EN Instructions for use EN 3 - EN 24
Pictograms used
Important information
Tip

EN 3
CONTENTS
Your microwave oven
Introduction 4
Description of the appliance 5
Guide rails/Telescopic guide rails 5
Accessories 5
Door 5
Cooling fan 6
Control panel 6
Navigation and control 7
First use
Before first use 9
Use
Microwaves 11
Guidelines for cookware 12
Please note! 13
Explanation of the knobs and the keys 13
Description of the functions 15
Plus menu 16
Operation
Using the appliance functions 17
Settings
Settings menu 19
Maintenance
Cleaning the appliance 20
Cleaning function (Steam clean) 20
Removing and cleaning the guide rails 21
Replacing the oven lamp 21
Malfunctions
General 22
Environmental aspects
Disposal of the appliance and packaging 24

EN 4
YOUR MICROWAVE OVEN
Introduction
Congratulations on choosing this microwave oven. This product is designed with simple
operation and optimum comfort in mind.
This manual shows how you can best use this microwave. In addition to information about
operating the appliance, you will also find background information that may be useful when using
the appliance.
Please read the separate safety instructions carefully before
using the appliance!
Read this manual before using the appliance and keep it in a safe place for future use.
The installation instructions are included separate.

EN 5
Description of the appliance
1. Control panel
2. Oven levels
3. Oven door
4. Door handle
Guide rails
• The oven has four guide rails (Level 1 to 4). Level 1 is mainly used for microwave functions.
Accessories
Your appliance is accompanied by a range of accessories, depending on the model. Only use
original accessories; they are specially suited toyour appliance. Be sure that all the accessories
that are being used are able to withstand the temperature settings of the chosen oven function.
Note: not all accessories are suitable/available for every appliance (itmay also differ by country).
When purchasing, always provide the exact identification number of your appliance. Please see
the sales brochures or check online for more details about optional accessories.
Accessories that can be supplied with your appliance (depending on the model)
Glass baking tray; for microwave and oven use.
• NOT suitable for pyrolysis cleaning.
Door
• The door switches interrupt the operation of the oven when the door is opened during use.
The oven continues operating when the door is closed.
YOUR MICROWAVE OVEN
1
3
Level 1
Level 2
Level 3
Level 4
2
4

EN 6
Cooling fan
• The appliance is equipped with a cooling fan that cools the casing and control panel.
Control panel
12 13 14 15 16 17
1 10 116 7 8 95432
1. Function knob (in ‘Off’ position)
2. Defrost programs
3. Automatic programs
4. Defrost
5. My microwave
6. Microwave
7. Warming
8. Clean air
9. Cleaning
10. Display
11. Selection knob
12. On/off key and stop (cancel) key
13. Light key
14. Navigation key left
15. Navigation key right
16. Plus key
17. Confirm key (add 30 seconds microwave time / available when using the ‘Microwave’ function)
The keys respond best if you touch them shortly with a large area of your fingertip.
Every time you touch a key during use, a short acoustic signal will sound.
YOUR MICROWAVE OVEN

EN 7
Navigation and control
Activated area (grey background)
Set a function and settings
1. Touch and hold the on/off key to switch on the appliance.
2. Turn the function knob to set a main oven function.
The main oven functions are visible around the oven function knob and in the display.
The function icon is displayed larger. The ‘active area’ (recognizable by a grey background)
moves to the right.
3. Turn the selection knob to select a sub oven function.
The ‘active area’ shows the several different sub oven functions. Scroll up or down to view
the different functions. If a chosen main function does not have a sub function then the next
available setting appears in the active area.
4. Touch the selection knob (or the right navigation key) to confirm the chosen sub oven
function or setting.
The ‘active area’ (grey background) moves to the right.
5. Turn the selection knob to change the next available settings (left = decrease, right =
increase) and confirm by touching the selection knob or touching the right navigation key.
• When all elements in the screen are set, then confirm these settings by touching the
confirm key.
• When the confirm key is blinking it is possible to start the oven with the default settings.
• Touch the left navigation key to move the active area to the left to change an already made
setting. Change the setting by turning and touching the selection knob.
• Touch the stop key to go one-step back in the menu.
Follow the instructions on the display.
YOUR MICROWAVE OVEN

