WinPAC-8000 Quick Start Guide
Version 1.0.3, October 2009
Congratulations on purchasing Win PAC-8000 - the most popular automation solution
for remote monitoring and control application. This Quick Start Guide will provide
information needed to get started with WinPAC. Please also consult the User Manual
for detailed information on the setup and use of Win PAC.
In addition to this guide, the package includes the following items:
Win PAC Module
1GB Micro SD card
Software Utility CD Screw Driver
WP-8141: 1 slot
WP-8441: 4 slots
WP-8841: 8 slots
(1C016)
2.4 mm
1
--------------------------------------------------------------------------------
Preparing for Start-up the WinPAC-8000
Power Supply: +10V ~ +30V/DC (Ex: DP-665):
http://www.icpdas.com/products/Accessories/power_supply/power_list.htm
2
---------------------------------------------
Configuring the boot mode
Make sure the rotary switch placed in
the “0” position.
•WinPAC-8000 Quick Start Guide
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

Copyright © 2009 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [email protected]
-2
WinPAC-8000 Quick Start Guide
3
--------------------------------------------------------------------------------
Setting up the power supply and other I/O devices
The diagram below shows the connections of WP-8141.
The diagram below shows the connections of WP-8441/WP-8841.
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

Copyright © 2009 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [email protected]
-3
WinPAC-8000 Quick Start Guide
4
--------------------------------------------------------------------------------
Start the WinPAC Utility to manage the Win PAC
The WinPAC Utility is a toolkit used to quickly control and manage the Win PAC.
Step 1: Run the WinPAC Utility
located on desktop
Step 2: Configure IP(DHCP), FTP Server,
Auto Execution…, etc
Step 3: Save and Reboot
5
--------------------------------------------------------------------------------
Inserting and Wiring the I/O modules
Only high profile I-8K and I-87K
series modules can be plugged.
For more information about
this expansion I/O modules,
please refer to
CD:\NAPDOS\io_module\
http://www.icpdas.com/products/PAC/winpac/IO_Expansion.htm
6
--------------------------------------------------------------------------------
Start the DCON Utility to configure I-87K modules
DCON Utility is a tool kit used to quickly control and manage I-87K series expansion
I/O modules.
Step 1: Run the DCON firmware on the Win PAC
The DCON firmware is located at:
\System_Disk\tools\DCON_CE\
ГК Атлант Инжиниринг – официальный представитель вРФ иСНГ
[phone] [email protected] www.bbrc.ru

Copyright © 2009 ICP DAS Co., Ltd. All Rights Reserved. E-mail: [email protected]
-4
WinPAC-8000 Quick Start Guide
Step 2: Run the DCON Utility on the host PC
The DCON Utility can be obtained from:
CD:\Napdos\wp-8x4x_ce50\PC_Tools\DCON_Utility\
http://ftp.icpdas.com/pub/cd/winpac/napdos/wp-8x4x_ce50/pc_tools/dcon_utility/
Step 3: Click the WIN CE button
Step 4: On the WINCE device connection, enter the IP address of the Win PAC to
search the I-87K series expansion I/O modules
Step 5: It will display a list of
I-87K series expansion
I/O modules, then select
the module name that you
want to configure
WinPAC 8000 User Manual
CD:\Napdos\wp-8x4x_ce50\Document\
http://ftp.icpdas.com/pub/cd/winpac/napdos/wp-8x4x_ce50/document/
WinPAC 8000 Demo References
CD:\NAPDOS\wp-8x4x_ce50\Demo\
http://ftp.icpdas.com/pub/cd/winpac/napdos/wp-8x4x_ce50/demo/
DCON User Manual
CD:\NAPDOS\wp-8x4x_ce50\PC_Tools\DCON_Utility\Manual\
http://ftp.icpdas.com/pub/cd/winpac/napdos/wp-8x4x_ce50/PC_To
ols/DCON_Utility/Manual/
WinPAC Website
http://www.icpdas.com/products/PAC/winpac/introduction.htm/
Technical Support
