Asus ZenBeam E2 User manual

2 LED projector E-Manual
COPYRIGHT AND WARRANTY INFORMATION
No part of this manual, including the products and software described in it, may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language in any form or by any means, except
documentation kept by the purchaser for backup purposes, without the express written permission of
ASUSTeK COMPUTER INC. (“ASUS”).
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the is
defaced or missing.
ASUS PROVIDES THIS MANUAL “AS IS”WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED,
INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR
AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING
DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS
AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM
ANY DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’benet, without intent to infringe.
SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL
USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE
CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY
ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND
SOFTWARE DESCRIBED IN IT.
Copyright © 2021 ASUSTeK COMPUTER INC. All Rights Reserved.
LIMITATION OF LIABILITY
Circumstances may arise where because of a default on ASUS’ part or other liability, you are entitled to
recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to
claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death) and
damage to real property and tangible personal property; or any other actual and direct damages resulted
from omission or failure of performing legal duties under this Warranty Statement, up to the listed contract
price of each product.
ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or
infringement under this Warranty Statement.
This limit also applies to ASUS’suppliers and its reseller. It is the maximum for which ASUS, its suppliers, and
your reseller are collectively responsible.
UNDER NO CIRCUMSTANCES IS ASUS LIABLE FOR ANY OF THE FOLLOWING: (1) THIRD-PARTY CLAIMS
AGAINST YOU FOR DAMAGES; (2) LOSS OF, OR DAMAGE TO, YOUR RECORDS OR DATA; OR (3) SPECIAL,
INCIDENTAL, OR INDIRECT DAMAGES OR FOR ANY ECONOMIC CONSEQUENTIAL DAMAGES (INCLUDING
LOST PROFITS OR SAVINGS), EVEN IF ASUS, ITS SUPPLIERS OR YOUR RESELLER IS INFORMED OF THEIR
POSSIBILITY.
SERVICE AND SUPPORT
Visit our multi-language web site at https://www.asus.com/support/

LED projector E-Manual 3
Table of Contents
About this manual ............................................................................................. 5
Conventions used in this manual ............................................................... 6
Typography......................................................................................................... 6
Multi-language versions ................................................................................ 6
Safety precautions ............................................................................................. 7
Using your LED projector............................................................................... 7
Servicing and replacement of parts .......................................................... 7
Caring for your LED projector ...................................................................... 8
Proper disposal.................................................................................................. 9
Chapter 1: Knowing your LED projector
Features ...............................................................................................................12
Top View.............................................................................................................12
Extended features ..........................................................................................15
Flashlight ..............................................................................................................15
Emergency light mode....................................................................................16
Front View..........................................................................................................17
Rear View ...........................................................................................................18
Right View .........................................................................................................20
Bottom View.....................................................................................................21
Chapter 2: Setting up
Operating your LED projector .....................................................................24
Connect the LED projector to the power adapter..............................24
AC power plug requirements........................................................................26
Connect the LED projector to your device............................................27
Press the power button................................................................................28
Adjust the focus ring .....................................................................................29
Portrait mode...................................................................................................30
Screen size and projection distance table................................................31

4 LED projector E-Manual
Chapter 3: Using the LED projector
Using your LED projector for the rst time.............................................34
Operating the onscreen display menu.....................................................35
Using the Wi-Fi dongle...................................................................................36
For Android devices.......................................................................................37
For iOS devices ................................................................................................38
Onscreen display menu options.................................................................40
Volume .............................................................................................................40
Input .............................................................................................................40
Splendid.............................................................................................................40
Brightness..........................................................................................................40
Contrast .............................................................................................................41
Keystone ............................................................................................................41
Projector Position ...........................................................................................41
Setup .............................................................................................................42
Information.......................................................................................................43
Turning o your LED projector....................................................................44
Appendices
Federal Communications Commission Statement ..............................46
Regional notice for California ......................................................................47
Canadian Department of Communications Statement.....................47
Global Environmental Regulation Compliance and Declaration ...48
ASUS Recycling/Takeback Services ...........................................................48
HDMI Connectivity ..........................................................................................49
Supported PC Timings....................................................................................50
Specications for E2 LED projector............................................................52

LED projector E-Manual 5
About this manual
This manual provides information about the hardware and software
features of your LED projector through the following chapters:
Chapter 1: Knowing your LED Projector
This chapter details the parts of your LED projector.
Chapter 2: Setting up
This chapter shows you how to set up your LED projector and
use its parts for input device connection.
Chapter 3: Using the LED projector
This chapter describes the features of the LED projector’s control
panel buttons and how to use them to launch the functions of
your LED projector.
Appendices
This section includes safety notices for your LED projector.

