Asus C-PKND User manual

R
C-PKND
Dual Pentium®II CPU Card
USER’S MANUAL

ASUS C-PKND User’s Manual
2
USER’S NOTICE
No part of this manual, including the products and softwares described in it, may be repro-
duced, transmitted, transcribed, stored in a retrieval system, or translated into any language
in any form or by any means, except documentation kept by the purchaser for backup pur-
poses, without the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOTLIMITED TOTHE IMPLIED
WARRANTIES OR CONDITIONS OF MERCHANTABILITYOR FITNESS FORAPAR-
TICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS,
EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDEN-
TAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF
PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSI-
NESS AND THE LIKE), EVEN IF ASUS HAS BEENADVISED OF THE POSSIBILITY
OF SUCH DAMAGESARISING FROM ANY DEFECT OR ERROR IN THIS MANUAL
OR PRODUCT.
Products and corporate names appearing in this manual may or may not be registered trade-
marks or copyrights of their respective companies, and are used only for identification or
explanation and to the owners’ benefit, without intent to infringe.
• Intel, LANDesk, and Pentium are registered trademarks of Intel Corporation.
• IBM and OS/2 are registered trademarks of International Business Machines.
• Symbios is a registered trademark of Symbios Logic Corporation.
• Windows and MS-DOS are registered trademarks of Microsoft Corporation.
• Sound Blaster AWE32 and SB16 are trademarks of Creative Technology Ltd.
• Adobe and Acrobat are registered trademarks of Adobe Systems Incorporated.
The product name and revision number are both printed on the board itself. Manual revisions
are released for each board design represented by the digit before and after the period of the
manual revision number. Manual updates are represented by the third digit in the manual
revision number.
For previous or updated manuals, BIOS, drivers, or product release information, contactASUS
at http://www.asus.com.tw or through any of the means indicated on the following page.
SPECIFICATIONSAND INFORMATION CONTAINED IN THIS MANUALARE FUR-
NISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT
ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COM-
MITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBLITY OR LIABILITY FOR
ANYERRORSOR INACCURACIESTHATMAYAPPEARINTHISMANUAL,INCLUD-
ING THE PRODUCTS AND SOFTWARES DESCRIBED IN IT.
Copyright © 1997 ASUSTeK COMPUTER INC.All Rights Reserved.
Product Name: ASUS C-PKND
Manual Revision: 1.02
Release Date: July 1997

ASUS C-PKND User’s Manual 3
ASUS CONTACT INFORMATION
ASUSTeK COMPUTER INC.
Marketing Info
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112, ROC
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
Fax: [phone]
BBS: [phone]
Email: [email protected]
WWW: www.asus.com.tw
Gopher: gopher.asus.com.tw
FTP: ftp.asus.com.tw/pub/ASUS
ASUS COMPUTER INTERNATIONAL
Marketing Info
Address: 721 Charcot Avenue, San Jose, CA 95131, USA
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
BBS: [phone]
Email: [email protected]
WWW: www.asus.com
ASUS COMPUTER GmbH
Marketing Info
Address: Harkort Str. 25, 40880 Ratingen, BRD, Germany
Telephone: [phone]
Fax: [phone]
Email: [email protected]
Technical Support
BBS: 49-2102-448690
Email: [email protected]
Hotline: [phone]

ASUS C-PKND User’s Manual
4
CONTENTS
I. INTRODUCTION............................................................................ 7
How this Manual is Organized ........................................................ 7
Item Checklist .................................................................................. 7
II. FEATURES ..................................................................................... 8
Features of the ASUS C-PKND CPU Card ..................................... 8
The ASUS C-PKND CPU Card ................................................. 9
ASUS C-PKND CPU Card Layout............................................ 9
III. INSTALLATION .......................................................................... 10
1. Jumpers ....................................................................................... 10
Jumper Settings .................................................................... 10
2. System Memory (DRAM/SDRAM & SRAM) ........................... 11
3. External Connectors..................................................................... 11
4. Central Processing Unit (CPU)................................................... 12
ASUS C-PKND Components .................................................... 12
Preparing the CPU Card for Baseboard Installation .................. 13
Optional AAVID Heatsink.................................................... 15
Optional Elan Vital Heatsink ................................................ 15
Installing the CPU Card into Your Computer ............................ 18
System Case.......................................................................... 18
Opening the Computer ......................................................... 20
Power Connection Procedures ................................................... 22
BIOS Support ............................................................................. 22
Recommended Case Suppliers......................................................... 23
ElanVital Corporation........................................................... 23
Chenbro Micom Co., Ltd...................................................... 23
Chieftec Industrial Co., Ltd. ................................................. 23
IV. BIOS SOFTWARE ........................................................................ 24
Support Software........................................................................ 24
Flash Memory Writer Utility...................................................... 24
Main Menu ........................................................................... 24
Advanced Features Menu ..................................................... 25
Managing & Updating your Motherboard’s BIOS..................... 26

