Asus ESC2000 User manual

ESC2000
Conguration Guide

II
Copyright © 2010 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language in any form or by any means,
except documentation kept by the purchaser for backup purposes, without the express written permission
of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS provides this manual “as is” without warranty of any kind, either express or implied, including but not
limited to the implied warranties or conditions of merchantability or tness for a particular purpose. In no
event shall ASUS, its directors, ofcers, employees, or agents be liable for any indirect, special, incidental,
or consequential damages (including damages for loss of prots, loss of business, loss of use or data,
interruption of business and the like), even if ASUS has been advised of the possibility of such damages
arising from any defect or error in this manual or product.
Specications and information contained in this manual ae furnished for informational use only, and are
subject to change at any time without notice, and should not be construed as a commitment by ASUS.
ASUS assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual,
including the products and software described in it.
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
E5930
First Edition
August 2010

III
Contents
Revision history
Revision Revision history Date
V1 First release of ESC2000 conguration guide July 2010
Revision history.......................................................................................... III
Safety information ...................................................................................... IV
Chapter 1: Product introduction
1.1 Key features.................................................................................. 1-2
1.2 System overview.......................................................................... 1-3
1.3 Front panel features..................................................................... 1-4
1.4 Rear panel features...................................................................... 1-5
1.5 Systemspecications ................................................................. 1-6
Chapter 2: Components
2.1 Upgrading CPU and CPU heatsink............................................. 2-2
2.2 Upgrading system memory......................................................... 2-3
2.3 Upgrading hard disk drives......................................................... 2-6
2.4 Replacing hard disk drive cage .................................................. 2-7
2.5 Installing ASUS PIKE SAS RAID card ........................................ 2-8
2.6 Upgrading 5.25-in drives ............................................................. 2-9
2.7 Installing ASUS Server Management Board............................ 2-10
2.8 Upgrading graphics card........................................................... 2-11
2.9 Installing MIO Audio card.......................................................... 2-12
2.10 Upgrading front system fan ...................................................... 2-13
2.11 Rackmount rail kit...................................................................... 2-14
2.12 OS support list ........................................................................... 2-15

IV
Safety information
Electrical Safety
• Before installing or removing signal cables, ensure that the power cables for
the system unit and all attached devices are unplugged.
• To prevent electrical shock hazard, disconnect the power cable from the
electrical outlet before relocating the system.
• When adding or removing any additional devices to or from the system, contact
a qualied service technician or your dealer. Ensure that the power cables for
the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you service.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied
service technician or your dealer.
Operation Safety
• Servicing of this product or units is to be performed by trained service
personnel only.
• Before operating the server, carefully read all the manuals included with the
server package.
• Before using the server, make sure all cables are correctly connected and the
power cables are not damaged. If any damage is detected, contact your dealer
as soon as possible.
• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Place the server on a stable
surface.
Lithium-Ion Battery Warning
CAUTION! Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the manufacturer’s
instructions.
CD-ROM Drive Safety Warning
CLASS 1 LASER PRODUCT
Heavy System
CAUTION! This server system is heavy. Ask for assistance when moving or
carrying the system.
This product is equipped with a three-wire power cable and plug for the user’s
safety. Use the power cable with a properly grounded electrical outlet to avoid
electrical shock.

1-
This chapter describes the key features
of ESC2000. It includes the product
overview and general specications.
Chapter 1
Product introduction

Chapter 1: Product introduction1-2
1.1 Key features
ASUS ESC2000 is not only a server with exible expandability and high-capacity
storage but also a dual processor personal super computer supporting dual GPU
computing cards.
Versatile Applications
• Cost-performance 2-way Intel Xeon system for small & medium business
• PCI-E 2.0 x16 slot reserved for professional graphic card usage
• Optional ASUS unique MIO audio card support
Expandable for Growing Business
• Up to four SAS/SATA HDDs for storage demanding applications
• Hot-swap storage bay design for online expansion
Quiet & Power-saving
• Adopt 80+ high efciency power supply
• Support DDR3 has higher transfer speed and lower power consumption
• Intelligent fan technology has low acoustic and effective system cooling
Wide Memory Choices
• 18-DIMM slots support latest DDR3 1333/1066 Reg./Unbuffered ECC memory
modules
ASUS PIKE Technology & Flexible I/O Expansion
• Easily upgradable to support SAS storage for better I/O performance
• Total RAID solution without additional effort for verication

ASUS ESC2000 1-3
1.2 System overview
1
2
3
79
8
6
5
4
10
10
11
Items
1. Central processing unit (CPU)
2. CPU heatsink and fan
3. System memory
4. Hard disk drives
5. PIKE 1064E/1068E/1078/6480/2008/2008 IMR module (optional)
6. Graphics card
7. ASUS Server management board (optional)
8. Single power supply
9. System fan
10. Rackmount rail kit (optional)
11. Optical drive (optional)

Chapter 1: Product introduction1-4
1.3 Front panel features
Optical drive
Empty 5.25-inch
bays (optional)
Power button
Reset button
Message LED
HDD access LED
Power LED
USB 2.0 ports
Security lock
4-bay HDD cage
LAN1 LED
LAN2 LED
Headphone output
jack*
Microphone jack*
*The audio jacks function only with an optional MIO audio card.

