Appendix 5. User Manual
Refer to the following pages

Getting Started Guide
Software User’s Guides
Choose one of the following categories:
Online Manual
Technical Specifications
Compliance Information
Part Number 137-40178-50

USING VIDEO IN/OUT
User’s Guides
ALL-IN-WONDER 128
ALL-IN-WONDER PRO
Click on your product:
ATI MULTIMEDIA CENTER
ATI-TELETEXT MANUAL
Some ATI Graphics cards will not support all of the features
and functionality in the ATI Multimedia Center
ATI-TV WONDER
ATI-TV

RAGE FURY MAXX
RAGE FURY PRO
RAGE FURY
Technical InformationTechnical Information
ALL-IN-WONDER 128
ALL-IN-WONDER PRO
ALL-IN-WONDER
RAGE MAGNUM
XPERT 99
XPERT@WORK
XPERT 2000
XPERT@PLAY
XPERT 128
XPERT LCD
Click on your product:
XPERT 98
3D CHARGER
ALL-IN-WONDER 128 PRO

Getting Started...
• Installing Your ATI Graphics Accelerator Card
• Installing Enhanced Drivers for Windows® 95
and Windows® 98
• Installing Enhanced Drivers for Windows® NT
• Multiple Display Support in Windows® 98
• Troubleshooting Tips
• Using the Online Manual
ATI’s graphics accelerators are the most advanced on the market today. They
improve the performance of your system and display exceptional graphics.
Your ATI graphics accelerator comes complete with enhanced drivers and
comprehensive award-winning software utilities designed to make you more
productive. Please read this guide before attempting to install your card.
Preparing Your Computer
If you are using Windows®NT, you need to update your operating system to
Service Pack 3 (SP3) or later before installing your ATI graphics accelerator.
Additionally, if your current system configuration uses special drivers that are
not 640x480 VGA, you may encounter conflicts with the card. We recommend
that you first reconfigure your operating system to use a VGA driver supplied
with your operating system before installing the card. For more information
about changing your operating system configuration, see your operating system
documentation.
Turn off the power to your system and discharge your body’s static
electric charge by touching a grounded surface—for example, the metal
surface of the power supply—before performing any hardware procedure.
The manufacturer assumes no liability for any damage, caused directly or
indirectly, by improper installation of any components by unauthorized
service personnel. If you do not feel comfortable performing the
installation, consult a qualified computer technician.
Damage to system components, the accelerator card, and injury to
yourself may result if power is applied during installation.
M
E FIRST
RAGE™ 128 Version 2.0

Getting Started... 2
Installing Your ATI Graphics Accelerator Card
Now that you have prepared your computer, you are ready to install your
graphics accelerator card.
To install your graphics accelerator card
Power off the computer and monitor, then disconnect the display
cable from the back of your computer.
Remove the computer cover. If necessary, consult your computer’s
manual for help in removing the cover.
If you intend to run multiple displays with Windows®98 (see page 6),
then proceed to step 4. Otherwise, remove any existing graphics card
from your computer.
Or, if your computer has any on-board graphics capability, you may need to
disable it on the motherboard. For more information, see your computer
documentation.
1
DISPLAY CABLE
VIDEO OUTPUT
CONNECTOR
2
POWER SUPPLY
Remember to
discharge your
body’s static
electricity by
touching the
metal surface
of the
computer
chassis.
3
SCREW
EXISTING GRAPHICS CARD
If the old
graphics card
sticks, rock it
gently from
end to end.
Remember to
save the
screw.

Getting Started... 3
If necessary, remove the metal cover from the empty expansion slot that
you select (PCI card use a PCI slot; AGP cards use an AGP slot); then
align your new card with the expansion slot, and press it in firmly
until the card is fully seated.
Replace the screw to fasten the card in place, and replace the
computer cover.
Plug the display cable into your card; then turn on the computer and
display device. For cards with a Digital Flat Panel (DFP) connector,
connect your monitor or flat panel display (or both) to the appropriate
connector, as shown. Next, reboot your system.
You are now ready to proceed with the installation of ATI’s enhanced drivers.
For detailed instructions, select your operating system from the list below:
•Windows
®95/98, see Windows® “New Hardware Found” on page 4.
•Windows
®NT, see page 6.
4
ATI3DGRAPHICSCARD
CORRESPONDING EXPANSION SLOT
(PCI OR AGP)
Grasp the new
card by the top
edge and
carefully seatit
into the
appropriate
expansion slot
(PCI or AGP).
Ensure that
the metal
contacts are
completely
pushed into
the slot.
5
SCREW
ATI 3D
GRAPHICS CARD
6
DISPLAY CABLE
Make sure all
cables are
securely
connected.
TOVGA MONITOR
(ALL GRAPHICS CARDS)
TO FLAT PANEL DISPLAY
(DFP-READY CARDS ONLY)

