Ascon tecnologic e30V User manual

Ascon Tecnologic - e30V - OPERATING INSTRUCTIONS - PAG. 1
e30V
DIGITAL
ELECTRONIC
THERMOMETER
OPERATING INSTRUCTIONS
18/01 - code: ISTR_M_e30V_E_01_--
ASCON TECNOLOGIC S.rl.
Viale Indipendenza 56, 27029 - VIGEVANO (PV) ITALY
Tel.: [phone] - Fax: [phone]
http:\\www.ascontecnologic.com
[email protected]
PREFACE
 This manual contains the information necessary for
the product to be installed correctly and also instruc-
tions for its maintenance and use; we therefore recom-
mend that the utmost attention is paid to the following
instructions and to save it.
This document is the exclusive property of Ascon Tecnologic
S.rl. which forbids any reproduction and divulgation, even
partially, of the document, unless expressly authorized.
Ascon Tecnologic S.rl. reserves the right to make any formal
or functional changes at any moment and without any notice.
Ascon Tecnologic S.rl. and its legal representatives do not
assume any responsibility for any damage to people, things
or animals deriving from violation, wrong or improper use or
in any case not in compliance with the instrument features.
 Whenever a failure or a malfunction of the device
may cause dangerous situations for persons, thing
or animals, please remember that the plant has to be
equipped with additional electromechanical devices
which will guarantee safety.
1. INSTRUMENT DESCRIPTION
1.1 General description
The E30V model is a digital microprocessor electronic ther-
mometer with NTC input probes equipped with functions for
temperature alarms.
The instrument is available with a keyboard or without a
keyboard (in this case, any parameter programming can only
take place via device A01).
1.2 Front panel pescription
P
U
e30V
1
2
3
4
5
6
1. :Pressed for 5 s allows to access the parameters
programming the functions. In programming mode is
used to enter the parameter edit mode and confirm the
values. In programming mode can be used together
with the key to change the programming level of the
parameters.
2. :In programming mode is used for decreasing the
values to be set and for selecting the parameters..
Index
1. Instrument description ............................................... 1
1.1 General description........................................................... 1
1.2 Front panel pescription ..................................................... 1
2. Programming ............................................................... 2
2.1 Standard mode parameters programming ........................ 2
2.2 Parameter protection using the password......................... 2
2.3 Customized mode parameter programming
(parameters programming level) ....................................... 2
2.4 Reset parameters to default value .................................... 2
3. Usage warnings........................................................... 3
3.1 Admitted use..................................................................... 3
4. Installation warnings................................................... 3
4.1 Mechanical mounting........................................................ 3
4.2 Dimensions [mm] .............................................................. 3
4.3 Electrical connections ....................................................... 4
5. Functions ..................................................................... 4
5.1 Measure and display configuration ................................... 4
5.2 Alarm functions ................................................................. 4
6. Accessories ................................................................. 5
6.1 Parameters configuration by “A01”.................................... 5
7. Programmable parameters table................................ 5
8. Problems, maintenance and warranty....................... 6
8.1 Notifications ...................................................................... 6
8.2 Cleaning............................................................................ 6
8.3 Warranty and Repairs ....................................................... 6
8.4 Disposal ............................................................................ 6
9. Technical data.............................................................. 6
9.1 Electrical characteristics ................................................... 6
9.2 Mechanical characteristics................................................ 6
9.3 Functional features ........................................................... 6
10. How to order ................................................................ 7

