Ascon tecnologic KM1E User manual

WINE CONTROLLER
1/16 DIN - 48 x 48
Model KM1E
Quick Guide •ISTR-FKM1E-ENG01
viale Indipendenza 56, 27029 - Vigevano (PV) - ITALY
Tel.: [phone], Fax: [phone]
internet site: www.ascontecnologic.com
E-mail: [email protected]
ube
DECLARATION OF CONFORMITY AND
MANUAL RETRIEVAL
KM1E is a panel mounting, Class II instrument. It has been
designed with compliance to the European Directives.
All information about the controller use can be found in the
Engineering Manual: ISTR-MKM_-ENG0x (“x” is the revision).
The Declaration of Conformity and the manual of the controller
can be downloaded (free of charge) from the web-site:
www.ascontecnologic.com
Once connected to the web-site, search: KM1E
then click on KM1E.
In the lower part of the product page (in any language) is present
the download area with links to the documents available for the
controller (in the available languages).
Warning!
- Whenever a failure or a malfunction of the device may cause
dangerous situations for persons, things or animals, please
remember that the plant must be equipped with additional
devices which will guarantee safety.
-
We warrant that the products will be free from defects in material and
workmanship for 18 months from the date of delivery. Products
and components that are subject to wear due to conditions of
use, service life and misuse are not covered by this warranty.
Disposal
The appliance (or the product) must be disposed of
separately in compliance with the local standards in
force on waste disposal.
KM1E
Process Value
(in eng. units)
Set Point
(auto mode)
Output Value
(manual mode)
Param. value or
State/Function
(Editing mode)
Output
LEDs
Manual
mode
Alarm
active
Unit
(°C/°F) Autotune
in progress
(flashing)
DISPLAY AND KEYS
Access to:
- Setpoint adjustment
(SP display)
- Setpoint validation
Increase the displayed
value
Decrease the displayed
value
Back to Operator mode
(long pressure)
Displays the previous parameter
in Control mode (short pressure)
Access to:
Control mode toggle
(Heat/Cool) (pressed for
more than 1 s)
Access to:
- Setpoint adjustment
Access to:
- Setpoint adjustment
Operator Mode Control Mode
Confirm and go to
Next parameter
MODEL CODE
The Hardware resources are identified by the following Model Code.
KM1E A B C D E F G H
Model:
RS485
DI1
OP3
OP2
OP1
OP4
(note)
DI2 (note)
Analogue input
mA
Note: Terminal 4 can be programmed as:
- Digital Input (DI2) connecting a free of
voltage contact between terminals 4 and 16;
- 0... 12 V SSR Drive Output (OP4) connecting
the load between terminals 4 and 16;
- 12 Vdc (20 mA) transmitter power supply
connecting the 2 wire transmitter between
terminals 4 and 1; for 3 wire transmitter connect
terminal 4 to transmitter power supply input and
terminal 1 and 2 to transmitter signal output.
Neutral
Line
12 VDC
(note)
PV
4... 20 mA
3 wire transmitter
12 VDC
(note)
PV
Pt100Pt1000/NTC/PTC
4... 20 mA
2 wire transmitter
100... 240 Vac/
18... 28 Vac/
20... 30 Vdc
Power
supply
TERMINALS
Pin connector
q1.4 mm max.
(0.055 in.)
Stripped wire
L: 5.5 mm
(0.21 in.)
L
ELECTRICAL CONNECTIONS
MOUNTING
2
2
1
1
3
DIMENSIONS
Overall dimensions (L x H x Dmax.): 48 x 48 x 73... 99 mm
(1.89 x 1.89 x 2.78... 3.89 in.)
Panel Cut-out (L x H): 45+0.6 x 45+0.6 mm
(1.78+0.023 x 1.78+0.023 in.)
KM1E KM1E KM1E
KM1E KM1E
KM1E
KM1E
2 s Press for 2 seconds
on the key
PARAMETERS SETTING
CONTROLLER DISPLAY
Increases the displayed value
Confirm value and pass to the next parameter
Decreases the displayed value
Parameter setting
To exit the parameters configuration procedure, press
for 3 seconds or wait for the end of the delay
(about 10 seconds)
The KM1E-xDRRRDxx controller is pre-configured (default
configuration) for wine applications where there is the
need to cool or reheat in thermostatic mode (on/off with
hysteresis) a tank with a PT100 probe in mono relay
output (Heat and Cool on OP1).
