USER MANUAL
AIR LIFT CHAIR

Thank you for choosing the Aspire Air Lift Chair.
This chair has been specifically designed to offer
comfort, support and safety.
It is important that you read this user manual
carefully before using your new Air Lift Chair.
© Aidacare Pty Ltd 2023
No part of this user manual may be copied, distributed, reproduced, scanned or stored on any electronic
database, whether in whole or in part in any form or by any means.
Due care has been taken to ensure all the information contained in this user manual is correct at the time
of printing. All measurements, pictures, colours and weight capacities are to be used as a guide only.
We reserve the right to modify the design or appearance of any product displayed in this user manual
without prior notice.
TABLE OF CONTENTS
Symbols & Label Information 4
Label Information 5
1. Introduction 6
2. General Guidelines 7
3. Your Air Lift Chair 10
4. Air Lift Chair Set Up 13
5. Operation 16
6. Troubleshooting 21
7. Care And Maintenance 23
8. Warranty 25
Specifications 26
Appendix 26

5
4aspirecare.com.au
SYMBOLS & LABEL INFORMATION LABEL INFORMATION
PRODUCT SAFETY SYMBOLS
The symbols below represent labels used on the product to identify warnings,
mandatory actions and prohibited actions. It is very important for you to read
and understand these symbols completely. Do not remove these labels from
your product. Please note that not all of the symbols may be used on your lift
chair model.
Electrical hazard Battery door location
Maximum weight capacity Class II equipment
Read and follow the information
in the owner’s manual.
Green LED indicates power to the unit
is on. Not applicable to all models
Do not connect an extension lead
to the AC/DC converter or the
battery charger
Degree of protection against
electric shock
Pinch/crush points hazard! Do not
place objects or appendages in the
path of moving parts
This product has been tested
and complies to IEC 60601-1-2
Do not place objects under the lift
chair. Make sure the area is clear of
obstructions, including pets and
small children during operation
Indoor use only. Avoid exposure to
rain, snow, ice, salt or standing water.
Maintain and store in a clean and
dry environment
Removal of grounding prong can
create electrical hazard. If necessary,
properly install an approved
3-pronged adapter to an electrical
outlet having 2-pronged plug access
Do not place objects under the
footrest when the lift chair is in the
fully reclined position. Make sure area
is clear of obstructions, including pets
and small children during operation
Properly dispose of all electronic
components, including the external
transformer, hand control, batteries,
actuator motors and wiring. Contact
your authorised aspire dealer for
more information
Do not cover or place the external
transformer under the riser recliner.
Keep in an open, well-ventilated area
free from foreign material and away
from possible pinch points
The symbols below are used throughout this owner’s manual and on the
product to identify warnings and important information. It is very important for
you to read them and understand them completely.
WARNING! Indicates a potentially hazardous condition/situation.
Failure to follow designated procedures can cause either personal
injury, component damage or malfunction. On the product, this
icon is represented as a black symbol on a yellow triangle with a
black border.
MANDATORY! These actions should be performed as specified.
Failure to perform mandatory actions can cause personal injury
and/or equipment damage. On the product, this icon is represented
as a white symbol on a blue dot with a white border.
PROHIBITED! These actions are prohibited. These actions should
not be performed at any time or in any circumstances. Performing
a prohibited action can cause personal injury and/or equipment
damage. On the product, this icon is represented as a black symbol
with a red circle and red slash.
Please fill out the following information for quick reference:
Aspire Dealer
Address
Phone Number
Purchase Date
Serial Number
NOTE: This owner’s manual is compiled from the latest specifications and
product information available at the time of publication. We reserve the right
to make changes as they become necessary. Any changes to our products may
cause slight variations between the illustrations and explanations in this manual
and the product you have purchased. The latest/current version of this manual is
available on our website.