6 LED projector E-Manual
Conventions used in this manual
To highlight key information in this manual, some text are presented
as follows:
IMPORTANT! This message contains vital information that must be
followed to complete a task.
NOTE: This message contains additional information and tips that can
help complete tasks.
WARNING! This message contains important information that must
be followed to keep you safe while performing tasks and prevent
damage to your LED projector's data and components.
Typography
Bold = This indicates a menu or an item that must be selected.
Italic = This indicates sections that you can refer to in this manual.
Multi-language versions
Download other language versions of this E-Manual via this website:
https://www.asus.com/support/

LED projector E-Manual 7
Safety precautions
Using your LED projector
• Refer to the manual and take note of the safety instructions
before operating your LED projector.
• Follow the notes and warnings stated in the user manual.
• DO NOT place your LED projector on uneven or unstable
surfaces.
• DO NOT use your LED projector in smoky environments. Smoke
residue may cause build-up on critical parts and damage the
LED projector or decrease its performance.
• DO NOT use damaged power cords, accessories, and other
peripherals with your LED projector.
• Keep the LED projector’s plastic packages out of the reach of
children.
• DO NOT block or place anything near the LED projector’s
ventilation holes. Doing so may cause internal heat build-up
that can degrade picture quality and damage the projector.
• Ensure that the operating voltage of your LED projector
matches the voltage of your power source.
Servicing and replacement of parts
• DO NOT disassemble or attempt to service this LED projector by
yourself. Contact your local ASUS service center for assistance.
• Risk of explosion if battery is replaced by an incorrect type.
Dispose used batteries according to safety instructions and
contact your local ASUS service center for assistance.
• When replacing parts of your LED projector, purchase items
as specied by ASUS and contact your local service center for
assistance.

8 LED projector E-Manual
Caring for your LED projector
• Switch o then unplug the LED projector from the power outlet
before cleaning it.
• When cleaning the LED projector’s housing, use a clean soft
cloth dampened with water or a mix of water and neutral
detergent. Wipe it dry using a soft dry cloth.
• Ensure that the lens is cool before cleaning it. Gently wipe the
lens using a lens cleaning paper. DO NOT touch the lens with
your hands.
• DO NOT use liquid or aerosole cleaners, benzene, or thinners on
your LED projector.
• Never operate this LED projector immediately after moving it
from a cold location. When the LED projector is exposed to a
drastic change in temperature, moisture may condense on the
lens and its other internal parts. To prevent this, use the unit two
(2) hours after an extreme or sudden change in temperature
occurs.
• DO NOT use a spray containing ammable gases to clean the
lens. This may cause a re due to excessive heat inside the
projector.
• DO NOT clean the lens while the projector is warming up as this
may cause the lens’ surface lm to peel o.
• DO NOT use a hard object to wipe or tap the lens.

LED projector E-Manual 9
Proper disposal
DO NOT throw your LED projector in municipal waste.
This product has been designed to enable proper
reuse of parts and recycling. The symbol of the crossed
out wheeled bin indicates that the product (electrical,
electronic equipment and mercury-containing button
cell battery) should not be placed in municipal waste.
Check local regulations for disposal of electronic
products.
DO NOT throw the battery in municipal waste. The
symbol of the crossed out wheeled bin indicates that
the battery should not be placed in municipal waste.

LED projector E-Manual 11
Chapter 1: Knowing your LED
projector
Chapter 1:
Knowing your LED
projector

12 LED projector E-Manual
Features
Top View
Control panel buttons
The control panel buttons allow you to navigate the onscreen display
menu. Individually, these buttons also correspond to a specic LED
projector setting as indicated below.
Select
(move up or down)
Adjust volume
(move left or right)
Back/Splendid Input
NOTE: For more information on using the control panel buttons to
access your LED projector’s settings, refer to Chapter 3: Using the LED
projector.

