DISASSEMBLYPROCEDURE
2-1
Chapter
2
SW1 Disassembly
Procedure
Pleasefollowthe informationprovidedinthissectiontoperform
thecompletedisassemblyprocedureofthenotebook.Besure
tousepropertoolsdescribedbefore.
W1SeriesNotebook consistsofvariousmodules.Thischapterdescribesthe
proceduresforthecompletenotebook disassembly.Inaddition,inbetween
procedures,thedetaileddisassemblyprocedureofindividualmoduleswillbe
provided foryour service needs.
Thedisassemblyprocedureconsistsofthefollowingsteps:
•BatteryModule
•KeyboardModule
•LCDModule
•ODD Module
•HDD Module
•CPUModule
•MemoryModule
•Top Cover Module
•MainBoardModule
S
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

DISASSEMBLYPROCEDURE
2-2
Batterymodule
TheillustrationbelowshowshowtoremovetheBatteryModule.
Turnthenotebookover,unlocklatchesandremovetheBatterypackfrombottom
side ofthenotebook.
. KeyboardModule
TheillustrationbelowshowshowtoremovetheK/Bcover andKeyboardPlate.
RemovingK/BCover
1. UnclenchK/BCoverat red loopinthechart anddriveup it.
RemovingK/B
1. CarefullyseparateKeyboardPlatefromTopCoverinthedirectionofarrowin
thechart.
2. DisconnectK/BCablefromMainBoard.
K/BREMOVAL
BATTERY
K/B MODULE
K/BCOVER
REMOVAL
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

DISASSEMBLYPROCEDURE
2-3
LCD module
TheillustrationsbelowshowhowtoremoveanddisassembletheLCDModule.
ThemodulecontainsLCDPanel,InverterBoard,LCDHingeBracket,Hinge
Cover,LCDBezelandLCDCover.
RemovingLCDModule
1. Release4pcsscrewonBaseDoor.
2. PulloutAntennaConn.
3. Release2pcsscrewonrear BaseCover.
4. Release2pcsscrewonsideBaseCover.
5. ReleasethescrewofLCDgroundcable.
6. PulloutAntennaCable,MICPhoneCable, LCDCable&LCDModule.
LCD
LCDREMOVAL
1
2
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

DISASSEMBLYPROCEDURE
2-4
Disassembling LCD Module
1. Remove6pcsrubberpadsandrelease6pcsscrewsfromtheLCDModule
2. OpeninsidefouredgesofLCDBezelwithyourfinger,andthenremove
LCDBezelfromLCDModule.
3. RemoveHingeCoverL&R.
4. Release4pcsscrewsfromLCDPaneland LCDCover.
5. DisconnectleftandrightcableontheInverterboard.
LCD
DIS-ASSEMBL
Y
2
3
4
6
5
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

DISASSEMBLYPROCEDURE
2-5
6. DisassembleLCDPaneland release4pcsscrewonthebothLCDBracket.
1,2
3
4
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

DISASSEMBLYPROCEDURE
2-6
ODD Module
TheillustrationsbelowshowhowtoremovetheODD Modulefromthenotebook.
RemovingODD Module
1. Release1pcsscrewontherearBaseCover.
2. Pull outtheODD Modulefrombottomsideofnotebook.
3. Release2pcsscrewontheODD Bracket.
5
2
ODDMODULE
ODDMODULE
REMOVAL
1
6
3
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

DISASSEMBLYPROCEDURE
2-7
HDD Module
TheillustrationsbelowshowhowtoremovetheHDD Modulefromthenotebook.
RemovingHDD Module
1. Release2pcsscrewsfrombottomofnotebook.
2. PullouttheHDD modulefromnotebook.
MemoryModule
TheillustrationsbelowshowhowtoremovetheMemorymodulefromthenotebook.
TheSW1SeriesNotebookcomesstandardwithoutmemoryonboard.
RemovingMemorymodule
Ifthereisanexistingmemory, removeit byopeningthelatches, whichwillpop
themoduleuptoa45°angle,and thenpulling outthemoduleinthatangle.
HDDMODULE
REMOVAL
HDDMODULE
1
MEMORY
REMOVAL
MEMORY
REMOVAL
2
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

DISASSEMBLYPROCEDURE
2-8
CPU Module
TheillustrationsbelowshowhowtoremovetheCPUmodulefromthenotebook.
ThemodulecontainsCPU,CPUThermalPadandCPUThermal Module.
RemovingCPU
1. Release2pcsscrewon Fan,pulloutFanCableandremoveFanModule.
2. Release4pcsscrewwith4,3,2,1orderon theCoolerandpull outCooler.
CPU
CPUREMOVAL
1
2
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

DISASSEMBLYPROCEDURE
2-9
3. TounlockCPUwithminusscrewdriver andfollowthedirectionofarrowbelow.
4. CarefullypulloutCPUupwardswithyourhand.
TOPCovermodule
Theillustrationsbelowshowhowtodisassembleand removetheTopCover
Moduleof thenotebook.ThemodulecontainstheTopCoveritselfand Touch
PadModule.
RemovingTopCoverModule
1. Release7pcsscrewsontheBase.
2. Release8pcsscrewon theTop.
3. RemovetheTopCover fromabovesideofTop Cover.
TOPCOVER
MODULE.
TOPCOVER
MODULE
1
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

DISASSEMBLYPROCEDURE
2- 10
RemovingMotherboardmodule
1. Release7pcsscrewsontheMainBoard.
2. RemoveHDD bracket&Modemcable.
3. PulloutDB/BandpulloutSpeakerR.
4. PulloutM/BModulecarefullyfromrightsideintheBaseCovertoremove
DVI orCRTconnectorandModemConnector,andremove1394Connector
andAudioJacktoseparatetheM/BfromBaseCover.
5. PulloutSpeakerLandremoveIO/B cable&PowerJackcable.
M/BMODULE
REMOVAL
2
1
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

DISASSEMBLYPROCEDURE
2- 11
4
1
RemoveIO
boardand
speaker
