Atmor Enjoy Operating instructions

www.atmorusa.com
Hot Water on Demand
Installation and Operation Guide
Enjoy
Electric Tankless Water Heater
Full Shower System
6kW/240V
Instant water heater provides endless supply of hot water
while signicantly conserving energy and water
o

2
Page
Safety Guidelines ..........................................................................................................................3
Technical Information.....................................................................................................................4
Plumbing........................................................................................................................................5
Mounting........................................................................................................................................6
Installation Procedure................................................................................................................ 7-8
Wiring ............................................................................................................................................9
Starting the System .....................................................................................................................10
Operation Guide .....................................................................................................................11-12
Care and Maintenance ................................................................................................................13
Troubleshooting...........................................................................................................................14
Table of Contents

3
Important Safety Guidelines
SAVE THESE INSTRUCTIONS
1. Safety Guidelines
Read this manual thoroughly before attempting to install the instant water heater.
Failure to follow the safety instructions in this manual may cause damage to the unit,
and could also result in property damage, personal injury, or loss of life.
Failure to comply with the safety, installation or operating instructions voids the
product warranty.
The product manufacturer and the product distributor will not be liable for any damages
or injury because of failure to comply with the installation and operating instructions
specied in this manual or because of improper use.
Never attempt to install, disassemble, inspect or repair, disassemble or service the water
heater without rst shutting off all power to the unit by means of the circuit breaker on the
main electrical panel.
The water heater must be installed by a licensed electrician and in compliance with all
national, state, provincial and local electrical and building regulations.
Always contact your local authorized distributor for service.
2. Safety – Important Notes .
•For power supply connection use 10 AWG or larger wires suitable for at least 194°F (90°C).
•The heater must be installed by a professional technician and according to the installation
instructions.
•The heater must be grounded.
•The heater must be connected to a dedicated circuit breaker on the main electrical panel.
•The plumbing installation must be completed before the electrical installation.
•The plumbing installation requires metal pipes or reinforced hoses that can withstand
pressure up to 101 psi (7 bar).
•To ensure proper operation, the water supply ow rate must be at least 4.35 psi (0.3 bar).
•Do not install the heater where it may be subjected to direct sunlight, rain, splashing water,
or freezing temperatures.
•This unit is intended for heating water only. Do not attempt to use the unit for heating any
other kind of liquid.
Before connecting the product to a public power network, consult your local power supply
authority to ensure the power network meets the stated requirements.

4
Technical Information
Electrical Specications
Enjoy
6 kW
Heating elements 1
Watts 6,000
Kilowatts 6 kW
Voltage 240 V
Circuit breaker amperage 1 x 30 A
Cable size (minimum) 3 x 10 AWG
Plumbing Specications
Minimum water ow to activate unit 0.47 gpm
Working pressure 4.35 psi - 101 psi
Tested pressure 203 psi
Water connections 1/2" NPT
Physical Dimensions
Height Width Depth Weight
15 inch (381 mm) 8½ inch (215 mm) 2¼ inch (55 mm) 4 lb 3 oz (1.8 kg)
Parts and Accessories
o
Shower head - Air Flow
A. Indicator light
B. Heating level selector:
0/Low/High
C. Hot water outlet
D. Cold water inlet
E. Reinforced pressure-
resistant hose
F. Hose and shower head
handle
G. Tap for water supply
to heater

5
Plumbing
01 02 The top of the heater should be at least 5 ft
(1.5m) above the oor.
The plumbing installation
must be completed before
the electrical installation.
05
0403
The plumbing installation requires pipes or
reinforced exible hoses that can withstand
pressure to 101 psi (7 bar) rated for high
temperature applications.
Residential plumbing
systems with unstable
pressure or pressure
above 72.5 psi (5 bar)
require the application of a
pressure stabilizer valve,
set to
58–72.5 psi (4–5 bar).
The shower head should be attached
to the slider rail at a comfortable
height for users.
06 Before proceeding to the electrical installation, run water through the
unit for several minutes to ush out any air bubbles from the water line.
While water is running, inspect all ttings and connections for leaks.

6
Mounting
01
03
02
04
The unit must be installed in an upright position with the
water inlet and outlet at the bottom.
The heater has two mounting options (Page 8, Figures 4 and
5) – either attach the backplate of the heater to the wall, or use
a slide wall-mount bracket. Using the backplate or the bracket
as a template, mark the mounting points on the wall.
The mounting surface
must be solid and secure.
Drill holes, and insert screw anchors that are suitable for screws
at least 1 inch in length.