7
6aspirecare.com.au
SAFETY
CONGRATULATIONS on purchasing your Aspire Air Lift Chair. The product you
have purchased combines state-of-the-art components with safety, comfort
and styling in mind. We are confident the design features will provide you with
the conveniences you expect during your daily activities. Understanding how to
safely operate and care for this product should bring you years of trouble-free
operation and service.
Read and follow all instructions, warnings and notes in this manual and all other
accompanying literature before attempting to operate this product for the first
time. In addition, your safety depends upon you, as well as your dealer, carer or
healthcare professional in using good judgement.
If there is any information in this manual which you do not understand, or if
you require additional assistance for setup or operation, please contact your
authorised Aspire Dealer. Failure to follow the instructions, warnings and
notes in this manual and those located on your Aspire product can result in
personal injury or product damage and will void the Aspire product warranty.
PURCHASER’S AGREEMENT
By accepting delivery of this product, you promise that you will not change, alter
or modify this product or remove or render inoperable or unsafe any guards,
shields or other safety features of this product; fail, refuse or neglect to install
any retrofit kits from time to time provided by Aidacare to enhance or preserve
the safe use of this product.
INFORMATION EXCHANGE
We want to hear your questions, comments and suggestions about this manual.
We would also like to hear about the safety and reliability of your new lift chair
and about the service you received from your authorised Aspire Dealer. Please
notify us of any change of address, so we can keep you apprised of important
information about safety, new products and new options that can increase your
ability to use and enjoy your lift chair.
Please feel free to contact us at the address below:
AUSTRALIA
Building 3A, 1 Moorebank Avenue,
Moorebank NSW Australia 2170
1300 133 120 |aidacare.com.au
UK
Arcadia House, Maritime Walk,
Ocean Village, Southampton SO14 3TL
United Kingdom
01622 541235 |aidacare.co.uk
NOTE: If you ever lose or misplace your product registration card or your copy of
this manual, contact us and we will be glad to send you a new one immediately.
1. INTRODUCTION
Your Air Lift Chair is a state-of-the-art life-enhancement device designed to
increase mobility and provide pressure relief. Please be aware that the final
selection and purchasing decision regarding the type of air lift chair to be used
is the responsibility of you, the air lift chair user, if capable of making such a
decision, and/or your healthcare professional (i.e. medical doctor, allied health
professional, therapist etc.).
MANDATORY! Read and follow the information provided in this
owner’s manual before attempting to operate your Air Lift Chair for
the first time.
There are certain situations, including some medical conditions, where you
will need to practise operating the Air Lift Chair in the presence of a trained
attendant. A trained attendant can be defined as a family member or healthcare
professional specially trained in assisting you with performing various daily
living activities while safely operating a lift chair.
Below are some precautions, tips and other safety considerations that will help
you become accustomed to operating the Air Lift Chair in a safe manner.
MODIFICATIONS
Aspire chairs are designed and engineered to provide maximum comfort
and utility. However, to prevent personal injury and/or damage to your Air
Lift Chair, you should not modify, add, remove or disable any feature, part or
function of your Air Lift Chair. Unauthorised modifications may also void your
product’s warranty.
NOTE: Use Aspire approved parts only for all repairs and replacements.
WEIGHT LIMITATIONS
Your Air Lift Chair is rated for a maximum weight capacity. The Aspire Air Lift
Chair has a safe working load (SWL) of 140 kg.
MANDATORY! Stay within the specified weight capacity of
your Air Lift Chair. Failure to do so may result in injuries and/or
product damage, Aidacare will not be held responsible for any
such issues/failures.
2. GENERAL GUIDELINES

9
8aspirecare.com.au
PINCH/CRUSH HAZARDS
The scissor and lift mechanisms are labeled as pinch/crush point hazards on
your Air Lift Chair. Keep clear of these areas and make sure the path of motion
is unobstructed. See figure 3.1 for pinch/crush point locations.
WARNING! Do not place objects or appendages in the path
of moving parts.