ASUS ESC2000 1-5
1.4 Rear panel features
• The ports for the PS/2 keyboard, PS/2 mouse, serial port, USB, VGA, and
Gigabit LAN do not appear on the rear panel if motherboard is not present.
• *The port is for ASUS ASMB4-iKVM controller card only.
1100W Single power
supply
Power connector
Expansion slots
PS/2 keyboard port
USB 2.0 ports
Serial port
VGA port
Chassis intrusion
switch
Gigabit LAN port 1
Chassis lock
120mm x 38mm
system fan
PS/2 mouse port
Gigabit LAN port 2
LAN port 3*

Chapter 1: Product introduction1-6
1.5 Systemspecications
Model Name ESC2000
Processor / System Bus
2 x Socket LGA1366
Intel® Xeon X5600 series processors (95W)
Intel® Xeon E5600 series processors (80W)
Intel® Xeon L5600 series processors (60W/40W)
Intel® Xeon X5500 series processors (95W)
Intel® Xeon E5500 series processors (80W)
Intel® Xeon L5500 series processors (60W/38W)
QPI 4.8 / 5.86 / 6.4 GT/s
Core Logic Intel® AC5520 (36D)
Intel®ICH10R I/O controller
Memory
Total Slots 18 (3-channel per CPU, 9 DIMM per CPU)
Capacity Maximum up to 144GB (RDIMM)
Maximum up to 48GB (UDIMM)
Memory Type DDR3 800 / 1066 / 1333 / Reg DIMM / Unbuffered
DIMM with ECC
Memory Size 1GB, 2GB, 4GB and 8GB (RDIMM)
1GB, 2GB and 4GB (UDIMM)
Expansion Slots
Total PCI/PCI-X/
PCI-E Slots 6
Slot Type
- Slot 1: PCI-E x8 (G1 x4 link) (Auto disabled if
PIKE slot is occupied)
- Slot 2: PCI 32
- Slot 3: PCI-E x16 (G2 x16 link) (Auto switch to
x8 link if slot 4 is occupied)
- Slot 4: PCI-E x16 (G2 x8 link)
- Slot 5: PCI-E x16 (G2 x16 link)
- Slot 6: PCI-E x16 (Gen2 x16 link) (Auto
disabled if slot 5 is occupied, MIO supported)
Additional Slot 1 1 x PIKE slot for storage expansion
Additional Slot 2 1 x MIO slot for Audio
Graphics
Onboard VGA Aspeed AST2050 8MB
CUDA Support Up to 2 x NVIDIA® Tesla™ C2050/C2070 or
1 x Tesla™ C1060 + 1 x Quadro™ Card
Multi-GPU
Support
Supports ATI® CrossFireX™ technology, up to
Dual CrossFireX™
(continued on the next page)

ASUS ESC2000 1-7
*Specicationsaresubjecttochangewithoutnotice.
Storage
SATA Controller
Intel®ICH10R:
- 6 x SATA2 300MB/s ports
- Intel®Matrix Storage (for Windows only)
- Supports software RAID 0, 1, 5 & 10
LSI®MegaRAID (for Linux / Windows):
- Supports software RAID 0, 1 & 10
SAS Controller
Optional:
ASUS PIKE 1064E 4-port SAS RAID card
ASUS PIKE 1068E 8-port SAS RAID card
ASUS PIKE 1078 8-port SAS HW RAID card
ASUS PIKE 6480 8-port SAS RAID card
ASUS PIKE 2008 8-port SAS2 6G RAID card
ASUS PIKE 2008/IMR 8-port SAS2 6G RAID card
HDD Bays
I = internal
A or S = hot-
swappable
4 x Hot-swap 3.5” HDD Bays
Networking LAN 1 x Dual Port Intel® 82576EB (VMDq) + 1 x Mgmt
LAN
Auxiliary Storage FDD / CD /
DVD
3 x 5.25” media bays (Option: NO ODD / DVD-ROM
/ DVD-RW)
Onboard I/O
1 x External serial port
3 x RJ-45 ports (1 for ASMB4-iKVM)
4 x USB 2.0 ports (Front x 2, Rear x 2)
1 x Internal A type USB port
1 x VGA port
1 x PS/2 keyboard port
1 x PS/2 mouse port
OS Support
Windows® XP / Vista / 7 32 / 64-bit
Windows® Server 2008 R2
Windows® Server 2008 Enterprise 32 / 64-bit
Windows® Server 2003 R2 Enterprise 32 / 64-bit
RedHat® Enterprise Linux AS5.4 / 5.5 32 / 64-bit
SuSE® Linux Enterprise Server 11 32 / 64-bit
(Subject to change without any notice)
Anti-virus Software Optional anti-virus CD pack
Dimension (HH x WW x DD) 445mm x 217.5mm x 545mm
Net Weight Kg (CPU, DRAM &
HDD not inclu ded) 20 Kg
Power Supply 1100W (80+ Gold) Single Power Supply
Power Rating Input: 100-240Vac, 15-8A, 50-60Hz, Class I
Environment
Operation temperature: 10°C–35°C
Non operation temperature: -40°C–70°C
Non operation humidity: 20%–90% ( Non-
condensing)

