ATEN ES0152 User manual

ES0152 / ES0152P
52-Port GbE (PoE) Managed Switch
CLI User Manual
www.aten.com

ES0152 / ES0152P CLI User Manual
ii
EMC Information
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT: This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
The device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate this
equipment.
Warning: Operation of this equipment in a residential environment could
cause radio interference.
KCC Statement
Suggestion: Shielded twisted pair (STP) cables must be used with the unit to
ensure compliance with FCC & CE standards.

ES0152 / ES0152P CLI User Manual
iii
RoHS
This product is RoHS compliant.
Copyright © 2019 ATEN® International Co., Ltd.
Manual Date: 2019-11-05
Altusen and the Altusen logo are registered trademarks of ATEN International Co., Ltd. All rights reserved.
All other brand names and trademarks are the registered property of their respective owners.

ES0152 / ES0152P CLI User Manual
iv
Content
EMC Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
RoHS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iv
About This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .ix
Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .xi
Chapter 1. Introduction
ES0152 / ES0152P CLI User Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Purpose. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Chapter 2. CLI Management
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2-1 Login. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2-2 Commands of CLI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Command Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Change Between Command Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2-3 Global Commands of CLI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Exit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Help. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
logout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 3. CABLEDIAG of CLI
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Chapter 4. CLEAR of CLI
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4-1 access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4-2 access-list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4-3 dot1x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4-4 ip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4-5 ipv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4-6 lacp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4-7 lldp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4-8 logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4-9 mac . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4-10 mvr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4-11 port-security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4-12 sflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4-13 spanning-tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4-14 statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4-15 system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

ES0152 / ES0152P CLI User Manual
v
Chapter 5. CONFIGURE Commands of CLI
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5-1 terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5-1.1 aaa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5-1.2 access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5-1.3 access-list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
5-1-3.1 ace. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
5-1.4 aggregation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
5-1.5 banner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
5-1.6 clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5-1.7 default . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5-1.8 dms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5-1.9 do . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5-1.10 dot1x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5-1.11 enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5-1.12 end . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5-1.13 event . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
5-1.14 green-ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
5-1.15 gvrp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
5-1.16 help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
5-1.17 hostname . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5-1.18 interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
5-1.19 ip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
5-1.20 ipmc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5-1.21 ipv6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
5-1.22 lacp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
5-1.23 line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
5-1.24 lldp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
5-1.25 logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
5-1.26 loop-protect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
5-1.27 mac . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
5-1.28 monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
5-1.29 mvr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
5-1.30 mvrp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
5-1.31 no . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
5-1.31.1 aaa. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
5-1.31.2 access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
5-1.31.3 access-list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
5-1.31.4 aggregation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
5-1.31.5 banner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .61
5-1.31.6 clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
5-1.31.7 dot1x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
5-1.31.8 enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .63
5-1.31.9 green-ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
5-1.31.10 gvrp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
5-1.31.11 hostname. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

ES0152 / ES0152P CLI User Manual
vi
5-1.31.12 interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
5-1.31.13 ip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
5-1.31.14 ipmc. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
5-1.31.15 ipv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
5-1.31.16 lacp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
5-1.31.17 lldp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
5-1.31.18 logging. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
5-1.31.19 loop-protect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
5-1.31.20 mac . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
5-1.31.21 monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
5-1.31.22 mvr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
5-1.31.23 mvrp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
5-1.31.24 ntp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
5-1.31.25 poe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
5-1.31.26 port-security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
5-1.31.27 privilege. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
5-1.31.28 prompt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
5-1.31.29 Qos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
5-1.31.30 radius-server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
5-1.31.31 rmon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
5-1.31.32 sflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
5-1.31.33 snmp-server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
5-1.31.34 spanning-tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
5-1.31.35 svl . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
5-1.31.36 switch2go-management . . . . . . . . . . . . . . . . . . . . . . . . 83
5-1.31.37 system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
5-1.31.38 tacacs-server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
5-1.31.39 udld . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
5-1.31.40 upnp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
5-1.31.41 username . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
5-1.31.42 vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
5-1.31.43 voice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
5-1.31.44 web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
5-1.32 ntp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
5-1.33 poe. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
5-1.34 port-security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
5-1.35 privilege . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
5-1.36 prompt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
5-1.37 qos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
5-1.38 radius-server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
5-1.39 rmon. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
5-1.40 sflow. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
5-1.41 smtp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
5-1.42 snmp-server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
5-1.42.1access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
5-1.42.2 community. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