DEGREE OF PROTECTION/MODE OF OPERATION
• Class II equipment/Type B protection against electric shock
• Degree of protection against the ingress of solid/liquids—IPX0
• Mode of operation—Maximum Duty Cycle: 2 min. ON/18 min. OFF
STORAGE AND OPERATION TEMPERATURES
• Transportation or storage: – 75°C/-104°F to 70°C/158°F
• Operation: 10°C/50°F to 40°C/104°F
ELECTROMAGNETIC AND RADIO FREQUENCY
INTERFERENCE (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic
and radio frequency waves can have an adverse affect on the
performance of electrically-powered devices, such as lift chairs.
Electromagnetic and Radio Frequency Interference can come from sources such
as cellular phones, mobile two-way radios (such as walkie-talkies), radio stations,
TV stations, amateur radio (HAM) transmitters, wireless computer links, Wifi,
microwave signals, paging transmitters and medium-range mobile transceivers
used by emergency vehicles. In some cases, these waves can cause unintended
movement or damage to the control system of electrically-powered devices.
The lift chair user can help prevent electromagnetic interference by maintaining
a minimum distance between portable and mobile RF communications
equipment. It is recommended that at least 3 metres (9 feet) of distance be
maintained between the lift chair and any handheld equipment emitting 10W
or more of output power. Refer to the manufacturer’s literature for the handheld
device to determine the maximum output power of that device.
Every electrically-powered device has an immunity (or resistance) to EMI. The
higher the immunity level, the greater the protection against EMI. Per EMC
standards, this product has passed immunity testing and is rated as a Group
1, Class B product, meaning the lift chair uses RF energy only for its internal
function. Therefore, its RF emissions are very low and are not likely to cause any
interference in nearby electronic equipment making the lift chair suitable for
use in all establishments, including domestic establishments and hospitals.
WARNING! Be aware that cell phones, two-way radios, laptops and
other types of radio transmitters may cause unintended movement
of your electrically-powered device due to EMI. Exercise caution
when using any of these items while operating your lift chair.
WARNING! The addition of accessories or components to the lift
chair can increase the susceptibility of the chair to EMI. Do not
modify your lift chair in any way not authorised by Aidacare.
WARNING! Your lift chair itself can disturb the performance of other
electrical devices located nearby, such as alarm systems.
NOTE: If unintended motion occurs, discontinue use of the Air Lift Chair. Contact
Aidacare to report the incident.
SHIPPING AND DELIVERY
Before using your Air Lift Chair, make sure your delivery is complete as some
components may be packaged individually. If you do not receive a complete
delivery, please contact your authorised Aspire Dealer immediately. Where
damage has occurred during transport, either to the packaging or content,
please contact the delivery company responsible.
MOTOR VEHICLE TRANSPORT
If you will be transporting your Air Lift Chair in a motor vehicle, individual
components (external transformer, etc.) should be secured. The Air Lift Chair
itself must also be secured (a possible hazard during vehicle braking).

11
10 aspirecare.com.au
BODY COMPONENTS
This section describes the features of your Air Lift Chair. Carefully review the
function and location of each item described, and note that the illustrations and
option locations shown in this manual may not reflect the type of lift chair that
you own.
Space Saver
Hand Control
Dual Action
Hand Control
Hand Pump –
Seating Surface Castors
3. YOUR AIR LIFT CHAIR
Lift Mechanism: Responds to the hand control commands to position the chair
in the sit, recline and stand positions.
Leg Levelers: Manually rotate up or down in order to stabilise the chair before
use (Fig. 3.2).
Rotate the leg levelers to raise or lower the chair
Rotate the leg levelers to raise or lower the chair
Figure 3.2 Leg Levelers
Mobility Castors: May be installed in addition to the leg levelers to allow users
to move and position chair with ease. (Fig. 3.3).
Figure 3.3 Mobility Castors
WARNING! Pinch/Crush Points
Hazard! Be aware that the
lift mechanism and scissor
mechanisms are a pinch
point on the air lift chair.
