Atmor Europe InLine 800 Series Operating instructions

1
P.N. 107343C
Hot Water on Demand
Installation and Operation Guide
Europe InLine 800 Series
3.5kW-12kW

2
GENERAL SAFETY INSTRUCTIONS
CAUTION!
1. This manual is an integral part of the product. Keep it with care with the appliance, and hand
it on to the next user/owner in case of change of property.
2. Read the instructions and warning in this manual carefully, they contain important information
regarding safe installation, use and maintenance.
3. The appliance must be installed and commissioned by a qualied technician in accordance
with local legislation and health and safety regulations. All power circuits must be shut off
before you open the terminal block.
4. DO NOT use the appliance for any other than its specied use. The manufacturer is not liable
for damage resulting from improper or incorrect use or failure to observe the instructions
given in this manual.
5. Incorrect installation can result in damage to property and injury to persons and animals; the
manufacturer is not liable for the consquences.
6. DO NOT leave the packaging materials (staples, plastic bags, expanded polystyrene, etc.)
within the reach of children - they can cause serious injury.
7. The appliance is not intended for use by persons under 8 years of age, with reduced
physical, sensory or mental capacity, or lacking the requisite experience and familiarity,
unless under supervision or following instruction in the safe use of the appliance and the
hazards attendant on such use. DO NOT permit children to play with the appliance. User
cleaning and maintenance may not be done by unsupervised children.
8. Any repairs, maintenance, plumbing and electrical hookup must be done by qualied
technicians using original spare parts only. Failure to observe the above instructions can
compromise the safety of the appliance and relieves the manufacturer of any liability for the
consequences.
9. The hot water temperature is regulated by a thermostat which also acts as a safety device to
prevent dangerous overheating.
10. The electrical hookup must be done as indicated in this manual.
11. If the appliance is equipped with a power cord, the latter may only be replaced by an
authorised service centre or professional technician.
12. Make sure to drain the appliance when it is out of service or in an area subject to subzero
temperatures.
13. Do not leave ammable materials in contact with or in the vicinity of the appliance.

3
Symbol Meaning
Failure to observe this warning can result in injury, which may even be fatal in certain circumstances
Failure to observe this warning can result in damage or injury, even to property; plants and animals
Observe the product's general and specic safety instructions.
GENERAL SAFETY STANDARDS
Ref. Warning Risk Symbol
1.Do not open the appliance or remove from
its installation
Electrocution hazard due to the presence of live
electrical equipment. Personal injury -overheated
burns caused by components and wounds caused
by sharp edges
2. Do not start or stop the appliance by
inserting/pulling the power plug
Electrocution hazard due to damage to the power
cord, its plug or the socket
3. Do not damage the power cord Electrocution hazard due to bare live wires
4. Do not leave objects on the appliance Personal injury due to objects falling off the
appliance as a result of vibration
Damage to the appliance or other property due
to objects falling off the appliance as a result of
vibration
5. Do not climb onto the appliance Personal injury due to falling off the appliance
Damage to the appliance or other property due to
the appliance itself detaching from its mounting
6. Do not clean the appliance without having
rst switched it off, pulled its power plug or
shut off its power switch
Electrocution hazard due to the presence of live
electrical equipment
7. Install the appliance to a solid wall which is
not subject to vibration
Danger of the appliance falling off the wall due to
structural collapse, or noisy operation
8. Make the electrical hookup with cables of
adequate cross-section
Danger of re due to overheating of undersized
electrical wires
9. Restore all safety and control functions after
working on the appliance and check that
they are operational before returning it to
service
Damage or blocking of the appliance due to
improper control
10. Drain all components containing hot water,
using the bleed cocks, before handling them
Danger of burns
11. Descale the system as given in the products
"safety sheet"; when doing so, ventilate the
room,wear safety clothing, make sure not
to mix products, and protect the appliance
itself and any adjacent objects
Personal injury due to contact of the skin and
eyes with add, inhalation or ingestion of noxious
chemicals
Damage to the appliance and adjacent objects
due to corrosion by acid
12. Do not use insecticides, solvents or
aggressive detergents to clean the
appliance
Damage to plastic and painted parts and
assemblies