Getting Started... 4
Windows®“New Hardware Found”
If you are running Windows® 95 or Windows®98, new hardware may be detected
after you restart your computer. Follow the step-by-step instructions below to
allow Windows®to correctly identify your new hardware.
To identify new hardware in Windows®95
1Windows®95 briefly displays the “New Hardware Found” dialog before
launching the “Update Device Driver Wizard”.
If the wizard does not appear, proceed directly to Installing Enhanced Drivers
for Windows® 95 and Windows® 98 on page 5.
2Click Next.
3Click Finish.
4Insert your Windows®95 CD-ROM into your CD-ROM drive.
5Click OK.
6Type the following:
D:\WIN95
(If Dis not your CD-ROM drive, substitute Dwith the correct drive letter.)
7Click OK.
8Click Yes to restart your computer.
You are now ready to install your ATI enhanced drivers. Proceed to Installing
Enhanced Drivers for Windows® 95 and Windows® 98 on page 5, and
follow the step-by-step instructions to complete the installation.
To identify new hardware in Windows®98
After restarting your system, Windows®98 will briefly display the “New
Hardware Found” dialog. Depending on your new hardware, you will either be
prompted to insert your Windows®98 CD-ROM or Windows®98 will launch
the “Add New Hardware Wizard”.
If Windows®98 automatically begins installing drivers for your new hardware,
click Yes to restart your computer when prompted; then proceed to Installing
Enhanced Drivers for Windows® 95 and Windows® 98 on page 5.
To identify new hardware using Windows®98 CD-ROM
1Insert your Windows®98 CD-ROM.
2Click OK.
3Type the following:
D:\WIN98
(If Dis not your CD-ROM drive, substitute D with the correct drive letter.)
4Click OK.
5Click Yes to restart your computer.

Getting Started... 5
You are now ready to install your ATI enhanced drivers. Proceed to Installing
Enhanced Drivers for Windows® 95 and Windows® 98 on page 5, and
follow the step-by-step instructions to complete the installation.
To identify new hardware using “Add New Hardware Wizard”
1Windows®98 launches the “Add New Hardware Wizard” which prompts you
to search for the Standard PCI Graphics Adapter (VGA).
2Click Next to continue.
3Select Search for the best driver for your device.
4Click Next to continue.
5Click Next to start the driver search.
6Click Next to install the Standard PCI Graphics Adapter (VGA).
7Click Finish.
8Click Yes to restart your computer.
You are now ready to install your ATI enhanced drivers. Proceed to Installing
Enhanced Drivers for Windows® 95 and Windows® 98 on page 5, and
follow the step-by-step instructions to complete the installation.
Installing Enhanced Drivers for Windows®95 and
Windows®98
With Windows®95 or Windows®98 running on your computer, you need to
install the enhanced ATI drivers to take advantage of your card’s higher
performance, resolutions, and special features.
To ensure that you install the latest drivers, install the ATI enhanced drivers
located on the CD-ROM shipped with your graphics accelerator card.
To install the ATI enhanced drivers for Windows®95 or
Windows®98
1Insert the ATI INSTALLATION CD-ROM into your CD-ROM drive.
If Windows®runs the CD-ROM automatically, proceed to step 6.
2Click Start.
3Select Run.
4Type the following:
D:\ATISETUP
(If Dis not your CD-ROM drive, substitute D with the correct drive letter.)
5Click OK.
6Click on ATI Easy Install to begin the Installation Wizard.
7Click Next.
8Click Yes.