Keep the following items and
similar objects clear of these
points when operating the air
lift chair:
• Appendages
• Small children
• Pets
• Wires
• Oxygen tubes
• Loose items, including
but not limited to clothing
and blankets
• Electrical power leads
Figure 3.1 Air Lift Chair Main Components
Scissor
Mechanism
(Pinch Point)
Figure 3.4 Scissor Mechanism
NOTE: Aidacare is not
responsible for damage due
to improper installation.
Power Lead
External
Transformer
Low Voltage
Connection Cable Scissor
Mechanisms
(Pinch Point)
Leg Levelers (Four Total)
Lift Mechanism
(Pinch Point)

13
12 aspirecare.com.au
ELECTRICAL COMPONENTS
Your Aspire Air Lift Chair is equipped with a low voltage DC motor system that
reduces the standard household alternating current of 90V AC – 264V AC to
direct current (24/39V DC). The electrical components include the external
transformer, batteries and hand control. Keep these a1reas free from moisture
at all times.
WARNING! Keep all electrical components free from moisture
at all times to prevent shock and/or electrical hazard.
External Transformer: Connects to a standard electrical outlet to provide power
to the air lift chair. The transformer may be equipped with an LED indicator,
which shows green when power to the transformer is on.
The external transformer may also come equipped with mounting brackets that
allow the transformer to be mounted to the wall directly under the standard
electrical outlet. The screws must be mounted to the wall stud for security.
Batteries: Provide the power needed to return the Air Lift Chair to an upright or
semi-upright position in the event of a power failure. Batteries are included with
the user manual and must be installed into the external transformer. See 4. Air
Lift Chair Set Up.
NOTE: The batteries will provide power for only a short period of time after
power is removed from the system, so it is important to act quickly in the event
of a power failure. Engage and hold the up/down switch in the UP position as
soon as possible. Maintain a steady pressure on the switch to avoid excessive
draw from the battery and achieve the most amount of lift. Keep in mind that
the amount of lift the batteries will be able to provide is affected by user weight
and battery condition.
Hand Control: Contains the controls needed to operate the various functions of
the lift chair. Refer to 5. “Operation” for more information. The hand control may
be equipped with a quick-release connector, which enables the user to detach
the hand control from the lift chair, disabling all functions of the hand control.
LIFT CHAIR PLACEMENT
Your Air Lift Chair should be placed near a standard electrical outlet on dry,
level ground where there is ample room to allow for proper operation. It is
recommended that you have the assistance of an attendant when positioning
the Air Lift Chair to avoid the possibility of injury when lifting.
Follow these steps to position the Air Lift Chair in a safe manner:
1. The back of the Air Lift Chair should be positioned with sufficient clearance
to avoid any obstructions, particularly behind the chair after reclining.
Suggested clearances by model are:
Space Saver (single motor) – 160mm | Dual Action (dual motor) – 350mm
2. Adjust the leg levelers to stabilise the Air Lift Chair (Fig. 3.2), or if desired
attach the 4 optional mobility castors.
3. Install the batteries into the external transformer. Refer to “Battery
Installation” for more information.
4. Position the external transformer on the floor in an open, well-ventilated area
where it will not be an obstruction.
5. Position the low voltage connection cable (cable from transformer to chair),
where it will not be pinched between the frame and the lift mechanism.
6. Connect the low voltage connection cable to the external transformer if it is
not already connected.
7. Plug the power lead directly into the electrical outlet. Do not use an
extension lead!
NOTE: If you discover a problem at any point during the set-up and positioning
of your air lift chair, stop and contact your authorised Aspire Dealer immediately.
To avoid personal injury and/or product damage, DO NOT plug the unit into
the electrical outlet until the problem is corrected and do not attempt to fix
electrical problems by yourself.
