Asus X00BD User manual

E11709
User Guide
15060-82600000
E11709_ZB500KG_UM_Booklet_EU.indd 1
2016-09-12 09:58:56

First Edition/ September 2016
Model: ASUS_X00BD (ZB500KG)
Before you start, ensure that you have read all the
safety information and operating instructions in this
User Guide to prevent injury or damage to your
device.
NOTE: For the latest updates and more detailed
information, please visit www.asus.com.
Front features
Sensor
Touch screen
display
Receiver
Touch keys
Front camera
LED Indicator
E11709_ZB500KG_UM_Booklet_EU.indd 2
2016-09-12 09:58:57

Side features
Audio jack
Micro USB port
Power key
Groove
NOTE: Pry open the rear cover from the groove.
E11709_ZB500KG_UM_Booklet_EU.indd 3
2016-09-12 09:58:57

Rear features
NOTES:
• Removetherearcovertodisplaythedual
micro SIM and microSD card slots.
• ThemicroSIMcardslotssupportWCDMA
and GSM/EDGE network bands.
• ThemicroSDcardslotsupportsmicroSDand
microSDHCcardformats.
NOTES:
• Useonlythepoweradapterthatcamewithyour
device. Using a different power adapter may
damage your device.
• UsingthebundledpoweradapterandASUSPhone
signal cable to connect your ASUS Phone to a
power outlet is the best way to charge your ASUS
Phone.
• Theinputvoltagerangebetweenthewalloutletand
thisadapterisAC100V-240V.Theoutputvoltage
ofthemicroUSBcableisDC5.2V,1A.
IMPORTANT!
• YourASUSPhonecomespartiallychargedbutyou
mustchargeitfullybeforeusingitforthersttime.
Readtheimportantnoticesandcautionsbefore
charging your device.
• WhenusingyourASUSPhonewhileitispluggedto
a power outlet, the grounded power outlet must be
near to the unit and easily accessible.
• WhenchargingyourASUSPhonethroughyour
computer, ensure that you plug the micro USB
cable to your computer’s USB 2.0 / USB 3.0 port.
• AvoidchargingyourASUSPhoneinan
environment with ambient temperature of above
35oC(95oF).
Rear camera
Rear cover
Volume key
Speaker
Camera ash
E11709_ZB500KG_UM_Booklet_EU.indd 4
2016-09-12 09:58:57

Rear features
Charging your ASUS Phone
To charge your ASUS Phone:
1. ConnecttheUSBconnectorintothepower
adapter’s USB port.
2. ConnecttheotherendofthemicroUSBcable
to your ASUS Phone.
3. Plug the power adapter into a wall socket.
NOTES:
• Useonlythepoweradapterthatcamewithyour
device. Using a different power adapter may
damage your device.
• UsingthebundledpoweradapterandASUSPhone
signal cable to connect your ASUS Phone to a
power outlet is the best way to charge your ASUS
Phone.
• Theinputvoltagerangebetweenthewalloutletand
thisadapterisAC100V-240V.Theoutputvoltage
ofthemicroUSBcableisDC5.2V,1A.
IMPORTANT!
• YourASUSPhonecomespartiallychargedbutyou
mustchargeitfullybeforeusingitforthersttime.
Readtheimportantnoticesandcautionsbefore
charging your device.
• WhenusingyourASUSPhonewhileitispluggedto
a power outlet, the grounded power outlet must be
near to the unit and easily accessible.
• WhenchargingyourASUSPhonethroughyour
computer, ensure that you plug the micro USB
cable to your computer’s USB 2.0 / USB 3.0 port.
• AvoidchargingyourASUSPhoneinan
environment with ambient temperature of above
35oC(95oF).
3
1
2
E11709_ZB500KG_UM_Booklet_EU.indd 5
2016-09-12 09:58:57