Getting Started... 6
9Follow the Wizard’s on-screen instructions to complete the installation.
The Express installation option is recommended. If your ATI product includes a
multimedia component, the software for that component will automatically be
installed, along with the ATI enhanced drivers, by selecting this option.
Installing Enhanced Drivers for Windows®NT
Make sure that your operating system has been updated to Service Pack 3 (SP3)
or later before attempting to install your ATI graphics accelerator card. After
installing your card, Windows®NT will default to standard VGA mode (640 x
480, 16 colors).
To install the ATI enhanced drivers for Windows®NT 4.0
1Insert the ATI INSTALLATION CD-ROM into your CD-ROM drive.
If Windows®NT runs the CD-ROM automatically, proceed to step 6.
2Click Start.
3Select Run.
4Type the following:
D:\ATISETUP
(If Dis not your CD-ROM drive, substitute D with the correct drive letter.)
5Click OK.
6Click on ATI Easy Install to begin the Installation Wizard.
7Follow the Wizard’s on-screen instructions to complete the installation.
Multiple Display Support in Windows®98
IMPORTANT: Please read the Readme file on the ATI Installation CD-ROM
for the latest information regarding Multiple Display Support in Windows®98.
Windows®98 provides support for using more than one display device at a time
– you simply install a separate PCI or AGP graphics card for each additional
display you intend to use. With multiple displays, you can expand your desktop,
run different programs on separate displays, even play some newer games with
multiple views. And each display can have a different resolution and color
depth!
Note that, under Windows®98, one graphics card is automatically designated by
the system as the primary graphics card. Each additional graphics card is
designated by the system as a secondary graphics card. Certain 3D and
multimedia features are only available on the primary graphics card. The
primary graphics card is the one that displays the POST information during
startup. If you are installing more than one graphics card, you need to consider
the following:

Getting Started... 7
• If you install both a PCI and an AGP graphics card in the same system, the
AGP graphics card will become the secondary graphics card, in most
systems. Some manufacturers offer an upgraded BIOS that allows an AGP
card to be designated as the primary graphics card. Contact your system
vendor for details.
• If you install two or more PCI graphics cards in the same system, the primary
graphics card is typically the one installed in the PCI slot with the lowest
number. This is typically the PCI slot furthest from the computer’s ISA slots.
Consult your computer system manual for help in selecting a slot.
Troubleshooting Tips
The following troubleshooting tips may help if you experience problems.
Contact your dealer for more advanced troubleshooting information.
• Check that the card is seated properly in its expansion slot.
• Ensure the display cable is securely fastened to the card’s display connector.
• Make sure that the display and computer are plugged in and receiving power.
• If necessary, disable any built-in graphics capabilities on your motherboard.
For more information, see your computer’s manual.
• Make sure you selected the appropriate display device and graphics card
when you installed your enhanced driver.
• For more troubleshooting tips, right-click the ATI icon in the taskbar and
select Troubleshooting.
• If you have problems during start-up, start your computer in Safe Mode. In
Windows®95, press the F8 key when “Starting Windows 95” appears; or, in
Windows®98, press and hold the CTRL key until the Windows®98 Startup
Menu appears on the screen. Then select the number for Safe Mode, and
press Enter.

Getting Started... 8
Using the Online Manual
Your graphics accelerator comes with an online manual that describes the
extensive features of your graphics card. The Online Manual provides
reference, specification, disclaimer, legal, and compliance information that is
not contained in this paper guide.
To open the Online Manual
1Insert the ATI INSTALLATION CD-ROM into your CD-ROM drive.
If Windows®runs the ATI INSTALLATION CD-ROM automatically, proceed to
step 6.
2Click Start.
3Select Run.
4Type the following:
D:\ATISETUP
(If Dis not your CD-ROM drive, substitute D with the correct drive letter.)
5Click OK.
6Click on Online User Manual..

XPERT™ 2000
XPERT™ 2000
Technical Information
System Requirements
Pentium®II/III microprocessor-based, Celeron or compatible system
with Accelerated Graphics Port (AGP) slot.
AGP 1.0 compliant.
CD-ROM drive required for software.
DVD drive required for DVD playback. (Windows®95b, Windows®
98)
Specifications
Operating System Windows®95, Windows®98, Windows®NT 4.0
Memory Configuration 32 MB, non-upgradeable.
Sync Signals Separate horizontal and vertical sync at TTL levels.
Video BIOS AGP 1.0 compliant (AGP 2X compliant).
Video Output Connector CRT monitor, 15-pin D shell (female),
IBM standard.
Display support DDC1/2b/2b+ monitor support; VESA Display
Power Management support.
Video interrupt IRQ 11 is requested, although the actual IRQ
number is automatically assigned by the Plug & Play system BIOS.
Power +5V ±5% @ 0.4 A typical.
+3.3V ±5% @ 1.4 A typical.
+12V ±5% @ 0.3 A typical.

