ATI Technologies Radeon Setup guide

Choose one of the following categories:
Online Manual
Part Number 137-40178-104
• RADEON™/RADEON™ VE Getting Started...
• User’s Guides
• Technical Specifications
• Compliance Information

User’s Guides
ALL-IN-WONDER® 128 PRO / ALL-IN-WONDER® 128
ALL-IN-WONDER® PRO
Click on your product:
ATI-TELETEXT MANUAL
Some ATI Graphics cards will not support all of the
features and functionality in the ATI Multimedia Center
ATI-TV WONDER
ATI-TV
ALL-IN-WONDER® RADEON™
• RADEON™ / RADEON™ VE Using Video In/Video Out
ATI MULTIMEDIA CENTER
RADEON™ VE

Technical InformationTechnical Information
Click on your product:
• RADEON™ VE
• ALL-IN-WONDER®
• ALL-IN-WONDER® PRO
• ALL-IN-WONDER® 128
• ALL-IN-WONDER® 128 PRO
•RAGEFURY
• RAGEFURYMAXX
• RAGEFURYPRO
• RAGE MAGNUM
• XPERT 98
• XPERT 99
• XPERT 128
• XPERT 2000
• XPERT LCD
• XPERT@WORK
• XPERT@PLAY• XPERT 2000 PRO
• RADEON™ 32MB DDR
• RADEON™ 64MB DDR
• RADEON™ 32MB SDR• ALL-IN-WONDER® RADEON™

RADEON™/RADEON™ VE
Getting Started...
• Safety Instructions for TV Tuner Products
• Installing Your RADEON™/RADEON™ VE
• Installing the ATI Driver for Windows® 98 SE,
Windows® Me
• Installing the ATI Driver for Windows® 2000
• Multiple Display Support: Windows® 98 SE,
Windows® Me
• Troubleshooting Tips
• Using the Online Manual
Please read this guide before attempting to install your card.
Preparing Your Computer
Before installing your RADEON™/RADEON™ VE we recommend that you
first uninstall the driver for your current video card and reconfigure your
operating system to use the standard display driver (VGA) supplied with your
operating system. For more information about changing to the VGA driver, see
your operating system documentation.
Turn off the power to your system and discharge your body’s static
electric charge by touching a grounded surface—for example, the metal
surface of the power supply—before performing any hardware procedure.
The manufacturer assumes no liability for any damage, caused directly or
indirectly, by improper installation of any components by unauthorized
service personnel. If you do not feel comfortable performing the
installation, consult a qualified computer technician.
Damage to system components, the accelerator card, and injury to
yourself may result if power is applied during installation.
READ ME FIRST
RADEON™/RADEON™ VE Version 1.2
NOTE:

Safety Instructions for TV Tuner Products
IMPORTANT SAFETY INSTRUCTIONS
•Read Instructions - All the safety and operating instructions should
be read before the product is operated.
•Retain Instructions - The safety and operating instructions should be
retained for future reference.
•Heed Warnings - All warnings on the product and the operating
instructions should be adhered to.
•Compatibility - This option card is for use only with IBM AT or compat-
ible UL listed personal computers that have Installation Instructions
detailing user installation of card cage accessories.
•Grounding - CAUTION: For continued protection against risk of elec-
tric shock and fire, this accessory should be installed only in products
equipped with a three-wire grounding plug, a plug having a third
(grounding) pin. This plug will only fit into a grounding-type power out-
let. This is a safety feature. If you are unable to insert the plug into the
outlet, contact your electrician to replace the obsolete outlet. Do not
defeat the safety purpose of the grounding-type plug.
• All option card securement pins shall be completely tightened, as to
provide continuous bonding between the option card and the PC chas-
sis.
•Outdoor Antenna Grounding - Since an outdoor antenna or cable
system is connected to the product, be sure that the antenna or cable
system is grounded so as to provide some protection against voltage
surges and built-up static charges. Article 810 of the National Electri-
cal Code, ANSI/NFPA 70, provides information with regard to proper
grounding of the mast and supporting structure, grounding of the lead-
in wire to the antenna discharge unit, size of grounding conductors,
location of antenna-discharge unit, connection of grounding elec-
trodes, and requirements for the grounding electrode.
•Lightning - For added protection for this product during a lightning
storm, or when it is left unattended and unused for long periods of
time, unplug it from the wall outlet, and disconnect the antenna or
cable system. This will prevent damage to the product due to lightning
and power-line surges.
•Power Lines - An outside antenna system should not be located in the
vicinity of overhead power lines or other light or power circuits, or
where it can fall into such power lines or circuits.
• When installing an outside antenna system, extreme care should be
taken to keep from touching such power lines or circuits, as contact
with them may be fatal.
Note to CATV System Installer - This reminder is provided to call the
CATV systems installer’s attention to Section 820-40 of the NEC, which
provides guidelines for proper grounding and, in particular, specifies that
the cable ground shall be connected to the grounding system of the
building, as close to the point of cable entry as practical.

