Asus RT-AX92U User manual

RT-AX92U
Wireless AX6100 Tri band Gigabit Router
Quick Start Guide
APAC15956 / Revised Edition V4 / September 2019

Table of Contents
English.......................................................................................................................................... 3
󰰋 ..................................................................................................................................... 13
簡體中文 ..................................................................................................................................... 23
Bahasa Indonesia....................................................................................................................... 33
 
Bahasa Melayu........................................................................................................................... 53
ไทย ............................................................................................................................................. 63
Tiếng Việt..................................................................................................................................... 73

3
English
1
Plug the adapter into the DC-IN port, and press the power button.
2
The Power, 2.4GHz and 5GHz LEDs will light up when your hardware is ready.
Hardware Explanations
Button and Port Explanations
RESET BUTTON
Reset the system to its factory defaults.
WAN PORT
Connect your modem to this port with a network cable.
LAN PORT 1-4
Connect your PC to a LAN port with a network cable.
WPS
button
Power
button
DC-IN
port
WAN
port LAN port 1-4
Reset
button
USB 2.0
port
USB 3.0
port
DC Power adapter DC Output: +19V with max 1.75A current
Operating Temperature 0~40oC Storage 0~70oC
Operating Humidity 50~90% Storage 20~90%
Specications:

4
English
Preparing to setup a standalone router
01
BEFORE SETTING
1
Go to ONE ROUTER SETUP STEPS.
ONE ROUTER SETUP
Preparing to setup an AiMesh Wi-Fi system
02
1
Two (2) ASUS routers (models supporting AiMesh https://www.asus.com/AiMesh/).
2
Assign one as AiMesh router, and another one as AiMesh node.
** If you have multiple AiMesh routers, we recommend using the router with the highest specifications as your
AiMesh router and the others as AiMesh nodes.
3
Go to AiMesh SETUP STEPS.
AiMesh SETUP STEPS
AiMesh routerAiMesh node

5
English
ONE ROUTER SETUP STEPS
Prepare your Modem
01
1
Unplug the power of cable / DSL modem. If it
has a battery backup, remove the battery.
2
Connect your modem to the router with the
network cable provided.
3
Power on the modem. Plug modem to the
power outlet and power on.
WE SUGGEST...
Modem back
Modem back

6
English
4
Check the modem LED lights to ensure the
connection is active.
If you are using DSL for internet, you will need
your username / password from your Internet
service provider (ISP) to properly configure
your router.
Connect your Device
02
1
Power on the router.
Plug in and press the power button at the back of your router.
2
Check the WAN and 2.4GHz/5GHz LED lights to ensure the hardware connection is ready.
Modem front

7
English
3
Connect your PC to the router using an additional network cable.
Login and Connect
03
1
Open a web browser.
You will be redirected to the ASUS Setup Wizard. If not, navigate to http://router.
asus.com.

8
English
AiMesh SETUP STEPS
Prepare
01
Place your AiMesh router and node within 1-3 meters of each other during the
setup process.
1
Refer to ONE ROUTER SETUP STEPS to connect your AiMesh router to your PC
and modem, and then log in into the web GUI.
AiMesh node
02
Factory default status. Keep power on and standby for AiMesh system settings.
AiMesh router
03
within
1-3 meters
AiMesh router AiMesh node
AiMesh routerModem AiMesh node
Logout/Reboot
AiMesh Router
02 03

9
English
2
Go to Network Map page, click AiMesh icon and then Search for your extending
AiMesh node.
3
Click Search, it will automatically search for your AiMesh node. When the AiMesh
node shows on this page, click it to add it into the AiMesh system.
** If you cannot find any AiMesh node, please go to TROUBLE SHOOTING.

10
English
4
A message is displayed when synchronization is completed.
5
Congratulations! You will find the pages below show up when an AiMesh node has been
successfully added to the AiMesh network.
TROUBLESHOOTING
If your AiMesh router cannot find any AiMesh node nearby or synchronization fails,
please check the following and try again.
a
Move your AiMesh node closer to the AiMesh router ideally. Ensure that it is within 1-3
meters.
b
Your AiMesh node is powered on.
Successfully added RT-ABCDE to your AiMesh
system, it will take awhile to show up as connected
in the AiMesh router list.
OK

11
English
RELOCATION
Locate the AiMesh router and node at the best place.
THE BEST PERFORMANCE
NOTES: To minimize interference, keep the routers away from devices like cordless phones,
Bluetooth devices and microwave ovens.
We recommend that you place the routers in an open or spacious location.
ASUS ROUTER APP
Download free ASUS Router APP to set up and manage your router(s).

