To USB port
To RS-422/485
Serial Port
Terminal Block Table
Pin RS-422 (4-wire) RS-485 (2-wire)
1 TxD-(A) Data-(A)
2 TxD+(B) Data+(B)
3 RxD+(B) -
4 RxD-(A) -
5 GND GND
1
2
3
or
or
543 2 1
Alarm
Sensor
Camera
Control
Male DB9
123 4
67 8 9
5
DB9 Pin Assignment
Pin RS-422 (4-wire) RS-485 (2-wire)
1 TxD-(A) Data-
2 TxD+(B) Data+
3 RxD+(B) -
4 RxD-(A) -
5 GND GND
6 RTS- -
7 RTS+ -
8 CTS+ -
9 CTS- -
or
UC485 USB to RS-422/485 Adapter Adaptador USB a RS-422/485 UC485
Adaptateur USB vers RS-422/485 UC485 Adattatore USB-RS-422/485 UC485
USB-zu-RS-422/485-Netzteil UC485 UC485 Адаптер USB - RS-422/485
www.aten.com www.aten.com
www.aten.com www.aten.com
www.aten.com www.aten.com
A
Hardware Review
Front View
1USB Connector
2Serial Connector
3Connector Nut
4Power LED
5Mode Selector
6Terminal Connectors
7Adapter Connector (Female)
8Connector Screws
B
Hardware Installation
To install the UC485, do the following:
1Connect the USB plug to the computer and allow the drivers to install.*
2Plug the RS-422/485 connector to a serial device.
3(Optional) If you are using terminal connectors, plug the Terminal Adapter
included with this package to the RS-422/485 Serial Connector and use the
Terminal Block Table to wire the connections.
4Use the mode selector to configure the connection type.
5Power on the serial devices.
*If you are using an older computer that doesn’t contain the drivers for this
device, please go to our website to download the UC485 drivers and install
them before setting up the hardware.
A
Hardwareübersicht
Ansicht von vorne
1USB-Anschluss
2Serieller Anschluss
3Anschlussmutter
4Betriebsanzeige-LED
5Modusauswahl
6Terminalanschlüsse
7Netzteilanschluss (Buchse)
8Anschlussschrauben
B
Hardwareinstallation
Gehen Sie zur Installation des UC485 wie folgt vor:
1Verbinden Sie den USB-Stecker mit dem Computer und erlauben Sie die
Installation der Treiber.*
2Verbinden Sie den RS-422/485-Anschluss mit einem seriellen Gerät.
3(Optional) Wenn Sie Terminalanschlüsse verwenden, stecken Sie den
mitgelieferten Terminaladapter in den seriellen Anschluss (RS-422/485) und
verwenden Sie die Anschlussblocktabelle zur Verkabelung.
4Konfigurieren Sie mit dem Moduswähler den Verbindungstyp.
5Schalten Sie die seriellen Geräte ein.
*Falls Sie einen älteren Computer benutzen, der keine Treiber für dieses Gerät
enthält, rufen Sie bitte unsere Webseite auf, laden Sie die UC485-Treiber
herunter und installieren Sie diese, bevor Sie die Hardware einrichten.
A
Aperçu du matériel
Vue de devant
1Connecteur USB
2Connecteur série
3Écrou du connecteur
4LED d'alimentation
5Sélecteur de mode
6Connecteurs de bornes
7Connecteur de l'adaptateur (Femelle)
8Vis du connecteur
B
Installation du matériel
Pour installer l'UC485, procédez comme suit :
1Connectez la prise USB à l'ordinateur et laissez les pilotes s'installer.*
2Branchez le connecteur RS-422/485 à un appareil série.
3(Optionnel) Si vous utilisez des connecteurs de bornes, branchez l'adaptateur
de bornes inclus avec cet emballage au connecteur série RS-422/485 et utilisez
le tableau du bornier pour câbler les connexions.
4Utilisez le sélecteur de mode pour configurer le type de connexion.
5Mettez sous tension les appareils série.
*Si vous utilisez un ordinateur plus ancien qui ne contient pas les pilotes pour
cet appareil, veuillez vous rendre sur notre site Web pour télécharger les pilotes
UC485 et les installer avant de configurer le matériel.
A
Resumen de hardware
Vista frontal
1Conector USB
2Conector serie
3Tuerca de conector
4LED de alimentación
5Selector de modo
6Conectores del terminal
7Conector del adaptador (hembra)
8Tornillos del conector
B
Instalación del hardware
Para instalar el adaptador UC485, realice el siguiente procedimiento:
1Conecte el enchufe USB al equipo y deje que se instalen los controladores.*
2Enchufe el conector RS-422/485 a un dispositivo serie.
