Asus F1 Series Guide

T
H
R
R
O
O
H
S
1
:
8
W
E
N
.
S
0
LED projector
E-Manual
F1 Series

2
LED projector E-Manual
COPYRIGHT AND WARRANTY INFORMATION
No part of this manual, including the products and software described in it, may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except
documentation kept by the purchaser for backup purposes, without the express written permission of
ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the is
defaced or missing.
ASUS PROVIDES THIS MANUAL“AS IS”WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR
AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING
DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS
AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM
ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’benet, without intent to infringe.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL
USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE
CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY
ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND
SOFTWARE DESCRIBED IN IT.
Copyright © 2019 ASUSTeK COMPUTER INC. All Rights Reserved.
LIMITATION OF LIABILITY
Circumstances may arise where because of a default on ASUS’ part or other liability, you are entitled to
recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to
claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death) and
damage to real property and tangible personal property; or any other actual and direct damages resulted
from omission or failure of performing legal duties under this Warranty Statement, up to the listed contract
price of each product.
ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or
infringement under this Warranty Statement.
This limit also applies to ASUS’suppliers and its reseller. It is the maximum for which ASUS, its suppliers, and
your reseller are collectively responsible.
UNDER NO CIRCUMSTANCES IS ASUS LIABLE FOR ANY OF THE FOLLOWING: (1) THIRD-PARTY CLAIMS
AGAINST YOU FOR DAMAGES; (2) LOSS OF, OR DAMAGE TO, YOUR RECORDS OR DATA; OR (3) SPECIAL,
INCIDENTAL, OR INDIRECT DAMAGES OR FOR ANY ECONOMIC CONSEQUENTIAL DAMAGES (INCLUDING
LOST PROFITS OR SAVINGS), EVEN IF ASUS, ITS SUPPLIERS OR YOUR RESELLER IS INFORMED OF THEIR
POSSIBILITY.
SERVICE AND SUPPORT
Visit our multi-language web site at https://www.asus.com/support
E14384
First Edition
March 2019

LED projector E-Manual
3
Table of Contents
About this manual ............................................................................................. 5
Conventions used in this manual ............................................................... 6
Typography......................................................................................................... 6
Multi-language versions ................................................................................ 6
Safety precautions ............................................................................................. 7
Using your LED projector............................................................................... 7
Servicing and replacement of parts .......................................................... 7
Caring for your LED projector ...................................................................... 8
Proper disposal.................................................................................................. 8
Chapter 1: Knowing your LED projector
Features ...............................................................................................................10
Top view.............................................................................................................10
Front view..........................................................................................................12
Rear view ...........................................................................................................13
Left side .............................................................................................................14
Right side...........................................................................................................15
Bottom view .....................................................................................................16
Mounting your LED projector......................................................................17
Projecting les from a mounted position..............................................18
Ceiling mount hole details..........................................................................18
LED projector remote control......................................................................19
Replacing the battery ...................................................................................21
Remote control eective range.................................................................23
Chapter 2: Setting up
Operating your LED projector .....................................................................26
Connect the LED projector to the power adapter..............................26
Connect the LED projector to your device............................................28
Adjust the height of the LED projector...................................................32
Press the power button................................................................................34
Adjust the image focus.................................................................................35

4
LED projector E-Manual
Chapter 3: Using the onscreen display menu
Using your LED projector for the rst time.............................................38
Adjusting your LED projector's settings ..................................................39
Onscreen display menu options.................................................................40
Image .............................................................................................................40
Display .............................................................................................................41
Input .............................................................................................................42
System .............................................................................................................43
Turning o your LED projector....................................................................45
Using 3D glasses...............................................................................................46
Multi-language versions ..............................................................................47
Appendices
Federal Communications Commission Statement.............................50
Regional notice for California.....................................................................51
Global Environmental Regulation Compliance and Declaration .52
ASUS Recycling/Takeback Services..........................................................52
Specications for F1 series LED projector..............................................53
Supported PC Timings..................................................................................56

LED projector E-Manual
5
About this manual
This manual provides information about the hardware and software
features of your LED projector through the following chapters:
Chapter 1: Knowing your LED Projector
This chapter details the parts of your LED projector and its
accompanying remote control.
Chapter 2: Setting up
This chapter shows you how to set up your LED projector and
use its parts for input device connection.
Chapter 3: Using the onscreen display menu
This chapter talks about the features of your LED projector’s
onscreen display menu and how to navigate it using the control
panel.
Appendices
This section includes safety notices for your LED projector.

