YOKOGAWA FA-M3 YHLS Master Module User manual

Applicable Modules:
Model Code Model Name
F3LH01-1N YHLS Master Module
F3LH02-1N YHLS Master Module
User’s
Manual
IM 34M06H46-04E
YHLS Master Module
IM 34M06H46-04E
2nd Edition
Yokogawa Electric Corporation

Blank Page

i
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
Media No. IM 34M06H46-04E (CD) 1st Edition : April, 2008 (AR)
All Rights Reserved Copyright 2008, Yokogawa Electric Corporation
Applicable Product
Range-free Multi-controller FA-M3
Model code : F3LH0-1N
Name : YLHS Master Module
The document number and document model code for this manual are given below.
Refer to the document number in all communications; also refer to the document
number or the document model code when purchasing additional copies of this manual.
Document No. : IM 34M06H46-04E
Document Model Code : DOCIM

ii
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
Important
About This Manual
- This Manual should be passed on to the end user.
- Before using the controller, read this manual thoroughly to have a clear
understanding of the controller.
- This manual explains the functions of this product, but there is no guarantee that
they will suit the particular purpose of the user.
- Under absolutely no circumstances may the contents of this manual be transcribed
or copied, in part or in whole, without permission.
- The contents of this manual are subject to change without prior notice.
- Every effort has been made to ensure accuracy in the preparation of this manual.
However, should any errors or omissions come to the attention of the user, please
contact the nearest Yokogawa Electric representative or sales office.
Safety Symbols
- Danger. This symbol on the product indicates that the operator must follow the
instructions laid out in this user's manual to avoid the risk of personnel injuries,
fatalities, or damage to the instrument. Where indicated by this symbol, the manual
describes what special care the operator must exercise to prevent electrical shock
or other dangers that may result in injury or the loss of life.
- Protective Conductor Terminal
This terminal is to prevent electric shock. Before using the instrument, connect to
the Protective earth (Comply with the regulation of each country.), and route the line
through the shortest path possible.
- Functional Earth Terminal
This terminal is for stable operation. Before using the instrument, be sure to ground
this terminal.
- Alternating current. Indicates alternating current.
- Direct current. Indicates direct current.

iii
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
The following symbols are used only in the user's manual.
WARNING
- Indicates a “Warning”.
Draws attention to information essential to prevent hardware damage, software
damage or system failure.
CAUTION
- Indicates a “Caution”
Draws attention to information essential to the understanding of operation and
functions.
TIP
- Indicates a “TIP”
Gives information that complements the present topic.
SEE ALSO
- Indicates a “SEE ALSO” reference.
Identifies a source to which to refer.
Safety Precautions when Using/Maintaining the Product
- For the protection and safe use of the product and the system controlled by it, be
sure to follow the instructions and precautions on safety stated in this manual
whenever handling the product. Take special note that if you handle the product in
a manner other than prescribed in these instructions, the protection feature of the
product may be damaged or impaired. In such cases, Yokogawa cannot guarantee
the quality, performance, function and safety of the product.
- When installing protection and/or safety circuits such as lightning protection devices
and equipment for the product and control system as well as designing or installing
separate protection and/or safety circuits for fool-proof design and fail-safe design of
processes and lines using the product and the system controlled by it, the user
should implement it using devices and equipment, additional to this product.
- If component parts or consumable are to be replaced, be sure to use parts specified
by the company.
- This product is not designed or manufactured to be used in critical applications
which directly affect or threaten human lives and safety — such as nuclear power
equipment, devices using radioactivity, railway facilities, aviation equipment,
shipboard equipment, aviation facilities or medical equipment. If so used, it is the
user’s responsibility to include in the system additional equipment and devices that
ensure personnel safety.
- Do not attempt to modify the product.
- To avoid electrical shock, turn off the power before wiring.
- This product is classified as Class A for use in industrial environments. If used in a
residential environment, it may cause electromagnetic interference (EMI).
In such situations, it is the user's responsibility to adopt the necessary measures
against EMI.
Exemption from Responsibility
- Yokogawa Electric Corporation (hereinafter simply referred to as Yokogawa Electric)
makes no warranties regarding the product except those stated in the WARRANTY
that is provided separately.
- Yokogawa Electric assumes no liability to any party for any loss or damage, direct or
indirect, caused by the use or any unpredictable defect of the product.

