AT&T FreeAgent BTH01 User manual

Bluetooth®Stereo Headset
user’s
manual
FreeAgent
model #: BTH01

Page 3Page 2
Micro USB Cable
Bluetooth Headset
Thank you for purchasing
FreeAgent [ BTH01].
Bluetooth®Stereo Headset
Features
The Bluetooth®word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc.
What’s Included
Unpack FreeAgent and make
sure all accessories are put
aside so they will not be lost.
· Bluetooth 2.1 + EDR
· Real 3D Sound
· Make / Receive phone calls
· Talk up to 14 hours / Music up to 12 hours
· Forward / Backward Track
· Call Reject / Waiting / Cancel
· Echo Cancellation
· Noise Suppression
· Voice Prompt
· Easy Pairing
hello.

Page 5Page 4
Introduction
What’s Included
Safety Information
Getting Started
Controls
Operational Instructions
Pairing
Power ON/OFF
Connecting the Headset
Making Phone Calls
Listening to Music
3D Sound
Resetting the Headset
LED Light Messages
Voice Prompt Messages
Troubleshooting
Compliance with FCC Regulations
Specifications
Warranty Information
2
3
5
7
8
9
9
10
11
12
13
14
14
15
16
17
18
Important Safety Instructions
1. WATER AND MOISTURE - BTH01 should not
be used near water. For example: near a
bathtub, washbowl, kitchen sink, laundry tub,
swimming pool or in a wet basement.
2. OBJECTS AND LIQUID ENTRY - Care should
be taken so that external objects do not
fall into and liquids are not spilled onto any
openings or vents located on the product.
3. HEAT - BTH01 should be situated away from
heat sources such as radiators, heat
registers, stoves or other appliances
(including amplifiers) that produce heat.
4. DAMAGE REQUIRING SERVICE - BTH01
should be serviced by qualified service
personnel when:
A. objects have fallen into or liquid has been spilled
onto the enclosure.
B. BTH01 has been exposed to rain.
C. BTH01 has been dropped or the enclosure
damaged.
D. BTH01 exhibits a marked change in performance
or does not operate normally.
Please read all safety and operating
instructions carefully before installation
and use, and keep these instructions handy
for future reference. Take special note of all
warnings listed in this user’s manual and on
FreeAgent.
Contents Safety Information

Page 7Page 6
Controls
Safety Information Getting Started
5. SERVICING - The user should not attempt to
service BTH01 beyond those methods
described in the user’s manual. Opening
or removing covers will expose you to
dangerous voltage and other hazards.
Service methods not covered in the user’s
manual should be referred to qualified
service personnel.
6. SAFETY CHECK - Upon completion of any
service or repair to BTH01, ask the service
technician to perform safety checks to
determine that the product is in proper
working condition.
7. BATTERY - This device contains a
rechargeable Lithium Polymer battery.
Please do not attempt to replace the battery
yourself. The battery may only be replaced
by our authorized service centers.
POWER & TALK button
Play/Pause button
Logo
(with LED)
Volume Contro
l
buttons
Left/Right
Receivers
Microphone
USB Port
button
/

Page 9Page 8
Pairing
While the headset is off, press and hold the
button for 6 seconds to start pairing mode.
Once the headset is in the pairing mode, select
‘BTH01’ among discovered Bluetooth devices
on the phone and enter the password ‘0000’
to pair the headset. When connected , voice
prompt will be “Connected”.
Easy Pairing
The FreeAgent supports easy pairing. When
pairing to a device that supports easy pairing,
there is no need to enter the password ‘0000’.
Note: Host device also has to support easy pairing.
Multi Pairing
1. All Bluetooth devices to be used in multi
pairing must be first paired individually
using the appropriate profiles. (HSP or HFP
for phone conversation, and A2DP for high
quality audio)
Note: Each profile cannot be used to connect
more than one device simultaneously. See
‘Notice’ below for more details. The auto
connect function of the headset will connect
each profile to the last connected device.
2. Once the host devices are paired,
connections can be made by:
a. Turning the headset off and on
(Auto connect function will take effect).
b. Or connecting from host devices.
Power ON/OFF
Press and hold button for 3 seconds to
switch the headset on or off. The Power ON/
OFF voice prompts are “Hello” and “Bye”.
Connecting the Headset
Connecting from the phone - Among registered
Bluetooth devices on the phone, select ‘BTH01’.
Connecting from the headset - Through
the auto-connect function, the headset
automatically connects to the last device it was
connected to when powered on.
Operational Instructions Operational Instructions