Ascon Tecnologic - e30V - OPERATING INSTRUCTIONS - PAG. 2
3. :In programming mode is used for increasing the
values to be set and for selecting the parameters. In
programming mode can be used together with key to
change parameters level.
4. : Pressed and released displays the limit temperatures
measured by the instrument (min: Lt and max.: Ht).
In programming mode is used to return to normal
operation.
5. LED dp: During the normal operation is the decimal
point. In programming mode, while the parameter code
is displayed, the dot indicates the parameter protection
level: not protected (lit up), protected (flashing) and
hidden (turned OFF).
6. LED :Indicates the alarm status: ON (lit),
OFF (turned OFF) or silenced (flashing).
2. PROGRAMMING
2.1 Standard mode parameters programming
To access the instrument function parameters when pass-
word protection is disabled, press the key and keep it
pressed for about 5 seconds, after which the display shows
the code that identifies the first programmable parameter
The desired parameter can be selected using the /keys,
then, pressing the key, the display shows the parameter
code alternated to its value that can be changed with the
and keys.
Once the desired value has been set, press the key
again: the new value is stored and the display shows only
the code of the selected parameter.
Pressing the and keys, it is possible to select another
parameter and change it as described.
To exit the programming mode, press no keys for about 30 s
or keep the key pressed for 2 s.
Previous
Param.
Normal mode
Parameters
(Program mode)
Set parameter
Next
Param.
2 s
5 s Increase
value
Decrease
value
-28.5
iup C1
2.2 Parameter protection using the password
The instrument has a parameter protection function using a
password that can be personalised through the tPP parameter
To protect the parameters, set the desired password number
at the parameter tPP.
When the protection is active, press the key to access
the parameters and keep it pressed for about 5 s, after which
the display shows r.p.
Press the key, the display shows 0.
Using the / keys, insert the programmed password
number and press the key again.
If the password is correct the instrument displays the code
of the first parameter at this point i possible to program the
instrument in the same way previously described.
The password protection can be disabled by setting tPP = oF.
Normal mode
2 s
5 s Increase
value
Decrease
value
-25.5
r.p 0 iup
Password
Request
Insert Correct
Password
Parameters
(Program mode)
Note: If the Password gets lost, just switch OFF then ON the
instrument, push key during the initial test keeping
it pressed for 5 s. In this way it is possible to access all
the parameters, verify and modify the parameter tPP.
2.3 Customized mode parameter programming
(parameters programming level)
By the instrument factory setting the password protection func-
tion affects all parameters. To make a parameter accessible
without having to enter the password when tPP password
protection is activate, use the procedure that follows:
–Enter the program mode using the tPP Password;
–Select the parameter that must be accessible (no pass-
word protection);
–Once a parameter is selected, if the dp LED flashes, the
parameter is programmable by entering the password (is
“protected”). If the dp LED is steady ON the parameter
is programmable without password (is “unprotected”).
–To change the parameter visibility, press the key and
keeping it pressed also press the button. The dp LED
changes its state indicating the new level of parameter acces-
sibility (ON = not protected; flashing = password protected).
In case some parameters are not protected, accessing
the the programming mode the display first shows the not
protected parameters, then the r.p parameter (through which
will be possible to access the “protected” parameters).
Normal mode
2 s
5 s
Increase
value
Decrease
value
-28.5
r.p
Previous
Param.
Not protected
parameters
Set Parameter
Password
request
Insert correct
password
Parameters
Program Mode
Next
Parameter
Increase
value
Decrease
value
AHA 35.0
0 iup
2.4 Reset parameters to default value
The instrument allows the reset of the parameters to values
programmed in factory as default
To restore the default parameters value set value -48 at r.p
password request Therefore, to make the reset to the default
parameters, enable the Password using the tPP parameter
so that the r.p setting is requested, at this point insert -48
instead of the programmed access password.
Once confirmed the password with the key the display
shows “---” for 2 s therefore the instrument resets all the
parameters to factory default setting.

Ascon Tecnologic - e30V - OPERATING INSTRUCTIONS - PAG. 3
3. USAGE WARNINGS
3.1 Admitted use
 The instrument has been projected and manufactured
as a measuring and control device to be used accord-
ing to EN60730-1 at altitudes operation below 2000 m.
Using the instrument for applications not expressly permitted
by the above mentioned rule must adopt all the necessary
protective measures.
The instrument MUST NOT BE USED in dangerous environ-
ments (flammable or explosive) without adequate protections.
The instrument used with NTC 103AT11 probe (identifiable
by the printed code “103AT-11” visible on the sensor part)
is compliant with standard EN 13485 (“Thermometers for
measuring the air and product temperature for the transport,
storage and distribution of chilled, frozen, deep-frozen/quick-
frozen food and ice cream”) with the following classification:
[EN13485 air, S, A, 2, -50°C +90°C]
Remember that the end user must periodically check and veri-
fy the thermometers in compliance with standard EN 13486.
The installer must ensure that the EMC rules are respected,
also after the instrument installation, if necessary using
proper filters.
4. INSTALLATION WARNINGS
4.1 Mechanical mounting
The instrument, in case 78 x 35 mm, is designed for flush-
in panel mounting. Make a 71 x 29 mm hole and insert the
instrument, fixing it with the provided special brackets.
We recommend that the gasket is mounted in order to obtain
the front protection degree as declared.
Avoid placing the instrument in environments with very high
humidity levels or dirt that may create condensation or intro-
duction of conductive substances into the instrument
Ensure adequate ventilation to the instrument and avoid
installation in containers that house devices which may
overheat or which may cause the instrument to function at a
higher temperature than the one permitted and declared.
Connect the instrument as far away as possible from sources
of electromagnetic disturbances such as motors, power re-
lays, relays, solenoid valves, etc..
4.2 Dimensions [mm]
4.2.1 Mechanical dimensions
P
U
e30V
28
12.2
14.5
8
63478
35
4.2.2 Panel cut-out
29 +0.6
71
+0.6
RECOMMENDED
PANEL CUTOUT
min. 12 mm
min. 15 mm
4.2.3 Mounting
Brackets
Panel + Gasket max. 2.5 mm
34