3
Installing Your RADEON™/RADEON™ VE
Now that you have prepared your computer, you are ready to install your
RADEON™/RADEON™ VE graphics accelerator card.
To install your graphics accelerator card
Poweroffthecomputerandmonitor,thendisconnect the display
cable from the back of your computer.
Remove the computer cover. If necessary, consult your computer’s
manual for help in removing the cover.
Remove any existing graphics card from your computer.
Or, if your computer has any on-board graphics capability, you may need to
disable it on the motherboard. For more information, see your computer
documentation.
1
DISPLAY CABLE
VIDEO OUTPUT
CONNECTOR
2
POWER SUPPLY
Remember to
discharge your
body’sstatic
electricity by
touching the
metal surface
of the computer
chassis.
3
SCREW
EXISTINGGRAPHICS CARD
If the old
graphics card
sticks, rock it
gently from end
to end.
Remember to
save the screw.

RADEON™/RADEON™ VE Getting Started... 4
Locate the AGP/PCI slot. If necessary, remove the metal cover from this
slot; then align your RADEON™/RADEON™ VE with the
AGP/PCI slot, and press it in firmly until the card is fully seated.
Replace the screw to fasten the card in place, and replace the
computer cover.
Plug the display cable into your card; then turn on the computer and
monitor. If your RADEON™/RADEON™ VE came with a DVI
connector, you can connect a flat panel display to the appropriate
connector, as shown below...
You are now ready to proceed with the installation of the ATI driver. For detailed
instructions, select your operating system from the list below:
•Windows®98 SE / Windows®Me, see Windows® “New Hardware
Found” on page 5.
•Windows®2000, see page 6.
4
ATI RADEON™/
AGP/PCI SLOT
RADEON™ VE CARD
Grasp the
RADEON™/
RADEON™
VE by the top
edge and
carefully seat it
into the
AGP/PCI slot.
Ensure that
the metal
contacts are
completely
pushed into
the slot.
5
SCREW
ATI RADEON™/
RADEON™ VE CARD
6
DISPLAY CABLE
TO VGA MONITOR
(ALL GRAPHICS CARDS)
TO FLAT PANEL DISPLAY
(DVI-READY CARDS ONLY)
Make sure all
cables are
securely
connected.

