Atag SQ4211T User manual

instructions for use
steam oven
SQ4211T
SQ4292T
SQ4311T
SQ4392T

3
Contents
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Oven features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Using this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 10
Filling the water tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Explanation of knobs and buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 - 16
Before you begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17 - 18
Modes and settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 - 20
Adjusting the cooking time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Setting the delayed start time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Using the steam mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 - 25
Using the hot air + steam mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26 - 27
Using the reheat mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Using the hot air mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29 - 30
Using the grill mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31 - 32
Using the auto cook mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33 - 44
Using stage cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45 - 46
Add your own programmed dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47 - 48
Choose your own programmed dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Delete your own programmed dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Using the defrost mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51 - 52
Using the keeping warm mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Setting the water hardness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Descaling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55 - 56
Using the steam clean feature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58 - 60
Changing the oven lamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Error codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Technical specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Disposal of package and appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

4
Control Panel
1. MODE KNOB
2. BACK BUTTON
3. MENU BUTTON
4. COOK TIME BUTTON / DELAYED START TIME BUTTON
5. TEMPERATURE BUTTON
6. WEIGHT BUTTON
7. NEXT BUTTON
8. DISPLAY
9. SELECTION KNOB
10. STOP BUTTON
11. START BUTTON
23 4 5 6 71 9 10 118

5
Control Panel
Door Handle
Drip Tray
Top Heating Elements
Oven Light
Steam Outlet
Door
Level 1
Water Tank
Evaporator dish
Level 5
Level 6
Level 4
Level 3
Level 2
Fan
Note
●Shelf levels are numbered from the bottom up.
●The levels 4, 5 and 6 are mainly used for the grill function.
●Levels 1 is mainly used for baking and roasting.
●Please refer to the Cooking Guides provided throughout this booklet to determine the
appropriate shelf level for your dishes.
Oven Features

6
Accessories
The following accessories are provided with your Combi Steam Oven:
1Multi pan (for level 1 or 6) 2Grill insert for multi pan or for
unperforated steam dish
3Wire rack (for all levels) 4Large steam dish, perforated, 40 mm deep, GN 2/3 (useful for steam mode,
for level 2, 3, 4 and 5)
5Large steam dish, unperforated, 40 mm deep, GN 2/3 (useful during
steam mode for collecting condensa-
tion, for level 2, 3, 4 and 5)
For steaming, you can place the perfo-
rated steam dish or the grill insert into
the unperforated steam dish.
Accessories can be purchased from www.atag.nl.
Use only the accessories supplied with the product or available from the after-sales service.
They are specially designed for your appliance.
325 mm
265 mm 175 mm 175 mm
325 mm
GN 1/3GN 1/3
GN 1/2
350 mm
325 mm
GN 2/3

7
Using this Manual
Thank you for purchasing this ATAG Combi Steam Oven.
Your Owner’s Manual contains important safety instructions and essential infor-
mation on using and caring for your new Combi Steam Oven.
Before using your oven, please read all the information in this manual and keep
it for future reference.
Before installaton
Environmentally-friendly
disposal
Unpack the appliance and dispose of the packaging in an
environmentally-responsible manner.
This appliance is labelled in accordance with European
Directive 2002/96/EU on Waste Electrical and Electronic
Equipment - WEEE.
The directive gives a framework for the collection and
recycling of old appliances, which is valid across the EU.
After unpacking Do not open the cooking compartment door while the
appliance is on the floor. The cooking compartment
door could touch the floor and be damaged.
Check the appliance for damage after unpacking it.
Do not connect the appliance if it has been damaged
in transport.
Your appliance was thoroughly factory tested for
proper operation. It may therefore contain some
remaining water.
Installation and connection Please observe the special installation instructions.
Electrical connection If the power cable is damaged, it must be replaced by
customer service in order to prevent hazards.

