Asko T754 User manual

Dear Customer,
Thank you for choosing this quality product from ASKO. We hope it will meet your
expectations and fulll your needs for many years to come. Scandinavian design
combines clean lines, everyday functionality, and high quality. These are key charac-
teristics of all our products and the reason they are greatly appreciated throughout
the world.
To ensure that you get the most out of your new machine, we recommend that you
read the operating instructions before using the machine. The operating instructions
also contain information on how to avoid damaging the environment.
Operating Instructions
Tumble dryer
ASKO T754 W
WARNING: Read the instructions before using the machine.

Before using your machine for the
rst time 3
Important safety instructions 4
Grounding instructions 5
Packing material 5
Disposal 5
Child safety 6
General 6
Description of the tumble dryer 7
Advice and tips before you tumble dry 8
Materials that can be tumble dried 8
Materials that should not be tumble dried 8
Static electricity 8
Operating instructions 9
Sort your fabrics 9
Press the main power switch until the display
lights. 9
Open the door, load the items, and then
close the door 9
Select the program 10
Selecting Options 12
Press the Start button 12
Drying program nished 13
Care and maintenance instructions 14
Cleaning the lint lter 14
Cleaning the outside of the machine 14
Troubleshooting 15
The machine will not start 15
The machine loses all power during a
program 15
Drying takes too long 15
Error messages 15
Technical information 16
Technical data 16
Service and guarantee 17
Before contacting the Customer Care
Center 18
Installation instructions 19
Positioning the tumble dryer 19
Adjusting the feet 21
Built-in 21
Air exhaust 22
Electrical installation 24
Reversing the door 28
Follow these instructions: 29
2Customer Care Center
1-800-898-1879
www.askona.com
Contents

3
Customer Care Center
1-800-898-1879
www.askona.com
Before using your machine for the rst time
Laundry labels
Certain materials are not suitable for tumble
drying. Always check and follow the instructions
on each item's laundry label. You can nd more
information in the Advice and tips before you
tumble dry chapter.
NOTE!
When starting the tumble dryer for the rst time
or after a long period without use, you may hear
a slight thumping noise. This noise is completely
normal and will disappear after a few loads.
Do you need this Use&Care Guide in Spanish? Log on to www.askona.com/customer-care to download.
¿Necesita esta Instrucciones de uso y cuidado en español? Entre en www.askona.com/customer-care.

4Customer Care Center
1-800-898-1879
www.askona.com
SAVE THESE INSTRUCTIONS FOR
FUTURE REFERENCE
WARNING!
WARNING - To reduce the risk of re, electric
shock, or injury to persons when using your
appliance, follow basic precautions, including
the following:
• Read all instructions before using the
appliance.
• Do not wash or dry articles that have been
previously cleaned in, washed in, soaked in, or
spotted with gasoline, dry-cleaning solvents,
cooking oils, other ammable or explosive
substances as they give o vapors that could
ignite or explode.
• Do not allow children to play on or in the
appliance. Children should be closely
supervised when near the appliance.
• Before the appliance is removed from service
or discarded, remove the door to the drying
compartment.
• Do not reach into the appliance if the drum is
moving.
• Do not install or store this appliance where it
will be exposed to the weather.
• Do not tamper with controls.
• Do not attempt to repair or replace any part of
the appliance or perform any servicing unless
specically recommended in this guide.
• Do not use fabric softeners or dryer sheets
unless the manufacturer gives written
assurance that the product will not damage a
tumble dryer.
• Do not heat dry items containing vinyl, plastic,
foam rubber or similarly textured rubberlike
materials, berglass, or wool unless the label
species “washable”.
• Clean the lint lter before or after each load.
• Keep the area around the exhaust opening
and adjacent surrounding areas free from the
accumulation of lint, dust and dirt.
• The interior of the machine should be cleaned
periodically by an authorized ASKO service
agent.
• Do not place items exposed to cooking oils in
your dryer. Items contaminated with cooking
oils may contribute to a chemical reaction that
could cause a load to catch re.
• Electrical installation, if required, must be
done by a licensed electrician.
• Do not operate appliance while away from
the home.
• Do not heat dry items that have been dry-
cleaned.
• The dryer is made and marked to facilitate
recycling. When it is no longer useful, contact
your local refuse collection service for advice
on how to properly dispose of the dryer for
purposes of recycling.
• Damaged power cables should only be
replaced by a certied professional.
• Provide sucient ventilation, otherwise smoke
from open res or fumes from equipment
burning other fuels can be drawn into the
room.
CAUTION!
During the program, the back of the dryer will get
very hot. Let the machine cool completely before
touching the back.
WARNING!
This appliance must be properly grounded.
Important safety instructions