4
TECHNICAL CHARACTERISTICS
For the technical specications, refer to the nameplate (the nameplate is located on the right side
of the water heater).
Remark: Venturi product is up to 10.5kW only.
Product Information
Power (kW) 3.5 5.0 5.5 6.0 7.0 7.5 7.7 8.0 9.0 9.5 10.5 12.0 12
Voltage 220-240V 400-415
Phases Mono 3 phase
Installation Hidden Installation
Constructions Close Outlet
Model Refer to name plate
Frequency 50/60hz
Amper 16.0 22.7 25.0 27.2 31.8 34.0 35.0 36,4 40,9 43,2 47.7 54.5 17.3
Water Protection IP24
Pipe Connection 1/2" BSP
Minimu, Water Flow 2.1L/Min
Qelec (kWh) 2.119 2.119 2.224 2.191
max water pressure 8 BAR
Load Prole XXS XXS XS XS
Lwa (db) 15db
Hwh 40% 40% 38% 39%
Rated Volume (lt)
400cc
Weight 2400 gr
Dimensions 304 mm x 178 mm x 98 mm
The power consumption data in the table and the other information given in the Product Data
Sheet (Enclosure A to this manual) are dened in relation to EU Directives 812/2013 and 814/2013.
The products without the label and the data sheet for water heaters and solar devices, stipulated
in regulation 812/2013, are not intended to be used in such assemblies.
Products equipped with a regulator knob have the thermostat positioned in the <ready to use
setting indicated in the Data Sheet (Enclosure A), according to which the relevant energy class
has been declared by the manufacturer.
This appliance is conforming with the international electrical safety standards IEC
60335-1 and IEC 60335-2-35. When present, The CE marking of the appliances
attests its conformity to the following EC Directives, of which it satises the
essential requisites:
- LVD Low Voltage Directive: EN 60335-1, EN 60335-2-35, EN 60529, EN 62233, EN 50106.
- EMC Electro-Magnetic Compatibility: EN 55014-1, EN 55014-2, EN 61000-3-2, EN 61000-3-3,
EN 61000-3-11 and EN 61000-3-12.
- ERP Energy related Products: Eu812, Eu814, EN50193-1-2013

5
INSTALLATION INSTRUCTIONS
The appliance must be installed and commissioned by a qualied technician in accordance with
established regulations and local health and safety regulations..
1. Open the four screws located on the top and bottom of the device and remove the cover
from base.
2. Fix the base horizontally against a wall or side of cabinet,
ground wire must be connected
to the unit, the inlet and outlet water pipes are on the down/bottom side of the unit. Use 4
mounting screws provided.
3.
Use the supplied water lter on the inlet water pipe line (see diagram Page 9).
4. Connect the incoming water line (cold only) to the inlet water pipe on the bottom left side and
the outgoing water line to the outlet water pipe on the bottom right side. Open the mains cock
of water supply and check there is no water leakage from the unit.
5. Before performing any operations, disconnect the appliance from the electricity mains using
the external switch then connect the power to cable to the appliance. The appliance must be
earthed and the earth cable (show with a letter in the drawing) is xed to the terminal marked
by the symbol .
6. Turn on the unit and check that it is operating as required.
7. Reconnect the cover to the base with 4 screws.
8. It is required that a Ground Fault Circuit Interrupter/Earth Leakage Circuit Breaker be
incorporated in the circuit.
9.
Make sure to install in the right way the pressure relief valve (supplied with the
product) before Inlet pipe (diagram Page 9).
10. It is required to install a ow control restrictor (AERATOR) at the sink or shower.
N
G
L3
L2
L1
Mono
3 Phases
L
L
G
G
N
N
AURES
SLIMMULTI
Inline 800
0
L
O
W
M
I
D
H
I
G
H
N
N
G
G
L3
L3
L2
L2
L1
L1
Mono
InLine Venturi Under Sink
3 Phases

6
11. WARNING: UNIT MUST BE PROPERLY GROUNDED
12. THIS HEATER MUST HAVE ITS OWN INDEPENDENT CIRCUIT USING A
CORRECTLY RATED CIRCUIT BREAKER AND SUITABLE WIRE, SEE TABLE
RECOMMENDED CABLE.
OPERATING INSTRUCTIONS
1. Your new Instant Water Heater is ow activated. Regulate the knob in one of the 3 setting
power (Low, Med, High) the product will switch ON and turn on the hot water tap. the
heating element will work and warm the water only when there is a ow of water through the
appliance.. You will need to allow at least 2.1 liters per minute to ow through the unit in order
to activate the Instant Heating System. Run water through the heater for a few minutes.
2. Be sure to every so often clean the spray head of sediment to assure a smooth water ow.
3. Be sure to every so often clean the incoming water lter.
4. Be sure to install your Instant Water Heater in a heated location. The appliance cannot be
installed in areas where the temperature may drop critically and there may be a risk that ice
may form.
5. The user can adjust the hot water temperature regulating the setting power on the unit. the
user can choose till 4 setting poer position:
- Power - Heating element is off
- Low - Only the 1st Heating element switches on.
- Med - Only the 2nd heating element switches on.
- High - 1st and 2nd heating elements switch on, working together.

