Ascotel A150 User manual

Ascotel® IntelliGate® Communications Systems
A150
A300
2025
2045
2065
Office 60IP
User’s Guide
eud-0840_en.book Page 1 Wednesday, January 24, 2007 1:46 PM

Operating and Display Elements
2
Operating and Dis play Elements
n Operating elements
1
Display
Status display with symbols, current displays on telephone traffic, dis-
plays the available Foxkey functions.
2
Indicator LED
• Left LED flashes: Call.
• Right LED flashes: Voice Mail, message, or callback.
3Key block
Enters digits or letters.
4
Navigation key
Scrolls back and forth in a menu, opens or exits menus, navigates in
lists.
5Foxkey
Executes displayed function using the key.
6Correction key
Deletes the last character or goes back one step in the menu.
7Foxmenu
Opens the menu or calls up other Foxkey functions.
8
Absence key with LED
Preconfigured as call forwarding. The Absence key can be configured
as a function key or digit key.
1
2
3
7
4
6
16
14
15
8
910
11 12
13 17
5
*
c
eud-0840_en.book Page 2 Wednesday, January 24, 2007 1:46 PM

Operating and Display Elements
3
9Phone book key
Opens phone books.
10 Redialkey
Selects the phone numbers last dialled.
11 Microphone key
Switches handset microphone off/on.
12 Loudspeaker key
Open listening mode on/off.
13 Volume/cursor keys
Adjustsvolume.
14 Call key
Set up / answer a call.
15
End key
• Ends a call.
• Exits input without saving and goes back to the idle state.
16
Configurable Keys
Freely configurable as a number or function key:
• Number key with 2 storage locations: (1. Phone number: press once,
2nd phone number: Press twice).
• Function key: Activate / Deactivate function.
Configure key: press and hold down.
17
Write-on labels
Write-on labels for the configurable keys can be found as an electronic
document on the internet. You can fill out the fields directly on your PC
and then print out the labels. The internet address is listed on the last
page of this document.
eud-0840_en.book Page 3 Wednesday, January 24, 2007 1:46 PM

Operating and Display Elements
4
n Display symbols
More text information available
Fox (display symbol): Access to
the menu or the available
Foxkey functions
Other menu entries available Loudspeaker activated
Text mode activated Function activated
Entries on the call list Search mode
Microphone deactivated Activate discreet ringing
Forwarding activated New text messages
Call parked New Voice Mail
eud-0840_en.book Page 4 Wednesday, January 24, 2007 1:46 PM

Security
5
Security
n Safety Information
Failure to observe this information can be hazardous and infringe existing laws.
n User information
Your terminal has been supplied with a Quick User’s Guide, safety information and, where appli-
cable, with other terminal-specific information. You can also download these documents as a
complete User’s Guide from www.aastra.ch/docfinder. More information on your terminal can
be found at www.aastra.ch or in the documentation or your dealer’s homepage. It is your
responsibility to inform yourself about the scope of functions, operation and proper use of your
equipment.
• Check whether you have all the user information available on your terminal, whether it con-
forms to your terminal’s version and whether it is up to date.
• Read through the user information carefully before putting your terminal into operation.
• Store the user information within easy reach and refer to it whenever uncertainties arise in
connection with the use of the terminal.
• When handing over your terminal to others, make sure you enclose the relevant user infor-
mation.
Connections
Always plug the phone cable connectors into the appropriate sockets. Do not modify
the connections in any way.
Maintenance
Use original accessories only. Make sure all installation and repair work is carried out by
a specially qualified technician.
Always use a soft, moistened, or antistatic cloth to clean your phone. Do not use chem-
icals or other chemical products.
Environmental influences
Do not operate the phone outside the temperature range of +5 °C to approx. +40 °C.
Avoid direct sunlight and other sources of heat.
Protect your phone against the wet, excessive dust, corrosive liquids and steam.
Do not expose your phone to electromagnetic fields (electric motors, household appli-
ances). The speech quality could be affected. To prevent interference, avoid placing
your handset in the immediate vicinity of computers, radios, TV sets, VCRs, and other
telephone sets.
Disposal
Be sure to dispose of your phone and its packaging in an environmentally compatible
way; alternatively send it back to your supplier or servicing agent.
eud-0840_en.book Page 5 Wednesday, January 24, 2007 1:46 PM