5
Windows®“New Hardware Found”
New hardware will be detected after you restart your computer. To finish setting
up your hardware click Ye s when prompted to restart
To identify new hardware in Windows®98 SE or Windows®Me
1Windows®98 SE or Windows®Me may launch the “Update Device Driver
Wizard” to install the Standard VGA Driver. If it does, follow the step-by-
step instructions below to allow Windows®to correctly identify your new
hardware.
If theWizard does not appear, proceed directly to Installing the ATI Driver for
Windows® 98 SE, Windows® Me on page 5.
2Click Next.
3Click Finish.
4Insert your Windows®98 SE or Windows®Me CD into your CD-ROM drive.
5Click OK.
6Type the following:
D:\WIN98 or D:\WINME
(If Dis not your CD-ROM drive, substitute Dwith the correct drive letter.)
7Click OK.
8Click Ye s to restart your computer.
You are now ready to install the ATI driver. Proceed to Installing the ATI
Driver for Windows® 98 SE, Windows® Me on page 5, and follow the step-
by-step instructions to complete the installation.
Installing the ATI Driver for Windows®98 SE, Windows®Me
With Windows®98 SE or Windows®Me running on your computer, you need
to install the ATI driver to take advantage of the higher performance, resolutions,
and special graphic features of the RADEON™/RADEON™ VE.
To ensure you install the latest driver, use the ATI Installation CD that shipped
with your RADEON™/RADEON™ VE.
To install the ATI driver for Windows®98 SE or Windows®Me
1Insert the ATI INSTALLATION CD into your CD-ROM drive.
If Windows®runs the CD automatically, proceed to step 6.
2Click Start.
3Select Run.
4Type the following:
D:\ATISETUP
(If Dis not your CD-ROM drive, substitute Dwith the correct drive letter.)

RADEON™/RADEON™ VE Getting Started... 6
5Click OK.
6Click on AT I E a s y I n s t a l l to begin the Installation Wizard.
7Click Next.
8Click Ye s to the license agreement.
9Follow the Wizard’s on-screen instructions to complete the installation.
The Express installation option is recommended. If your
RADEON™/RADEON™ VE includes a multimedia component, the software for
that component will automatically be installed, along with the ATI driver, by
selecting this option.
Installing the ATI Driver for Windows®2000
With Windows®2000 running on your computer, you need to install the ATI
driver to take advantage of the higher performance, resolutions, and special
graphic features of the RADEON™/RADEON™ VE.
To ensure you install the latest driver, use the ATI Installation CD that shipped
with your RADEON™/RADEON™ VE.
To install the ATI driver for Windows®2000
1Insert the ATI INSTALLATION CD into your CD-ROM drive.
If Windows®runs the CD automatically, proceed to step 6.
2Click Start.
3Select Run.
4Type the following:
D:\ATISETUP
(If Dis not your CD-ROM drive, substitute Dwith the correct drive letter.)
5Click OK.
6Click on AT I E a s y I n s t a l l to begin the Installation Wizard.
7Click Next.
8Click Ye s to the license agreement.
9Follow the Wizard’s on-screen instructions to complete the installation.
The Express installation option is recommended. If your
RADEON™/RADEON™ VE includes a multimedia component, the software for
that component will automatically be installed, along with the ATI driver, by
selecting this option.

7
Multiple Display Support: Windows®98 SE, Windows®Me
IMPORTANT: Please read the Readme file on the ATI Installation CD for the
latest information regarding Multiple Display Support.
Troubleshooting Tips
The following troubleshooting tips may help if you experience problems.
Contact your dealer or AT I for more advanced troubleshooting information.
• Check that the card is seated properly in the AGP/PCI slot.
• Ensure the display cable is securely fastened to the card’s display connector.
• Make sure that the monitor and computer are plugged in and receiving power.
• If necessary, disable any built-in graphics capabilities on your motherboard.
For more information, consult your computer’s manual or manufacturer.
(NOTE: Some manufacturers do not allow the built-in graphics to be disabled
or to become the secondary display.)
• Make sure you selected the appropriate display device and graphics card
when you installed theATI driver.
• For more troubleshooting tips, right-click the ATI icon in the taskbar and
select Troubleshooting.
• If you have problems during bootup, start your computer in Safe Mode.In
Windows®98 SE and Windows®Me, press and hold the CTRL key until the
Microsoft®Windows®Startup Menu appears on the screen. Then select the
number for Safe Mode, and press Enter. (You can also use F8 to bring up the
Microsoft Windows®Startup Menu.) In Safe Mode, bring up the Device
Manager and check for duplicate display adapter and monitor entries if you
are only using one graphics card.
• For more assistance, use the Troubleshooting Guide locatedinthe
Windows® Help or contact your computer manufacturer.
• To contact ATI Technical Assistance, see your Technical Support and
Warranty Service guide