iv
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
Software Supplied by the Company
- Yokogawa Electric makes no other warranties expressed or implied except as
provided in its warranty clause for software supplied by the company.
- Use the software with one computer only. You must purchase another copy of the
software for use with each additional computer.
- Copying the software for any purposes other than backup is strictly prohibited.
- Store the original media that contain the software in a safe place.
- Reverse engineering, such as decompiling of the software, is strictly prohibited.
- Under absolutely no circumstances may the software supplied by Yokogawa Electric
be transferred, exchanged, or sublet or leased, in part or as a whole, for use by any
third party without prior permission by Yokogawa Electric.

v
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
General Requirements for Using the FA-M3 / e-RT3 Controller
Set the product in a location that fulfills the following requirements:
- Where the product will not be exposed to direct sunlight, and where the operating
surrounding air temperature is from 0°C to 55°C (32°F to 131°F).
There are modules that must be used in an environment where the operating
surrounding air temperature is in a range smaller than 0°C to 55°C (32°F to 131°F).
Refer to “Hardware Manual” (IM 34M06C11-01E) or the applicable user's manual. In
case of attaching such a module, the entire system's operating surrounding air
temperature is limited to the module's individual operating surrounding air
temperature.
- Where the relative humidity is from 10 to 90%.
In places where there is a chance of condensation, use a space heater or the like to
constantly keep the product warm and prevent condensation.
- For use in Pollution Degree 2 Environment.
- Where there are no corrosive or flammable gases.
- Where the product will not be exposed to mechanical vibration or shock that exceed
specifications.
- Where there is no chance the product may be exposed to radioactivity.
Use the correct types of wire for external wiring:
- USE COPPER CONDUCTORS ONLY.
- Use conductors with temperature rating above 75°C.
Securely tighten screws:
- Securely tighten module mounting screws and terminal screws to avoid problems
such as faulty operation.
- Tighten terminal block screws with the correct tightening torque as given in this
manual. Refer to the “Hardware Manual” (IM 34M06C11-01E) or the applicable
user's manual for the appropriate tightening torque.
Securely lock connecting cables:
- Securely lock the connectors of cables, and check them thoroughly before turning
on the power.
Interlock with emergency-stop circuitry using external relays:
- Equipment incorporating the FA-M3 / e-RT3 controller must be furnished with
emergency-stop circuitry that uses external relays. This circuitry should be set up to
interlock correctly with controller status (stop/run).
Ground for low impedance:
- For safety reasons, connect the [FG] grounding terminal to a protective earth
(Comply with the regulation of each country.). For compliance to CE Marking, use
braided or other wires that can ensure low impedance even at high frequencies for
grounding.
Configure and route cables with noise control considerations:
- Perform installation and wiring that segregates system parts that may likely become
noise sources and system parts that are susceptible to noise. Segregation can be
achieved by measures such as segregating by distance, installing a filter or
segregating the grounding system.

vi
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
Configure for CE Marking Conformance:
-For compliance to CE Marking, perform installation and cable routing according to
the description on compliance to CE Marking in the “Hardware Manual” (IM
34M06C11-01E).
-The list of CE conforming models is available in Appendix A2. of “Hardware
Manual”.
Keep spare parts on hand:
- We recommend that you stock up on maintenance parts, including spare modules,
in advance.
- Preventive maintenance (replacement of the module) is required for using the
module beyond 10 years.
Discharge static electricity before touching the system:
- Because static charge can accumulate in dry conditions, first touch grounded metal
to discharge any static electricity before touching the system.
Wipe off dirt with a soft cloth:
- Gently wipe off dirt on the product's surfaces with a soft cloth.
- If you soak the cloth in water or a neutral detergent, tightly wring it out before wiping
the product. Letting water enter the module interior can cause malfunctions.
- Do not use volatile solvents such as benzine or paint thinner or chemicals for
cleaning, as they may cause deformity, discoloration, or malfunctioning.
Avoid storing the FA-M3 /e-RT3 controller in places with high
temperature or humidity:
- Since the CPU module has a built-in battery, avoid storage in places with high
temperature or humidity.
- Since the service life of the battery is drastically reduced by exposure to high
temperatures, take special care (storage surrounding air temperature should be
from -20°C to 75°C).
- There is a built-in lithium battery in a Sequence CPU module which serves as backup
power supply for programs, device information and configuration information.
The service life of this battery is more than 10 years in standby mode at room
temperature. Take note that the service life of the battery may be shortened when
installed or stored at locations of extreme low or high temperatures. Therefore, we
recommend that modules with built-in batteries be stored at room temperature.
Always turn off the power before installing or removing modules:
- Failing to turn off the power supply when installing or removing modules, may result
in damage.
Do not touch components in the module:
- In some modules you can remove the right-side cover and install ROM packs or
change switch settings. While doing this, do not touch any components on the
printed-circuit board, otherwise components may be damaged and modules may fail
to work.
Do not use unused terminals:
- Do not connect wires to unused terminals on a terminal block or in a connector.
Doing so may adversely affect the functions of the module.