XPERT™ 2000
Ambient Temperature
Operating 50° to 122° F (10° to 50° C).
Storage 32° to 162° F (0° to 70° C).
Relative Humidity
Operating 5% to 90% non-condensing.
Storage 0% to 95%.
MTBF >300,000 hours.
EMC Certification FCC Class B.
Video Mode Table
XPERT 2000 Video Mode Table
Display
Screen
Resolution
Refresh
Rate
(Hz)
Hor.
Scan
(kHz)
Pixel
Clock
(MHz)
Colors
(Bits Per Pixel)
32 MB
816 24 *32
640x480 60 31.5 25.2 ••••
640x480 72 37.9 31.5 ••••
640x480 75 37.5 31.5 ••••
640x480 85 43.3 36.0 ••••
640x480 90 45.4 37.8 ••••
640x480 100 50.9 43.1 ••••
640x480 120 61.8 52.4 ••••
640x480 160 84.3 72.8 ••••
640x480 200 108.0 95.0 ••••
800x600 48 26.4 29.3 ••••
800x600 56 35.1 36.0 ••••
800x600 60 37.9 39.9 ••••
800x600 70 43.7 45.5 ••••
800x600 72 48.1 50.0 ••••
800x600 75 46.9 49.5 ••••
800x600 85 53.7 56.3 ••••
800x600 90 56.8 60.0 ••••
800x600 100 63.6 68.1 ••••
800x600 120 77.1 83.9 ••••
800x600 160 105.4 116.4 ••••
800x600 180 120.0 132.5 ••••
800x600 200 135.0 149.0 ••••
1024x768 43 35.5 44.9 ••••
1024x768 60 48.4 65.0 ••••
1024x768 70 56.5 75.0 ••••

XPERT™ 2000
1024x768 72 57.6 78.4 ••••
1024x768 75 60.0 78.8 ••••
1024x768 85 68.7 94.5 ••••
1024x768 90 72.8 100.1 ••••
1024x768 100 81.4 113.3 ••••
1024x768 120 98.7 139.0 ••••
1024x768 140 116.6 164.2 ••••
1024x768 150 125.7 176.9 ••••
1024x768 160 134.8 192.0 ••••
1024x768 180 153.5 218.6 ••••
1024x768 200 172.8 264.1 ••••
1152x864 43 38.0 56.0 ••••
1152x864 47 41.7 62.1 ••••
1152x864 60 53.7 81.6 ••••
1152x864 70 63.0 96.7 ••••
1152x864 75 67.5 108.0 ••••
1152x864 80 72.4 112.3 ••••
1152x864 85 77.0 119.6 ••••
1152x864 100 91.5 143.4 ••••
1152x864 120 111.1 176.0 ••••
1152x864 150 141.4 226.3 ••••
1152x864 160 151.6 242.6 ••••
1280x1024 43 45.1 75.1 ••••
1280x1024 47 49.4 83.0 ••••
1280x1024 60 64.0 108.0 ••••
1280x1024 70 74.6 128.9 ••••
1280x1024 74 79.0 138.5 ••••
1280x1024 75 80.0 135.0 ••••
1280x1024 85 91.1 157.5 ••••
1280x1024 90 97.0 169.2 ••••
1280x1024 100 108.5 190.9 ••••
1280x1024 120 131.6 233.7 •••
1280x1024 125 137.6 244.4 ••••
1280x1024 130 143.5 254.9 ••••
1600x1200 52 64.2 137.7 ••••
1600x1200 58 71.9 155.4 ••••
1600x1200 60 75.0 162.0 ••••
1600x1200 66 82.2 178.9 ••••
1600x1200 72 90.0 195.9 ••••
1600x1200 75 93.8 202.5 ••••
1600x1200 76 95.2 208.7 ••••
XPERT 2000 Video Mode Table
Display
Screen
Resolution
Refresh
Rate
(Hz)
Hor.
Scan
(kHz)
Pixel
Clock
(MHz)
Colors
(Bits Per Pixel)
32 MB
816 24 *32