Security
6
n Intended Purpose
This phone is part of the Ascotel® IntelliGate® communication system and is intended to be
operated on that system.
Ascotel® IntelliGate® is an open, modular and comprehensive communication system that com-
prises the IP-PBX (referred to in the end-user information as “the system”), a vast number of
expansion cards and modules, and a complete series of system terminals including IP system
terminals. The system and all its component parts were designed to cover in full all the telecom-
munication requirements of companies and organisations with a single user-friendly solution.
The individual components of the overall system are fully compatible and must not be used for
other purposes or replaced by third-party components (except when connecting other author-
ized networks, applications and terminals to the interfaces provided specifically for that pur-
pose).
n About this document
Document number: eud-0840
• Document version: 1.0
• Valid for systems upwards: I7.5
• © 01.2007
eud-0840_en.book Page 6 Wednesday, January 24, 2007 1:46 PM

Contents
7
Dialling and Phoning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
You Receive a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
You Want to Make a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Using the Display and Operating Elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Menu-Guided Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Supplementary features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Making and answering calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Using functions while in a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Organising absences from the desk. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Functions for special situations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Setting functions by remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .45
Personalizing Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Setting the Ringing Properties (Audio). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
General settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Protection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Phone Book Management. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Configuring Voice Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
Configuring Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Formulating Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57
Local settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
Further information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
Declaration Open Source Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Liability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
Installation and First-Time Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Equipment provided . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
Setting up and mounting the phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64
Connecting the phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Labelling Configurable Keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68
eud-0840_en.book Page 7 Wednesday, January 24, 2007 1:46 PM

8
Dialling and Phoning
The following sections explain how to make phone calls simply and the functions your phone offers
you whenever you receive a call.
You Receive a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
You Want to Make a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
eud-0840_en.book Page 8 Wednesday, January 24, 2007 1:46 PM

Dialling and Phoning
9
You Receive a Call
This section explains the procedure for answering a call.
n Answering a Call
Your phone is ringing and the indicator LED is flashing. To answer the call, proceed as follows:
n Ending a Call
You want to end the call.
After the call the call duration is indicated. Call charges are also displayed after any external call
which you initiated, provided your provider supports this function.
Pick up the handset.
Note:
If the caller's phone number is received, it is shown on the display. If the phone
number is stored in the private phone book or in the system, the display also
shows the corresponding name.
Put the handset on-hook.
eud-0840_en.book Page 9 Wednesday, January 24, 2007 1:46 PM

Dialling and Phoning
10
You Want to Make a Call
This section explains the different ways you can make a call with your phone.
n Dialling with the Phone Number
You want to call someone and key in that person's phone number.
With call preparation you can enter a phone number without it being dialled automatically, so
you have time to check the number and, if necessary, correct it. The number is not dialled until
you go off-hook, for example by picking up the handset.
n Dialling with Redial
You want to call a person you have already called.
In the last-number redial list your phone automatically stores the phone numbers of the per-
sons you have already called, complete with their names, where available. You can now call the
person in question using this last-number redial list.
Enter a phone number in call preparation.
Note:
You can use the Correction key to delete any incorrect character.
Pick up the handset.
ÞThe person is called.
Or:
Press the Call key or the Foxmenu > Foxkey Call.
ÞThe person is called.
Press the Redial key.
ÞThe first phone number on the last-number redial list is displayed.
Press the Redial key several times or press the down navigation key to scroll
through all the phone numbers you last dialled.
Pick up the handset.
ÞThe phone number displayed is dialled.
*
eud-0840_en.book Page 10 Wednesday, January 24, 2007 1:46 PM

Dialling and Phoning
11
n Using Your Phone in Open Listening Mode
You want other people in the room to be able to listen in to the call.
The open listening function lets you activate the loudspeaker in addition to the handset.
n Muting the Microphone
In the middle of a call you want to talk briefly with other persons in the room without your call
partner hearing your conversation.
You can switch the microphone on and off during a call.
During a call:
Press the Loudspeaker key.
ÞOpen listening is now activated, is displayed.
Note:
You can continue with the call as usual using the handset.
Deactivating open listening:
Press the Loudspeaker key a second time.
ÞOpen listening is now deactivated.
Note:
To end a call in open listening mode, you need to press the Loudspeaker key
and hang up the phone.
Switching the microphone off:
Press Microphone key.
ÞThe microphone is now deactivated, is displayed.
Switching the microphone back on:
Press the Microphone key once again.
eud-0840_en.book Page 11 Wednesday, January 24, 2007 1:46 PM