vii
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
Use the following power source:
- Use only F3PU- as the power supply module.
- If using this product as a UL-approved product, for the external power supply, use a
limited voltage / current circuit power source or a Class 2 power source.
Refer to the user's manual before connecting wires:
- Refer to the “Hardware Manual” (IM 34M06C11-01E) or the applicable user’s
manual for the external wiring drawing.
- Refer to “A3.6.5 Connecting Output Devices” in the “Hardware Manual” before
connecting the wiring for the output signal.
- Refer to “A3.5.4 Grounding Procedure” in the “Hardware Manual” for attaching the
grounding wiring.
Authorized Representative:
- The Authorized Representative for this product in the EEA is:
Yokogawa Europe B. V.
Euroweg 2, 3825 HD Amersfoort, The Netherlands


viii
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
General Requirements for Using the FA-M3 Slave Units (TAH Series)
Connect YHLS cable to SHIELD terminal:
- Connect the DRAIN line of the YHLS cable to the SHIELD terminal of the YHLS
master module securely. Failing to do so may affect the performance of the YHLS
system.
Do not touch components in the unit:
- Do not remove the back cover of the unit. Doing so may cause a failure.


ix
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
How to dispose the batteries
This is an explanation about the new EU Battery Directive. This directive is only valid in
the EU.
Batteries are included in some modules of this product. The procedure is different when
the user can remove or cannot remove.
Batteries the user can remove
The battery of F3RP6and F3RP7can be removed by yourself.
When you remove the battery from F3RP6and F3RP7and dispose it, discard them
in accordance with domestic law concerning disposal. See the User's Manual of
F3RP6and F3RP7for the removal procedure. Take a right action on waste
batteries, because the collection system in the EU on waste batteries are regulated. If
you don't remove the battery from this product, please see .
Batteries the user cannot remove
Dispose the battery together with this product.
When you dispose this product in the EU, contact your local Yokogawa Europe
B.V.office.
Do not dispose them as domestic household waste.
Battery category: Lithium battery
Note: With reference to Annex II of the new EU Battery Directive, the above symbol
indicates obligatory separate collection.

x
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
Introduction
Overview of the Manual
This manual describes the specifications, operations, and communications protocol of
the YHLS (Yokogawa High-speed Link System) master module F3LH0-1N.
Related User’s Manuals
For individual sequence CPU modules, read the latest versions of the relevant user's
manuals as required.
F3SP71, F3SP76 functions
- Sequence CPU Instruction Manual – Functions (for F3SP71-4N/4S, F3SP76-
7N/7S) (IM34M06P15-01E)
- Sequence CPU – Network Functions (for F3SP71-4N/4S, F3SP76-7N/7S)
(IM34M06P15-02E)
F3SP66, F3SP67 functions
- Sequence CPU – Functions (for F3SP66-4S, F3SP67-6S) (IM34M06P14-01E)
- Sequence CPU – Network Communication Functions (for F3SP66-4S, F3SP67-6S)
(IM34M06P14-02E)
F3SP28, F3SP38, F3SP53, F3SP58, or F3SP59 functions
- Sequence CPU – Functions (for F3SP28-3N/3S, F3SP38-6N/6S, F3SP53-4H/4S,
F3SP58-6H/6S, F3SP59-7S) (IM34M06P13-01E)
F3SP21, F3SP25, F3SP35, F3SP05, or F3SP08 functions
- Sequence CPU – Functions (for F3SP21, F3SP25, and F3SP35) (IM34M06P12-
02E)
The following user’s manuals are common to all sequence CPUs.
Instructions
- Sequence CPU – Instructions (IM34M06P12-03E)
Ladder programming
- FA-M3 Programming Tool WideField3 (IM34M06Q16-01E)
For the FA-M3 specifications and configurations*1, installation and
wiring, test run, maintenance, and module installation restrictions, refer
to:
*1: Refer to the relevant product manuals for specifications except for power supply modules, base modules, input/output
modules, cables and terminal units.
All sequence CPU modules
- Hardware Manual (IM34M06C11-01E)

