Atmor 100 Series Operating instructions

Hot Water on Demand
Installation and Operation Guide
ATMOR 100 Series
Models: 100, 100V, 101, 101V, 101P, 101PV, 102, 102V, 102P, 102PV
Instant hot water heater provides endless supply of hot water
while signicantly conserving energy and water
www.atmor.net
P.N. 000000
Reset
Pump

Hot Water on Demand
2
Dear Customer,
Thank you for purchasing Atmor
instantaneous water heater:
• High energy efciency
• Slim design
• Flow controlled

Hot Water on Demand
3
1. Carefully read the instructions below.
2. Check the data on data sticker and compare it with your mains voltage.
3. The heater must be installed and put into operation by a licensed specialized.
• Do not switch ON the heater when it obviously frozen in.
• The heater operates at a minimum water ow rate of 1.6L/Min. For direct connection to the water tank,
the heater must have a minimum of 1.0m below the water tank.
• Separate electric circuits must be provided for the heater via a double pole linked switch with a
minimum contact gap of 3mm in both poles and must be permanently connected to the direct main
current supply. The switch must be readily accessible and clearly identiable and out of reach of
person using a xed bath or shower.
• The use of a plug and socket is not recommended.
• The appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities or lack of experience and knowledge, unless they have been
• Using Double Pole ELSD For Phase and neutral ,Optional Single Pole ELSD
Technical data
For technical characterizes, please refer to the appliance Data sticker:
Without pumpWith pumpModel
1.9 kg2.3 kgWeight
381 (H) * 215 (W) * 77(D) mmDimensions
WARNING!
"Earth" Led (Blue), indicate the product properly grounded to protect from electrocution.
In case the EARTH led is OFF switch OFF the incoming power supply and call
proffesional electrician.
1. The appliance must be earthed.
2. If any of the following conditions occur, immediately switch off the mains and contact Service. Never
attempt to repair the unit yourself.
• If the heater begins to make an odd noise, smell or smoke.
• ELSD and heater lamp does not light up.
• Water temperature can not be controlled.
• If the heater shows signs of a distinct change in performance.
• If found water leakage from inside.
Safety
MODEL: 100
220- 240V
3.0-3.6kW
Max. Water Pressure:600 kPa(6 bar)
Min. Water Pressure: 30 kPa (0.3 bar)
Rated Pressure: 0 kPa (0 bar)
SERIAL No.
Made in China
A.C.
50Hz
IP25
Sample Data Sticker

Hot Water on Demand
4
Installation instruction
Note: The control knobs are integral parts of the cover – do
not attempt to remove them.
• Unscrew the bottom & top A& B (g.1) retained screws and lift
the cover from the back plate.
• Use the back plate as a template and mark the xing holes.
• The heater position should be 1.5 meter from the bathroom
oor. (g.2)
• Drill the holes: 2 Options: (Fig 3 Or Fig. 4) and insert the wall
plugs.
• Insert the cables through the cable entry of the heater.
• Fit the heater to the wall. (Fig 3 Or Fig 4)
• To mount the shower accessory, mark 2 screws points
for positioning the slider rail set beside the heater. It is
recommended the top of the portion with the top of the heater.
Remove the terminal cover from the mounting terminal and
screw the mounting to position. Close the cover.
Insert the shower holder and soap Tray.
Close the cover.
1. For the correct size of wire conductor corresponding to
different electrical loading, please refer to table 1.
2. The built – in ELSD will automatic cut off the power supply in
case there is a current leakage as low as 15mA. To ensure
correct operation of the ELSD, DO NOT installs this product if
the line voltage is lower than 175V.
3. The thermostat will automatic cut off the power if it has sensed
an abnormal rise in showing water temperature. Only qualied
technicians are allowed to reset the thermal cut- out built
inside the appliances.
Fig.1
Fig.4Fig.3
Option 1 Option 2
1.5o m
Fig.2
A
B