ES0152 / ES0152P CLI User Manual
vii
5-1.42.3 security-to-group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
5-1.42.4 user . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100
5-1.42.5 view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .101
5-1.43 spanning-tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
5-1.43.1 mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .102
5-1.43.2 mst. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
5-1.44 svl. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103
5-1.45 switch2go-management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
5-1.46 system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
5-1.47 tacacs-server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
5-1.48 udld . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106
5-1.49 upnp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
5-1.50 username . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
5-1.51 vlan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
5-1.52 voice. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
5-1.53 web. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Chapter 6. COPY Commands of CLI
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .115
Chapter 7. DELETE Commands of CLI
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .117
Chapter 8. DIR Commands of CLI
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
Chapter 9. DISABLE Commands of CLI
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121
Chapter 10. DO Commands of CLI
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .123
Chapter 11. DOT1X Commands of CLI
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .125
Chapter 12. ENABLE Commands of CLI
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
Chapter 13. FIRMWARE of CLI
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .129
Chapter 14. IP Commands of CLI
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .131
Chapter 15. IPV6 Commands of CLI
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .133
Chapter 16. MORE of CLI
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .135

ES0152 / ES0152P CLI User Manual
viii
Chapter 17. NO Commands of CLI
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Chapter 18. PING of CLI
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139
Chapter 19. PLATFORM Commands of CLI
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141
Chapter 20. RELOAD of CLI
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Chapter 21. SEND of CLI
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
Chapter 22. SHOW of CLI
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147
22-1 aaa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
22-2 access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
22-3 access-list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
22-4 aggregation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
22-5 board-data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
22-6 clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
22-7 dot1x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
22-8 event . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
22-9 green-ethernet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
22-10 history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
22-11 interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 158
22-12 ip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
22-13 ipmc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
22-14 ipv6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
22-15 lacp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
22-16 line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 165
22-17 lldp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
22-18 logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
22-19 loop-protect. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
22.20 mac . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 170
22-21 monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
22-22 mrp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
22-23 mvr . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
22-24 ntp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
22-25 platform. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176
22-26 poe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
22-27 port-security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
22-28 privilege. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
22-29 process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180
22-30 pvlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180

ES0152 / ES0152P CLI User Manual
ix
22-31 qos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 181
22-32 radius-server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .182
22-33 rmon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183
22-34 running-config . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 184
22-35 sflow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .185
22-36 smtp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186
22-37 snmp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 187
22-38 spanning-tree . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189
22-39 svl . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .189
22-40 switch2go-management . . . . . . . . . . . . . . . . . . . . . . . . . . . . .190
22-41 switchport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .191
22-42 system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .191
22-43 tacacs-server. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192
22-44 terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .192
22-45 udld . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
22-46 upnp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194
22-47 user-privilege. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .195
22-48 users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195
22-49 version. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .196
22-50 vlan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 196
22-51 voice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199
22-52 web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Chapter 23. TERMINAL of CLI
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .205
Chapter 24. TRACEOUTE of CLI
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .207
Chapter 25. CLI COMMAND REFERENCES
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .209
25-1 Privilege level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .209
25-2 Command modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .209