4. AIR LIFT CHAIR SET UP

15
14 aspirecare.com.au
ADJUST THE SEAT DEPTH
1. Remove the Backrest by releasing the latch on both sides.
2. Unscrew and remove the two screws holding the bracket in place.
3. Remove and re-position the bracket to align with the alternative position.
4. Align the bracket screw holes then, carefully, insert and tighten the two
holding screws.
5. Check that bracket is secure and then replace the backrest, making sure
the latch clicks into place
Battery Door
Power Lead
External Transformer
(Top and Bottom View)
Figure 4.2 Air Lift Chair Battery Backup Location
BATTERY INSTALLATION
Your Air Lift Chair may be equipped with a battery backup system that will
activate during a power failure. The backup system is powered by two 9V
batteries (not included) that need to be installed into the external transformer.
Follow these steps to install the batteries:
1. Unplug the external transformer power lead from the electrical outlet
(lead from transformer to wall).
2. Open the marked battery door on the external transformer.
3. Install two 9V batteries into the external transformer (Fig. 4.2).
4. Replace the battery door.
NOTE: Always make sure the external transformer is equipped with two fresh 9V
batteries. The battery backup system does not recharge itself. Fresh batteries
are defined as 9V alkaline batteries that are replaced every time the battery
backup system is activated during a power failure, or once a year if the battery
backup system has not been activated.
NOTE: If you unplug your air lift chair for an extended period of time
(more than one hour), remove the batteries from the external transformer.
The air lift chair will draw power from the batteries even when it is not in use.
IDEA: Check 9V battery every year when you check your smoke alarm!
Position 2Position 1
Brackets
Battery Door
External Transformer
(Top and Bottom View)
Power Lead

17
16 aspirecare.com.au
5. OPERATION
SAFE OPERATING PRECAUTIONS
There are certain precautions that should be taken during the operation of your
Air Lift Chair. Read and follow these precautions carefully in order to ensure safe
Air Lift Chair operation and to prevent injury and/or product damage.
• Plug the power lead directly into the electrical outlet. DO NOT use an
extension lead!
• Ensure the power lead is unplugged before moving the Air Lift Chair
• When transferring a patient on / off the chair, ensure the rear castors are
locked (if installed)
• DO NOT place anything (e.g. a drinking glass) on top of or near the
external transformer.
• If the external transformer box or hand control requires cleaning, unplug
the power lead from the electrical outlet and use a clean, dry cloth or lightly
dampened cloth. Dry completely before plugging the power lead back into
the electrical outlet.
• Periodically check the hand control and all power leads for visible damage.
• Keep the hand control away from all heated surfaces.
• Ensure the hand control is out of the way before sitting in the chair.
• Keep children and pets away from all moving parts while operating the
Air Lift Chair.
• DO NOT allow children to play on or operate the Air Lift Chair. Only the
intended user should operate the air lift chair.
• AVOID pinch points, such as the lift and scissor mechanisms.
Keep hands and feet clear of these areas.
• ALWAYS leave the Air Lift Chair in an upright and closed position when not in use.
• DO NOT sit or stand on the legrest.
• DO NOT “drop” into the Air Lift Chair when sitting if it is in a partially raised
position, this will damage the seating and void warranty.
• DO NOT use as a CPR bed
PROHIBITED! Do not place objects under the Air Lift Chair.
Make sure area is clear of obstructions, including pets and small
children during operation.
WARNING! Prevent the risk of electrical shock, fire, falls and/or
being pinched. Follow all instructions and precautions provided.
WARNING! Prevent potential equipment damage!
DO NOT place the external transformer under the Air Lift Chair.
WARNING! Do not cover the external transformer. Keep the
transformer in an open, well-ventilated area free from foreign
material/debris to ensure proper operation.
HAND CONTROL OPERATION
Depending on lift chair model, the hand control may be equipped with switches
that control the movement of the chair-back, chair base and legrest (Fig. 5.1, 5.2
and 5.3).