Heat mode
The controller action type can be identified by the color of the upper display (measurement):
Red: Heat mode only
Green: Cool mode only
Orange:The controller responds to temperature changes and selects the appropriate control mode
by operating the appropriate control output and displaying the setpoint to be reached.
The numbered red LEDs indicate, when lighted, the active (on) state of the corresponding relay output.
Cool mode Automatic Heat/Cool
selection
Line KME
Power Supply B
24Vac (-25... +12%) or 24Vdc (-15... +25%) L
100... 240 Vac (-15... +10%) H
Input + Ditigal input1 C
PT100, PT1000, mA + Digital Input 1 D
PTC, NTC, mA + Digital Input 1 P
Output OP1 (control output) D
Relay (1 SPST NO, 4 A/250 Vac) R
Output OP2 (control output) E
None -
Relay SPST NO 2 A/250 Vac (resistive load) R
Output OP3 (alarm output) F
None -
Relay SPST NO 2 A/250 Vac (resistive load) selectable if Output 1 is present R
Output OP4 (configurable) G
Digital I/O (see the Electrical Connections paragraph for details) D
Serial Communications H
TTL Modbus -
RS485 Modbus S
Terminal Type I
Standard (screw type non removable terminal blocks) -
With plug-in screw type terminal blocks E
With plug-in clamp type terminal blocks M
With plug-in terminal blocks (fixed part only) N
Model Code example: KM1E-LDRRRD-E
KM1E controller for Wine applications
- Power supply: 24Vac/dc,
- Inputs: PT1000 or 4... 20 mA +1 Digital Input,
- 3 Relay Outputs (OP1: Alarm, OP2: Cold, OP3 Alarme),
- Confiigurable OP4: Digital Input 2 or Transmitter power supply,
- TTL Port,
- Removable screw type terminals.
Parameters List (PASS: 30)
Group Param. Description Value range or selection list Default User
selection Note
inp
node Control mode selection 1 Heat or Cool on OP1 only,
2 Heat (OP1) or Cool (OP2),
3 Heat (OP1) and Cool (OP2), 1
When only 1 output is
present, the controller
does not display the
node parameter.
It is fixed on “Mode 1”
sEns Measurement input type Pt1 Pt100
Pt10 Pt1000
4.20 4… 20 mA Pt1
dp Decimal point position 0... 2 0
diF1 Digital input 1 function Stby Mode Standby (transition)
Stby2 Mode Standby (status)
HC.tr Chaud <-> Froid (transition)
HC.St Chaud <-> Froid (status)
nonE
diF2 Digital input 2 function nonE
di.a Digital Inputs Action 0... 3 0 See the manual for
details
Pan usrb Key function
Stby Standby Mode
1H2C Heat <-> Cool toggle
HC.Sb Heat <-> Cool and
Auto <-> Standby
Auto
If HC.Sb: a 1 s pressure
toggles between
Heat <-> Cool mode.
A 5 s pressure puts the
controller in standby
ser
Add Modbus address of the controller 1... 254 1 Modbus RTU slave
Protocol
bAud Modbus transmission speed 1200, 2400, 9600 baud,
19.2, 38.4 kbaud 9600
Several successive pressures on the key allow the various groups of parameters to be scrolled.
A long pressure on the key allows to exit the Configuration mode and return to the Operator mode
Parameters List (PASS: 20)
Param. Description Value range or selection list Default User
selection Note
OPEr Operative mode selection reg Auto,
stdy Standby reg stdy: Control action stopped reg: Control action running
SP Set point 1 -1999... +9999 (Engineering Unit) 0
SP2 Set point 2 -1999... +9999 (Engineering Unit) 0
HstH Heat Hysteresis 0... 9999 (Engineering Unit) 1
HstC Cool Hysteresis 0... 9999 (Engineering Unit) 1
AL1 Alarm 1 threshold (Low) AL1L... AL1H 0
AL2 Alarm 2 threshold (High) AL2L... AL2H 80
dP Decimal point position 0... 2 0
SPLL Setpoint Low Limit From 0 to the SPHL value 0
SPHL Setpoint High Limit From the value of SPLL to 1999 90
FiL Digital filter on the measured value 0 oFF
0.1... 20.0 s 1.0
HAL1 Alarm 1 Hysteresis 0...9999 (Engineering Unit) 1
HAL2 Alarm 2 Hysteresis 0...9999 (Engineering Unit) 1
Al.o Adjust Low Offset -300…+300 (Engineering Unit) 0
Note: Several successive pressures on the key allow to scroll the available Control parameters.
m Pressing no keys for 5 s, the controller automatically exits PASS20 menu and returns to the standard display and the current measurement.