EN 8
Egg timer
Clock
Cooking time
Finishing time
Power level 14:30
Feedback bar
Active area (grey background)
Main function icon
750
600
1000
W
• The display will show the icon and name of the activated function for about 1.5 seconds.
• The feedback bar shows what setting you are changing.
Delayed start
• Set an desired cooking time and finishing time to start cooking at a later time.
Display
When the appliance is in progress you see the following information in the display:
• Temperature
• Active oven (sub) function
• Egg time (when set / See ‘Plus menu’)
• Cooking time (cooking time counting up or counting down when cooking time has been set)
• Finishing time (when cooking time has been set)
Stand-by mode
The stand-by display will show the time, date and the timer (if set). The appliance goes to stand-
by mode after turning the function knob to 0 (‘off’ position).
Switching on the appliance
• Touch and hold the on/off key to switch on the appliance.
• The appliance can also be switched on by turning the function knob to a function.
Shutting down the appliance
• Touch and hold the stop key to shut down the appliance manually.
• Default the appliance will shut down when there has been no action during 30 minutes.
YOUR MICROWAVE OVEN

EN 9
FIRST USE
Before first use
• Clean the appliance interior and accessories with hot water and washing-up liquid.
Do not use aggressive cleaning agents, abrasive sponges and similar.
• The appliance will emit a particular odor when it is used for the first time; this is normal.
Make sure that there is good ventilation during initial use.
When the appliance is first plugged in or after connection when the appliance was
disconnected from the power mains for a long period of time, you have to set ‘Language’,
‘Date’ and ‘Time’.
Setting the language
English
Nederlands
12:00Language
Français
In case you are not comfortable with the language on the display, you can select another
language. The default setting is ‘English’.
1. Turn the selection knob and select your preferred language from the displayed list.
2. Confirm the setting by touching the confirm key.
The next screen will be displayed.
Setting the date and time
English
Nederlands
12:00Language
Français
12:00Year
01 01
2017
2018
12:00Hours
30
11
13
12
1. Turn the selection knob and change the first setting (Year).
2. Confirm this setting by touching the right navigation key or by touching the selection knob.
3. Turn the selection knob and change the next setting (Month).
4. Confirm this setting by touching the right navigation key or by touching the selection knob.
5. Turn the selection knob and change the last setting (Day).
6. Confirm this setting by touching the confirm key.
The next screen will be displayed. Now set the hours and minutes with the selection knob
and navigation key. Confirm your setting by touching the confirm key.

EN 10
FIRST USE
All the start-up settings are now set and the display will show the stand-by screen. The appliance
is now ready for use.
The language, time and date can be adjusted in the settings menu (see ‘Settings menu’
chapter). The settings menu can be opened from the start display via the ‘Plus’ menu.

EN 11
Microwaves
Microwaves are high-frequency electromagnetic waves. The energy makes it possible to cook
orwarm up a dish without affecting the form or colour.
Cooking principle
• The microwaves the microwave generates are spread evenly by a distribution system.
Thiscooks the dish evenly.
• The food absorbs the microwaves to a depth of approximately 2.5 cm. Cooking then
continues, because the heat is spread in the dish.
• The cooking times vary and depend on the dish you use and the properties of the food:
▷Quantity and density
▷Moisture content
▷Starting temperature (whether or not it is chilled)
Please note!
The dish is cooked from the inside out by means of heat distribution. The cooking
continues even when you take the dish from the oven. Standing times in recipes should
therefore be adhered to, in order to ensure:
• Even heating into the middle of the dish.
• Equal temperatures in all parts of the dish.
Microwave power setting
Power Use
1000 W For quick heating of drinks, water and dishes containing a lot of moisture.
For cooking fresh or frozen vegetables.
750 W For prepairing and heating of drinks and dishes.
600 W For melting chocolate.For cooking fish and seafood.
For heating on two levels.
For cooking dried beans at low temperatures.
For heating or cooking delicate dishes with eggs.
360 W For cooking dairy products or jam at low temperatures.
180 W For fast defrosting of dishes.
For softening butter or ice cream.
90 W For defrosting cakes containing cream.
Guidelines for cookware
USE

EN 12
Cookware that you use for the microwave function should not block the microwaves. Metals
such as stainless steel, aluminium and copper reflect microwaves. For that reason, do not use
metal cookware. Cookware which is designated as microwave-safe can be used safely. For more
information about suitable cookware, consult the following guidelines and always use the glass
baking tray on level one if you use the microwave function.
Cookware Microwave
safe Remarks
Aluminium foil 37 Can be used in small quantities to prevent certain parts of
the dish from overcooking. Arcing can occur if the foil is too
close to the oven wall or if too much foil is used.
Porcelain and
earthenware
3Porcelain, earthenware, glazed earthenware and ivory
porcelain are usually suitable, unless they have a metal edge.
Disposable crockery
made from polyester
or cardboard
3Frozen meals are sometimes packaged in disposable
tableware.
Fast food packaging
• Polystyrene
cups
• Paper bags or
newspaper
• Recycled paper
or metal edges
3
7
7
Can be used to warm up dishes.
Polystyrene can melt if it overheats.
Can catch fire.
Can cause arcing.
Glassware
• Oven dishes
• Fine glassware
• Glass jars
3Can be used, unless it has a metal edge.
Can be used to warm up dishes or liquids. Thin glass can
break or shatter with sudden heating.
The lid must be removed. Only suitable for warming.
Metal 7Can cause arcing or fire.
Paper
• Plates, cups,
kitchen paper
• Recycled paper
3
7
For short cooking times and warming. For absorbing excess
moisture.
Can cause arcing.
Plastic 3Only use heat-resistant thermoplastic material. Other types
of plastic can warp or discolour at high temperatures. Do not
use melamine plastic. Only if boil-proof or ovenproof.
Must not be airtight. If necessary, prick it with a fork.
3: Recommended
37 : Careful
7: Unsafe
Please note!
USE