7
8.0kW-10.5kW (220V-240V) 8.0kW-10.5kW (220V-240V)
12kW (220V-240V) 12kW (220V-240V)
3.0-7.0kW (220V-240V)
Install Line 1 (L1), E(G)-Ground, Line 2 (L2)
3.0-7.0kW (220V-240V)
Install Line 1 (L1), E(G)-Ground, Line 2 (L2)
1 2
8
3 4 5 6 7
R.R
85º
Led 1
Led 2
85º
57º
L1
G
(N)
23 4 6 7
1 5
8
R.R
85º
Led 1
Relay
Switch
Relay
Led 2
85º
57º
L1
G
(N)
8
24 7
1 5
85º
Led 2
Relay
1
H.E 1
H.E 2
H.E 3
Relay
2
Switch
Led 1
85º
85º
L1
G
(N)
R.R
6
(L1,L2,L3)
1. Terminal block
2. Thermal cut-out with reset
3. Thermal cut-out
4. Relay
5. Switch 0- Off
1- Low
2- Medium
3- High
6. Light
7. Heating element
8. Read sensor
9. ELCB
1 2
8
3 4 5 6 7
R.R
85º
Led 1
Led 2
85º
57º
L1
G
(N)
9
23 4 6 7
1 5
8
R.R
85º
Led 1
Relay
Switch
Relay
Led 2
85º
57º
L1
G
(N)
9
8
24 6 7
1 5
85º
Led 2
Relay
1
H.E 1
H.E 2
H.E 3
Relay
2
Switch
Led 1
85º
85º
L1
G
(N)
R.R
9
1
8
34 5 6 7
R.R
K1
Led 1
Led 2
T1
L1
G
(N)
1
8
34 5 6 7
K1
Led 1
Led 2
T1
L1
G
(N)
R.R
9
Electrical Diagram:
InLine InLine+ELCB
L1/L2 = Line1/Line2 (Black or Red)
E(G) = Ground (Green/Yellow)
*N = Neutral (White or Silver)
*Neutral acts as Line 2 (L2) for 220V/240V
(L1,L2,L3)

8
23 4 6 7
15
85º
Led 1
Switch
Led 2
85º
57º
L1
G
(N)
Relay
Ventury
1. Terminal block
2. Thermostat
3. Ventury Part
4. Switch 0- Off
1- Low
2- Medium
3- High
5. Light
6. Heating element
1. Terminal block
2. Thermostat
3. Ventury Part
4. Switch 0- Off
1- Low
2- Medium
3- High
5. Light
6. Heating element
1. Terminal block
2. Thermostat
3. Ventury Part
4. Relay
5. Switch 0- Off
1- Low
2- Medium
3- High
6. Light
7. Heating element
6.0kW-8.0kW (220V-240V)
9-10.5kW (220V-240V)
3.0-5.5kW (220V-240V) - Install Line 1 (L1), E(G)-Ground, Line 2 (L2)
L1/L2 = Line1/Line2 (Black or Red)
E(G) = Ground (Green/Yellow)
*N = Neutral (White or Silver)
*Neutral acts as Line 2 (L2) for 220V/240V
Electrical Diagram: Venturi
12 3 4 5 6
85º
Led 1
Led 2
85º
L1
G
(N)
Switch
Ventury
1 2 3 4 5 6
Led 1
Led 2
L1
G
(N)
Switch
Ventury