5
Customer Care Center
1-800-898-1879
www.askona.com
Important safety instructions
Grounding instructions
A) Grounding instructions for a
grounded, cord-connected appliance
In the event of malfunction or breakdown,
grounding will reduce the risk of electric shock
by providing a path of least resistance for electric
current. This appliance (Canadian market only)
is equipped with a cord having an equipment-
grounding conductor and a grounding plug.
The plug must be plugged into an appropriate
outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
WARNING!
Improper connection of the equipment-
grounding conductor can result in a risk of
electric shock. Check with a qualied electrician
or service representative or personnel if you are
in doubt as to whether the appliance is properly
grounded. Do not modify the plug provided with
the appliance (Canadian market only). If it will not
t the outlet, have a proper outlet installed by a
qualied electrician.
To reduce the risk of re, this appliance must be
exhausted outdoors or the equivalent. Do not
exhaust into a chimney, wall, ceiling or concealed
space in a building.
B) Grounding instructions for a
permanently connected appliance:
This appliance must be connected to a
grounded metal, permanent wiring system, or
an equipment-grounding conductor must be run
with the circuit conductors and connected to the
equipment-grounding terminal or lead on the
appliance.
NOTE!
This manual does not cover every possible
condition and situation that may occur. Use
common sense and caution when installing,
operating, and maintaining any appliance.
Installation
See the section Installation instructions.
Packing material
Please sort waste materials in accordance with
local guidelines.
Disposal
This machine is manufactured and labeled for
recycling. In order to prevent personal injury, the
machine must be made inoperable after deciding
to take it out of service. Contact your municipality
for information about where and how your
machine can be recycled correctly.

6Customer Care Center
1-800-898-1879
www.askona.com
General
WARNING!
Do not allow children to play with
the tumble dryer.
• If the door is opened when a program is
running, the garments may be very hot, with a
risk of burn injuries.
• The tumble dryer does not start automatically
when the door is closed (if a child pulls the
door shut from the inside, for example).
Child safety

7
Customer Care Center
1-800-898-1879
www.askona.com
Description of the tumble dryer
1. Main power switch
2. Panel
3. Serial number tag and rating plate
4. Lint lter
5. Outer door
4 52
1 3

8Customer Care Center
1-800-898-1879
www.askona.com
Advice and tips before you tumble dry
Here are some tips that may help you before you
begin tumble drying.
Have the clothes been spun?
Items to be tumble dried should be spun at 1000
rpm or faster. Higher spin speeds save energy
and reduce drying time.
Materials that can be tumble dried
This symbol means that the material is
suitable for tumble drying. Fabrics best suited
to tumble drying are cotton fabrics, terry cloth,
and synthetic bers. Garments will be softer and
lighter when tumbled than when hung out to dry.
NOTE!
The tumble dryer does not cause any signicant
wear on fabrics. The lint trapped in the lint lter
consists of dust and ber residues formed when
the items are used.
Materials that should not be
tumble dried
This symbol means that the material is not
suitable for tumble drying. Certain materials may
melt or become a re hazard if exposed to heat
and others can lose their shape or shrink.
And do not tumble dry
• materials labeled "Do not dry near heat".
• garments that have been dry-cleaned at
home.
• plastic foam.
• berglass material.
• wool must not be tumble dried due to the risk
of piling.
Static electricity
To reduce the risk of static electricity in the
laundry after tumble drying, you can:
• Use fabric softener when washing.
• Wait ve minutes after the drying program
ends before opening the door and removing
the laundry from the dryer.
NOTE!
You can stop the tumble dryer by pressing the
Stop button for three seconds or by opening the
door. In both cases the program is stopped and
starts from the beginning if restarted.
If you do not want to restart the program,
immediately remove all laundry and spread it out
to allow the heat to dissipate.