6
LED projector E-Manual
Conventions used in this manual
To highlight key information in this manual, some text are presented
as follows:
IMPORTANT! This message contains vital information that must be
followed to complete a task.
NOTE: This message contains additional information and tips that can
help complete tasks.
WARNING! This message contains important information that must
be followed to keep you safe while performing tasks and prevent
damage to your LED projector's data and components.
Typography
Bold = This indicates a menu or an item that must be selected.
Italic = This indicates sections that you can refer to in this manual.
Multi-language versions
Download other language versions of this E-Manual via this website:
https://www.asus.com/support

LED projector E-Manual
7
Safety precautions
Using your LED projector
• Refertothemanualandtakenoteofthesafetyinstructions
before operating your LED projector.
• Followthenotesandwarningsstatedintheusermanual.
• DonotplaceyourLEDprojectoronunevenorunstablesurfaces.
• DonotuseyourLEDprojectorinsmokyenvironments.Smoke
residue may cause build-up on critical parts and damage the
LED projector or decrease its performance.
• KeeptheLEDprojector’splasticpackagesoutofthereachof
children.
• DonotblockorplaceanythingneartheLEDprojector’s
ventilation holes. Doing so may cause internal heat build-up
that can degrade picture quality and damage the projector.
• EnsurethattheoperatingvoltageofyourLEDprojector
matches the voltage of your power source.
Servicing and replacement of parts
• DonotdisassembleorattempttoservicethisLEDprojectorby
yourself. Contact your local ASUS service center for assistance.
• WhenreplacingpartsofyourLEDprojector,purchaseitems
as specied by ASUS and contact your local service center for
assistance.

8
LED projector E-Manual
Caring for your LED projector
• SwitchothenunplugtheLEDprojectorfromthepoweroutlet
before cleaning it.
• WhencleaningtheLEDprojector’shousing,useacleansoft
cloth dampened with water or a mix of water and neutral
detergent. Wipe it dry using a soft dry cloth.
• Ensurethatthelensiscoolbeforecleaningit.Gentlywipethe
lens using a lens cleaning paper. Do not touch the lens with
your hands.
• Donotuseliquidoraerosolcleaners,benzene,orthinnerson
your LED projector.
• NeveroperatethisLEDprojectorimmediatelyaftermovingit
from a cold location. When the LED projector is exposed to a
drastic change in temperature, moisture may condense on the
lens and its other internal parts. To prevent this, use the unit two
(2) hours after an extreme or sudden change in temperature
occurs.
Proper disposal
Do not throw your LED projector in municipal waste. This
product has been designed to enable proper reuse of parts
and recycling. The symbol of the crossed out wheeled bin
indicates that the product (electrical, electronic equipment
and mercury-containing button cell battery) should not
be placed in municipal waste. Check local regulations for
disposal of electronic products.
Do not throw the battery in municipal waste. The symbol
of the crossed out wheeled bin indicates that the battery
should not be placed in municipal waste.

LED projector E-Manual
9
Chapter 1: Knowing your LED
projector
Chapter 1:
Knowing your LED
projector

10
LED projector E-Manual
Features
Top view

LED projector E-Manual
11
Control panel buttons
These buttons correspond to a specic LED projector setting
as indicated below.
Keystone Input Power
NOTE: In the event that your LED projector becomes
unresponsive, unplug the power cord and wait until your LED
projector shuts down.
Joystick
This joystick allows you to navigate the onscreen display
menu and select menu settings. This joystick also correspond
to specic LED projector settings as indicated below.
Open main menu / OK
(push center)
Adjust focus
(move up or down)
Adjust volume
(move left or right)
NOTE: For more information on using your LED projector’s
settings, refer to the Using the onscreen display menu section
in this manual.

12
LED projector E-Manual
Front view
T
H
R
R
O
O
H
S
1
:
8
W
E
N
.
S
0
Lens cover
The lens cover protects the lens from scratches and possible
dirt build-up.
IMPORTANT! Remove the lens cover before using your LED
projector.
Lens
The lens projects video or image les onscreen from your
input device.
WARNING! Do not touch the lens using your hands or any
sharp object.
Auto focus camera
This camera helps the LED projector with the auto focus
feature.