RADEON™/RADEON™ VE Getting Started... 8
Using the Online Manual
The RADEON™/RADEON™ VE comes with an online manual that describes
its advanced features. The Online Manual provides reference, specification,
disclaimer, legal, and compliance information that is not contained in this
Getting Started guide.
ToopentheOnlineManual
1Insert the ATI INSTALLATION CD into your CD-ROM drive.
If Windows®runs the CD automatically, proceed to step 6.
2Click Start.
3Select Run.
4Type the following:
D:\ATISETUP
(If Dis not your CD-ROM drive, substitute Dwith the correct drive letter.)
5Click OK.
6Click Online User Manual.
ATI is a registered trademark of ATI Technologies Inc. in Canada, the United States
and/or other countries. RADEON is a trademark of ATI Technologies Inc. in Canada, the
United States, and/or other countries. Windows is a registered trademark of Microsoft
Corporation in the United States and/or other countries. All other trademarks and/or
registered trademarks are the properties of their respective owners.
© Copyright 2001, ATI Technologies Inc. P/N: 117-40128-30
Printed in Canada

RADEON™ VE
Technical Information
System Requirements
Pentium®4/III/II, Celeron™,AMD
®K6/Athlon or compatible
system with AGP2Xor AGP2X/4Xuniversal slot.
CD-ROM drive required for software installation.
DVD drive
required for DVD playback with a Pentium
®
II processor (or
equivalent) and 32MB of system memory.
Operating System Windows®2000 Windows®98SE Windows®Me
Specifications
Memory Configuration 64MB, 32MB and 16MB Double Data Rate
non-upgradable.
Sync Signals Separate horizontal and vertical sync at TTL levels.
Video BIOS Compatible with VESA for Super VGA.
Monitor Support CRT monitor, 15-pin D shell (female), IBM
standard VGA connector. DVI-I (flat panel display) connector.
Display Support DDC1/2b/2b+monitor support;VESA Display
Power Management support. Register compatible with VGA.
TV/Video-out Connector S-Video. NTSC output.
Power +5V±5% @ 0.4A typical.
+3.3V ±5% @ 1.4A typical.
+12V ±5% @ 0.3A typical.

RADEON™ VE
Ambient Temperature
Operating 50° to 122° F (10° to 50° C).
Storage 32° to 162° F (0° to 70° C).
Relative Humidity
Operating 5% to 90%non-condensing.
Storage 0%to 95%.
MTBF >300,000 hours.
EMC Certification FCC Class B.
Video Mode Table
RADEON VE Video Mode Table
Display
Screen
Resolution
Refresh
Rate
(Hz)
Hor.
Scan
(kHz)
Pixel
Clock
(MHz)
Colors (Bits per pixel)
816 32
640x480 60 31.5 25.2 • • •
640x480 72 37.9 31.5 • • •
640x480 75 37.5 31.5 • • •
640x480 85 43.3 36.0 • • •
640x480 90 45.4 37.8 • • •
640x480 100 50.9 43.1 • • •
640x480 120 61.8 52.4 • • •
640x480 160 84.3 72.8 • • •
640x480 200 108.0 95.0 • • •
800x600 60 37.9 39.9 • • •
800x600 70 43.7 45.5 • • •
800x600 72 48.1 50.0 • • •
800x600 75 46.9 49.5 • • •
800x600 85 53.7 56.3 • • •
800x600 90 56.8 60.0 • • •
800x600 100 63.6 68.1 • • •
800x600 120 77.0 83.2 • • •
800x600 160 105.4 116.4 • • •
800x600 200 135.0 149.0 • • •
1024x768 70 56.5 75.0 • • •
1024x768 72 56.6 78.4 • • •
1024x768 75 60.0 78.8 • • •
1024x768 85 68.7 94.5 • • •