12
English
FAQ FREQUENTLY ASKED QUESTIONS
Q1
Does the AiMesh router support Access Point mode?
A: Yes. You can choose to set the AiMesh router as router mode or access
point mode. Please go to web GUI (http://router.asus.com), and go to the
page Administration > Operation Mode.
Q2
Could I set up wired connection between AiMesh routers (Ethernet backhaul)?
A: Yes. The AiMesh system supports both wireless and wired connection
between the AiMesh router and node to maximize throughput and stability.
AiMesh analyzes the wireless signal strength for each frequency band
available, and then determines automatically whether a wireless or wired
connection is the best to serve as the inter-router connection backbone.
1
Follow the setup steps to establish a connection between the AiMesh router and
node via Wi-Fi first.
2
Place the node in the ideal locations for best coverage. Run an Ethernet cable from
the LAN port of the AiMesh router to the WAN port of AiMesh node.
3
The AiMesh system will auto-select the best path for data transmission, whether
wired or wireless.

13
繁體中文

1
 將電源變壓器插入無線路由器的電源插孔（DC-IN），並按下電源按鈕。
2
 當您的路由器準備就緒後，電源指示燈、2.4GHz和5GHz指示燈將會亮起。
硬體說明
按鈕及插孔說明
重置按鈕
此按鈕可重置或回復系統至其初始設定。
WAN 連接埠
請使用網路線將您的數據機連接至此連接埠。
LAN 1-4 連接埠
請使用網路線將您的電腦連接至LAN連接埠。
WPS 按鈕
電源按鈕 電源插孔
（DC-IN）
WAN
連接埠 LAN 1-4 連接埠
重置按鈕
USB 2.0
連接埠
USB 3.0
連接埠
直流電源變壓器 DC輸出：+19V，最大電流1.75A
運作溫度 0~40°C 儲存溫度 0~70°C
運作濕度 50~90% 儲存濕度 20~90%
規格：

14
繁體中文
準備設定一台單獨的路由器
01
設定前

1
 請至一台路由器的設定步驟章節。
設定一台路由器
準備設定 AiMesh Wi-Fi 系統
02

1
 準備兩台華碩無線路由器（欲了解支援 AiMesh 的華碩無線路由器型號，請參考 https://www.
asus.com/tw/AiMesh/）。

2
 將一台路由器設定為AiMesh路由器，另一台設定為AiMesh節點。
 **若您有多台 AiMesh 路由器，建議您將擁有更高規格的路由器設定為 AiMesh 路由器，其他路由器設定為
AiMesh節點。

3
 請至AiMesh 設定步驟章節。
AiMesh 設定步驟
AiMesh路由器AiMesh節點

15
繁體中文
一台路由器的設定步驟
準備數據機
01

1
 拔除您的電纜/DSL數據機電源，若數據機內含
備用電池，請移除電池。

2
 使用隨附的網路線連接您的數據機與無線路由
器。

3
 開啟數據機，將數據機連接至電源插座並開機。
數據機後側
數據機後側
建議您......

16
繁體中文

4
 檢查數據機上的LED指示燈，確認已經連線。
若您使用DSL連線網際網路，需要向您的網路
服務供應商（ISP）取得登入名稱/密碼，以正
確設定您的無線路由器。
連接您的裝置
02

1
 開啟路由器電源：
 插入電源線並按下路由器後側的電源按鈕。

2
 檢查WAN和2.4GHz/5GHz指示燈是否亮起以確認硬體連線是否準備就緒。
數據機正面

17
繁體中文

3
 使用另一條網路線連接您的電腦與無線路由器。
登入並連線網路
03

1
 開啟網頁瀏覽器。
 您將進入ASUS設定精靈。若未出現此頁面，請手動輸入http://router.asus.com。

18
繁體中文
AiMesh 設定步驟
準備
01
設定過程中，請將AiMesh節點距離AiMesh路由器1-3公尺放置。

1
 請參照一台路由器的設定步驟章節連接您的AiMesh路由器和電腦、數據機，然後
登入網頁管理介面（webGUI）。
AiMesh 節點
02
原廠預設狀態。設定AiMesh系統時，請保持路由器處於通電及運作狀態。
AiMesh 路由器
03
1-3公尺內
AiMesh路由器AiMesh節點
AiMesh路由器數據機 AiMesh節點
登出 / 重啟
AiMesh 路由器
02 03

19
繁體中文

2
 前往網路地圖頁面，點選AiMesh圖示，然後點選搜尋以搜尋AiMesh節點。

3
 點選搜尋，路由器將自動搜尋您的AiMesh節點。當AiMesh節點顯示於此頁面時，
點選節點並將其新增至AiMesh系統。
 **若您無法搜尋到任何AiMesh節點，請查看疑難解答部分的內容。

20
繁體中文

4
 同步完成後，將出現如下資訊。

5
 恭喜！當AiMesh節點成功新增至AiMesh網路後，將顯示如下頁面。
疑難解答
若您的AiMesh路由器無法搜尋到任何附近的AiMesh節點或同步失敗，請檢查
以下兩點並重新搜尋。

a
 將您的AiMesh節點移至距AiMesh路由器更近的地方。請確認AiMesh節點距離AiMesh路
由器1-3公尺。
b
 AiMesh節點已開機。
成功將RT-ABCDE新增至您的AiMesh系統，稍後已連
線的裝置名稱將顯示於AiMesh路由器清單中。
確定