9
Customer Care Center
1-800-898-1879
www.askona.com
WARNING!
To reduce the risk of electric shock or injury to
persons, read the "Important Safety Instructions"
section before operating this appliance.
Below are step-by-step instructions to help you
achieve the best possible tumble drying results.
1
Sort your fabrics
You will achieve the most uniform drying
results if the items are made of the
same type of material. Close zippers and fasten
buttons or belts; sort the items and adjust load
and temperature.
2
Press the main power switch
until the display lights.
3
Open the door, load the
items, and then close the
door
Operating instructions

10 Customer Care Center
1-800-898-1879
www.askona.com
4
Select the program
Operating instructions
Guidelines as to what specic
programs can be used for:
Auto Heavy
Program with the maximum temperature. This
program is for items that are particularly dicult
to dry, such as jeans with very thick seams.
NOTE!
Knitted fabrics in particular are prone to shrinkage.
Use the Auto Normal, Auto Delicate, or Auto Iron
Dry programs for these items. Stretch clothes
back into shape immediately after drying.
Auto Normal and Auto Delicate
These programs end automatically when the
load is dry. The Auto Normal program leaves the
laundry slightly more dry than Auto Delicate.
Auto Iron Dry
This program shuts o the heat once the load is
just damp enough for ironing or pressing.
Timed dry
The most suitable programme time depends
on what you intend to do with the items after
tumble-drying them. Use trial and error to nd
out what works best. When you use Timed dry
to tumble-dry a load of mixed fabrics, some of
the garments may remain damp. Tumble-dry any
damp garments for a further 30 minutes or so
using the Timed dry programme.
Select the desired time by pressing the Delayed
Start button. A programme time between 30
minutes and 3 hours can be selected and each
button press changes the time by 15 minutes.
NOTE!
When using the Timed dry programme with a
programme time that is too long, the garments
can become "over-dry". This can cause items
to shrink or crease and feel rough to the touch.
Synthetic materials can also become charged
with static electricity.
Air Flu
Use the Air Flu program when you just want to
refresh, air out, or soften up items.
Select the desired time by pressing the Delayed
Start button. A program time between 15 minutes
and 3 hours can be selected and each button
press changes the time by 15 minutes.
Select a program by turning the program selector. An LED lights next to the selected program. Use the
option buttons to select any options.
/
Program selector
Options buttons
Main power switch Display window
Start Stop

11
Customer Care Center
1-800-898-1879
www.askona.com
Operating instructions
Program chart
Here we present the energy and time consumption of a few dierent programs. The table shows the
eect of using dierent spin speeds when washing the load. Consumption can vary depending on room
temperature, humidity, load, variations in the power supply, and selected options.
For the consumption values given below, the requirements are as follows:
Temperature of intake air: 73 °F (23 °C)
Moisture content of intake air: 55 %
Drying temperature: Normal
Heater output: 3000W
Program Material Load Spin speed (rpm) Energy consumption,
approx. (kWh)
Program time,
approx. (min)
Auto Heavy Cotton, linen 1/1 800 rpm 4.0 1:40
1000 rpm 3.8 1:35
1400 rpm 3.3 1:25
1600 rpm 3.1 1:20
Auto Normal Cotton, linen 1/1 800 rpm 3.9 1:30
1000 rpm 3.6 1:25
1400 rpm 3.1 1:15
1600 rpm 2.9 1:10
Wrinkle-resistant, polyester/
cotton
1/2 1000 rpm 1.8 0:50
Auto Delicate Cotton, linen 1/1 800 rpm 3.8 1:25
1000 rpm1) 3.51 1:20
1400 rpm 2.8 1:10
1600 rpm 2.5 1:00
Wrinkle-resistant, polyester/
cotton
1/2 1000 rpm1) 1.30 0:35
Auto Iron Dry Cotton, linen 1/1 800 rpm 3.7 1:35
1000 rpm1) 3.03 1:25
1400 rpm 2.4 1:05
1600 rpm 2.0 0:50

