, which is shown in Figure
1-1. See Table 1-5 on page 19 for a list of the cables. See Chapter 4, Connector Pin Assignments.
The cable used for connecting the MVME761 transition module to the P2 adapter is provided
with the MVME761-0x1
Figure 1-3 Five Row P2 Adapter
J5
2
1
1
64
63
+
U1
9
25
17
CR1
R4
C8
C9
U3
P1
132
2
1
64
63
J1
J3
J4
1
U2
9
25
17
+
133
D
C
B
A
Z
D
C
B
A
Z

General Information
MVME7616E Transition Module Installation and Use (6806800A43F)
18
1. You will need to purchase or fabricate the port cables.
Table 1-2 MVME761 Transition Module Connectors
Type Number Description
COM1 and
COM2
J5
J6
9-pin male DIN asynchronous serial port connector
Serial port 3
Serial port 4
J7
J8
26-pin female HD-26 synchronous serial port
connector
Parallel port J4 36-pin female parallel port connector
10Base-T,
100Base-TX
J9 8-pin female RJ-45 Ethernet port connector
SIM J1, J12 60-pin female connector
VME P2 64-pin male connector to J2 on the P2 adapter
Table 1-3 3-Row P2 Adapter Connectors (MVME761-001)
Type Number Description
VME P1 96-pin female DIN 41612 connector to the chassis backplane
J3 64-pin male connector for output to P2 on the MVME761 transition
module
SCSI J2 50-pin male IDC connector for internal SCSI devices
Table 1-4 5-Row P2 Adapter Connectors (MVME761-011)
Type Number Description
VME P1 160-pin female DIN 41612 connector to the chassis backplane
J4 64-pin male connector for output to P2 on the MVME761
transition module
PMC I/O J3 64-pin male connector for PMC I/O
SCSI J1 68-pin female IDC connector for internal SCSI devices

General Information
MVME7616E Transition Module Installation and Use (6806800A43F) 19
1.9 Specifications
The MVME761 transition module specifications are shown in the next table.
Table 1-5 Transition Module Cables
Part Number Description
Included with the
MVME761-0x1
64-line flat ribbon cable with 96-pin DIN connectors that connects P2
on the MVME761transition module to J3 on the 3-row P2 Adapter or J4
on the 5-row P2 adapter; 13 inches long. (30-W2799B02A).
User-supplied EIA-232-D DTE or DCE cable (pins used depend on the processor
VMEmodule)
User-supplied Centronics- type parallel printer cable, male-to-male
User-supplied 20-conductor cable; usually supplied with the modem
User-supplied 6-conductor cable; usually supplied with the modem
CBL761HD26DB25 Straight-through adapter cable with male HD-26 connector and female
DB-25 connector, 3 feet long. (30-NW9302B27)
If you supply your own 64-line cable to connect the P2 adapter to the MVME761 transition module, the
cable should not be longer than 1.5 feet. A longer cable is likely to cause problems, especially for the
Ethernet and parallel port signals.
Table 1-6 MVME761-0x1 Specifications
Characteristics Specifications
Power Requirements +12 Vdc, 100 mA typical, 200 mA maximum
-12 Vdc, 100 mA (for some of the SIMs)
Operating temperature 0oto 55oC at chassis point of entry of forced air
(approximately 5 CFM)
Storage temperature -40oto +85oC
Relative Humidity 5% to 90% (non-condensing)

General Information
MVME7616E Transition Module Installation and Use (6806800A43F)
20
1.10 Cooling Requirements
The MVME761-0x1 is tested to operate under forced air cooling with an incoming air
temperature range of 0 degrees C to 55 degrees C. Adequate cooling can be achieved with air
flowing over the module at 5 cubic feet per minute. The exact amount of airflow required for
cooling depends on the ambient air temperature and the type, number, and location of
modules and other heat sources.
1.11 FCC Compliance
The MVME761-0x1 was tested in an FCC-compliant chassis, and meets the requirements for
Class A equipment. For minimum RF emissions, it is essential that you implement the following
conditions:
Install shielded cables on all external I/O ports
Connect conductive chassis rails to earth ground to provide a path for connecting shields
to earth ground
Tighten all front panel screws
Board Size
(excluding front panel)
Height: 9.187 inches(233.35 mm)
Height: 3.200 inches(80.00 mm)
Thickness: 0.063 inches (1.60 mm)
MVME761P26E-001: 1.85" deep, 3.75" high
MVME761026E-011: 2.725"1deep, 3.75" high
1. J2 extends 1/4" further from the edge of the board.
Table 1-6 MVME761-0x1 Specifications (continued)
Characteristics Specifications