Page 11Page 10
Making Phone Calls
Voice dial
Press the button once to activate voice
dial. (Some phones might not support this
function.)
Last Number Redial
Double click the button to redial last
number.
Answer a call
When receiving a call, press the button to
answer the call.
Ending a call
While talking on the phone, press the button
to end the call.
Rejecting a call
While receiving a call, press the button to
refuse the call.
Volume Control
Use the +/- buttons to adjust the volume level.
Call Transfer
During a phone conversation, press the
button to switch the call between the headset
and the phone.
Listening to Music
Play/Pause
1. Press the button to launch the
phone’s MP3 player and to start listening to
music.
2. While the MP3 player is in use, press the
button to pause or to resume play.
3. Press and hold the button to end
music playback.
Song Selection
While MP3 player is in use, press the or
buttons to select songs.
Rewind/Forward
While music is playing, press and hold the or
buttons to rewind or fast forward the song.
(Some devices may not support this function.)
Operational Instructions Operational Instructions

Page 13Page 12
Answering a Call While Listening to
Music
1. When receiving a call, press the button
to answer the call.
2. Press the button while on the phone
to end the call.
3. When receiving a call, press the button
to reject the call. (Music will resume playing
when the call is rejected.)
Volume Control
Use the +/- buttons to adjust the volume level.
3D Sound
Using 3D Sound
5 types of 3D sound effect are programmed in
the order below. While in the Play/Pause mode,
double click the button to select the 3D sound
effect of your choice.
Types of 3D Sound Effect
Normal: No 3D sound effect is applied.
Note: Two beeping sounds will indicate that
the headset is in Normal mode.)
Xome: Provides a comfortable and persistent
listening environment by taking
distractible sound away from the ears
and head when using the FreeAgent.
Live: Delivers a natural and soft 3D
sound field effect simulating that of a live
performance.
Wide: Widely spread main vocal and
center-placed instruments by providing
a panoramic 3D audio image.
Max: Not only delivers a wide stereo sound
image, but also enhances low-frequency
sound to provide rich and deep bass
tones.
Resetting the Headset
In case the headset needs to be reset, press
the , and +buttons together
simultaneously.
Operational Instructions Operational Instructions

Page 15Page 14
Operational Instructions Troubleshooting
Remarks:
If troubleshooting does not eliminate the problem,
shut down the headset by pressing and holding the
on the device to reset. Shutting down the headset
resets it to factory default settings and results in the
deletion of all previous settings. In case the problem
still exists, see warranty information on page 18 to
obtain service.
Symptom
Music is not
streaming over
Bluetooth
BTH01 doesn’t
answer phone
calls
Music doesn’t
resume after
hanging up a call
No music control
by BTH01
No power
Solution
Make sure BTH01 is fully
charged.
Make sure your Bluetooth
device has A2DP profile.
Check if both devices are
paired and connected
over Bluetooth.
Restart the BTH01 to
auto-connect with your
Bluetooth device.
Make sure your mobile has
HSP/HFP profile.
Check if both devices are
paired and connected
over Bluetooth.
Restart the BTH01 to
auto-connect with your
Bluetooth device.
Press play to resume
music.
Make sure your Bluetooth
device has AVRCP profile.
LED Light Messages
· Blue LED light is on: Powering on
· Red LED light dims and disappears:
Powering off
· Red LED light continues to blink: Low
battery
· Red LED light stays on: Recharging
· Blue LED lights stays on: Recharging
complete
· Blue and Red LED lights flash rapidly:
Pairing Mode
· Blue LED light blinks every two seconds:
Connection complete
· Blue LED light flashes rapidly: Receiving
a call
· Blue LED light repeatedly brightens and
dims: Talking on the phone/Playing music
Voice Prompt Messages
· When you turn the headset power on,
voice prompt is “Hello”.
· When you turn the headset power off,
voice prompt is “Bye”.
· When pairing is completed, voice prompt is
“Connected”.
· When the battery reaches less than 20%
capacity, voice prompt is “Battery low”.
· “Battery low” voice prompt settings;
- At 3.5v = 20% capacity - Once.
- At 3.3v - Every 30 seconds until the
headset powers off.