8
Using this Manual (Continued)
Safety precautions
This appliance is intended only for domestic use. This
appliance must only be used for food preparation.
•This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
• Children should be supervised to ensure that they do not
play with the appliance.
Hot cooking cavity There is a risk of burning!
• During use the appliance becomes hot. Care should be
taken to avoid touching heating elements.
• Open the cooking compartment door carefully. Hot steam
can escape.
WARNING
• Accessible parts may become hot during use. Young
children should be kept away.
Risk of fire!
• Never store combustible items in the cooking compart-
ment.
There is a risk of short-circuiting!
• Never trap cables of electrical appliances in the hot cook-
ing compartment door. The cable insulation could melt.
Hot accessories There is a risk of burning!
• Never take accessories out of the appliance without
using oven gloves.
Cleaning Risk of scalding!
• Do not clean the appliance immediately after switching it
off. The water in the evaporator dish is still hot. Wait until
the appliance has cooled down.
• A Steam cleaner is not to be used.
Repairs Danger of electric shock!
• Incorrect repairs are dangerous. Repairs may only
be carried out by one of our experienced after-sales
engineers. If the appliance is faulty, switch it off using the
fuse in the fuse box or disconnect the appliance at the
mains connection. Contact the after-sales service.
WARNING: Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric shock.

9
Using this Manual (Continued)
Important information about the use of the appliance
Do not use the cooking compartment door as a shelf.
Do not store any food in the appliance. This can lead to
corrosion.
Ovenware Use only the accessories provided. They are specially
designed for your appliance.
Ovenware must be heat and steam resistant. Silicone
baking tins are not suitable for combined operation with
hot air and steam.
Do not use ovenware that shows signs of rust. Even the
smallest spots of rust can lead to corrosion in the cooking
compartment.
Care and cleaning The cooking compartment in your appliance is made of steel
covered with enamel. Improper care can lead to corrosion
in the cooking compartment. Refer to the care and cleaning
instructions in the instruction manual.
Salts are very abrasive. If salt is deposited in the cooking
compartment, rust could develop in places.
Acidic sauces, such as ketchup and mustard, or salted foods,
e.g. cured roasts, contain chloride and acids. These affect the
stainless steel surface. Clean the cooking compartment after
each use.
DO NOT use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can scratch
the surface, which may result in shattering of the glass
(if provided).

10
Using this Manual (Continued)
Causes of damage
Very dirty seal If the seal on the outside of the cooking compartment is
very dirty, the cooking compartment door will no longer
close properly during operation. The fronts of adjacent
units could be damaged. Keep the seal clean.
Cooking compartment door
as a seat
Do not stand or sit on the cooking compartment door.
Transport Do not hold or carry the appliance by the door handle.
The door handle cannot hold the weight of the appliance
and may break off.
Important information about installing the combi steam
oven
• This appliance is NOT intended for use in a commercial environment.
• Please observe the installation instructions provided and note that this appliance should
only be installed by a qualified technician.
• The appliance is fitted with a plug and must only be connected to a properly installed
earthed socket. The fuse protection must be rated at 16 amps (L or B-type miniature
circuit breakers).
• In case a new socket is needed, installation and cable connection must only be done
by a qualified electrician. If the plug is no longer accessible following installation, a pole
disconnecting device must be present on the installation site with a contact gap of at
least 3 mm.
• Adapters, multiway strips and extension cords must not be used. Overloading can result
in fire.
• Plug in
When the appliance has been connected for the first time, the display is prompting
you to select the language and set the clock. Do not forget to reset the clock when you
switch to and from summer or winter (see the instructions on page 17).

11
Filling the Water Tank
When you open the cooking compartment door, you will see the water tank on the right-hand
side. Only fill the tank with fresh tap water or with still bottled water. If your water is very hard,
we recommend that you use softened water (see also “Water hardness).
Caution Do not fill the water tank with distilled water or any other
liquids.
Fill the water tank before
each use
Lift the water tank over the interlock and pull the tank out of
the appliance. Fill the water tank with cold water up to the
“max.” mark. Close the lid until you feel it engage.
Slide the water tank back until it engages.
Empty the water tank after
each use
Pull the water tank out of the appliance slowly. Pulling it
out quickly may cause water to spill. Hold the water tank
horizontally, so that no remaining water can drip out of the
valve seat.
Empty out the water.
Thoroughly dry the water tank in the appliance and the lid.
“Fill water tank” display If the water tank is empty, a signal sounds.
A symbol appears in the display. The operation is inter-
rupted.
1. Open the cooking compartment door carefully. Steam will
escape.
2. Take out the water tank, fill to the “max” mark and rein-
sert.
3. Press the START button.
Removing drip tray Empty drip tray at regular intervals. Push drip tray in until
you hear a click, and remove tray from locked position.
Drip tray
Push in and remove