12
Using the Display and
Operating Elements
The following sections explain how to operate your phone quickly and simply.
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Menu-Guided Navigation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
eud-0840_en.book Page 12 Wednesday, January 24, 2007 1:46 PM

Using the Display and Operating Elements
13
Display
n Display symbols and display text
New events such as a call in your absence, a new message or activated functions (e.g. Forward-
ing) are signalled on the display in the idle state by a symbol or a display text. You can then use
the relevant Foxkey to call up the information.
Keys
n Pressing a Key
A key may have various functions depending on the situation and the operating mode. The
function activated depends on the number of times the key is pressed or whether it is pressed
quickly or held down for a moment. Here are some examples:
n Using the Foxmenu key
The Foxmenu key gives you access to the menu or the Foxkey functions available in each case.
Press the key directly on the Fox symbol
You have access to the menu or the Foxkey functions available in each case.
To see the rest of the text:
Press the horizontal navigation key.
End
Deleting the display text:
Foxmenu > Press the End Foxkey.
ÞThe display returns to the idle state; the function remains activated.
Function activated:
The activated function or selected setting is indicated by a check mark.
Press the Foxkey.
<long>
Keep the Foxkey held down for a moment (about 2 seconds).
<2x short>
Press the key twice in quick succession.
Pressing the Foxmenu:
In the idle state: Opens the menu.
In the menu/during a call: Retrieves available Foxkey functions.
Þis displayed.
eud-0840_en.book Page 13 Wednesday, January 24, 2007 1:46 PM

Using the Display and Operating Elements
14
n Using the Foxkey
The Foxkey has variable functions. These functions are displayed above the key.
Several contacts are stored under the broad Foxkey, which means you need to press the Foxkey
precisely under the function you want.
Input
n Enters digits
The digit keys are used to enter the digits 0 to 9.
n Enter the letters
You can also use the digit keys to enter letters and special characters. A number of letters and
special characters are assigned to each key.
To enter letters using the digit keys, you need to be in text mode. The text mode is activated
automatically if the phone is expecting a text input. You can switch back and forth between
number mode and letter mode during your input.
Press the Foxkey under the position where the display shows the function you
want.
abc-->123
Switching between number mode and letter mode during your input:
Foxmenu > Press Foxkey abc-->123 or 123-->abc.
Þis displayed.
eud-0840_en.book Page 14 Wednesday, January 24, 2007 1:46 PM

Using the Display and Operating Elements
15
n Digit keys
The characters are assigned to the digit keys as follows. Press the relevant digit key repeatedly
until the character you want is displayed:
n Switching between Upper and Lower Case
You want to switch between upper and lower case while making an input in text mode.
Upper-case input is automatically activated when the first letter is entered. The text mode then
automatically switches to lower-case input. You can use the Foxkey to switch manually between
upper-case and lower-case input.
n Correcting your Input
You notice you have entered a wrong digit or character. You can either delete the input one
character at a time or cancel the entire input.
- . ? 1 ! , : ; ’ " ¿ ¡ A B C 2 Ä Æ Å Ç
a b c 2 ä æ å à ç
D E F 3 É
d e f 3 é è ê
G H I 4
g h i 4 ì
J K L 5
j k l 5
M N O 6 Ñ Ö Ø
m n o 6 ñ ö ø ò
P Q R S 7
p q r s 7 ß
T U V 8 Ü
t u v 8 ü ù
W X Y Z 9
w x y z 9 + 0
@ * / ( ) < = > % £ $ € ¥ ª & § <Space> #
a>A
Switching between upper case and lower case in text mode:
Foxmenu > Press Foxkey a>A or A>a.
To delete the last character:
Press the correction key.
Note:
With the navigation key you can go straight to the character you want to
delete.
End input without saving:
Press the End key.
c
eud-0840_en.book Page 15 Wednesday, January 24, 2007 1:46 PM