Chapter 1: Product introduction1-8

1-
This chapter lists the key components
and optional accessories for the server
system.
Chapter 2
Components

Chapter 2: Components2-2
2.1 Upgrading CPU and CPU heatsink
The ASUS ESC2000 supports 1–2 Quad-core Intel® Xeon® X5500 / E5500 / L5500
series processor.
We recommend to install CPUs with the same frequency.
5
2
6
1
4
3
Order P/N Description
90-S000U08Y1T Six-Core Intel Xeon X5670, 2.93G, QPI 6.4GT/s, 12MB L2
(with Heatsink)
90-S000U08X1T Six-Core Intel Xeon X5660, 2.80G, QPI 6.4GT/s, 12MB L2
(with Heatsink)
90-S000U08W1T Six-Core Intel Xeon X5650, 2.66G, QPI 6.4GT/s, 12MB L2
(with Heatsink)
90-S000U08V1T Quad-Core Intel Xeon E5640, 2.66G, QPI 5.86GT/s, 12MB L2
(with Heatsink)
90-S000U08U1T Quad-Core Intel Xeon E5630, 2.53G, QPI 5.86GT/s, 12MB L2
(with Heatsink)
90-S000U08T1T Quad-Core Intel Xeon E5620, 2.40G, QPI 5.86GT/s, 12MB L2
(with Heatsink)
90-S000U0740T Quad-Core Intel Xeon X5570, 2.93G, QPI 6.4GT/s, 8MB L2
(with Heatsink)
90-S000U0750T Quad-Core Intel Xeon X5560, 2.80G, QPI 6.4GT/s, 8MB L2
(with Heatsink)
90-S000U0760T Quad-Core Intel Xeon X5550, 2.66G, QPI 6.4GT/s, 8MB L2
(with Heatsink)
90-S000U0770T Quad-Core Intel Xeon E5540, 2.53G, QPI 5.86GT/s, 8MB L2
(with Heatsink)
90-S000U0780T Quad-Core Intel Xeon E5530, 2.40G, QPI 5.86GT/s, 8MB L2
(with Heatsink)
90-S000U0790T Quad-Core Intel Xeon E5520, 2.26G, QPI 5.86GT/s, 8MB L2
(with Heatsink)
90-S000U07A0T Quad-Core Intel Xeon E5506, 2.13G, QPI 4.8GT/s, 4MB L2
(with Heatsink)
90-S000U07B0T Quad-Core Intel Xeon E5504, 2.00G, QPI 4.8GT/s, 4MB L2
(with Heatsink)
90-S000U07C0T Dual-Core Intel Xeon E5502, 1.86G, QPI 4.8GT/s, 4MB L2
(with Heatsink)

ASUS ESC2000 2-3
2.2 Upgrading system memory
The motherboard comes with six (6) Double Data Rate 3 (DDR3) Dual Inline
Memory Modules (DIMM) sockets.
DIMM_D1
DIMM_E3
DIMM_E2
DIMM_E1
DIMM_F3
DIMM_F2
DIMM_F1
DIMM_D2
DIMM_D3
1
1
2
DIMM_A3
DIMM_A2
DIMM_A1
DIMM_B3
DIMM_B2
DIMM_B1
DIMM_C3
DIMM_C2
DIMM_C1
1
1
2