Ascon Tecnologic - e30V - OPERATING INSTRUCTIONS - PAG. 4
4.3 Electrical connections
Carry out the electrical wiring by connecting only one wire to
each terminal, according to the following diagram, checking
that the power supply is the same as that indicated on the
instrument and that the load current absorption is no higher
than the maximum electricity current permitted.
As the instrument is built-in equipment with permanent con-
nection inside housing, it is not equipped with either switches
or internal devices to protect against current overloads: the
installation will include an overload protection and a two-
phase circuit-breaker, placed as near as possible to the in-
strument and located in a position that can easily be reached
by the user and marked as instrument disconnecting device
which interrupts the power supply to the equipment
It is also recommended that the supply of all the electrical cir-
cuits connected to the instrument must be protect properly, us-
ing devices (ex. fuses) proportionate to the circulating currents.
It is strongly recommended that cables with proper insulation,
according to the working voltages and temperatures, be used.
Furthermore, the input cable of the probe has to be kept sepa-
rate from line voltage wiring. If the input cable of the probe is
screened, it has to be connected to the ground at only one side.
4.3.1 Electrical wiring diagram
Supply
1 32 4 56
INPUT
Pr1
5. FUNCTIONS
5.1 Measure and display configuration
With the iuP it is possible to select the temperature engi-
neering unit and the desired measure resolution (C0 = °C/1°;
C1 = °C/0.1°; F0 = °F/1°; F1 = °F/0.1°).
The instrument allows the measure calibration, which can
be used to recalibrate the instrument according to applica-
tion needs, The calibration is made by using parameters iC1
(input Pr1).
5.2 Alarm functions
The alarm conditions of the instrument are:
–Probe errors E1, -E1;
–Temperature alarms Hi and Lo;
The alarm functions act on the LED .
Any active alarm condition is signaled lighting up the LED ,
while the acknowledged alarm status is shown by flashing the
LED .
5.2.1 Temperature alarms
The temperature alarm works according to Pr1 probe
measurement, the alarm thresholds set at parameters AHA
(maximum alarm) and ALA (minimum alarm) and the relative
differential AAd.
The alarm intervention can be delayed by the time set at
parameter AAt.
AHA
SP
ALA
offoffoff ON ON
Hi Lo
Temp.
time
AL
AAd
AAd
Pr1
The maximum and minimum temperature alarms can be disa-
bled by setting the related parameters AHA and ALA = oF.

Ascon Tecnologic - e30V - OPERATING INSTRUCTIONS - PAG. 5
6. ACCESSORIES
The instrument is equipped with a 5-pole connector which
can be used to link some external accessories that allow to
perform some functions in “off-line” mode.
6.1 Parameters configuration by “A01”
The A01 device an be linked to the 5 poles connector to trans-
fer from and toward the instrument the functioning parameters.
This device it is mainly usable for the serial programming of
some instruments which need to have the same parameters
configuration or to keep a copy of the parameters setting of an
instrument and allow its rapid retransmission.
The same device allows to connect a PC via USB with which,
through the appropriate configuration software for “AT Univer-
salConf tools”, the operating parameters can be configured.
To use the A01 device with the e30V instrument, the A01 must
be correctly supplied.
AC supply
Supply adapter
12 VDC
Enter
PWS 12 V
A B C TTL
+-
USB to PC
USB
For additional info, please have a look at the “A01 instruc-
tion manual”.
7. PROGRAMMABLE PARAMETERS TABLE
Here below is a description of all the parameters available
on the instrument. Some of them may not be present, either
due to the fact they depend on the type of instrument or be-
cause they are automatically disabled as unnecessary.
Parameter Description Range Def. Note
1 iuP Unit of measurement and
resolution (decimal point)
C0 °C, resolution 1°;
F0 °F, resolution 1°;
C1 °C, resolution 0.1°;
F1 °F, resolution 0.1°.
C1
2 iFt Measurement filter oF ÷ 20.0 s 2.0
3 iC1 Pr1 Probe Calibration -30.0 ÷ +30.0°C/°F 0.0
4 AHA High temperature Alarm
threshold
oF Disabled;
-99.9 ÷ +999°C/°F. oF
5 ALA Low temperature Alarm
threshold
oF Disabled;
-99.9 ÷ +999°C/°F oF
6 AAd Temperature Alarms
Differential 0.0 ÷ 30.0°C/°F 1.0
7 AAt Temperature Alarms Delay oF Disabled;
0.01 ÷ 9.59 (min.s ) ÷ 99.5 (min.s x 10).
oF
8 tPP Password to Access
Parameter functions
oF Disabled;
001 ÷ 999. oF