Hot Water on Demand
5
INCORRECT INSTALLATION
CORRECT INSTALLATION
Plumbing connection
Warning: The outlet of the heater acts as a vent and MUST
NOT be connected to any TAP, CONTROL VALVE OR FITTING
TO THE WATER OUTLET.
1. Connect the stop valve to the water inlet with rubber washer.
Use correct tools to tighten and be careful not to break the
plastic nut.
2. Insert Mesh lter washer then connect the incoming water
piping end to the stop valve (1/2” BSP).
3. Connect the PVC hose and hand shower to the outlet of the
heater; be sure to put in the rubber washer.
4. Hook the hand shower to the slider Rail Holder and adjust to
your ideal position.
• THE WATER INLET AND OUTLET MUST BE INSTALLED
CORRECTLY, OTHERWISE THE HEATER CAN NOT
FUNCTION.
• DO NOT USE PLUMBING CEMENT ON CONNECTION. IF
NECESSARY, USE ONLY THREAD OR SEALING TAPE.
Turn on the water mains to drain out all plumbing dirt and to ll up
the heater tank
Check for any water leakage. (IMPORTANT: This step will
prevent damage to the Heating element).
Fig.5
Fig.6
Danger:
Outlet on the
Left size of unit.
Inlet
Outlet

Hot Water on Demand
6
This appliance must be EARTHED.
The EARTH continuity conductor of the electrical
installation must be effectively connected electrically
to all exposed metal parts of other appliances in the
room in Which the heater installed.
SWITCH OFF at mains before carrying out any electrical work.
Refer to the Electrical Loading Table (Table 1) for the correct
cable size.
DO NOT install this product if the line voltage is lower than 175V.
1. Use double coated exible cable having nominal cross-
sectional area between 4 and 6 mm
2
. (IEC/EN 60335-1).
2. Lead the power cable from the circuit breaker to a “ON/OFF”
double bipolar switch outside the bathroom, then lead a cable
connected to terminal block inside the unit (g.5).
Note: Conduit entry can only from rear.
3. Connect the cable to terminal block and fully
tighten them
(insure no cable insulation is trapped under the screws) as
follow: (g.5) BROWN or RED FOR LIVE (L)
BLUE or BLACK for NEUTRAL (N)
GREEN or Green/ Yellow for EARTH ( ).
The cable clamp must be used to secure the cable. (g.6)
4. Check the wiring connection is tightens and correct then close
the front cover. When close back the front cover , please take
note the below procedure:
• To ensure the correct position, turn the temperature knob
insert to OFF position as shown in g.8. (At the heater base).
• To install the front cover, turn the temperature control knob
to OFF position to align with the knob insert as shown in g.8
(At the front cover).
For pump models, the same align procedure is apply to both
pump speed VR insert And pump knob.
5. Fix back the screws A & B. (g. 7)
Do not switch on the electricity supply until the cover has been
tted.
Fig.5
Fig.6
Fig.7
Fig.8
A
B
Electrical connection

Hot Water on Demand
7
Reset
Pump
Testing
THE HEATER TANK MUST BE FILLED UP WITH WATER
BEFORE TURN ON THE ELECTRICITY SUPPLY. THIS
IS TO PREVENT ANY DRY BURNT DAMAGE TO THE
HEATING ELEMENT.
1. Turn on the water supply (J) then wait until the water ow
through the Hand shower.
2. Switch on the electrical supply and the Green Led (ELSD) lamp
will turn on (F).
3. Turn on the temperature control knob (E) to ‘ON’, the red LED
(Heater) lamp will turn on; the hot water will come out in a few
seconds. The higher the temperature indicator position, the
hotter is the shower.
4. The shower might not be enough even at the maximum position
if the incoming water supply from the mains is too cold or the
ow too high. In this case, you can adjust the water inow in
order to get the desired showering temperature.
5. Check the Built-in ELSD as follow:
• Press the “TEST” button (B), the unit should trip and cut off
the power supply,
• All leds lamps should light off.
6. Press the “RESET” button (C), the unit should resume normal
function, Green LED lamp should light on. If the above
mentioned procedures prevail, the ELSD is functioning in
normal condition.
7. If shower accessory is available, the height and the direction of
the shower holder is adjustable.
For pump model:
8. Turn on the pump control knob (D) to test run the pump.
If the shower is not hot enough, you can adjust the knob (A)
to reduce the pump speed until you get the desired shower
temperature.
For power ON/OFF model:
9. After turn ON supply (J) and press power ON/OFF button (G)
then wait until the water ow through the hand shower.
Testing
A
J
B
C
D
E
F
G
H