XPERT™ 2000
1600x1200 85 106.3 229.5 ••••
1600x1200 90 113.8 251.2 ••••
1792x1344 60 83.5 203.0 •••
1792x1344 75 105.2 259.3 •••
1800x1440 60 89.4 219.5 ••••
1800x1440 65 97.1 238.5 •••
1800x1440 70 104.9 249.9 •••
1800x1440 75 112.7 278.7 •••
1856x1392 60 86.5 218.6 •••
1856x1392 75 109.0 277.2 •••
1920x1080 60 67.0 172.7 ••••
1920x1080 70 78.6 205.1 ••••
1920x1080 75 84.6 220.6 ••••
1920x1080 80 90.4 237.4 ••••
1920x1200 60 74.5 193.1 •••
1920x1200 72 90.0 222.2 ••••
1920x1200 75 93.9 231.4 ••••
1920x1200 76 95.2 245.0 •••
1920x1200 80 100.5 263.7 •••
1920x1200 85 107.1 282.7 •••
*32 - 24bpp color data is processed using a 32bpp data format.
2D and 3D resolutions and refresh rates are subject to change.
XPERT 2000 Video Mode Table
Display
Screen
Resolution
Refresh
Rate
(Hz)
Hor.
Scan
(kHz)
Pixel
Clock
(MHz)
Colors
(Bits Per Pixel)
32 MB
816 24 *32

Compliance Information
Compliance Information
FCC Compliance Information
This device complies with FCC Rules Part 15. Operation is subject to
the following two conditions:
This device may not cause harmful interference, and
This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with manufacturer's instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment to an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
The use of shielded cables for connection of the monitor to the
graphics card is required to ensure compliance with FCC regulations.
Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user's authority to
operate this equipment.

Compliance Information
Industry Canada Compliance Statement
ICES-003This Class B digital apparatus meets all requirements of the
Canadian Interference-Causing Equipment Regulations.
Cet appareil numérique de la Classe B Respecte toutes les exigences
du Règlement sur le matérial brouiller du Canada.
CE Compliance Information
EMC Directive 89/336/EEC and Amendment 92/31/EEC, Class B
Digital Device
EN 50081-1, Generic Emissions Standard for Residential, Commercial
and Light Industrial Products
(EN 55022/CISPR 22, Limits and Methods of Measurement of Radio
Interference Characteristics Information Technology Equipment)
Warning: This is a Class B product. In a domestic environment this
product may cause radio interference in which case the user may be
required to take adequate measures.
EN 50082-1, Generic Immunity Standard for Residential, Commercial
and Light Industrial Products
(IEC 801-2, IEC 801-3, IEC 801-4)
Directive EMC 89/336/CEE et amendement 92/31/CEE, dispositif
numérique de Classe B
EN 50081-1, Norme sur les émissions génériques pour les produits
domestiques, commerciaux et industriels légers
(EN 55022/CISPR 22, Limites et méthodes de mesure des
caractéristiques d'interférences radiophoniques, Matériel des
technologies de l'information)
Mise en garde: ceci est un produit de
Classe B. Il risque produire des interférences radiophoniques dans un
environnement domestique auquel cas l'utilisateur peut se voir
demandé de prendre des mesures adéquates.
EN 50082-1, Norme sur l'immunité générique pour produits
domestiques, commerciaux et industriels légers.
(CEI 801-2, CEI 801-3, CEI 801-4)
EMC Richtlinie 89/336/EEC und Änderung 92/31/EEC, Digitales Gerät
der Klasse B
EN 50081-1, Allgemeiner Emissions-Standard für Haushalt- und
kommerzielle Produkte sowie Erzeugnisse der Leichtindustrie

Compliance Information
(EN 55022/CISPR 22, Beschränkungen und Verfahren der Messung
von informationstechnischen Ausrüstungen mit Funkstörmerkmalen)
Warnung: Dies ist ein Erzeugnis der Klasse B. Dieses Erzeugnis kann
Funkstörungen im Wohnbereich verursachen; in diesem Fall können
entsprechende Maßnahmen seitens des Benutzers erforderlich sein.
EN 50082-1. Allgemeiner Unempfindlichkeits-Standard für Haushalt-
und kommerzielle Produkte sowie Erzeugnisse der Leichtindustrie
(IEC 801-2, IEC 801-3, IEC 801-4)
Product Notices
Macrovision Corporation
This device is protected by U.S. Patent numbers 4,631,603; 4,577,216;
and 4,819,098 and other intellectual property rights. The use of
Macrovision’s Copy Protection technology in the device must be
authorized by Macrovision and is intended for home and other limited
pay-per-view uses only, unless otherwise authorized in writing by
Macrovision. Reverse engineering or disassembly is prohibited.
Dolby®Laboratories, Inc.
Manufactured under License from Dolby Laboratories. Confidential
Unpublished Works. (c) 1992-1997 Dolby Laboratories, Inc. All rights
reserved.
