AT&T PBH20 User manual

Bluetooth®/Wired Headphones
Bluetooth®Headphones
user’s
manual
model #: PBH20

Page 2
Thank you for purchasing the AT&T
Bluetooth®
/wired headphones
[PBH20].
Bluetooth®Headphones
Features
• Bluetooth 2.1 technology with amazing sound
• Built-in microphone with echo cancellation
• Full controls for playback and calls
• Portable folding design
• 3.5 mm auxiliary input jack
The Bluetooth®word mark and logos are registered trademarks owned by
Bluetooth SIG, Inc.
hello.
Page 3
What’s Included
Micro USB Cable Audio Cord
UnpacktheBluetooth®headphonesandmakesureallaccessories
are put aside so they will not be lost.
Bluetooth Headphones

Contents
Page 4
Introduction
What’s Included
Safety Information
Getting Started
Location of Main Unit Controls
Operational Instructions
Charging
Power ON/OFF
Pairing
Making Phone Calls
Listening to Music
Troubleshooting
Compliance with FCC Regulations
Warranty Information
Specifications
2
3
5
6
7
7
7
8
9
10
12
13
14
Page 5
Contents
Safety Information
Important Safety Instructions
1. ATTACHMENTS - Do not use attachments not
recommended by the manufacturer.
2. WATER AND MOISTURE - The unit should not be used near
water. For example: near a bathtub, washbowl, kitchen sink,
laundry tub, swimming pool or in a wet basement.
3. VENTILATION - The unit should be situated so that its
location or position does not interfere with its proper
ventilation. For example, it should not be situated on a
bed, sofa, rug or similar surface that may block ventilation
openings. Also, it should not be placed in a built-in
installation, such as a bookcase or cabinet, which may
impede the flow of air through the ventilation openings.
4. OBJECTS AND LIQUID ENTRY - Care should be taken so that
external objects do not fall into and liquids are not spilled
onto any openings or vents located on the product.
5. POWER SOURCE - The unit should be connected only
to a power supply of the type described in the operating
instructions or as marked on the unit. If you are not sure,
please consult the dealer or local power company.
6. HEAT - The unit should be situated away from heat sources
such as radiators, heat registers, stoves or other appliances
(including amplifiers) that produce heat.
7. SERVICING - The user should not attempt to service the
unit beyond those methods described in the user’s manual.
Opening or removing covers will expose you to dangerous
voltage and other hazards. Service methods not covered
in the user’s manual should be referred to qualified service
personnel.
Please read all safety and operating instructions carefully before
installation and use, and keep these instructions handy for
future reference. Take special note of all warnings listed in this
user’s manual and on the PBH20.

Page 6
Getting Started
Location of Main Unit Controls
1. ON/OFF / Pairing / Play /
Pause
2. Previous song / Volume-
3. Next song / Volume +
4. Answer / Disconnect /
Redial
5. Microphone
6. AUX-In Jack
7. LED indicator light
8. Micro USB charging port
2
3
4
1
6
7
8
5
Page 7
Operational Instructions
Charging
Charge your PBH20 through any USB jack or wall charger. A red
LED indicator willlight upwhencharging. Beforeusing for thefirst
time, charge at least 4 hours. After the first charge, the headset
will charge in 2 to 3 hours and the LED indicator will stop blinking
when the charge is complete.
Note: When the battery is fully charged, the LED indicator will
turn off.
Power ON/OFF
Press and hold the ON/OFF button for 1 second to switch the
headset on. The LED will flash white when powered on. Press and
hold the ON/OFF button for 3 seconds to switch the headset off.
When powering off, the white LED light will stop flashing and then
turn off.
Pairing
While the headset is off, press and hold the ON/OFF – Bluetooth
Pairing buttons for 5 seconds to start pairing mode. Once
the headset is in the pairing mode (the LED will start flashing
white), select ‘LHB15’ among discovered Bluetooth devices on
the phone. If requested, enter the password ‘0000’ to pair the
headset. When connected, you will hear a beep and your mobile
device will show “Paired”.
Note: If the headset is not pair with any Bluetooth device in 3
minutes, it will turn itself off.

Page 8
Operational Instructions
Making Phone Calls
Making a call
Once paired, use your mobile device to dial a number as
usual. Once connected, the call will be heard on your PBH20
headset.
Last number redial
Double press the Answer / Disconnect /Redial button to redial
last number.
Answer a call
When receiving a call, press the Answer / Disconnect /Redial
button to answer the call.
Ending a call
While talking on the phone, press the Answer / Disconnect /
Redial button to end the call.
Rejecting a call
While receiving a call, press and hold the Answer / Disconnect /
Redial button to refuse the call.
Volume control
Use the Volume +/ Volume - buttons to adjust the volume level.
Page 9
Operational Instructions
Listening to Music
Play/Pause
Press the Play button to launch the phone’s music player and
to start listening to music. While listening to music, press the
Pause button to pause or to resume play.
Song Selection
While music is playing, press the Next Song or Previous Song
buttons to select songs.
Answer a call while listening to music
When receiving a call, press the Answer / Disconnect /Redial
button to answer the call. Press the Answer / Disconnect /Redial
button while on the phone to end the call. When receiving a call,
press and hold the Answer / Disconnect /Redial button to reject
the call. (Music will resume playing when the call is rejected.)
Volume control
Press and hold the Volume + and Volume - buttons to adjust the
volume level.
Blinking white light
Status
Powering ON
Powering OFF
Low battery
Charging
Pairing mode
Connection complete
Incoming call & on the phone
Playing music
LED indicator
LED turns off
Blinking red & headset emits a beep
Solid red light
Blinking white light
White light blinks every 3 seconds
Solid white light
White light blinks every 3 seconds
LED Indicator Chart

