Astral Pool IX Series Operating instructions

27/05/2010
INSTALLATION AND
OPERATING INSTRUCTIONS
Melbourne: 03 8796 8600 Gold Coast: 07 5552 2600 Perth: 08 9350 2600
Sydney: 02 9853 2100 Townsville: 07 4750 3100 [email protected]
Brisbane: 07 3308 5400 Adelaide: 08 8152 7600 www.astralpool.com.au
Bolero ND
Cleaner
INSTALLATION AND OPERATING INSTRUCTIONS I INSTALLATION AND OPERATING INSTRUCTIONS
IX Series
Leaf Canister

IX Leaf Canister V05_10
2
INSTALLATION
1. Install Leaf Canister filter on a clean, stable and level base. Canister should be installed on the inlet side
of the pump.
2. The leaf canister has one inlet ports (from Pool/Spa) and three outlet ports (to Pump). Glue 50mm tail
into the inlets and one 50mm tail into one of the outlets of the filter that suits the plumbing configuration.
3. Glue in blanking caps into the two remaining inlets. Allow a minimum on one hour for glue to dry.
START UP INSTRUCTIONS
1. Before start up make sure the canister basket is in the tank.
2. Fill canister with water to top.
3. Fit lid and lock ring and ensure it is in place and tightened.
4. Close both the Air Bleed Screws fitted to the lid.
5. Start pump –Check there is a good flow of water back in the pool.
6. Clean the basket when the flow to the pool reduces.
TO CLEAN CANISTER BASKET
1. Stop pump-close valves on the suction and return lines of the canister.
2. Open one the air bleed valve on the lid.
3. Loosen lock ring and remove basket.
4. Lift out basket. Remove debris with hand. Do not bang against hard surfaces to remove debris; Damage
to basket may occur voiding warranty. Replace the basket –carefully locating it on the bottom spigot.
5. Clean the lid ‘o’ ring. Replace the lid and press firmly into place.
6. Tighten the lid lock ring until safety catch locks.
7. Fill with water
8. Close the valves –start the pump.
NEVER LOOSEN THE LOCK RING WHEN
THE PUMP IS WORKING

IX Leaf Canister V05_10
3
WARRANTY
Your IX Leaf Canister is covered by a limited five year warranty against defects in materials or manufacture. The
outer case, lid and lock ring are covered for a period of five years from date of purchase plus 30 days to allow for
installation.
The basket is a consumable item and is covered for a period of 30 days. Regular cleaning will ensure a longer
life.
In field labour warranty applies only within capital city metropolitan areas or within 20 kilometers of an authorised
Hurlcon service agent. Should you reside outside these locations, a traveling charge may be applied. Should the
gauge or cartridge element fail, it must be returned to Hurlcon freight pre paid for repair or replacement at our
option.
Hurlcon shall not be responsible for consequential damages of any kind. This warranty does not cover damage
caused by accident or misuse. The warranty is only valid when the filter is used on swimming pool and spa pool
applications only. No person is authorised to make representations on behalf of Hurlcon.
Commercial Installations
On Commercial Installations, such as health clubs, motels/hotels and hydrotherapy, parts and in field labour
warranty (within capital city metropolitan areas or 20km radius of authorised service agents) is 12 months from the
date of purchase plus 30 days. The cartridge element is warranted for 30 days.

IX Leaf Canister V05_10
4
ASTRALPOOL Pty. Limited. A.B.N. 97 007 284 504
www.astralpool.com.au email: s[email protected]
Information and specifications subject to change without notice.