ES0152 / ES0152P CLI User Manual
x
About This Manual
The CLI User Manual provides specific information about using CLI to operate
this switch.
Overview
Chapter 1, Introduction, introduces you the release version, purpose, and
audience for ES0152 / ES0152P CLI user guide.
Chapter 2, CLI Management, provides step-by-step instructions for CLI
management, including login, commands of CLI, and global commands of
CLI.
Chapter 3, CABLEDIAG of CLI, shows a description, syntax, parameter,
and example for CABLEDIAG commands.
Chapter 4, CLEAR of CLI, shows a table of CLEAR commands with
description, syntax, parameter, and example.
Chapter 5, CONFIGURE Commands of CLI, shows a table of
CONFIGURE commands with description, syntax, parameter and example.
Chapter 6, COPY Commands of CLI, shows a description, syntax,
parameter, and example for COPY commands.
Chapter 7, DELETE Commands of CLI, shows a description, syntax,
parameter, and example for DELETE commands.
Chapter 8, DIR Commands of CLI, shows a description, syntax,
parameter, and example for DIR commands.
Chapter 9, DISABLE Commands of CLI, shows a description, syntax,
parameter, and example for DISABLE commands.
Chapter 10, DO Commands of CLI, shows a description, syntax,
parameter, and example for DO commands.
Chapter 11, DOT1X Commands of CLI, shows a description, syntax,
parameter, and example for DOT1X commands.
Chapter 12, ENABLE Commands of CLI, shows a description, syntax,
parameter, and example for ENABLE commands.
Chapter 13, FIRMWARE of CLI, shows a description, syntax, parameter,
and example for FIRMWARE commands.
Chapter 14, IP Commands of CLI, shows a description, syntax, parameter,
and example for IP commands.

ES0152 / ES0152P CLI User Manual
xi
Chapter 15, IPV6 Commands of CLI, shows a description, syntax,
parameter, and example for IPV6 commands.
Chapter 16, MORE of CLI, shows a description, syntax, parameter, and
example for MORE commands.
Chapter 17, NO Commands of CLI, shows a description, syntax,
parameter, and example for NO commands.
Chapter 18, PING of CLI, shows a description, syntax, parameter, and
example for PING commands.
Chapter 19, PLATFORM Commands of CLI, shows a description, syntax,
parameter, and example for PLATFORM commands.
Chapter 20, RELOAD of CLI, shows a description, syntax, parameter, and
example for RELOAD commands.
Chapter 21, SEND of CLI, shows a description, syntax, parameter, and
example for SEND commands.
Chapter 22, SHOW of CLI, shows a table of SHOW commands with
description, syntax, parameter and example.
Chapter 23, TERMINAL of CLI, shows a description, syntax, parameter,
and example for TERMINAL commands.
Chapter 24, TRACEOUTE of CLI, shows a description, syntax, parameter,
and example for TRACEOUTE commands.
Chapter 25, CLI COMMAND REFERENCES, explains the privilege
level, and a table of commands with description, privilege level, and the
corresponding mode.

ES0152 / ES0152P CLI User Manual
xii
Product Information
For information about all ATEN products and how they can help you connect
without limits, visit ATEN on the Web or contact an ATEN Authorized
Reseller. Visit ATEN on the Web for a list of locations and telephone numbers:
International http://www.aten.com

1
Chapter 1
About This Guide
Purpose
This guide gives specific information on how to operate CLI to manage this
switch.
Audience
The guide is intended for use by network administrators who are responsible for
operating and maintaining network equipment; consequently, it requires a
basic working knowledge of general switch functions, the RS-232 Console,
Internet Protocol (IP), and Telnet Protocol.

ES0152 / ES0152P CLI User Manual
2
This Page Intentionally Left Blank

3
Chapter 2
CLI Management
Overview
The following description briefly describes how to build up the network
connection.
Attach the RJ45 to DB9 Serial Console Cable to the console port on the
ES0152 / ES0152P’s front panel for telnet configuration
At “Com Port Properties” Menu, configure the parameters as below: (see
the next section)
Spec
Baud Rate 115200 bps
Stop Bits 1
Data Bits 8
Parity N
Flow Control None