9
Inline 800
0
L
O
W
M
I
D
H
I
G
H
Inline 800
Model Name Amper
(230V) 220V 230V 240V Heating Elements Phases Min Field wire mm2
3.5 kW 21.7 3.5kW 3.8kW 4.2kW 2+1.5 Mono 2.5
5 kW 22.7 5kW 5.5kW 6kW 2+3 Mono 4
5.5 kW 25.0 5.5kW 6kW 6.5kW 2.0+3.5 Mono 4
6 kW 27.2 6.0kW 6.5kW 7.1kW 2.5+3.5 Mono 4
7 kW 31.8 7.0kW 7.6kW 8.3kW 3+4 Mono 6
7.7 kW 35.0 7.7kW 8.4kW 9.1kW 3.3+4.4 Mono 6
8 kW 36.3 8.0kW 8.7kW 9.5kW 3.8+4.2 Mono 6
9.5 kW 240V 38.6 8.0kW 8.7kW 9.5kW 4.5+5 Mono 6
9.5 kW 230V 41.3 9.0kW 9.5kW 10.7kW 4+5 Mono 10
9.5 kW 43 9.5kW 10.3kW 11.3kW 4.5+5 Mono 10
10.5 kW 47.7 10.5kW 11.4kW 12.5kW 5.25+5.25 Mono 10
12 kW 230V 54.5 12.0kW 13.0kW 14.2kW 4+4+4 Mono 10
Model Name Amper 400V 415V -- Heating
Elements Phases Min Field wire mm2
9.0 kW 13 9kW 9.8kW -- 4+5 3 Phase 3x4
12 kW 17.3 12.0kW 13kW -- 4+4+4 3 Phase 3x4
• Operating water pressure 0.5-8 bar (7-116 psi) • W ater pressure operated ow switch
• Standard 1/2"Ø compression inlet connection • Top-left and right cable entry • Bottom-left water entry
UNIT DIMENSIONS: HEIGHT 178mm WIDTH 304mm DEPTH 98mm
Remark: Venturi product is up to 10.5kW only.
Inline 800
0
L
O
W
M
I
D
H
I
G
H
Table I: Recommended Cable
Inlet
Inlet and
outlet at
the bottom
Outlet
Incorrect InstallationCorrect Installation
WARNING!
BEFORE BEGINNING ANY WORK ON THE ELECTRICAL INSTALLA-
TION BE SURE THAT THE CIRCUIT BREAKER IS IN THE “OFF” POSI-
TION TO AVOID DANGER OF ELECTRICAL SHOCK

10
Inline 800
Close cover Steps
A B
Inline 800
0
L
O
W
M
I
D
H
I
G
H
Power Led
Power Knob
Water Inler
Pressure Relief Device
Filter
Water Outlet

11
This product conforms to Directive
WEEE 2012/19/EU.
The symbol of the crossed waste paper basket on the appliance indicates that at the end of its
working life the product should be disposed of separately from normal domestic household rub-
bish, it must be disposed of at a waste disposal center with dedicated facilities for electric and
electronic appliances or returned to the retailer when a new replacement product is purchased.
The user is responsible for the disposal of the product at the end of its life at an appropriate waste
disposal center.
The waste disposal center (which using special treatment and recycling processes effectively
dismantles and disposes of the appliance) helps to protect the environment by recycling the
material from which the product is made.
For further information about waste disposal systems visit your local waste disposal center or the
retailer from which the product was purchased.
Product sizes
304
102
181
Inline 800
0
L
O
W
M
I
D
H
I
G
H

12
Troubleshooting
SYMPTOM POSSIBLE CAUSE SOLUTION
Water not hot
enough
Too much water owing through
the heater
Reduction In tha ambient
temperature
Water Pressure below of 100
kPa
Electrical Malfunction
Reduce the ow rate of the water via
the outlet tap.
Switch to higher temperature setting.
Check if the mains stop valve is fully
open and that the there are no other
restriction in the supply line.
Have the Heater unit check by a
qualied eIectrician or contact your
local authorised distributor.
Water too hot Not enough Water owing
through the heater
Increase in the ambient
temperature
Increase the ow rate via the outlet
tap
Switch to lower temperature setting
Heater switch
Off during use
Interruption of mains electrical
supply
Check incoming power supply, MCB,
switches and supply cabling.
Water ceases
to ow
Blockage of spray head, twisted
or blocked exible shower hose.
No water supply.
Clean or replace spray head, check
for free passage of water through
hose. Replace as necessary.
Check water supply, stop valve
Open? and no blockage.
Water
temperature
varies from hot
to cold during
use
Water pressure has dropped
below min. level.
Increase hot water supply,
No hot water
despite fully
open hot water
faucet
No electrical power
The activation ow rate needed
to turn on the heating element
has not been reached.
Check the circuit breaker and check
voltage at the wiring block.
Clean lter screen
• Turn circuit breaker off
• Open hot valve to release pressure
from the unit.
• Turn circuit breaker on.
