ATD-5830
3/16” AIR RIVETER INSTRUCTION MANUAL
Safety Precautions
xDo not use the tool outside of the designed intent.
xNever modify the tool for any purpose.
xNormal use of this product is likely to expose the user to dust and /or microscopic
particles containing chemicals known to the State of California to cause cancer, birth
defects or other reproductive harm. Always wear appropriate safety equipment and
clothing when using this product. Study, understand and follow all instructions
provided with this product.
xAlways wear ANSI approved goggles when using this product.
xAlways select the correct accessories of the correct size and design for the job that
you are attempting to perform.
xAlways work in a clean, safe, well-lit, organized and adequately equipped area.
xDo not begin repairs without assurance that vehicle is in secure position and will not
move during repair.
Important:
Read these instructions carefully before installing, operating, servicing or repairing this tool.
Keep these instructions in a safe accessible place.
Unpacking:
When unpacking this unit, check the parts diagram and part number listing to make sure all
parts are included. If any parts are missing or damaged please call your distributor.
Product Information:
xPowerful durable, high speed production tool
xQuick release air valve permits cylinder to return quickly for high speed assembly
operations: Prevents overloading for long life.
xPerforms well at any angle
xGets into hard-to-reach areas
xProvides quick, quiet and comfortable operation preventing user fatigue
xIncludes 3/16”(4.8mm), 5/32”(4mm), 1/8”(3.2mm) & 3/32”(2.4mm) nosepieces

Specifications:
Rivet Capacity: 3/16”
Overall Length: 10-5/8”(270mm)
Net Weight: 3lbs(1.41kg)
Stroke: 1/2”(14mm)
Motor: 1/2hp
Air Inlet Thread NPT: 1/4”
Air Hose I.D. Size: 3/8”(10mm)
Avg. Air Consumption: 4cfm
Air Pressure: 90-120psi
Maintenance/Adding Oil for Hydraulic Riveter
1. Turn off air supply
2. Use spanner wrench to dismantle the riveter head (fig. 1).
3. Use spanner wrench to open bottom cover of the riveter (fig. 2).
4. Remove piston from cylinder (fig. 3).
5. Clean inside of the cylinder and lubricate cover seal (fig. 4).
6. Lubricate the intake with oil until full (fig. 5).
7. Clean piston stem and add grease on the inner wall of the cylinder and the ring.
8. Reassemble (fig.6).
Cleaning/Maintenance for the Head of Riveter
1. Turn off air supply.Assure all pressure is released prior to disassembly.
2. Use spanner wrench to dismantle the riveter head (fig.1).
3. Use spanner wrench to disassemble (fig. 2).
4. Clean all inner/assembly parts of the riveter head with a brush.
5. Reassemble the inner/assembly parts.
6. Oil the parts and reassemble riveter head completely.

ATD-5830

ATD-5830
ITEM# ORDERING PART# PART DESCRIPTION ITEM# ORDERING PART# PART DESCRIPTION
1 PRT5830-01 NOSEPIECE 26 PRT5830-26 LINK
2 PRT5830-02 OUTER CYLINDER 27 PRT5830-27 PRESS PLANK
3 PRT5830-03 JAW CARRIER 28 PRT5830-28 AIR VALVE
4 PRT5830-04 JAW 29 PRT5830-29 VALVE SPRING
5 PRT5830-05 JAW PUSHER 30 PRT5830-30 COPPERWASHER
6 PRT5831-06 JAW PUSHSPRING 31 PRT5830-31 AIRPROOF PLASTIC
7 PRT5830-07 JAW CYLINDER 32 PRT5830-32 AIRPROOF SPRING
8 PRT5830-08 CASE LOCK NUT 33 PRT5830-33 AIRPROOF NUT
9 PRT5830-09 PRINCIPAL AXIS B01 PRT5830-B01 O-RING
10 PRT5830-10 PLASTIC RING B02 PRT5830-B02 O-RING
11 PRT5830-11 HANDLE B03 PRT5830-B03 O-RING
12 PRT5830-12 LEAD AXIS B04 PRT5830-B04 O-RING
13 PRT5830-13 PLASTIC RING B05 PRT5830-B05 O-RING
14 PRT5830-14 RESTORE SPRING B06 PRT5830-B06 SPRING PIN
15 PRT5830-15 POTHOOK B07 PRT5830-B07 SPRING PIN
16 PRT5830-16 AIRPROOF LID B08 PRT5830-B08 SPRING PIN
18 PRT5830-18 LOCK NUT B09 PRT5830-B09 SPRING PIN
19 PRT5830-19 AIR CYLINDER B10 PRT5830-B10 O-RING
20 PRT5830-20 POLE PISTON B11 PRT5830-B11 O-RING
21 PRT5830-21 CUSHION B12 PRT5830-B12 O-RING
22 PRT5830-22 PISTON B13 PRT5830-B13 O-RING
23 PRT5830-23 NUT C01 PRT5830-C01 BOTTLE
24 PRT5830-24 AIR CYLINDER LID C02 PRT5830-C02 NUT
25 PRT5830-25 TRIGGER