RADEON™ VE
1024x768 90 72.8 100.1 • • •
1024x768 100 81.4 113.3 • • •
1024x768 120 98.7 139.0 • • •
1024x768 140 116.6 164.2 • • •
1024x768 150 125.7 176.9 • • •
1024X768 160 134.8 192.0 • • •
1024x768 180 153.5 218.6 • • •
1024X768 200 172.8 246.1 • • •
1152x864 60 53.7 81.6 • • •
1152x864 70 63.0 96.7 • • •
1152x864 75 67.5 108.0 • • •
1152x864 80 72.4 112.3 • • •
1152x864 85 77.0 119.6 • • •
1152x864 100 91.5 143.4 • • •
1152x864 120 111.1 176.0 • • •
1152x864 150 141.4 226.3 • • •
1280x1024 60 64.0 108.0 • • •
1280x1024 70 74.6 128.9 • • •
1280x1024 74 79.0 138.5 • • •
1280x1024 75 80.0 135.0 • • •
1280x1024 85 91.1 157.5 • • •
1280x1024 90 97.0 169.2 • • •
1280x1024 100 108.5 190.9 • • •
1280X1024 120 131.6 233.7 • • •
1280X1024 125 137.6 244.4 • • •
1280X1024 130 143.5 254.9 • • •
1600x1200 52 64.2 137.7 • • •
1600x1200 58 71.9 155.4 • • •
1600x1200 60 75.0 162.0 • • •
1600x1200 66 82.2 178.9 • • •
1600x1200 72 90.0 195.9 • • •
1600x1200 75 93.8 202.5 • • •
1600x1200 76 95.2 208.7 • • •
1600x1200 85 106.3 229.5 • • •
1600x1200 90 113.8 251.2 • • •
1920x1440 60 90.0 234.0 • • •
1920x1440 75 112.5 297.0 • • •
2048x1536 75 120.2 340.4 • • •
Some display modes and color depths may not be available for all
drivers. 2D & 3D resolutions & color depths are subject to change.
RADEON VE Video Mode Table
Display
Screen
Resolution
Refresh
Rate
(Hz)
Hor.
Scan
(kHz)
Pixel
Clock
(MHz)
Colors (Bits per pixel)
816 32

RADEON™ VE
RADEON VE DVI (Flat Panel Display) Modes
Display Screen Resolution Refresh Rate (Hz)
640x480 85
800x600 85
1024x768 85
1280x1024 75
DVI (Flat Panel) display cannot be used
concurrently with TV-output display.
DVI “hotplugging” is not supported.

RAGEFURYMAXX
RAGEFURYMAXX
Technical Information
System Requirements
Pentium®4/III/II, AMD®K6/Athlon, or compatible system with
AGP2Xor AGP2X/4Xuniversal slot (2.0 compliant).
CD-ROM drive required for software installation.
DVD drive
required for DVD playback (Windows
®
98 only).
Operating System Windows®98.
Specifications
Memory Configuration 64 MB non-upgradeable.
Sync Signals Separate horizontal and vertical sync at TTL levels.
Video BIOS AGP 2.0 compliant. Compatible with VESA for SVGA.
Monitor Support CRT monitor, 15-pin D shell (female), IBM
standard VGA connector.
Display Support DDC1/2b/2b+monitor support;VESA Display
Power Management support. Register compatible with VGA.
Video Interrupt IRQ11 is requested, although the actual IRQ
number is automatically assigned by the Plug &Play system BIOS.
Power +5V±5% @ 0.6Atypical.
+3.3V ±5% @ 2.2 A typical.
+12V ±5% @0.5Atypical.