12 Customer Care Center
1-800-898-1879
www.askona.com
Operating instructions
5
Selecting Options
By selecting options, you can tailor a
drying program to suit your requirements.
The available options depend on the selected
program. Once you have started the program,
the options you selected are saved for the next
time you use the same program.
Temperature Low
You can selectTemperature Low with all programs
except Air Flu .
• Select Temperature Low by pressing the
button next to the symbol.
• The lamp next to the button lights when
Temperature Low is selected.
Time saver
You can select Time saver with all programmes
except Revitalise. The programme is shortened
by about 12 minutes.
• Press the button next to the symbol.
• The lamp next to the button lights when
Temperature Saver is selected.
Anti Wrinkle
This option means that the drum will rotate for
three seconds per minute for two hours after the
drying program has nished. If you are unable to
remove the items immediately after the program
has nished, this option prevents the garments
from remaining in the same position and
becoming wrinkled. Cannot be selected with the
Air Flu program.
• Select Anti Wrinkle by pressing the button
next to the symbol.
• The lamp next to the button lights when Anti
Wrinkle is selected.
Delayed Start
Select a program and then press Delayed Start.
Press the button to select a delayed start of 1 to
24 hours.The lamp next to the button lights when
this option is activated. Next, press Start and the
machine will count down 1 hour at a time and
start after the selected delay. To cancel Delayed
Start, press and hold Stop for three seconds.
Delayed Start cannot be selected with Timed Dry
or Air Flu .
6Press the Start button
Remaining drying time
YAn estimate of the remaining drying
time will be shown on the display a few minutes
after the drying program starts. 1:35 means that
it will take approximately 1 hour and 35 minutes
for the load to dry.
The actual remaining time may be longer than
the estimated time shown on the display. The
remaining time is then shown as 0:15 until the
laundry is suciently dry. If you selected Time
saver, the display will show 0:05 instead.
You can stop the tumble dryer by pressing the
Stop button or by opening the door. In both
cases the program is stopped and starts from the
beginning if restarted.
NOTE!
The program will not be aected if you change the
program selector after the program has started.

13
Customer Care Center
1-800-898-1879
www.askona.com
7
Drying program nished
The text "End" is shown on the display for
2 minutes. The machine then turns o.
NOTE!
• Clean the lint lter in the outer door after
each load. See the Care and maintenance
instructions chapter.
WARNING!
If the lint lter becomes clogged, the machine’s
automatic overheating cut-out may be triggered.
Clean the lter, wait until the machine has cooled,
then try starting it. If it still does not start: Call the
Customer Care Center.
Once drying has nished
Remove the clothes and close the door to prevent
small children from climbing into the machine.
Operating instructions

14 Customer Care Center
1-800-898-1879
www.askona.com
Care and maintenance instructions
Cleaning the lint lter
The lint lter must be cleaned after each load.
1. Lift the lter from the holder in the door.
2. Open the lint lter. Use your thumb to press on
the edge as illustrated and pull it out.
3. Use your hand or a soft cloth to remove the lint
from all sides of the lter. If necessary, use a
damp sponge and a small amount of washing-
up liquid dish soap to remove any deposits.
Dry the lter thoroughly with a towel.
4. Close the lint lter and put it back in the door.
Close the lint lter before closing the door.
Cleaning the outside of the
machine
Clean the outside of the machine and the
program panel with a mild cleaner. Do not use
solvents, as these can damage the machine. Do
not hose down or spray the machine with water.
NOTE!
Do not allow dust to accumulate around the
machine. Keep the area around the tumble dryer
clean and cool; dust, heat, and moisture prolong
drying times.

15
Customer Care Center
1-800-898-1879
www.askona.com
Troubleshooting
The machine will not start
Check:
• that the door is properly closed.
• that the main power switch is on.
• that the Delayed Start option has not been
selected. To cancel Delayed Start, press the
Stop button for three seconds.
• that any plug is connected.
• that the house fuses or circuit breaker have
not been tripped.
• that the overheating cut-out has not been
triggered.
The machine loses all power
during a program
The overheating cut-o shuts o the tumble
dryer if the temperature is too high, caused by
lint clogging the lint lter, for instance.
• Clean the lint lter.
• Wait until the machine has cooled, then try
starting it. If it still does not start: Call the
Customer Care Center.
Drying takes too long
• Check that the lint lter is not blocked. See the
Care and maintenance instructions chapter.
Error messages
If F30 is ashing on the display, the maximum
permitted program time has been reached.
Check that the lint lter is not blocked. See the
Care and maintenance instructions chapter.