Page 17Page 16
The equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate Radio frequency
energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to
Radio communications.
However, there is no guarantee that interference will
not occur in a particular installation. If this equipment
does cause harmful interference to Radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment
and receiver.
- Connect the equipment into an outlet on a circuit
different from which the receiver is connected.
- Consult the dealer or an experienced Radio/
television technician for assistance.
THE SPECIFICATION AND EXTERNAL APPEARANCE OF
THE HEADSET ARE SUBJECT TO CHANGE WITHOUT PRIOR
NOTICE.
If at any time in the future you should
need to dispose of this product,
please note that: waste electrical
products should not be disposed of
with household waste. Please recycle
where facilities exist. Check with your
local authority or retailer for recycling
advice.
- Working distance: Maximum 33ft (10m)
- Frequency response: 2.4 ~ 2.4835 GHz
- Operating time:
Talk up to 14 hours/Music up to 12 hours
- Standby time: up to 340 hours
- Charging time: 2 hours
- Bluetooth 2.1 + EDR
- Bluetooth compatibility:
Bluetooth 2.0 or above device
with A2DP/AVRCP/HFP/HSP
Compliance with FCC
Regulations
Specifications
purchase date:
place of purchase:

Page 19Page 18
Limited Warranty
The AT&T brands are used under license. Any repair,
replacement, or warranty service, and all questions about this
product should be directed to Concept 101 LLC at www.att.
com/electronicsor call 1 [phone]from the
USA or Canada.
Concept 101 LLC warrants to the original purchaser that
the product will be free from defects in material, parts and
workmanship for the period designated for this product.
The warranty commences the day the product is purchased
and covers up to a period of one (1) year. Concept 101 LLC
agrees that it will, at its option, replace the defective product
with either a new or remanufactured headset equivalent to
your original purchase during the warranty period. Should
the Parts warranty period exceed the Labor warranty period,
Concept 101 LLC will supply at no charge for the remainder of
the Parts warranty, any new or remanufactured replacement
parts as required by the product. During this period all labor
and service charges will become the responsibility of the
customer.
Exclusions: This warranty does not apply to the
appearance or exterior of the product which
may have been damaged or defaced, altered
or modified in design or construction. This
warranty does not apply if the serial number is
altered or removed, or if there is any damage
due to power line surge, user damage to the AC
power cord, connection to improper voltage
source, general misuse, accidents, or repair
attempts by unauthorized service agents. Other
exclusions include ear pads, rechargeable and
non-rechargeable batteries.
REPAIR OR REPLACEMENT AS PROVIDED UNDER
THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE
CUSTOMER; Concept 101 LLC SHALL NOT BE LIABLE FOR
Obtaining Service: To obtain service, product literature,
supplies or accessories please call
1 888-920-8680, or visit
our website, www.att.com/
electronics,to create a ticket for
exchange/repair. Please make sure to
provide the date of purchase, model
number and a brief description of
the problem. Our customer service
representative will contact you or send
detailed return instructions.
Some states do not allow the exclusion or limitations of
incidental or consequential damages, or limitations on how
long the warranty lasts. In these cases the above exclusions
or limitations may not apply to you. This warranty gives you
specific legal rights and you may also have other rights which
vary from state to state.
Concept 101 LLC does not warrant that the headset will
work properly in all environmental conditions, and makes no
warranty and representation, either implied or expressed,
with respect to the quality, performance, merchantability,
or fitness for a particular purpose other than the purpose
identified within this user’s manual. Concept 101 LLC has made
every effort to ensure that this user’s manual is accurate and
disclaims liability for any inaccuracies or omissions that may
have occurred. Information in this user’s manual is subject to
change without notice and does not represent a commitment
on the part of Concept 101 LLC. Concept 101 LLC reserves
the right to make improvements to this user’s manual and/or
to the products described in this user’s manual at any time
without notice. If you find information in this manual that
is incorrect, misleading, or incomplete, please contact us
through our website.
Warranty Information Warranty Information
ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR
BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON
THIS PRODUCT, EXCEPT TO THE EXTENT PROHIBITED
BY APPLICABLE LAW. ANY IMPLIED WARRANTY OF
MERCHANTABILITY OF FITNESS FOR A PARTICULAR
PURPOSE ON THIS PRODUCT IS LIMITED TO THE
DURATION OF THE WARRANTY.

©2015 Concept 101 LLC. All Rights Reserved. AT&T
and the AT&T logo are trademarks of AT&T Intellectual
Property licensed to Concept 101 LLC, New York, New
York 10018. Issue 1.1 AT&T 12/2015.
www.att.com/electronics