Hot Water on Demand
8
Read the section ‘WARNING ‘rst.
Test the “ELSD” regularly
Turn on the electricity (G) and water supply (J), the green ELSD
lamp (F) will light up. If the temperature control knob (E) is in ‘ON’
position; the red heater lamp will light up also.
Press The ELSD test knob (B), the ELSD and heater lamp should
go off. Press the reset knob (C) to resume the electricity supply.
If the ELSD or heater lamp does not go off when you press the
ELSD test knob, SWITCH OFF the main supply and contact
service. NEVER try to repair the unit by yourself.
The users shall test the built in ELSD at least once a month to
ensure the heater is safe to use.
Cleanthelter
Remove the lter by turn it anti clockwise and ush it with water to
remove any trapped Sediments.
Fitting and cleaning the Shower head
Warning: Metallic / chromed hose and conductive control
valve shall not be used. (Apply for products installed in
Malaysia only)
• Fit the two end brackets to the Rod.
• Place the brackets with rod onto the wall and mark the position
on the two screw holes.
• Fit the end brackets, holder and rod onto the wall with the wall
plugs and screw provided.
• Fit the exible hose to the shower head.
• Connect the exible hose with shower head to the heater using
the rubber sealing washer.
• Place the shower head in the holder.
• The heater is now ready to be tted to the electrical supply.
Note: The shower head must be periodically clean to ensure no
blockage occurred.
Do not use thinner, alcohol, petrol or any other organic solutions
to clean the set.
Maintenance

Hot Water on Demand
9
Electrical connection
Wattage Amperage (AMPs) Cable Size
(mm2)
1Ø 220V 1Ø 230V 1Ø 240V
2kW 9.1 8.7 8.3 2.5mm2
3.3kW 13.6 13.0 12.5 2.5mm2
3.5kW 15.0 14.3 13.7 2.5mm2
4.5kW 20.5 19.5 18.8 2.5-4.0mm2
5.5kW 25 23.9 22.9 4-6mm2
6.5kW 29.5 28.2 27.0 4.0-6.0mm2
Wattage Amperage (AMPs) Cable Size
(mm2)
1Ø 220V 1Ø 230V 1Ø 240V
7.5kW 34.1 32.6 31.3 4.0-6.0mm2
8.5kW 38.6 37.0 35.4 6.0-10.0mm2
9.5kW 43.2 41.3 39.6 6.0-10.0mm2
3Ø 220V 3Ø 230V 3Ø 240V
8.5kW 12.9 12.3 11.8 2.52
9.5kW 14.4 13.7 13.2 2.52
Table 1: Electrical Loading Table
Wiring Diagram - With Pump
Power, Pump & 2P ELSD Control PCBA
Power, Pump SV & 2P ELSD Control PCBA
+24V
0V
Speed Control

Hot Water on Demand
10
Wiring Diagram - Without Pump
Electrical connection

Hot Water on Demand
11
Part List
Terminal Block
PCBA DP ELSD
(Optional SP)
ELSD+PUMP Model Cover ELSD Cover Cover
SP Tank Assy
Main PCBA Control
Pump
Flow Switch Assy
Inlet
Outlet
Reset
Pump Reset
Reset

Hot Water on Demand
12 www.atmor.net
Trouble shooting
SYMPTOM POSSIBLE CAUSE SOLUTION
Water no! hot
enough
Too much waler fIowing through
the heater
Reduction In tha ambient
temperature
Water Pressure below of 1.0bar
Electrical Mallunction
Reduce the ow rate of the waler via
the outlet tap.
Switch to higher temperature setting.
Check if the mains stop valve is fully
open and that the there are no other
restriction in the supply line.
Have the Heater unit check by a
qualied eIectrician or contact your
local authorised distributor.
Water too hot Not enough Water owing through
the heater
Increase in the ambient
temperature
Increase the ow rate via the outlet tap
Switch to lower temperature setting
Heater switch Off
during use
Interruption of mains electrical
supply
ELSD trip, possible earth leakage
Check incoming power supply, MCB,
switches and supply cabling. Check
earth leakage and reset ELSD
If problem persists, call your local
authorised distributor for assistance.
Water ceases to
ow
Blockage of spray head, twisted or
blocked exible shower hose.
No water supply.
Clean or replace sprayheed, check for
free passage of water through hose.
Replace as necessary.
Check water supply, stop valve Open?
and no blockage.
Water
temperature
varies from hot to
cold during use
Water pressure has dropped
below min. level.
Increase hot water supply,
No hot water
despite fully open
hot water faucet
No electrical power
The activation ow rate needed to
turn on the heating element has
not been reached.
Check the circuit breaker and check
voltage at the wiring block.
Clean lter screen
• Turn circuit breaker off
• Open hot valve to release pressure
from the unit.
• Turn circuit breaker on.