16 Customer Care Center
1-800-898-1879
www.askona.com
Technical data
Height: 33 1/2'' (850 mm)
Width: 23 1/2'' (597 mm)
Depth: 23 7/8" (606 mm)
Weight (net): 88 lb (40 kg)
Cylinder volume: 29,6 gal (112 l)
Max. drying capacity: 15 lb (7 kg)
Speed: 50-55 rpm
Rated power: See serial number tag and rating plate.
Drum material: Stainless steel
Outer casing material: Powder-coated and hot-galvanized sheet steel or stainless
steel.
Setup Stacking or freestanding
Technical information

17
Customer Care Center
1-800-898-1879
www.askona.com
Service and guarantee
Limited Warranty – Residential
Appliances
ASKO Distribution North America, LLC.
(hereinafter “ASKO”) warrants the original
purchaser (the “ASKO Customer”) of the ASKO
product (the “ASKO Product”), who purchased
the appliance from a distributor, dealer,
manufactures representative or other seller
who has been authorized by ASKO (“Authorized
ASKO Dealer”), that this ASKO Product is free
of defects in material and workmanship, subject
to the terms and conditions set forth herein. The
limited warranty covers parts and labor, except
as set forth in this Limited Warranty. Service must
be provided by an ASKO designated service
company. YOUR SOLE AND EXCLUSIVE
REMEDY UNDER THIS LIMITED WARRANTY
SHALL BE PRODUCT REPAIR AS PROVIDED
HEREIN. The limited warranty is valid only in the
United States or Canada and applies only when
the appliance is used in the country in which it
was purchased. Proof of original purchase date
is required to obtain service under this limited
warranty.
Residential ASKO Products
Used Exclusively for Household/
Personal Purposes:
Two (2) Years limited Warranty – Any warranty
service claims for residential ASKO Products
must be led with ASKO within two (2) years from
date of purchase.
Residential ASKO Products Not
Used Exclusively for House Hold
Purposes, used Commercially
or Use in marine, Mobile or
Aeronautical Applications:
One (1) Year limited Warranty – Any warranty
service claims for ASKO Products not used
exclusively for household and personal use,
used commercially or used in marine, mobile, or
aeronautical application must be led with ASKO
within One (1) year from date of purchase.
ITEMS EXCLUDED FROM
WARRANTY
This limited warranty does not cover:
1. Replacement parts or repair labor if this
appliance is used in a manner that is
inconsistent to published user or operator
instructions and or/or installation instructions.
2. Service calls to correct the installation of your
appliance, to instruct you on how to use your
appliance, to replace or repair house fuses, or
to correct house wiring or plumbing.
3. Consumable parts are excluded from warranty
coverage.
4. Damage resulting from accident, alteration,
misuse, abuse, re, ood, acts of God,
improper installation, installation not in
accordance with electrical or plumbing codes,
or use of products not approved by ASKO.
5. Cosmetic damage, including scratches,
dents, chips or other damage to the nish of
your appliance, unless such damage results
from defects in material or workmanship and
is reported to ASKO within 5 days from date of
purchase.
6. Pickup and delivery. This appliance is intended
to be repaired in your home.
7. Repairs to parts or systems resulting from
unauthorized modications made to the
appliance.
8. Expenses for travel and transportation for
product service if your appliance is located in
a remote area where service by an authorized
ASKO servicer is not available.
9. The removal and reinstallation of your
appliance if it is installed in an inaccessible
location or is not installed in accordance with
ASKO’s published installation instructions.
10. Replacement parts or repair labor on
appliances with original model/serial numbers
that have been removed, altered or cannot be
easily determined.