ES0152 / ES0152P CLI User Manual
4
2-1 Login
3. The command-line interface (CLI) is a text-based interface. User can
access the CLI through either a direct serial connection to the device or a
Telnet session (Default IP address: 192.168.0.1). The default username is
admin. A preprogrammed password (inside the red square box below)
unique to each switch is provided on the sticker of the bottom side of the
switch. An example is shown:
If you are logging in for the first time or if you are sure that the password has
not been changed, use the preprogrammed password.
Note: This password is used for both CLI and web GUI interfaces, if it was
changed in either of the interfaces, use the new password to log in.
After you log in successfully, the prompt will be shown as “<sys_name>#“ .
See the following figures. It means you behave as an administrator and have
the privilege for setting the Managed Switch. If you log in as a guest instead of
an administrator, the prompt will be shown as “<sys_name>>”. It means you
behave as a guest and are only allowed to set the system under the
administrator. Each CLI command has its privilege.
Example:
Username: admin
Password: F759a987 (example only*)
ES0152#
Note: For “<sys_name>#“, we will use ES0152 as an example for our
ES0152 / ES0152P CLI User Manual.
The password should be retrieved from the bottom sticker of the
switch.

Chapter 2. CLI Management
5
2-2 Commands of CLI
The CLI is divided into serveral modes. If a user has enouth privilege to run a
particular command, the user has to run the command in the correct mode. To
see the command modes, please input “?” after the system prompt, then all the
commands will be listed in the screen. The command modes are listed as
belows:
Command Modes
Commands reside in the corresponding modes could run only in that mode. If
a user wants to run a particular command, the user has to change the mode to
the appropriate mode. The command modes are organized as a tree, and users
start from the enable mode. The following table explains how to change from
one mode to another.
Note:The Commands and parameters are not case-sensitive, which means
that any uppercase or lowercase character can be entered.
MODE: PROMPT COMMAND FUNTION IN THIS
MODE
exec <sys_name># Display current configuration,
diagnostics, maintenance
config <sys_name>(config)# Configure features other than
those below
config-if <sys_name>(config-
interface)#
Configure ports
config-if-vlan <sys_name>(config-if-vlan)# Configure static vlan
config-line <sys_name>(config-line)# Line Configuration
config-impc-profile <sys_name>(config-impc-
profile)#
IPMC Profile
config-snmp-host <sys_name>(config-snmp-
host)#
SNMP Server Host
config-stp-aggr <sys_name>(config-stp-
aggr)#
STP Aggregation
config-dhcp-pool <sys_name>(config-dhcp-
pool)#
DHCP Pool Configuration
config-rfc2544-
profile
<sys_name>(config-rfc2544-
profile)#
RFC2544 Profile

ES0152 / ES0152P CLI User Manual
6
Change Between Command Modes
MODE ENTER MODE LEAVE MODE
exec -- --
config Config terminal exit
config-interface Interface <port-type> <port-type-list> exit
config-vlan Interface vlan <vlan_list> exit

Chapter 2. CLI Management
7
2-3 Global Commands of CLI
Summary:
ES0152# ?
CableDiag Cable Diagnostic keyword
clear Reset functions
configure Enter configuration mode
copy Copy from source to destination
delete Delete one file in flash file system
dir Directory of all files in flash file
system
disable Turn off privileged commands
do To run exec commands in config mode
dot1x IEEE Standard for port-based Network
Access Control
enable Turn on privileged commands
exit Exit from the CLI
firmware Firmware
help Description of the interactive help
system
ip IPv4 commands
ipv6 IPv6 configuration commands
logout Exit from EXEC mode
more Display file
no Negate a command or set its defaults
ping Send ICMP echo messages
platform Platform configuration
reload Reload system
send Send a message to other tty lines
show Show running system information
terminal Set terminal line parameters
traceroute Trace the route to HOST

ES0152 / ES0152P CLI User Manual
8
Exit
Exit from EXEC mode.
Syntax:
Exit
Parameters:
None.
Example:
ES0152(config)# exit
Help
Description of the interactive help system.
Syntax:
Help
Parameters:
None.
Example:
ES0152# help
Help may be requested at any point in a command by
entering a question mark '?'. If nothing matches, the
help list will be empty and you must backup until
entering a '?' shows the available options.
Two styles of help are provided:
1. Full help is available when you are ready to enter a
command argument (e.g. 'show ?') and describes each
possible argument.
2. Partial help is provided when an abbreviated
argument is entered and you want to know what arguments
match the input (e.g. 'show pr?'.)
logout
Exit from EXEC mode.
Syntax:
Logout