WARNING! Do not lean on or apply downward force to the chair-
back when the Air Lift Chair is in the fully reclined position. Doing so
could cause the Air Lift Chair to tip, resulting in personal injury and/
or product damage.
WARNING! Do not use the legrest as a seat, or for purposes outside
its intended use. Doing so could cause instability in the air lift chair
and place undue stress on Air Lift Chair components, resulting in
personal injury and/or product damage.
WARNING! Be sure to lock or disconnect the hand control when the
Air Lift Chair is not in use.
WARNING! The hand control is not waterproof and should not be
washed or put in liquid
SPACE SAVER HAND CONTROL OPERATION
Follow these steps to sit in your Air Lift
Chair (Fig. 5.1):
1. Engage and hold the Stand Position
button to raise your Air Lift Chair to
the standing position.
2. Back into the Air Lift Chair and sit
in the centre of the seat, using the
armrests for support if needed.
3. Engage and hold the Recline Position
button to lower the Air Lift Char to a
comfortable seated position.
Follow these steps to recline your Air Lift Chair from the seated position
(Fig. 5.1):
1. Engage the Recline Position button and hold down until
comfortably reclined.
2. Engage and hold the Stand Position button to return to an upright, seated
position. Release the button when the Air Lift Chair reaches a comfortable
seated position.
Figure 5.1 Space Saver Hand Control
Backrest
Recline
Stand
Position

19
18 aspirecare.com.au
Follow these steps to stand up from your Air Lift Chair (Fig. 5.1):
1. Engage and hold the Stand Position button to raise your Air Lift Chair.
2. Release the button when the Air Lift Chair reaches a height where you can
stand up comfortably.
NOTE: The hand control on your Air Lift Chair may be equipped with an LED that
indicates power to the hand control.
If this LED is present and not lit when the hand control is in use, contact your
authorised Aspire Dealer.
DUAL ACTION HAND CONTROL OPERATION
Follow these steps to sit
in your lift chair (Fig 5.2):
1. Ensure the chair back is
raised by engaging the
Backrest Raise button
and the legrest is down
by engaging the Legrest
Down button.
2. Engage and hold the
Stand Position button
to raise the chair to the
standing position.
3. Back into the chair and
sit in the centre of the
seat, using the armrests
for support if needed.
4. Engage and hold the Seated Position button to lower the chair
to a comfortable seated position.
Follow these steps to recline your Air Lift Chair from the seated position (Fig. 5.2):
1. Engage and hold the Backrest Recline button until comfortably reclined.
Engage and hold Backrest Raise button to raise chair back up.
2. Engage and hold the Legrest Raise button until a comfortable leg position
is reached. Engage and hold the Legrest Down button to lower the legrest
back down.
Follow these steps to raise or lower your legrest while in the seated
or reclined position (Fig. 5.2):
1. Engage and hold the Legrest Raise button until a comfort leg position
is reached.
2. Engage and hold the Legrest Down button to lower the legrest back down.
Follow these steps to stand up from your Air Lift Chair (Fig. 5.2):
1. Ensure the chair back is raised by engaging the Backrest Raise button
and the legrest is down by engaging the Legrest Down button.
2. Engage and hold the Stand Position button to raise the chair to the
Standing Position.
3. With your feet firmly on the ground stand slowly out of the chair, using the
armrests for support if needed.
NOTE: The Primary or Secondary functions automatically override depending
on the current position of the chair
MOBILITY CASTORS
All Aspire Air Lift Chairs come with four genuine Tente mobility castors.
The two rear castors are locking. To lock the rear castors, push the lever to ‘ON’.
To unlock the castors, push the lever to ‘OFF’ (Fig. 5.3):
Locking Lever
Figure 5.3 Mobility Castors
Figure 5.2 Dual Action Hand Control
Primary:
Legrest Raise
Secondary:
Seated Position
Primary:
Stand Position
Secondary:
Legrest Down
Primary:
Backrest Recline
Primary:
Backrest Raise
