Atid ATD100N User manual

ATD100N USER GUIDE
ATID Co.,Ltd
Ver 0.1

2
ATD100N User Guide
Contents
BEFORE THE BEGINNING .......................................................................................................................... 3
PRODUCT OVERVIEW ................................................................................................................................ 3
KEY FEATURES ............................................................................................................................................. 4
PRODUCT SPECIFICATION......................................................................................................................... 5
CONFIGURATION OF THE PRODUCT ...................................................................................................... 6
1. PRODUCT APPEARANCE .....................................................................................................................................................6
2. USB CABLE ..........................................................................................................................................................................7
3. UHF ANTENNA ...................................................................................................................................................................7
OPERATION GUIDE..................................................................................................................................... 8
1. SERIAL MODE ......................................................................................................................................................................8
2. PRODUCT OPERATION IN SERIAL MODE........................................................................................................................... 8
3. HID (HUMAN INTERFACE DEVICES)MODE.....................................................................................................................9
4. PRODUCT OPERATION IN HID MODE .............................................................................................................................. 9
USING THE WINDOWS HOST DEMO APPLICATION.......................................................................... 10
SDK (SOFTWARE DEVELOPMENT KIT).................................................................................................. 11
PRODUCT WARRANTY ............................................................................................................................ 12
1. ATD100N PRODUCT DETAILS....................................................................................................................................... 12
2. SDK DOWNLOAD ............................................................................................................................................................ 12
3. WARRANTY AND TECHNICAL SUPPORT........................................................................................................................ 12
4. CERTIFICATIONS ................................................................................................................................................................ 12

3
ATD100N User Guide
Before the Beginning
The objective of user guide is to pass the basic contents related with ATD100N`s maintenance and smooth
uses. User guide inclusive of text, images, logos, product name may not be distributed, modified,
displayed, reproduced (in whole or in part) without the prior written permission of ATID Co,.Ltd.
Furthermore, the described contents in this document are subject to change without notice for improving
or maintaining the product and we inform the user that some material can be different with the described
contents due to the firmware changes of product.
Ownership of text, images, logos, product name in user guide is included in writer and some parts of
text, images, logos, product name in the user guide were borrowed for user`s understanding at
random. if there is a legal restriction such as a copyright law, it will be redistributed after adjustment.
Product Overview
ATD100N is a compact size UHF RFID desktop reader product. This product does not require a separate
power source and can be operated only by a USB connection. It can be used as a data collector in various
fields such as medicine management and inventory management.
This product can transmit the collected data to the Windows Host device through the USB transmission
method. SDK is supported to easily process the collected data.

4
ATD100N User Guide
Key Features
1) This product is a compact size UHF RFID desktop reader.
2) The RFID module of PHYCHIS was applied to read/write the UHF RFID tag.
3) Using the USB cable installed in the device, it is possible to connect to a Host device to operate and
transmit data.
4) It is possible to check the operation status of the device through the LED and buzzer.
5) Support HID (Human Interface Device) mode.

5
ATD100N User Guide
Product Specification
Performance
Processor
ARM7 Core
Supported Platforms
Windows
Physical Characteristics
Dimensions (W x H)
140 x 26 mm
Weight
210g
Power
USB 0.5A
USB Interface
1 USB, USB Type-A Cable (Fixed Type)
Host Protocol
Serial (VCP), HID
Standard I/O Port
USB Client
Notification
LED Indicator, Buzzer
Data Collection
RFID UHF
Protocol
EPC GEN2, ISO/IEC 18000-6C
Reading Range
~ 50 cm (Depending on environment and tag type)
Writing Range
~ 50 cm
RF Output
0.5W
Frequency Range
US / FCC
EU / CE
KR / KC
JP / TELEC
: 902MHz ~ 928MHz
: 865MHz ~ 868MHz
: 917MHz ~ 921MHz
: 920MHz ~ 923MHz (0.2W)
Antenna
Circular Antenna / 2.2 dBic
User Environment
Operating Temp
-10°C to 50°C
Storage Temp
-30°C to 70°C
Humidity
5~95% (non-condensing)

6
ATD100N User Guide
Configuration of the product
1. Product Appearance
1) Power Button / Status LED 1 : By keeping the button pressed, the product can be turned ON/OFF.
It also serves as an LED to indicate the status of the product.
2) Status LED 2 : LED indicating the status of the product.
3) Mode Setting Switch : The operation mode of ATD100N is set according to the switch setting as
shown table below. If user changes the operation mode, the setting is applied as the product
reboots.
Switch Setting
Operation Mode
S
Serial
H
HID
Status LED 2
Mode Setting Switch
(Serial / HID)
Power Button / Status LED 1