EN 13
Warning!
• Heating liquids in the microwave can result in delayed boiling. This means that the liquid
may start to boil furiously after it is removed from the microwave, with the risk ofscalding.
You can offset the delayed boiling effect by placing a plastic or glass spoon in the liquid
prior to heating it in the microwave.
• Take care with baby food:
▷Shake or stir the content of babies’ bottles or pots of baby food after heating.
▷Check the temperature of the food carefully prior to consumption to prevent
scaldinginjuries.
• Cutlery and tableware may become hot after using the microwave.
Explanation of the knobs and the keys
Function knob
Select a function
Turn this knob to select the desired function.
• See ‘Description of the functions’ for more information.
Selection knob
To choose an sub oven function
Turn this knob to choose a sub oven function.
• See ‘Control panel general use’ for more information.
Change the settings
Turn this knob to change the settings that are in the active area.
• See ‘Control panel general use’ for more information.
Go to the next setting
Touch this knob to go to the next setting.
• The next to change setting will be in the grey active area.
On/off key and stop key
USE

EN 14
To switch the appliance on or off
Touch and hold the key for several seconds to switch the appliance on or off.
To cancel or go back in the menu
Touch this key to cancel an operation or to go back one-step in the menu.
Lighting key
Switch the lighting on/off
Touch this key to switch the cavity lighting on or off.
Navigation keys
Navigate to the right
Touch the right navigation key to confirm the setting and to move the active area
to the right.
Navigate to the left
Touch the left navigation key to move the active area to the left.
Turn on/off the child lock function
Touch and hold the navigation keys simultaneously to activate/deactivate the
child lock function.
• The oven’s control panel can be locked by means of the Child Safety Lock,
to protect the oven against unintended use.
Plus key
To open the settings menu (see ‘Settings’)
Touch this key in stand-by mode to open or exit the settings menu:
• Egg timer
• General
• Display
• Cooking
• System
To open extra options (see ‘Plus menu’)
Touch this key in operation mode to open or exit the extra options possible at
that moment:
• Egg timer
Confirm key
USE

EN 15
Confirm
To confirm all the white settings/elements in the screen.
Add microwave time
Add 30 seconds microwave time (microwave function).
Description of the functions
Consult the table to select the preferred function. Also consult the instructions for preparation on
the dish packaging.
In ‘Microwave function’: do not use metal cookware or utensils and do not preheat
the oven.
Main functions (to select with the function knob)
Function Description
My microwave
• Default microwave power and cooking time (default settings can be changed in
the settings menu).
Defrost programs
• Use ‘Defrost programs’ for defrosting by selecting a setting from the list of
pre-programmed settings.
Programs
• You can use ‘automatic programs’ for baking and roasting by selecting a dish from
a list of pre-programmed dishes. First select the type of dish and then the dish
itself from the available list.
• All the program categories have a picture. When a dish is selected, the program
settings will appear. The name of the dish and and the name of the active
selection are shown in the text bar.
• In the settings, first a picture of the dish is visible (not editable), the weight
(depending on the dish) (if it is editable), the intensity (not always editable) and the
cooking time. If necessary, adjust the intensity and/or the weight.
Defrost
• This function uses microwaves. Dishes are defrosted quickly and efficiently.
• Suggested power: 90 W
USE

EN 16
Function Description
Microwave
• Microwave energy is used to cook and defrost foods. It provides fast efficient
cooking without changing the colour or form of food.
• Place the glass dish on level one.
• Suggested power: 750 W
Warming
• Keep warm: this function is used to keep already cooked dishes warm.
Clean air
• The fans are operating for cooling and deodorization.
Cleaning
• To clean the oven cavity. Grease and grime can easily be removed from the
oven walls with a damp cloth.
Plus menu
Touch the Plus key to choose extra functionality (after you have chosen a main function and
settings).
• Select a function in the plus menu by turning the selection knob and confirm with the
confirm key.
• To exit the plus menu, touch the ‘stop key’ or ‘plus key’; the display will show the previous
screen again.
Plus menu Description
Egg timer
The egg timer can be used independently of the oven function.
• When the egg timer goes off, a message pop-up will appear and an acoustic
signal will sound.
• Touch the stop key to switch off the signal and close the pop-up menu.
• The sound will stop automatically after approximately two minutes.
• To cancel the timer, set the time to 0:00.
USE