Ascon Tecnologic - e30V - OPERATING INSTRUCTIONS - PAG. 6
8. PROBLEMS, MAINTENANCE AND WARRANTY
8.1 Notifications
8.1.1 Error messages
Error Reason Action
E1 -E1
The probe may be interrupted
(E) or in short circuit (-E) or
may measure a value outside
the range allowed
Check the probe connec-
tion with the instrument
and check that the probe
works correctly
epr Internal EEPROM memory
error Press
P
key
err Fatal memory error Replace the instrument or
ship to factory for repair
8.1.2 Other messages
Message Reason
Hi Maximum temperature alarm in progress
Lo Minimum temperature alarm in progress
8.2 Cleaning
We recommend cleaning of the instrument only with a slightly
wet cloth using water and not abrasive cleaners or solvents.
8.3 Warranty and Repairs
The instrument is under warranty against manufacturing flaws
or faulty material, that are found within 18 months from deliv-
ery date. The warranty is limited to repairs or to the replace-
ment of the instrument.
The eventual opening of the housing, the violation of the instru-
ment or the improper use and installation of the product will
bring about the immediate withdrawal of the warranty effects.
In the event of a faulty instrument, either within the period
of warranty, or further to its expiry, please contact our sales
department to obtain authorisation for sending the instrument
to our company.
The faulty product must be shipped to Ascon Tecnologic with
a detailed description of the faults found, without any fees or
charge for Ascon Tecnologic, except in the event of alternative
agreements.
8.4 Disposal
The appliance (or the product) must be
disposed of separately in compliance
with the local standards in force on
waste disposal.
9. TECHNICAL DATA
9.1 Electrical characteristics
Power supply: 230 VAC, 115 VAC, 24 VAC/VDC,
12 VAC/VDC ±10%;
AC frequency: 50/60 Hz;
Power consumption: about 2 VA;
Inputs: 1 input for NTC temperature probes (103AT-2, 10 kW
@ 25°C);
Overvoltage category: II;
Protection class: Class II;
Isolation: Reinforced insulation between the low voltage
parts (type C or D power supply) and front panel; Reinforced
insulation between the low voltage parts (type C or D power
supply) and the extra low voltage section (inputs); No isolation
between power supply (type F or L power supply) and input.
9.2 Mechanical characteristics
Housing: Self-extinguishing plastic, UL 94 V0;
Ball Pressure Test as described in EN60730: accessible
parts 75°C; support live parts 125°C;
Heat and fire resistance category: D;
Dimensions: 78 x 35 mm, depth 34 mm;
Weight: About 90 g;
Mounting: Incorporated flush in panel (thickness max. 2.5
mm) in a 71 x 29 mm hole;
Connections:
Inputs: Fixed or removable screw terminal block for
0.14 ÷ 1.5 mm2/AWG 28 ÷ 16 cables;
Power supply: Fixed or removable screw terminal block
for 0.2 ÷ 2.5 mm2/AWG 24 ÷ 14 cables;
Protection degree: IP65 mounted with gasket;
Pollution degree: 2;
Operating temperature: 0 ÷ 50°C;
Operating humidity: < 95 RH% with no condensation;
Storage temperature: -25 ÷ +60°C.
9.3 Functional features
Measurement range: NTC: -50 ÷ +109°C/-58 ÷ +228°F;
Display resolution: 1° or 0.1° (range -99.9 ÷ +99.9°);
Overall accuracy: ±(0.5% fs + 1 digit);
Sampling rate: 130 ms;
Display: 3 Digit Red (Blue optional), height 17.7 mm;
Software class and structure: Class A;
Compliance: Directive 2004/108/CE (EN55022: class B;
EN61000-4-2: 8kV air, 4kV cont.; EN61000-4-3: 10V/m;
EN61000-4-4: 2kV supply and relay outputs, 1kV inputs;
EN61000-4-5: supply 2kV com. mode, 1 kV\diff. mode;
EN61000-4-6: 3V),
Directive 2006/95/CE (EN 60730-1, EN 60730-2-9),
Control 37/2005/CE (EN13485 air, S, A, 2, -50°C +90°C with
probe NTC 103AT11).

Ascon Tecnologic - e30V - OPERATING INSTRUCTIONS - PAG. 7
10. HOW TO ORDER
MODEL
e30V = Instrument
a: POWER SUPPLY
D = 230 VAC
C = 115 VAC
L = 24 VAC/VDC
F = 12 VAC/VDC
b: NOT USED
d: DISPLAY
I = Red (standard)
C = Blue
c: TERMINALS
V = Screw terminals (standard)
E = Complete removable screw terminals
N = Removable screw terminals (fixed part only)
f, g: RESERVED CODES; hh, ii: SPECIAL CODES
cae30V bdefghh ii
e: Keyboard
W = With keys
X = With no keys

Ascon Tecnologic - e30V - OPERATING INSTRUCTIONS - PAG. 8