xi
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
Copyrights and Trademarks
Copyrights
The copyright of the programs and online manuals contained in the software medium of
the Software Product shall remain in YOKOGAWA.
You are allowed to print the required pages of the online manuals for the purposes of
using or operating the Product; however, reprinting or reproducing the entire document
is strictly prohibited by the Copyright Law.
Except as stated above, no part of the online manuals may be reproduced, transferred,
sold, or distributed to a third party in any manner (either in electronic or written form
including, without limitation, in the forms of paper documents, electronic media, and
transmission via the network). Nor it may be registered or recorded in the media such as
films without permission.
Trademarks
The trade names and company names referred to in this manual are either trademarks
or registered trademarks of their respective companies.

Blank Page

TOC-1
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
CONTENTS
Applicable Product....................................................................................i
Important...................................................................................................ii
Introduction...............................................................................................x
Copyrights and Trademarks ...................................................................xi
1. Overview ....................................................................................... 1-1
1.1 What is YHLS?......................................................................................... 1-1
1.2 Features of YHLS..................................................................................... 1-2
1.2.1 Communications between YHLS Master Module and
Slave Units ................................................................................1-2
1.2.2 Constant Communication Cycle Time....................................... 1-2
1.2.3 Output Control Function ............................................................ 1-2
1.2.4 Daisy-chain Connection.............................................................1-2
1.2.5 Transmission Line Quality Indicators......................................... 1-2
2. Specifications............................................................................... 2-1
2.1 Standard Specifications.......................................................................... 2-1
Model and Suffix Codes.......................................................................2-1
Operating Environment........................................................................ 2-1
General Specifications ......................................................................... 2-1
Components and Functions................................................................. 2-2
External Dimensions............................................................................2-2
2.2 External Connection ...............................................................................2-3
Connection Topology............................................................................2-3
Connector Pin Assignment................................................................... 2-3
Cable....................................................................................................2-4
Connector............................................................................................. 2-4
Shield Treatment..................................................................................2-4
Pin Terminals........................................................................................ 2-4
2.3 Attaching/Detaching the Module............................................................ 2-5
Attaching the Module ...........................................................................2-5
Detaching the Module..........................................................................2-5
Attaching the Module in Intense Vibration Environments....................2-6
3. Functions...................................................................................... 3-1
3.1 List of Functions ..................................................................................... 3-1
3.2 Communication with Slave Units........................................................... 3-2
3.2.1 Starting Communications........................................................... 3-2
3.2.2 Input...........................................................................................3-2
FA-M3
YHLS Master Module
IM 34M06H46-04E 2nd Edition