12
Explanation of knobs and buttons
After you have pressed the Menu Button, you can choose several settings by turning the Selection
Knob. Choose a setting, press the Next Button to confirm and again you can choose several set-
tings by turning the Selection Knob. In the table below you can see the settings you can choose.
Menu
Time Hours/Minutes
(see page 17)
Language
English
Language is adjusted
Nederlands
Deutsch
Français
Dansk
Sound On Sound is adjusted
Off
Contrast
1
Contrast is adjusted2
3
Cleaning Steam clean Steam clean starts
Decalcify Decalcify starts
Water hardness
Water hardness
1. Very soft
2. soft
3. hard
4. very hard
Water hardness is adjusted
Dishes Add (see page 47-48)
Delete (see page 50)
Auto shut off (clock) Yes Auto shut off is turned on (see page 17)
No Auto shut off is turned off (see page 17)
Cook time
/
Cook time is blinking Set the cooking time Confirm, the cooking
time stops blinking
If the ‘Temperature’
button is pressed, these
functions will start blink-
ing and can be adjusted

13
Explanation of knobs and buttons (Continued)
Delayed start time
Press for three
seconds /
Delayed start time is
blinking
Set the delayed start
time
Confirm, the delayed
start time stops blinking
If the ‘Cook Time’ or
‘Temperature’ button
is pressed, those func-
tions will start blinking
and can be adjusted
(if available)
Temperature
/
Temperature is blinking Change the tempera-
ture
Confirm, the tempera-
ture stops blinking
If the ‘Cook Time’ or
‘Delayed start time’
button is pressed, those
functions will start blink-
ing and can be adjusted
(if available)
Weight
/
Weight is blinking Change the weight Confirm, the weight
stops blinking
If the ‘Cook Time’,
‘Temperature’ or
‘Delayed start time’
button is pressed, those
functions will start blink-
ing and can be adjusted
(if available)
Childlock
Press at the same time Child lock is set
(lock symbol light is on)
Press at the same time
again
Child lock is released
(lock symbol light is off)

14
Explanation of knobs and buttons (Continued)
If you have choosen a mode with the Mode Knob, you can also choose and change several
settings by turning the Selection Knob.
Auto Cook Mode
Auto Cook Menu Select a category and
press ‘Next’ to confirm
Select a food item
and press ‘Next’ to
confirm
See page 33 - 34 for
further information
Reheat Mode
Reheat
Press to adjust
the cooking time/
delayed start
time
Set the cooking
time/delayed
start time
Confirm Start
Hot Air + Steam Mode
Hot air + Steam
Press to adjust
the cooking time/
delayed start
time/temperature
Set the cooking
time/delayed
start time/tem-
perature
Confirm Start
Steam Mode
Steam
Press to adjust
the cooking time/
delayed start
time/temperature
Set the cooking
time/delayed
start time/tem-
perature
Confirm Start

15
Explanation of knobs and buttons (Continued)
Hot air Mode
Hot air
Press to adjust
the cooking time/
delayed start
time/temperature
Set the cooking
time/delayed
start time/tem-
perature
Confirm Start
Grill Mode
Grill
Press to adjust
the cooking time/
delayed start
time
Set the cooking
time/delayed
start time
Confirm Start
Defrost Mode
Defrost
Press to adjust
the cooking time/
delayed start
time/temperature
Set the cooking
time/delayed
start time/tem-
perature
Confirm Start
Keeping Warm Mode
Keeping warm
Press to adjust
the cooking time/
delayed start
time
Set the cooking
time/delayed
start time
Confirm Start

16
Explanation of knobs and buttons (Continued)
If you choose an Auto Menu by turning the Mode Knob or if you press the Menu button, you will
see text in the display. There are also some symbols in the display. In the table below you can see
what you can do if you see these symbols.
Symbols in the Textdisplay
Symbols in the textdisplay Buttons/knobs Explanation
Turn to choose (‘scroll’
through the menu)
Confirm
Turn to choose (‘scroll’
through the menu)
Confirm
Go back one step
Start (no more ‘scrolling’)
Go back one step

17
Setting the Language and the Clock
When the power is first supplied to the oven, you must set the language and the time.
1 Turn the Selection Knob to set the
language. Press the Start Button to
confirm. 2 Now you have to set the right time.
The ‘ ’ and ‘12’ will blink.
3 Example: to set 1:30.
Turn the Selection Knob to set the
hour of the day. 4 Press the Next Button to confirm. The
‘ ‘ and ‘00’ will blink.
5 Turn the Selection Knob to set the
minute of the time and press the Start
Button to finish setting the clock.
‘ ‘ will disappear and ‘30’ will stop
blinking.
6 The display shows the time of day.
The appliance is now ready to use. If
you want to change the time later on,
you can do this by pressing the Menu
Button and choose ‘Time’ by turning
the Selection Knob. Then follow step
2-6 as described on this page.
Automatic shut off (clock)
If the knobs of the oven are not operated for more than 30 minutes, the display will turn off auto-
matically for energy saving reasons. By operating any key, the display is switched on again.
If desired, this function can be turned off (see page 12; ‘Auto shut off’).
Before you begin