7
ATD100N User Guide
2. USB Cable
ATD100N is equipped with a USB TYPE-A, 1.5m USB cable as standard. It supplies power and transmits
data to the host device through the USB cable connection.
3. UHF Antenna
The antenna of ATD100N is located in the center of the product. The closer the tag is located at the
center of the product, the higher the recognition rate.
Two types of antennas (866MHzk, 912MHz) are supported according to each country's frequency
range. It is necessary to select an antenna according to the region where the product is used.
USB TYPE-A
UHF Antenna

8
ATD100N User Guide
Operation Guide
1. Serial Mode
When the device is set to Serial mode, the device uses the ATID protocol to communicate with the HOST
device in a command. In order to connect the host device to the device, a demo program provided by
ATID or a program developed using SDK is required.
2. Product operation in serial mode
1) When the USB cable of the product is connected to the Windows Host device, the product turns
on with a buzzer sound.
2) When booting is normally completed, ‘Status LED 2’ blinks in green.
3) When connected to Windows Host without problems, the device is assigned a COM port.
•COM Port is assigned a different number depending on the PC situation.
•Check the COM Port number assigned to the ‘AT91 USB to Serial Converter’in ‘Device
Manager →Ports (COM & LPT)’of the control panel.
•Depending on the PC situation, driver installation may be required.
4) When the program of Windows Host device and ATD100N are connected, ‘Status LED 2’ stops
blinking and stays on.
5) If data collection starts while the demo program is connected, ‘Status LED 1’ blinks in red
depending on whether there is data or not.
6) Press and hold the power switch or unplug the USB cable from the host device to turn off the
product.

9
ATD100N User Guide
3. HID (Human Interface Devices) mode
When the ATD100N is set to HID mode, the device transmits the collected EPC data to the host in HEX
format. In this case, open a program that can create documents (txt, docx, xlsx, etc.) and place the
cursor on the program to display the collected data.
4. Product operation in HID mode
1) When the USB cable of the product is connected to the Windows Host device, the product turns
on with a buzzer sound.
2) When booting is normally completed, ‘Status LED 1’ turns green and ‘Status LED 2’ blinks in red.
When connected to Host, ‘Status LED 2’ stops blinking and stays on.
3) When connected to the host, data collection starts automatically.
4) When data collection starts, status LED 1 blinks in orange depending on whether there is data or
not.
5) Data collected in HID mode is transmitted only EPC excluding CRC and PC to the host device.
Terminator is set to line breaks.
6) Press and hold the power switch or disconnect the USB cable from the host device to turn off the
product.

10
ATD100N User Guide
Using the Windows Host Demo Application
1) To connect ATD100N and Windows Host device, connect via USB.
2) User can install the demo app included in the SDK on the host device.
For details on how to use the Windows demo application, refer to the ‘ATID Reader Demo Guide
for Windows’ document included in the SDK.

11
ATD100N User Guide
SDK (Software Development Kit)
In order to utilize the data transmitted to the host device, a separate program must be developed
referring to the SDK provided by ATID.
Platform
Development Tool
Development Language
Windows
Visual Studio
.NET Framework (C#), UWP (C#)
SDK Package
Configuration
Details
Demo
Demo Application
Doc
Development documents such as user guides / manuals,
programmer guides, demo guides, etc.
Lib
Library for application development
Sample
Sample Code
USB Drive for Windows
Windows USB Driver of ATID Bluetooth Reader

12
ATD100N User Guide
Product Warranty
1. ATD100N Product Details
For more information on product details ATD100N, please visit the address below.
http://www.atid1.com
2. SDK Download
If you need an ATD100N SDK, please contact us or the place of purchase.
3. Warranty and Technical Support
All ATID products can be repaired free of charge for one year based on the product manufacturing date.
However, in principle, any defects caused by customer carelessness in use shall be repaired even during
the free repair period.
For warranty, technical support and inquiries on this product, please contact the distributor or ATID.
4. Certifications
This product is KC, FCC, CE and TELEC certified, but we are not responsible for any issues arising during
use outside of the certified area.
For details, please contact the distributor or ATID.
ATID
Address
: #1402, 83, Gasan Digital-1ro, Geumcheon-gu, Seoul, Republic of Korea (Zip code. 08589)
Phone
: [phone]
Fax
: [phone]
Homepage
: www.atid1.com
Email
: inquir[email protected]m
The contents of the user manual are subject to change without notice for product specifications change or improvement.