TOC-2
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
3.2.3 Output........................................................................................3-2
3.3 Constant Communication Cycle Time................................................... 3-3
3.3.1 When a Slave Unit is Withdrawn from Communication.............3-3
3.3.2 When a Slave Unit Resumes Communication .......................... 3-3
3.4 Output Control Function......................................................................... 3-4
3.5 Transmission Line Quality Indicators ................................................... 3-4
4. Response Time............................................................................. 4-1
4.1 Data Transfer Time .................................................................................. 4-1
4.2 Remote Scan time (RST)........................................................................ 4-3
5. Communication Preparation Flow.............................................. 5-1
6. List of I/O Relays.......................................................................... 6-1
6.1 Output Relays.......................................................................................... 6-1
6.2 Input Relays............................................................................................. 6-2
7. List of Registers........................................................................... 7-1
7.1 Input Data area......................................................................................... 7-2
7.2 Output Data area...................................................................................... 7-4
7.3 Parameter Setup Area............................................................................. 7-6
7.3.1 Last Address.............................................................................. 7-7
7.3.2 Transmission Speed.................................................................. 7-7
7.3.3 Communications Mode.............................................................. 7-8
7.3.4 Monitored Slave List.................................................................. 7-8
7.4 Parameter Monitoring Area .................................................................... 7-9
7.4.1 Last Address............................................................................7-10
7.4.2 Transmission Speed................................................................ 7-10
7.4.3 Communications Mode............................................................7-10
7.4.4 Alive Slave List........................................................................ 7-10
7.4.5 Failed Slave List (non-latched).................................................7-11
7.4.6 Failed Slave List (latched).......................................................7-12
7.4.7 Monitored Slave List................................................................ 7-12
8. Troubleshooting........................................................................... 8-1
8.1 Troubleshooting Using LEDs................................................................. 8-1
8.2 Troubleshooting Using FlowCharts....................................................... 8-3
8.2.1 Main Flowchart.......................................................................... 8-3
8.2.2 RDY LED is not Lit..................................................................... 8-4
8.2.3 L LED is not Lit .......................................................................... 8-5
8.2.4 A LED is Lit................................................................................8-6
8.2.5 No Output to Slave Unit.............................................................8-7
8.2.6 No Input from Slave Unit ........................................................... 8-7
9. Sample Program........................................................................... 9-1
Appendix: KM8Cable Preparation............................................ Appx-1
Index...............................................................................................Index-1
Revision Information........................................................................Rev-1

1-1
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
1. Overview
The Yokogawa High-speed Link System (YHLS) master module F3LH01-1N has one
YHLS master interface port, while the F3LH02-1N has two master interface ports for
connecting slave units to perform remote I/O.
Table 1.1 Applicable Module
Model Code Module Name Description
F3LH01-1N YHLS Master Module One YHLS port
F3LH02-1N YHLS Master Module Two YHLS ports
1.1 What is YHLS?
Yokogawa High-speed Link System (YHLS) is designed for implementing high-speed
remote I/O in the FA-M3 system.
A YHLS system consists of the FA-M3 master module (F3LH0-1N) connected to
multiple distributed slave units through a communication cable to allow high-speed
control of remote I/O units from a sequence CPU. It has the following merits:
- High-speed scan of 63 slave units in just 0.96 ms.
- Reduced wiring through use of distributed devices within a system
- Simple mechanism for high-speed exchange of ON/OFF signals and numerical data
with remote devices
- Adoption of the HLS open network allows flexibility in building customized
application systems by connecting HLS-compliant I/O units from different vendors.

1-2
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
1.2 Features of YHLS
1.2.1 Communications between YHLS Master Module and
Slave Units
Through periodic communications with connected slave units, the YHLS master module
acquires ON/OFF information of switches connected to these slave units into its input
data area, as well as outputs information stored in its output data area as ON/OFF
information for actuators. By accessing the I/O data areas of the YHLS master module
using READ and WRITE instructions, the sequence CPU module can thus exchange
information with field equipment.
Sequence CPU
Module
Internal
devices
Internal
devices
YHLS Master
Module
Input
area
Output
area
READ
instruction
WRITE
instruction
Slave
Unit
Input
Output
Communi-
cation
Communi-
cation
1.2.2 Constant Communication Cycle Time
YHLS features a constant communication cycle time, not affected by automatic
participation or withdrawal of slave units, thus delivering reliable communications with
constant cycle time under all circumstances.
1.2.3 Output Control Function
The YHLS master module can be made to suspend YHLS communications when the
sequence CPU module “stops”. By combining this feature with output control functions
of individual slave units, which can be used to reset or hold the contact outputs of
individual slave units when YHLS communication stops, you can implement output
control of the entire YHLS system when sequence stops.
1.2.4 Daisy-chain Connection
As YHLS adopts a daisy-chain connection inside each communication connector, a
slave unit that is powered off or down does not affect normal communication with the
other slaves.
1.2.5 Transmission Line Quality Indicators
The YHLS master module indicates transmission line quality using its L (LINK) LED and
A (ALARM) LED. It also stores transmission line quality status information in its internal
registers.