KM1E KM1E KM1E
Set Point Change
Operative Set Point Modified Set Point
Press the key (3 s) or
wait for the 10s time out to
store the new Set Point
and return to Normal Mode
CONTROLLER OPERATION
or
The Setpoint temperature setting is made pressing for a long time on the arrow keys / , small changes are made
with short pressures on the arrow keys / or by pressing the key when the display shows SP.
Chenge the value with the arrow keys / , then validate the valueby pressing .
KM1E KM1E
KM1E
KM1E KM1E KM1E
KM1E
1 s
In 30, the navigation between the different groups is
carried out by means of the key . To access the
parameters of the selected group, press the key and
modify the value using the / keys. A brief pressure
on the key is used to exit the group, a long one to exit
the configuration menu.
The change of the control direction between heating and
cooling is done by pressing the key for at least 1 s.
The new mode is pointed out changing the main display
when this button is released.
Note: Active if USrb = 1H2C
Not active in Mode 3
(Automatic Heat ↔ Cool toggle)
Heat ↔ Cool mode
Control Mode Selection (PASS: 30)
Cool ModeHeat Mode
Heat or Cool with 1 relay Heat or Cool with 2 relays
Heat on OUT1
Cool on OUT2
Heat or Cool with 2 relays
Heat on OUT1
Cool on OUT2
 When only output 1
is present, the node
parameter is not
displayed and the
Control Mode is
forced to 1
KM1E KM1E
KM1E
Press the key or wait for the
timeout to store the new Setpoints
and return to Operator Mode
Separate Heating (SP) and Cooling (SP2) Setpoints
2 s
Heat
Setpoint change Cool Setpoint change
KM1E
KM1E KM1E KM1E
KM1E KM1E KM1E
Limits of the Setpoint values
Setting the lower limit of
the desired Setpoint
Validate the lower limit of
the desired Setpoint
Exit the setting mode
Setting the higher limit
of the desired Setpoint
Validate the higher limit
of the desired Setpoint
Exit the setting mode
2 s
KM1E KM1E KM1E KM1E
Heat output
Hysteresis in °C Cool output Hysteresis in °C
Setting the Hysteresis of Heat and Cool control outputs
2 s 2 s
KM1E KM1EKM1E KM1E
KM1E KM1E KM1E KM1E
Standby mode activation
at input state transition
The 1st contact closure
switches the controller
to Standby.
The 2nd one reactivates
the Automatic.
Standby mode activation
at input state change
The close contact switches
the controller to Standby.
The open contact
reactivates the Automatic.
Control mode selection
at input state transition
Each contact closure
reverses the control
mode and the
associated setpoint.
Control mode selection
at input state change
With the contact open
the controller is in HEAT
mode with SP.
With the contact close
the controller is in COOL
mode with SP2.
DI1/DI2 Digital Input functions (pass = 30)
2 s
or dif2or dif2or dif2or dif2
KM1E KM1E
KM1E KM1E
Low alarm
threshold in °C High alarm threshold in °C
Setting the temperature alarm thresholds
2 s 2 s
KM1E KM1E KM1E KM1E
Hysteresis of the
Low Alarm in °C Hysteresis of the High Alarm in °C
Setting the hysteresis of temperature alarms
2 s 2 s
KM1E
KM1E
KM1E KM1E KM1E
USrb Functions of the key (pAss 30)
KM1E
Standby mode activation
The 1st pressure switches
the controller to Standby.
The 2nd one reactivates
the Automatic.
Heat ↔ Cool selection
Heat with SP
or
Cool with SP2
(without Standby mode).
Heat or Cool or Standby
The short pressures change
the action Heat ↔ Cool.
The long pressures switch
the control Auto ↔ Standby.
2 s
To access the selected group
settings press the key .
With PASS = 30, the navigation
between the different groups is
carried out by means of the key .
To changhe the value press
the keys / . A short
pressure on the key allows
to exit the group; a long
pressure allows to exit the
configuration menu.
It is possible to reset the controller to factory parameters (default parameters).
To load the default parameter values, press the key for about 2 to display
PASS, set the PASS value to -481 and confirm with the key .
The device restarts in its initial configuration with the default settings shown in
the table at page 1.
RESET THE CONTROLLER TO FACTORY PARAMETERS
KM1E
2 s