LED projector E-Manual 13
Power indicator and battery status indicator
This LED indicator indicates the following scenarios for your LED
projector:
• It lights up when the LED projector is powered on.
• It lights up as either green or red depending on the battery
charge status.
For details on how this LED indicator functions as a battery
status indicator, refer to the following table:
Color Status
Solid Green The LED projector is plugged to a power source,
running on battery mode and the battery
power is more than 25%, or running in power
bank mode.
Solid Red The LED projector is running on battery mode
only and the battery power is not more than
25%.
Blinking Red The temperature of the LED projector
is too high and will lower its brightness
automatically. The LED projector will shut down
if the temperature is still too high to prevent
overheating.
Blinking Green The LED projector is currently used as a power
bank and charging your mobile device.
Blinking Red and
Green
A system error occurred. The LED projector will
shutdown automatically.

14 LED projector E-Manual
Battery charge indicator
This LED indicator lights up when the LED projector is plugged to a
power source using its power adapter.
IMPORTANT! Use only the bundled power adapter to charge
the battery pack and supply power to your LED projector.

LED projector E-Manual 15
Extended features
Your LED projector also have stand-alone features that are launched
by pressing the Back/Splendid button while your LED projector is
on battery mode.
NOTE:
• These feature are only available when you disconnect all
peripherals and the Wi-Fi dongle from the LED projector.
• To turn o or switch between the ashlight and emergency light
feature of your LED projector, just press the Back/Splendid
button until your preferred lighting feature is disabled or enabled.
IMPORTANT! Ensure that your LED projector is charged and can run
on battery mode before enabling these features. Battery time varies
depending on usage.
Flashlight
The LED projector ashes a steady white light when you use this
feature.
Back/Splendid
button
To use your LED projector as a ashlight:
1. Disconnect all peripherals and the Wi-Fi dongle from your LED
projector then press the power button to turn it on.

16 LED projector E-Manual
Emergency light mode
The LED projector ashes a blinking white light when you use this
feature.
Back/Splendid
button
To use your LED projector as an emergency light:
1. Disconnect all peripherals and the Wi-Fi dongle from your LED
projector then press the power button to turn it on.
2. Press the Input button and change the input source to HDMI.
3. Press repeatedly until the LED projector ashes a blinking
white light.
2. Press the Input button and change the input source to HDMI.
3. Press repeatedly until the LED projector ashes a steady
white light.

LED projector E-Manual 17
Front View
Lens
The lens projects video or image les onscreen from your input
device.
WARNING!
• DO NOT touch the lens with your hands or any sharp object.
• DO NOT look directly into the lens.

18 LED projector E-Manual
Power button
Long press this power button to turn on or turn o your LED projector.
Short press this button to turn on or turn o power bank mode.
Manual reset hole
If your LED projector is unresponsive, insert a straightened paper clip
into this hole to turn o your LED projector, then press the power
button to turn on your LED projector again.
Power (DC) input port
Insert the bundled power adapter into this port to charge the battery
pack and supply power to your LED projector.
IMPORTANT! Use only the bundled power adapter to charge
the battery pack and supply power to your LED projector.
WARNING! The adapter may become warm to hot while in use.
DO NOT cover the adapter and keep it away from your body
while it is connected to a power source.
Rear View

LED projector E-Manual 19
HDMI port
This port is for the HDMI (High-Denition Multimedia Interface)
connectors. These port are HDCP compliant for HD DVD, Blu-ray, and
other protected content playback.
Audio output jack port
The audio output jack port allows you to connect your LED projector
to headphones.
Power output/Wi-Fi dongle port
This power output port provides up to 5V/1A of output voltage and
current. You can connect your mobile device to this port to keep it
charged while using it with your LED projector.
You can also insert the bundled Wi-Fi dongle that allows you to mirror
or cast content from your mobile device.
NOTE: For more details, refer to the Using the Wi-Fi dongle
section in this manual.

20 LED projector E-Manual
Focus ring
The focus ring allows you to adjust the image focus of your LED
projector.
Air vents
The air vents allow cool air to enter and warm air to exit the LED
projector.
WARNING! Ensure that paper, books, clothing, cables, or other
objects do not block any of the air vents or else overheating
may occur.
Right View

LED projector E-Manual 21
Bottom View
Tripod socket
Attach the LED projector to a tripod using this socket.
Adjustable foot
Rotate this adjustable foot to adjust the height of the LED projector.