2-1
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
2. Specifications
2.1 Standard Specifications
Model and Suffix Codes
Model Suffix
Code Style
Code Option Code Description
F3LH01 -1N …… …… 12 Mbps max., 1 YHLS port
F3LH02 -1N …… …… 12 Mbps max., 2 YHLS ports
Operating Environment
There is no restriction on the type of CPU module that can be used with the F3LH0-1N
module.
General Specifications
Item Specifications
Operating ambient
temperature 0 to 55C
Operating ambient
humidity 10 to 90% RH (non-condensing)
Operating ambient
atmosphere Must of free of corrosive gases, flammable gases and heavy dust
Storage ambient
temperature -20 to 75C
Storage ambient humidity 10 to 90% RH (non-condensing)
Performance Specifications
Item Specifications
F3LH01-1N F3LH02-1N
Communications mode 4-wire full-duplex or 2-wire half-duplex
Transmission speed 3 Mbps, 6 Mbps or 12 Mbps
Transmission format HLS compliant
Synchronization Bit synchronization
Transmission distance 300 m (at 3 Mbps), 200 m (at 6 Mbps), or 100 m (at 12 Mbps)
Error detection CRC-12
Number of ports 1 2
Number of connectors 2 4
Max. number of slaves
per module 63
*1
(32 per connector)
126
*1
(32 per connector)
Number of I/O points per
module 1008 inputs 1008 outputs
2016 inputs
2016 outputs
Impedance 100 Ω
Terminating resistor Internal
*
2
Connector type European type
Recommended
communication cable KM80 and KM81
RAS functions - Automatic slave unit participation - Reset/hold outputs when CPU stops
- Network quality monitoring
Current consumption 360 mA at 5 VDC 480 mA at 5 VDC
External dimensions 28.9 (W) x 100 (H) x 83.2 (D) mm
*3
Weight 100 g 105 g
*1: One connector can connect up to 32 slave units (one port supports up to 63 slave units).
To connect 63 slave units, connect 32 slaves to one connector 31 slaves to the other connector.
*2: The module has a built-in terminating resistor, which must be enabled for terminal stations (the farthest module on a
communication line) of the I/O system.
*3: Excluding protrusions (see External Dimensions for details).

2-2
IM34M06H46-04E 2nd Edition : Jan.31, 2017-00
Components and Functions
Front View
F3LH01-1N F3LH02-1N
LED status indicators
RDY: Lit when the internal circuitry is functioning normally.
(the RDY LED is shared by ports 1 and 2)
Each port is provided with one set of the following LEDs
(labeled as “1” for port 1 and “2” for port 2):
L : Lit when communicating with one or more slave units.
A : Lit on communications error at one or more slave units.
F : Lit when communicating in full-duplex mode.
H : Lit when communicating in half-duplex mode.
12 : Lit when communicating at 12 Mbps.
6 : Lit when communicating at 6 Mbps.
3 : Lit when communicating at 3 Mbps.
YHLS communication ports
LED Indicators
Designation
(color) Description When Lit When Not Lit
RDY (green) Internal circuit
status Normal Error
L (green) Communications
status (LINK)
Communicating with one or more
slave units.
Not communicating with slave
units.
A (yellow) Communications
error (ALARM)
Communication failure has been
detected at one or more slave
units.
No communication failure has been
detected at any slave unit or no
communication has occurred yet.
F/H (red) Communications
mode
Indicates communications mode
when Request to Communicate
relay is ON.
F: full duplex; H: half duplex
No indication when Request to
Communicate relay is OFF.
12/6/3 (red) Transmission
speed
Indicates transmission speed
when Request to Communicate
relay is ON.
12: 12 Mbps, 6: 6 Mbps, and 3: 3
Mbps
No indication when Request to
Communicate relay is OFF.
* For details on how to interpret combinations of LED indicators, see Chapter 8, “Troubleshooting.”
External Dimensions
F3LH01-1N
F3LH02-1N
(Unit: mm)