LED projector E-Manual
13
Power (DC) input port
Insert the bundled power adapter into this port to supply
power to your LED projector.
WARNING! The adapter may become warm to hot while in
use. Do not cover the adapter and keep it away from your
body while it is connected to a power source.
IMPORTANT! Use only the bundled power adapter to supply
power to your LED projector.
Remote sensor
The remote sensor detects signal from your LED projector’s
remote control, allowing you to access the LED projector’s
control panel from a distance of up to 8 meters and a
receiving angle of ±30
degrees.
HDMI ports
These ports are for the HDMI (High-Denition Multimedia
Interface) connectors. These port are HDCP compliant for HD
DVD, Blu-ray, and other protected content playback.
Rear view

14
LED projector E-Manual
Power output port
This power output port provides up to 5V/2A of output
voltage and current. You can connect your mobile device to
this port to keep it charged.
VGA port
This port allows you to connect your LED projector to other
VGA-compatible devices.
Audio output jack port
The audio output jack port allows you to connect your LED
projector to amplied speakers or headphones.
Air vents
The air vents allow cool air to enter and warm air to exit your
LED projector.
WARNING! Ensure that paper, books, clothing, cables, or other
objects do not block any of the air vents or else overheating
may occur.
Left side

LED projector E-Manual
15
Kensington® security slot
The Kensington® security slot allows you to secure your
LED projector using Kensington® compatible LED projector
security products.
Air vents
The air vents allow cool air to enter and warm air to exit your
LED projector.
WARNING! Ensure that paper, books, clothing, cables,
or other objects do not block any of the air vents or else
overheating may occur.
Right side

16
LED projector E-Manual
Bottom view
Built-in stand
This LED projector comes with a built-in stand that allows you
to adjust the height of the projector by either 5.7 degrees or
8.2 degrees.
Ceiling mount holes
Use these holes to connect the LED projector to a ceiling
mount.
Tripod socket
Connect the LED projector to a tripod using this socket.

LED projector E-Manual
17
Mounting your LED projector
Aside from using the LED projector as a tabletop device, you can also
mount it on the ceiling using the ceiling mount holes on its bottom
side.
IMPORTANT! Ask a specialist or your retailer for assistance when
mounting your LED projector to the ceiling. A qualied professional
should do the installation process.
NOTE:
• YoumayalsorefertotheScreensizeandprojectiondistancetable
section in this manual to specify the right distance for mounting
your LED projector on the ceiling.
• Keepareasonablespacebetweenthebracketandtheprojector
to allow for proper heat distribution.
• Inadditiontotheceilingmountkitandscrews,wealso
recommend using a metal bar or wire to hold the ceiling-mounted
LED projector for added protection and to prevent it from falling
due to natural causes such as earthquakes.
AURA RGB LED
The AURA RGB LED provides several lighting schemes for you
to customize your LED projector.
NOTE: For more details on customizing the AURA RGB LED,
refer to the Using the onscreen display menu section in this
manual.

18
LED projector E-Manual
Ceiling mount hole details
IMPORTANT! Ensure that the washers included in the ceiling mount
kit are placed between the ceiling mount and screw to protect your
LED projector and stabilize its position.
Projecting les from a mounted position
After mounting your LED projector, you need to change its image
position settings to ensure that les are automatically ipped and
projected correctly onscreen.
To change your image position settings:
1. Navigate to Display > Projection Position on your LED
projector.
2. Select Front Ceiling or Rear Ceiling to change the settings of
your LED projector.

LED projector E-Manual
19
LED projector remote control
NOTE: Actual appearance may vary depending on model.
Battery compartment
The battery compartment allows you to use CR2032 lithium
coin batteries to power your LED projector’s remote control.
NOTE: For more details on using the battery compartment, refer
to the Replacing the battery section in this manual.

20
LED projector E-Manual
Remote control buttons
These additional buttons allow you to use the LED projector
from a distance of up to 8 meters.
Power - Press this button to turn your LED projector
on or o.
Auto focus - Press this button to automatically focus
the image.
/
Back/Splendid - Press this button to go back to the
previous screen or select a Splendid mode for your
LED projector.
Keystone - Press this button to adjust the keystone
of your projection onscreen.
Input - Press this button to change the input source.
Volume down - Press this button to decrease the
volume.
Volume up - Press this button to increase the
volume.
Focus up/Up - Press this button to increase the
focus or move up.
Focus down/Down - Press this button to decrease
the focus or move down.
Left - Press this button to move left.
Right - Press this button to move right.
Menu/OK - Press this button to launch the menu or
conrm a menu selection.
NOTE: For more details on the onscreen display menu, refer to
the Using the onscreen display menu section in this manual.