Page 10
Troubleshooting
Symptom
Music is not
streaming over
Bluetooth
PBH20 does not
answer phone calls
Music does not
resume after ending
a call
Not able to control
music from the
PBH20
No power
Solution
Make sure the PBH20 is
fully charged.
Check to make sure
both devices are paired
and connected over
Bluetooth.
Restart the PBH20 to
auto-connect with your
Bluetooth device.
Check to make sure
both devices are paired
and connected over
Bluetooth.
Restart the PBH20 to
auto-connect with your
Bluetooth device.
Press play to resume
music.
Check and make sure
your mobile device
supports Bluetooth
A2DP profile.
Page 11
Contents
Compliance with FCC Regulations
The equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate
Radio frequency energyand, ifnot installedand usedin accordance with the
instructions, may cause harmful interference to Radio communications.
However, there isno guaranteethatinterferencewill notoccur in aparticular
installation. If this equipment does cause harmful interference to Radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from which the
receiver is connected.
- Consult the dealer or an experienced Radio/television technician for
assistance.
This equipment complies with FCC’s RF radiation exposure limits set forth
for an uncontrolled environment. The antenna(s) used for this transmitter
must be installed and operated to provide a separation distance of at
least 20 cm from all persons and must not be collocated or operating in
conjunction with any other antenna or transmitter. Installers must ensure
that 20 cm separation distance will be maintained between the device
(excluding its handset) and users.
THE SPECIFICATION AND EXTERNAL APPEARANCE OF THE
HEADPHONES ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
The useris cautionedthatchanges ormodifications notexpressly approved
by the party responsible for compliance could void the user’s authority to
operate the equipment.
If at any time in the future you should need to dispose
of this product, please note that waste electrical
products should not be disposed of with household
waste. Please recycle where facilities exist. Check with
your local authority or retailer for recycling advice.
Caution!

Warranty Information
Page 12
Limited Warranty
The AT&T brandsare usedunder license. Any repair, replacement,
or warranty service,and allquestions aboutthis productshould be
directed to Concept 101 LLC at www.att.com/electronics or call
1 [phone] from the USA or Canada.
Concept 101LLC warrants tothe original purchaserthat theproduct willbe free
from defects in material, parts and workmanship for the period designated
forthis product.The warranty commencesthe daythe productis purchased
and covers upto aperiod ofone (1) year. Concept 101LLCagrees that itwill, at
its option,replacethe defective productwith eithera new orremanufactured
headset equivalent to your original purchase during the warranty period.
Should theParts warranty periodexceed theLaborwarrantyperiod, Concept
101 LLC will supply at no charge for the remainder of the Parts warranty, any
new orremanufactured replacement parts asrequiredbythe product. During
this period all labor and service charges will become the responsibility of the
customer.
Exclusions: This warranty does not apply to the appearance or exterior
of the product which may have been damaged or defaced,
altered or modified in design or construction. This warranty
does not apply if the serial number is altered or removed, or
if there is any damage due to power line surge, user damage
to the AC power cord, connection to improper voltage
source, general misuse, accidents, or repair attempts by
unauthorized service agents. Other exclusions include ear
pads, rechargeable and non-rechargeable batteries.
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS
THE EXCLUSIVE REMEDY OF THE CUSTOMER; Concept 101 LLC SHALL
NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES
FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS
PRODUCT, EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW.
ANY IMPLIED WARRANTY OF MERCHANTABILITY OF FITNESS FOR A
PARTICULAR PURPOSEON THIS PRODUCTIS LIMITED TO THEDURATION
OF THE WARRANTY.
Some states do not allow the exclusion or limitations of incidental or
consequential damages, or limitations on how long the warranty lasts. In
these cases the above exclusions or limitations may not apply to you. This
warranty gives you specific legal rights and you may also have other rights
which vary from state to state.
Page 13
Warranty Information
Obtaining Service: To obtain service, product literature, supplies or
accessories please call 1 888-920-8680, or visit our
website, www.att.com/electronics, to create a ticket
for exchange/repair. Please make sure to provide
the date of purchase, model number and a brief
description of the problem. Our customer service
representative will contact you or send detailed return
instructions.
Concept 101 LLC does not warrant that the headset will work properly in
all environmental conditions, and makes no warranty and representation,
either implied or expressed, with respect to the quality, performance,
merchantability, or fitness for a particular purpose other than the purpose
identified within this user’s manual. Concept 101 LLC has made every effort
to ensure that this user’s manual is accurate and disclaims liability for any
inaccuracies or omissions that may have occurred. Information in this
user’s manual is subject to change without notice and does not represent
a commitment on the part of Concept 101 LLC. Concept 101 LLC reserves
the right to make improvements to this user’s manual and/or to the
products described in this user’s manual at any time without notice. If you
find information in this manual that is incorrect, misleading, or incomplete,
please contact us through our website.

Page 14
Specifications
- Bluetooth 2.1
- Bluetooth compatibility: Bluetooth 2.0 or above device with
A2DP/AVRCP/HFP/HSP
- Working distance: Up to 30 ft.*
* Up to 30 ft. wireless range as determined by Bluetooth SIG.
Range may vary depending on the line of sight obstacles.
Page 15
Contents
Memo
purchase date:
place of purchase:

© 2016 Concept 101 LLC. All Rights Reserved. AT&T and the AT&T logo are trademarks of
AT&T Intellectual Property licensed to Concept 101 LLC, New York, New York 10018. Issue 4.0
AT&T 5/2016.
www.att.com/electronics