RAGEFURYMAXX
Ambient Temperature
Operating 50° to 122° F (10° to 50° C).
Storage 32° to 162° F (0° to 70° C).
Relative Humidity
Operating 5% to 90%non-condensing.
Storage 0%to 95%.
MTBF >300,000 hours.
EMC Certification CISPR2:1998-Class B-Limits and methods of
measurement of radio disturbance characteristics of Information
Technology Equipment.
EN 50082-1:1997-Generic Immunity Standards- Residential,
Commercial and Light Industry.
FCC PART 15, SUBPART B-UNINTENTIONAL RADIATORS, CLASS B
COMPUTINGDEVICES FOR HOME AND OFFICE USE.
Video Mode Table
RAGE FURY MAXX 64 MB *Video Mode Table
Display
Screen
Resolution
Refresh
Rate
(Hz)
Hor.
Scan
(kHz)
Pixel
Clock
(MHz)
Colors (Bits Per Pixel)
2D Display
Modes
3D Display
Modes
816 24 *32 816 24 *32
640x480 60 31.5 25.2 • • • • • • • •
640x480 75 37.9 31.5 • • • • • • • •
640x480 85 43.3 36.0 • • • • • • • •
640x480 90 45.4 37.8 • • • • • • • •
640x480 100 50.9 43.1 • • • • • • • •
640x480 120 61.8 52.4 • • • • • • • •
640x480 160 84.3 72.8 • • • • • • • •
800x600 60 37.9 39.9 • • • • • • • •
800x600 75 46.9 49.5 • • • • • • • •
800x600 85 53.7 56.3 • • • • • • • •
800x600 90 56.8 60.0 • • • • • • • •
800x600 100 63.6 68.1 • • • • • • • •
800x600 120 77.1 83.9 • • • • • • • •
800x600 160 105.4 116.4 • • • • • • • •
1024x768 60 48.4 65.0 • • • • • • • •
1024x768 75 60.0 78.8 • • • • • • • •
1024x768 85 68.7 94.5 • • • • • • • •
1024x768 90 72.8 100.1 • • • • • • • •

RAGEFURYMAXX
1024x768 100 81.4 113.3 • • • • • • • •
1024x768 120 98.7 139.0 • • • • • • • •
1024X768 160 134.8 192.0 • • • • • • • •
1152x864 60 53.7 81.6 • • • • • • • •
1152x864 75 67.5 108.0 • • • • • • • •
1152x864 85 77.0 119.6 • • • • • • • •
1152x864 100 91.5 143.4 • • • • • • • •
1152x864 120 111.1 176.0 • • • • • • • •
1280x1024 60 64.0 108.0 • • • • • • • •
1280x1024 75 80.0 135.0 • • • • • • • •
1280x1024 85 91.1 157.5 • • • • • • • •
1280x1024 100 108.5 190.9 • • • • • • • •
1280X1024 120 131.6 233.7 • • • • • • • •
1600x1200 60 75.0 162.0 • • • • • • • •
1600x1200 72 90.0 195.9 • • • • • • • •
1600x1200 75 93.8 202.5 • • • • • • • •
1600x1200 85 106.3 229.5 • • • • • • • •
1600x1200 90 113.8 251.2 • • • • • • • •
*32 - 24bpp color data is processed using a 32bpp data format.
2D and 3D resolutions and refresh rates are subject to change.
RAGE FURY MAXX 64 MB *Video Mode Table
Display
Screen
Resolution
Refresh
Rate
(Hz)
Hor.
Scan
(kHz)
Pixel
Clock
(MHz)
Colors (Bits Per Pixel)
2D Display
Modes
3D Display
Modes
816 24 *32 816 24 *32