Using the Display and Operating Elements
16
n Moving the Cursor
You want to go to a certain character for an input or correction.
With the navigation key you can move the cursor to the left or right.
Menu-Guided Navigation
n Accessing the menu
The phone is in standby mode:
n Navigating with the navigation key
You can retrieve a particular menu entry even more simply and efficiently using the navigation
key. You can scroll vertically and horizontally through the different menu entries.
Move the cursor with the horizontal navigation key.
Press the Foxmenu.
ÞThe menu is displayed.
Menu
Press the Menu Foxkey.
ÞThe first menu entry is displayed.
Use the vertical navigation key to scroll through the menu entries.
Selecting
Press the Foxkey.
ÞAccessing the displayed menu.
Horizontal navigation key:
Left: scrolls back through the menu.
Right: scrolls forward through the menu, opens displayed menu, retrieves
detailed information.
Vertical navigation key:
Bottom: scrolls downwards in the list.
Top: scrolls upwards in the list.
eud-0840_en.book Page 16 Wednesday, January 24, 2007 1:46 PM

Using the Display and Operating Elements
17
n Undoing Actions
To cancel operating steps, proceed as follows.
n Other navigation possibilities
n Resetting activated features
You can deactivate again all the activated functions (e.g. Forwarding, Barring).
Signals
n Indicator LED Signals
Depending on the situation the indicator LEDs either flash or remain steadily lit.
End input without saving:
Press the End key.
Back to the idle state in the menu:
Press the End key.
Scrolling back through the menu:
Press the correction key.
Menu
Press Foxmenu, then the Foxkey.
Activated features
Scroll to Activated features and press the Foxkey.
ÞAll the activated functions are now displayed.
Reset
Reset the function in question.
ÞThe function is now deactivated.
Left LED flashes:
ÞPhone is ringing.
Right LED flashes:
ÞNew Voice Mail, message, or callback received.
c
eud-0840_en.book Page 17 Wednesday, January 24, 2007 1:46 PM

18
Supplementary features
The following sections explain the supplementary features provided by your phone for more efficient
use.
Making and answering calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Using functions while in a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Organising absences from the desk. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Functions for special situations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Setting functions by remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
eud-0840_en.book Page 18 Wednesday, January 24, 2007 1:46 PM

Supplementary features
19
Making and answering calls
This section explains some convenient features provided by your phone for making a call.
n Dialling by Name - Quickdial
You want to make a call by entering a name.
With Quickdial you only need to press the digit keys for each letter once, even though each key
is assigned several letters. An efficient algorithm provides quick search results.
The surname and first name have to be separated by a space (# key), for example "no s" (6 6 # 7)
for Noble Stephen. Ask your system administrator whether you should start with the surname
or the first name.
Requirement: The name and the corresponding call number are stored in one of the system’s
phone book or in an external phone directory connected to the system.
Note:
To be able to search in an external phone book using Quick Dial, you need to press the *-key or 0-key
before entering the first letter.
Press each of the corresponding digit keys once for the first few letters of the
name you are looking for.
ÞFor each letter, the display shows the corresponding digit, for example a "6"
for the letter "n".
Press the phone book key.
ÞThe phone searches for matching names.
You may have to enter another letter before the name you want or a list of
names is displayed.
Scroll through the list until the subscriber you want is displayed.
Pick up the handset.
ÞThe phone number displayed is dialled.
*
*
eud-0840_en.book Page 19 Wednesday, January 24, 2007 1:46 PM

Supplementary features
20
n Dialling from the phone book
You want to search directly in one of the connected phone books.
The surname and first name have to be separated by a space, for example "no s" for Noble
Stephen. Ask your system administrator whether you should start with the surname or the first
name.
Press the phone book key.
Finding an entry
Scroll to Search entry and press the Foxkey.
If required, enter the first few letters of the name you are looking for (first name
and surname separated by a space) until the subscriber or a list is displayed.
Notes:
• Text mode is activated automatically.
• Use the #-key to enter spaces.
Scroll through the list until the subscriber you want is displayed.
Pick up the handset.
ÞThe phone number displayed is dialled.
Notes:
• The search function is not affected by upper/lower case and special charac-
ters.
• If the phone is unable to find a matching name, List empty will appear on the
display.
• To find out to create a new contact in your private phone book, refer to the
Chapter "Creating a New Phone Book Entry", 52.
*
eud-0840_en.book Page 20 Wednesday, January 24, 2007 1:46 PM