18
Before you begin (Continued)
Notes
1) During cooking, COOK TIME, DELAYED START TIME and TEMPERATURE can be
changed.
►Cooking time: press the Cook Time Button, turn the Selection Knob and press the
Cook Time Button again to confirm (see page 21).
►Delayed start time: press and hold the Cook Time Button, turn the Selection Knob
and press the Cook Time Button again to confirm (see page 22).
►Temperature: press the Temperature Button, turn the Selection Knob and press the
Temparature Button again to confirm.
2) In Steam mode settings, the top and bottom steam heating elements switch off and on
throughout cooking to regulate the temperature.
3) In Hot air Mode settings, the top and bottom heating elements switch off and on throughout
cooking to regulate the temperature.
4) Be careful when removing the plate as it is hot. First leave the door a little open to allow
the hot steam to escape. Pay attention to the steam outlets as well.
5) When you have finished cooking/defrosting, pour out the water in the drip tray and empty
the tank.
6) Dry the cooking cavity with a dry cloth if there is any remaining water.
7) The cooling fan always works for 3 minutes after a steaming process. However, this is not
a malfunction and you do not need to worry about this.
If there is too little water while cooking, you
will see the symbol in the display along
with a beep being played. Add water into the
tank and press START to continue with the
steaming.
•You can add water into the tank at any
time while cooking.
Important
►When using the Hot Air + Steam mode, be sure that the baking dishes are suitable for
100-230 °C cooking temperatures.
►When using the Hot Air mode, be sure the baking dishes are suitable for 40 - 230 °C
cooking temperatures.
When the cooking has finished, the oven will beep and ‘End’ will flash four times. The
oven will then beep one time per minute.

19
Modes and Settings
The following table represents the various oven modes and settings of your oven.
Use the cooking guide tables for those modes as guidelines for cooking.
Steam Mode
Food is cooked by steam provided by the steam generator and injected
into the cavity by two jet nozzles.
This mode is suitable for steaming food like vegetables, fish, eggs, fruits
and rice. When cooking by using this mode, always fill the water tank
with fresh water.
Temperature range: 40~100 °C
Hot Air + Steam Mode
Food is cooked by hot air mode and the help of steam. The steam is
provided by the steam generator and injected into the cavity by interval.
This mode is suitable for baking pastries, such as puff pastry, brioches,
yeast buns, bread rolls, gratins and roasting meat. The superheated
steam will provide a nice crisp, shiny surface and fluffy structure. Meat
roasts and fish will keep a more juicy texture inside. When cooking with
this mode always fill the water tank with fresh water.
Temperature range: 100~230 °C
Reheat Mode
Food is reheated by hot air mode and the help of steam. The steam is
provided by the steam generator and injected into the cavity by interval.
This mode is suitable for plated meals. Dishes can be gently reheated
without drying out. When reheating with this mode always fill the water
tank with fresh water.
Temperature: 120 °C
Hot Air Mode
Food is heated by two heating elements on top of cavity and one bottom
heating element, while the fan from the side distributes the hot air evenly.
This setting is suitable for roasting meat, baking pizza and cake.
Temperature range: 40~230 °C
Grill Mode
Food is heated by the top heating elements. We recommend this mode
for grilling smaller pieces of meat, such as steaks and sausages, as well
for making toasts.

20
Modes and Settings (Continued)
Defrost Mode
Frozen food is defrosted by steam. The steam is provided by the steam
generator and injected into the cavity by interval.
This mode is suitable for frozen meat, poultry, fish and fruit. When
defrosting with this mode always fill the water tank with fresh water.
Temperature range: 40~70 °C
Keeping warm
This mode is suitable for keeping warm food.
(Do not keep food warm for longer than 2 hours. Warm food spoils more
quickly).
Temperature: 70 °C
Auto Cook Programmes
Several pre-programmed auto cook settings can be selected for your
convenience. Time and temperature will be set automatically. You
simply select the programme, the weight of your dish and start the
steam cooking process.