Chapter 2: Components2-4
Memory population table
For UDIMM and Quad Ranks RDIMM:
CPU1Conguration
DIMM_A3 DIMM_A2 DIMM_A1 DIMM_B3 DIMM_B2 DIMM_B1 DIMM_C3 DIMM_C2 DIMM_C1
1 DIMM -- -- -- -- -- -- -- --
2 DIMMs -- -- -- -- -- -- --
3 DIMMs -- -- -- -- -- --
4 DIMMs -- -- -- -- --
5 DIMMs -- -- -- --
6 DIMMs -- -- --
CPU2Conguration
DIMM_D3 DIMM_D2 DIMM_D1 DIMM_E3 DIMM_E2 DIMM_E1 DIMM_F3 DIMM_F2 DIMM_F1
1 DIMM -- -- -- -- -- -- -- --
2 DIMMs -- -- -- -- -- -- --
3 DIMMs -- -- -- -- -- --
4 DIMMs -- -- -- -- --
5 DIMMs -- -- -- --
6 DIMMs -- -- --
For RDIMM (Single Rank, Dual Ranks):
CPU1Conguration
DIMM_A3 DIMM_A2 DIMM_A1 DIMM_B3 DIMM_B2 DIMM_B1 DIMM_C3 DIMM_C2 DIMM_C1
1 DIMM -- -- -- -- -- -- -- --
2 DIMMs -- -- -- -- -- -- --
3 DIMMs -- -- -- -- -- --
4 DIMMs -- -- -- -- --
5 DIMMs -- -- -- --
6 DIMMs -- -- --
7 DIMMs -- --
8 DIMMs
9 DIMMs
CPU2Conguration
DIMM_D3 DIMM_D2 DIMM_D1 DIMM_E3 DIMM_E2 DIMM_E1 DIMM_F3 DIMM_F2 DIMM_F1
1 DIMM -- -- -- -- -- -- -- --
2 DIMMs -- -- -- -- -- -- --
3 DIMMs -- -- -- -- -- --
4 DIMMs -- -- -- -- --
5 DIMMs -- -- -- --
6 DIMMs -- -- --
7 DIMMs -- --
8 DIMMs --
9 DIMMs

ASUS ESC2000 2-5
Order P/N Description
90-S000I0310T 2GB DDR3 1333 Reg. ECC (10 in 1)
90-S000I0550T 4GB DDR3 1333 Reg. ECC (10 in 1)
90-S000I0560T 8GB DDR3 1333 Reg. ECC (10 in 1)
90-S000I0580T 4GB DDR3 1333 Reg. ECC (10 in 1)
90-S000I0590T 8GB DDR3 1066 Reg. ECC (100 in 1)

Chapter 2: Components2-6
2.3 Upgrading hard disk drives
The system supports four hot-swap SATAII/SAS hard disk drives.
We recommend that you install identical drives of the same model and capacity
for RAID conguration.
Order P/N Description
90-S000H6230T 146GB SAS 15000 rpm with tray
90-S000H6220T 300GB SAS 15000 rpm with tray
90-S000H6440T 450GB SAS 15000 rpm with tray
90-S000H6260T 500GB SATAII 7200 rpm with tray
90-S000H6240T 1TB SATAII 7200 rpm with tray

ASUS ESC2000 2-7
2.4 Replacing hard disk drive cage

Chapter 2: Components2-8
2.5 Installing ASUS PIKE SAS RAID card
The ASUS PIKE SAS RAID card allows users to create SAS RAID sets from SAS
hard disk drives connected to the SAS connectors on the motherboard.
A
2
3
4
5
B
C
D
B
A
C
D
1
1. Install the iButton*.
2. Insert the PIKE SAS RAID card into the PIKE card slot.
3. Remove the SATAII/SAS cables from the onboard SATA connectors.
4. Connect the SATAII/SAS cables to the SAS1–4 connectors on the
motherboard and the CON1–4 connectors on the SATAII/SAS backplane
board*.
5. Move the SGPIO_SEL1 jumper on the SATAII/SAS backplane to 2–3.
* PIKE 1078 module won’t function if the iButton is not installed.
Order P/N Description
90-C1SCM0-00UAY00Z PIKE 1064E (4-port SAS support Firmware RAID 0,1,1E)
90-C1SCN5-00UAY10Z PIKE 1078 (8-port SAS support Hardware RAID 0,1,10,5,50,6,60)
90-C1SDB0-00XBN00Z
(10 in 1) PIKE 6480 (8-port SAS support Firmware RAID 0,1,10,5)
90-C1SCU0-00UAY00Z PIKE 1068E (8-port SAS support Firmware RAID 0,1,1E)
90-C1SE10-00UAY00Z PIKE 2008 (8-port SAS 6G support Firmware RAID 0,1,1E)