EN 17
Using the appliance cooking functions
Consult ‘Control panel general use’ to get information about the general operation of
the appliance.
1. Touch the ‘On/off key to switch on the appliance.
2. Turn the function knob to select a main function.
▷Consult ‘Description of the functions’ to select the appropriate (available) function.
3. Turn the selection knob to adjust a setting.
▷The first to adjust setting is active.
4. Start directly the selected function (with pre-set values) by touching the confirm key (this key
is blinking if it is possible to start the program).
Available settings to adjust:
• the microwave power;
• the cooking time.
The next sub-function or setting becomes active (if available). Go back to an previous
selection or setting by touching the left navigation key.
If preferred, select any additional setting (for example ‘Egg timer’) using the plus menu.
See ‘Plus menu’ for more information.
5. Touch the confirm key to start preparing your meal with the chosen settings.
At the end of the cooking you can:
• Stop cooking
▷Touch the confirm key.
The finish display will be closed and the stand-by screen will be shown. If there is no action
within 10 minutes, the display will switch to stand-by mode.
• Add extra time
▷Touch the right navigation key to select ‘Add extra time’.
The time setting becomes active and can be changed directly by rotating the selection knob.
▷Touch the confirm key.
▷The previous process is activated again.
OPERATION

EN 18
Changing settings during the progress
• During progress, touching the navigation keys will show the active area. The selected setting
can now be changed. After confirmation with the confirm key the progress screen will be
shown with the changed settings.
• After 5 seconds without actions the progress settings are cancelled and the display will
return to the progress screen.
OPERATION

EN 19
SETTINGS
Settings menu
The settings menu is only available by touching the plus key when the appliance is in
stand-by mode.
Egg timer (setting an alarm time)
General
• Language of the display
• Time
▷Set time
▷Hour format
▷Clock size
• Date
▷Date yy-mm-dd
▷Date format
• Sound
▷Volume (low-mid-high)
▷Key sound (on / off)
▷Welcome sound (on / off)
Display
• Brightness low, mid, high
• Oven light
▷Auto. switch off after 1 min.
▷Switch off manually
• Night mode
▷Start and end time for lower display brightness:
▷First display set start timer, second display set end time
• Appliance to stand-by
▷Auto. switch off after 1 hour
▷Always on*
Cooking
• Program intensity
▷low / medium / high
• Quick start microwave
▷Microwave power and time
System
• Appliance information
▷Appliance name and SW version
• Factory settings
▷Return to factory settings
*Changing to manually switch off will increase energy consumption.
If the oven is switched off manually (or when an interruption of the power supply
occurs) this function will be reset (the display will automatically switch off).

EN 20
Cleaning the appliance
Clean the oven regularly to prevent fat and food particles from accumulating, especially
on the surfaces of the interior and the exterior, the door and the seal.
• Activate the child lock (to prevent that the appliance is switched on accidentally).
• Clean the exterior surfaces with a soft cloth and warm soapy water.
• Next wipe with a clean, damp cloth and dry the surfaces.
• Remove splashes and stains on the interior surfaces with a cloth and soapy water.
• Next wipe with a clean, damp cloth and dry the surfaces.
Important!
Make sure that no water enters the vents. Never use abrasive cleaning materials
or chemical solvents. Always make sure that the seal of the door is clean.
This prevents accumulation of dirt and allows you to close the door properly.
Cleaning function (Steam clean)
With Steam clean and a damp cloth, you can easily remove grease and dirt from the oven walls.
Using Steam clean
• Only use Steam clean when the oven has cooled down fully. It is more difficult to remove
dirt and grease if the oven is hot.
• The program takes 4 minutes. Then we advise you to wait for 30 minutes. Food remains on
the enamel walls will be sufficiently soaked after 30 minutes so that they can be removed
with a damp cloth.
1. Remove all accessories from the oven.
2. Pour 0.15 litres of water into the bottom of the oven.
3. Select ‘Cleaning’ with the function knob.
4. Touch the confirm key to start Steam clean.
Do not open the door during the cleaning program.
MAINTENANCE
This manual suits for next models
2
Table of contents
Other Atag Oven manuals
Popular Oven manuals by other brands

Mono
Mono 323 Compact Operating and maintenance manual

AEG
AEG BPK558270M user manual

AEG
AEG COMPETENCE 51581 B operating instructions

Pelgrim
Pelgrim OST980KOR/P01 manual

Middleby Marshall
Middleby Marshall PS520 Series Owner's operating and installation manual

VERDER
VERDER CARBOLITE GERO LGP 2/1750 Installation, operation and maintenance instructions