ALL-IN-WONDER® PRO
ALL-IN-WONDER® PRO
ALL-IN-WONDER®
Technical Information
System Requirements
All-In-Wonder® Pentium®III/II/Pro, Celeron™ or compatible
systems with 33MHz PCI local bus 2.1.
All-In-Wonder® Pro PCI Pentium®4/III/II/Pro, Celeron™ or
compatible systems with 33MHz PCI local bus 2.1.
All-In-Wonder® Pro AGP Pentium®4/III/II, Celeron™, or
compatible systems with AGP2Xbus (AGP 1.0 compliant).
CD-ROM drive required for software installation.
DVD drive
required for DVD playback ( All-In-Wonder Pro only ).
Operating System Windows®2000 (All-In-Wonder Pro only),
Windows®95, Windows®98. Graphics features only are supported
under DOS®5.0 or higher, Windows®3.1x, Windows®NT 3.51, 4.0,
OS/2 2.1®and OS/2 Warp®.
Specifications
Memory Configurations All-In-Wonder: 2 MB non-upgradable;
2MB upgradeable to 4 MB;4MB non-upgradeable. All-In-Wonder Pro:
4MB upgradable to 8MB;8MB non-upgradeable.
Sync Signals Separate horizontal and vertical sync at TTL levels.
TV Output Connectors Composite and S-Video. NTSC output (PAL
versions available).
Video BIOS PCI2.1compliant.AGP 1.0 compliant. Compatible with
VESA for SVGA.
Monitor Support CRT monitor, 15-pin D shell (female), IBM
standard VGA connector.
AMC Connector 2x20 pin header. Shares the same footprint with
the 2x13 pin VGA Feature Connector, VGA Out only, VESA standard.
Power +5V±5%,@1.3A typical.

ALL-IN-WONDER® PRO
Ambient Temperature
Operating 50°
°°
°to 122°
° °
° F(10 °
°°
°to 50°
° °
° C).
Storage 32°
°°
°to 162°
° °
° F(0 °
°°
°to 70°
° °
° C).
Relative Humidity
Operating 5% to 90%non-condensing.
Storage 0%to 95%.
MTBF 120,000 hours.
Video Mode Table
ALL-IN-WONDER and ALL-IN-WONDER PRO Video Mode Table
Display
Screen
Resolution
Refresh
Rate
(Hz)
Hor.
Scan
(kHz)
Pixel
Clock
(MHz)
Colors (Bits Per Pixel)
2MB 4MB 6MBor8MB
816 24 *32 816 24 *32 816 24 *32
640x480 60 31.5 25.1 • • • • • • • • • • • •
640x480 72 37.4 32.0 • • • • • • • • • • • •
640x480 75 37.5 31.5 • • • • • • • • • • • •
640x480 85 43.3 36.0 • • • • • • • • • • • •
640x480 90 48.0 39.9 • • • • • • • • • • • •
640x480 100 52.9 44.9 • • • • • • • • • • • •
640x480 120 63.7 55.0 • • • • • • • • • • • •
640x480 160 84.1 70.0 • • • • • • • • • • • •
640x480 200 100.2 81.0 • • • • • • • • • • • •
800x600 48 33.8 36.0 • • • • • • • • • • • •
800x600 56 35.2 36.0 • • • • • • • • • • • •
800x600 60 37.8 39.9 • • • • • • • • • • • •
800x600 70 44.5 44.9 • • • • • • • • • • • •
800x600 72 48.0 50.0 • • • • • • • • • • • •
800x600 75 46.9 49.5 • • • • • • • • • • • •
800x600 85 53.7 56.2 • • • • • • • • • • • •
800x600 90 57.1 56.6 • • • • • • • • • • • •
800x600 100 62.5 67.5 • • • • • • • • • • • •
800x600 120 76.0 81.0 • • • • • • • • • • • •
800x600 160 99.6 106.0 • • • • • • • • • • • •
800x600 200 125.9 135.0 • • • • • • • • • • • •
1024x768 43 35.5 44.9 • • • • • • • • • • • •
1024x768 60 48.4 65.0 • • • • • • • • • • • •
1024x768 70 56.5 75.0 • • • • • • • • • • • •
1024x768 72 58.2 75.0 • • • • • • • • • • • •
1024x768 75 60.0 78.8 • • • • • • • • • • • •
1024x768 85 68.7 94.5 • • • • • • • • • • • •