3(Opcional) Si utiliza conectores de terminal, enchufe el adaptador de terminal
incluido con este paquete al conector serie RS-422/485 y utilice la tabla de
bloque de terminales para cablear las conexiones.
4Utilice el selector de modo para configurar el tipo de conexión.
5Encienda los dispositivos serie.
*Si utiliza un equipo antiguo que no contenga los controladores para este
dispositivo, vaya a nuestro sitio web para descargar los controladores del
adaptador UC485 e instálelos antes de configurar el hardware.
A
Descrizione hardware
Vista anteriore
1Connettore USB
2Connettore seriale
3Dado connettore
4LED Power (Alimentazione)
5Selettore modalità
6Connettori terminali
7Connettore adattatore (femmina)
8Viti connettore
B
Installazione dell'hardware
Per installare l'UC485, agire come segue:
1Collegare la spina USB al computer e consentire l'installazione dei driver.*
2Collegare il connettore RS-422/485 ad un dispositivo seriale.
3(Opzionale) Se si utilizzano connettori terminali, collegare l'adattatore
terminale incluso in questa confezione al connettore seriale RS-422/485 e
utilizzare la Tabella morsettiera per collegare i connettori.
4Utilizzare il selettore modalità per configurare il tipo di collegamento.
5Accendere i dispositivi seriali.
*Se si utilizza un computer meno recente che non contiene i driver per questo
dispositivo, visitare il nostro sito web per scaricare i driver dell'UC485 e installarli
prima di configurarer l'hardware.
A
Обзор аппаратного обеспечения
Вид спереди
1Разъем USB
2Последовательный разъем
3Гайка разъема
4Индикатор питания
5Селектор режимов
6Разъемы клеммной колодки
7Разъем адаптера (гнездо)
8Винты разъема
B
Установка аппаратного обеспечения
Для установки UC485 выполните следующие действия.
1Подключите вилку USB к компьютеру и подождите, пока завершится
установка драйверов.*
2Подключите устройство с последовательным интерфейсом к разъему
RS-422/485.
3(Дополнительно) Если используются разъемы клеммной колодки,
подключите входящий в комплект поставки терминальный адаптер
к последовательному разъему RS-422/485 и соедините провода,
руководствуясь таблицей разъемов клеммной колодки.
4Настройте тип подключения, используя селектор режимов.
5Включите питание устройств с последовательным интерфейсом.
* Если используется компьютер старой модели, на котором отсутствуют
драйверы для данного устройства, зайдите на веб-сайт компании,
загрузите драйверы UC485 и установите их перед установкой
аппаратного обеспечения.
AHardware Review
© Copyright 2017 ATEN®International Co., Ltd.
ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All
other trademarks are the property of their respective owners.
This product is RoHS compliant.
Part No. PAPE-1223-I60G Printing Date: 07/2017
USB to RS-422/485 Adapter
Quick Start Guide
UC485
Package Contents
1 UC 485 USB to RS-422/485 Adapter
1 Terminal Adapter
1 User Instructions
Support and Documentation Notice
All information, documentation, firmware, software utilities, and
specifications contained in this package are subject to change without
prior notification bythe manufacturer.
To reduce the environmental impact of our products, ATEN
documentation and software can be found online at
http://www.aten.com/download/
Technical Support
www.aten.com/support
이 기기는 업무용(A급) 전자파적합기기로서 판매자 또는 사용자는 이 점을 주의하시기 바라며,
가정외의 지역에서 사용하는 것을 목적으로 합니다.
EMC Information
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT:
This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
Warning: Operation of this equipment in a residential environment could cause radio interference.
Suggestion: Shielded twisted pair (STP) cables must be used with the unit to ensure compliance
with FCC & CE standards.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:(1) this device mat not cause harmful interference, and(2) this device must accept any
interference received, including interference that may cause undesired operation.
Scan for
more information
2
6
7
4
8
3
5
1
Mode Selector
Switch Name Position Description
1No Term /
Term
No Term
(Default) The Terminator resistor is disabled.
Term The Terminator resistor is enabled.
2Echo /
No Echo
Echo The data transmitted is echoed back.
No Echo
(Default) No data is echoed back.
3 485 / 422
485
(Default) RS-485 2-Wire Mode
422 RS-422 4-Wire Mode
BHardware Installation