ASUS C-PKND User’s Manual 5
CONTENTS
5. BIOS Setup .................................................................................. 27
Load Defaults ....................................................................... 28
Standard CMOS Setup ............................................................... 28
Details of Standard CMOS Setup......................................... 28
BIOS Features Setup .................................................................. 31
Details of BIOS Features Setup............................................ 31
Chipset Features Setup ............................................................... 34
Details of Chipset Features Setup......................................... 34
Power Management Setup.......................................................... 37
Details of Power Management Setup ................................... 37
PNP and PCI Setup .................................................................... 39
Details of PNP and PCI Setup .............................................. 39
Load BIOS Defaults ................................................................... 41
Load Setup Defaults ................................................................... 41
Smart Alarm (LM78) Setup ....................................................... 42
Details of Smart Alarm (LM78) Setup ................................. 42
Supervisor Password and User Password .................................. 43
IDE HDD Auto Detection .......................................................... 44
Save & Exit Setup ...................................................................... 45
Exit Without Saving ................................................................... 45
V. DESKTOP MANAGEMENT......................................................... 46
Desktop Management Interface (DMI)............................................ 46
Introducing the ASUS DMI Configuration Utility..................... 46
System Requirements................................................................. 46
Using the ASUS DMI Configuration Utility.............................. 47
Edit DMI (or delete) ............................................................. 47
Save MIFD ........................................................................... 48
Load MIFD ........................................................................... 48
Load BIOS Defaults ............................................................. 48

ASUS C-PKND User’s Manual
6
FederalCommunications Commission Statement
This device complies with FCC Rules Part 15. Operation is subject to the following
two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installa-
tion. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with manufacturer’s instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the inter-
ference by one or more of the following measures:
• Re-orient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING! The use of shielded cables for connection of the monitor to the
graphics card is required to assure compliance with FCC regulations. Changes
or modifications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
CanadianDepartment of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the Cana-
dian Department of Communications.
FCC & DOC COMPLIANCE

ASUS C-PKND User’s Manual 7
I. INTRODUCTION
How this Manual is Organized
This manual is divided into the following sections:
I. Introduction: Manual information and checklist
II. Features: Information and specifications concerning this product
III. Installation: Instructions on setting up the CPU card
IV. BIOS Setup: BIOS software setup information
V. DMI Utility: BIOS supported Desktop Management Interface
Item Checklist
Please check that your package is complete. If you discover damaged or missing
items, please contact your retailer.
þASUS C-PKND CPU card
þTwo sets of Retention Mechanism and Heatsink Support
þSupport software (view FILELIST.TXT detailed contents and description)
• Bus Master IDE Drivers
• Flash Memory Writer utility
• Desktop Management Interface (DMI) Utility
• Readme files for descriptions and use of the files
• Technical Support Form
þCPU card support set
þASUS C-P2T CPU termination card
þThis user’s manual
I. INTRODUCTION
(Manual / Checklist)

8 ASUS C-PKND User’s Manual
II. FEATURES
Features of the ASUS C-PKND CPU Card
The ASUS C-PKND is carefully designed for the demanding PC user who
wants great versatility in the assembly of a computer system.The C-PKND:
•PS/2Connectors: Has PS/2mouseand PS/2keyboardconnectors oncard.
•Multi-SpeedSupport: Supports dual Intel Pentium®II (233–266MHz)
processors.
•Intel Chipset: Features Intel’s 440FX PCIset with I/O subsystems.
•Error Checking and Correcting (ECC): Detects and corrects 1-bit
memory errors using Intel’s 440FX PCIset and parity DRAM modules.
•CPU Built-In Level 2 Cache: Supports either 512K or 256K Pipelined
Burst Level 2 cache in the Pentium II Single Edge Contact (SEC) cartridge.
•Easy Installation: Supports autodetection of hard disks, PS/2 mouse,
and Plug and Play devices to make setup virtually automatic through the
BIOS.
(Features)
II. FEATURES

ASUS C-PKND User’s Manual 9
II. FEATURES
II. FEATURES
(C-PKND CPU CardII.
FEATURES)
PS/2 Mouse
PS/2 Keyboard
1432
Intel 440FX PCIset Intel 440FX PCIset
CPU Fan Power
CPU Fan Power
Pentium II Processor Single Edge Contact (SEC) Slots
Freq. Ratio
JP
Intel 440FX PCIset
Dual Pentium II Processor Single Edge Contact (SEC) Slots
PS/2
Mouse
PS/2
Keyboard
The ASUS C-PKND CPU Card
ASUS C-PKND CPU Card Layout

10 ASUS C-PKND User’s Manual
Installation Steps
Before using your computer with the CPU card, complete the following steps:
1. Set jumpers on the CPU card and the baseboard.
2. Install memory in your computer.
3. Connect ribbon cables, cabinet wires, and power supply.
4. Install expansion cards.
5. Install the processor/s.
6. Set up the BIOS software.
1. Jumpers
Several hardware settings are made by using jumper caps to connect jumper pins (JP) on
both the baseboard and CPU card. See the layout of the CPU card on page 9 and of the
baseboard for locations of jumpers. For a description and explanaton of the different
jumper settings and their graphical representations as used in this manual. see your
baseboard’s manual.
WARNING! Computer boards and components contain very delicate integrated
circuit (IC) chips. To protect them against damage from static electricity, take
some precautions whenever you work on your computer.
1. Unplug your computer before working on the inside.
2. Use a grounded wrist strap when handling computer components. If you do
not have one, touch both of your hands to a safely grounded object or to a
metal object, such as the power supply case.
3. Hold components by the edges and try not to touch the IC chips, leads, or
circuitry.
4. Place components on a grounded antistatic pad or on the bag that came with
the component whenever the components are separated from the system.
Jumper Settings
1. CPU to BUS Frequency Ratio (JP1, JP2, JP3, JP4)
These jumpers set the frequency ratio between the Internal frequency of the
CPU and the External frequency (called the BUS Clock) within the CPU.
(Jumpers)
III. INSTALLATION
III. INSTALLATION