18 Customer Care Center
1-800-898-1879
www.askona.com
Service and guarantee
DISLCAIMER OF IMPLIED
WARRANTIES
YOUR SOLE AND EXCLUSIVE REMEDY
UNDER THIS LIMITED WARRANTY SHALL
BE PRODUCT REPAIR AS PROVIDED
HEREIN. ASKO SHALL NOT BE LIABLE
FOR INCIDENTIAL OR CONSEQUENTIAL
DAMAGES. Some states and provinces do not
allow the exclusion or limitation of incidental or
consequential damages, so these limitations and
exclusion may not apply to you. This warranty
gives you specic legal rights, and you also may
have other rights that vary from state to state or
province to province.
If you think you need repair service, rst see the
“Trouble Shooting” section of the Use & Care
Guide.
If you are unable to resolve after checking
“Trouble Shooting” additional help can be found
by calling ASKO Customer Care at 1-800-898-
1879
Before contacting the Customer
Care Center
Before you contact the Customer Care Center,
make sure you know the model designation, type
designation, and serial number.
The model designation (1) can be found on the
rst page of the operating instructions and on
the machine panel. The type designation (2) and
serial number (3) can be found on the type plate,
which is found on the front of the tumble dryer
inside the outer door.
3
TYPE
2
Should you need further assistance, you can
write to ASKO Appliances with any questions or
concerns at the address below:
ASKO Distribution North America, LLC.
Customer Care Center
PO Box 44848
MADISON WI 53744
1

19
Customer Care Center
1-800-898-1879
www.askona.com
Installation instructions
WARNING!
WARNING - Risk of re.
Install the clothes dryer according to the
manufacturer's instructions and local codes.
Do not install a clothes dryer with exible plastic
venting materials. If exible metal (foil type)
duct is installed, it must be of a specic type
identied by the applience manufacturer that is
UL approved for use with clothes dryers. Flexible
venting materials are known to collapse, be
easily crushed, and trap lint. These conditions
will obstruct clothes dryer airow and increase
the risk of re.
To reduce the risk of of severe injury or death,
follow all installation instructions.
SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE.
Positioning the tumble dryer
The tumble dryer can be freestanding or stacked.
Remember that the tumble dryer produces heat
and should therefore not be located in a room
that is too small. If the room is very small, drying
will take longer due to the limited quantity of air.
WARNING!
• Clothes dryer installation must be performed
by a qualied installer.
• For proper ventilation, the machine should not
be installed behind a door.
• The tumble dryer's toe kick ventilation must
not be blocked by a rug or the like.
NOTE!
If the unit must be installed behind a door, the
door should be louvered. (please see door
ventilation requirements in the Built-in chapter).
To improve ventilation, the door where the tumble
dryer is located should be left open when the
dryer is in use.
Freestanding
The tumble dryer can be positioned beside the
washing machine.
Stacking
The tumble dryer can be placed on top of an
ASKO washing machine. Use the two foot cups
found in the document bag included with the
machine and the two tip guards attached to the
bottom of the back of the machine.
How to assemble the stacking kit:
1. Remove the two tip guards from the back of
the tumble dryer. Replace the screws that
held the tip guards in place.
2. Remove the two screws indicated on the back
of the washing machine.

20 Customer Care Center
1-800-898-1879
www.askona.com
Installation instructions
3. Secure the anti-tip device using the screws as
shown in the picture.
4. Attach the plastic cups for mounting the tumble
dryer’s front feet to the washing machine’s
top cover. This is essential, as only when the
tumble dryer’s feet are resting in the plastic
cups can you be sure that the tumble dryer is
correctly positioned on the washing machine.
Break o tab A on the cup tted on the right
side and tab B on the cup tted on the left
side. Then remove the paper from the self-
adhesive surface under the plastic cups.
5. Fit the plastic cups so that the "tags" marked
with arrows are against the front edge or side
edge of the cover and press them rmly onto
the cover. Then break o the remaining tabs.
6. Push out the knock-out hole on the back of
the tumble dryer (you don't have to completely
remove the knockout, just fold it up far enough
for the stacking bracket to t inside the slot)
using a hammer and a screwdriver.
7. Push the tumble dryer in under the metal
brackets. At the same time keep the front
edge raised by 7/16" (10mm) to 7/8" (20mm) .
8. Lower the tumble dryer’s front feet into the
plastic cups and adjust the tumble dryer to
ensure it is level.
A
B
Other manuals for T754
4
Table of contents
Other Asko Dryer manuals
