Aspire ADJUSTABLE HEIGHT DAY CHAIR User manual

ASPIRE ADJUSTABLE HEIGHT DAY CHAIR
www.aspirecare.com.au
1300 133 120
Carton Contains:
1. Seat base & frame x 1
2. Side frame left x 1
3. Side frame right x 1
4. Backrest & frame x 1
5. Backrest connectors x 2
6. Extension legs x 2 (front)
7. Extension legs with wheels x 2 (rear)
8. Head cushion x 1
9. Hand wheels x 8 (located on frame)
QUICK ASSEMBLY GUIDE
Step 1 – Attach side frames to seat base
Note – The front of the side frames has a near vertical leg section while the rear angles outwards. The front of the
seat base is the section with the knee bolster, a raised section of padding for additional support.
- Align left side frame with left side of seat base (A).
- Push horizontal connectors into place (B).
- Fasten with 2 x hand wheels (C).
- Repeat for right side
- Ensure all 4 hand wheels (2 x each side) are fastened tightly (D).
ASSEMBLY (3 STAGE PROCESS)
A B C D
www.aspirecare.com.au
1300 133 120

ASSEMBLY CONT..
Step 2 – Mount the backrest
- Align and insert backrest connectors x 2 into the seat base frame (A).
- Position backrest frame over the connectors so they insert into both sides, lower backrest to the desired height
(B) and fasten 2 x hand wheels (C).
Step 3 – Insert the extension legs
NOTE – Extension legs with wheels may only be located at the back of the frame, allowing the chair to be tilted to
manoeuvre (without a person in it).
- Align and insert to desired height 2 x extension legs without wheels to the front of frame (A).
- Align and insert to desired height 2 x extension legs with wheels to the rear of frame (B).
- Ensure locking pins click into place at the same height hole on both the left and right sides.
The adjustable day chair is now assembled.
A
A
B
B
C