7
Assembly Instructions
01
07 0908
02
04
06
03 05
Remove the appliance
covers (Figure 2).
Make sure the unit is level.
Mount on the wall, and
secure using 1 inch
screws.
Make sure power to the unit is shut
off by means of the dedicated circuit
breakers on the main electrical panel.
Insert the power cable into
the heater (Figure 3).
Do not connect to the
terminal block.
Connect the water hose
to the entry point of the
heater, and connect the
supplied accessories to
the water outlet.
Do not obstruct the
water outlet. Use
only accessories
supplied with the heater
(Figure 6).
Connect the power cable to the terminal
block within the unit. (Figure 7)
Caution: The heater must be
grounded.
Make sure all wire connections are secure.
Secure the power cable
with the designated
clamp (Figure 7).
Replace the front
cover onto the unit and
reattach it with 2 screws
(Figure 2).
Restore power to the unit
by means of the dedicated
circuit breakers on the
main electrical panel.

8
32
4 5
1
6 7
A
B
o
o
Washer
Option 2Option 1
Line 1
Ground
Line 2
Water
Filter

9
Electrical Diagram
1 2 3 4
5 6
6
1. Terminal block
2. Thermostat
3. Microswitches
4. Rotary switch
- Setting 0: Off
- Setting 1: Low 2.2 kW
- Setting 2: High 6 kW
5. Indicator light
6. Heating elements
L1
L2
E
240V

10
Starting the System for the First Time
01
03
02
04
Open the water tap (G)
to a gentle ow. Slowly
increase the ow until
the appliance lamp/s
light up. Wait 15 to 20
seconds for hot water to
ow out. Then adjust the
water temperature by
increasing/decreasing the
ow.
When nished using the
appliance, turn the selector
to the 0 setting
and close the tap (G).
Select the desired heating level (B):
Setting 0: Off
Setting 1: Low
Setting 2: High
Select the desired heating
level (B).
o
A. Indicator light
B. Heating level selector:
0/Low/High
C. Hot water outlet
D. Cold water inlet
E. Reinforced pressure-
resistant hose
F. Hose and shower head
handle
G. Tap for water supply to
heater

11
Operation Guide
Operating Instructions for the Home Owner
This electric water heater is designed to supply hot water. Unlike a conventional tank storage water
heater, this unit is a tankless water heater that does not store hot water. However, once you begin
using the system, you will nd it operates much like a conventional tank system.
Tankless systems deliver hot water instantaneously on demand. Since a tankless system does not
waste energy continually heating water that is idly sitting and losing heat in a storage tank, it provides
greater energy efciency than a conventional system.
With your new system, as soon as you turn on a hot water faucet, the demand for hot water is
detected, and high power heating elements are activated.
It is important to remember that all tankless water heaters are subject to a maximum ow rate. If this
ow rate is exceeded, the heater will not be capable of fully heating water.
Also keep in mind that conventional tank heaters are set to high temperatures to prevent running
out of hot water quickly, and thus a large amount of cold water needs to be mixed in to reach a
comfortable level for washing and showering. Since this unit heats water on demand, it is designed
to heat to a lower temperature. This means you only need to mix in a small amount of cold water,
or none at all.
Your hot water supply may also be affected by the incoming water temperature. During winter, if
incoming water temperature is very cold, you might not be able to run multiple hot water outlets at
the same time. However, you can run showers back-to-back without having to wait for water to heat.

12
Care and Maintenance
Periodic inspections and tests are recommended for the unit once every 6-12 months, depending
on the hardness in your water.
Remember that water heated to higher temperatures produces scale buildup much faster than at
lower temperatures.
Check and clean the lter every 6 months, or more often, depending on the hardness of your water.
Check and replace the washers if cracked or worn.
Electrical connections should be tested once a year by a qualied technician.
Plumbing connections on the water heater should be inspected at least once a year for any signs of
damage or failure. If the water supply has a high level of mineralization (hard water), the water heater
should be inspected and descaled more frequently.
As a result of maintenance or a water stoppage, air may be introduced into the plumbing system.
Under such circumstances, follow the steps below to ensure the unit can safely resume operation.
Operation Guide
Freezing Temperatures
If the ambient temperature falls below 32°F (0°C), protect the heater from potential damage. Shut
off power to the unit by means of the dedicated circuit breaker on the main electrical panel. Open
a faucet slightly to cause water to ow continuously through the device at a very low rate, without
heating. Restore power to the unit when temperature conditions allow.
If the water inside the heater freezes, it can cause damage that is not covered by warranty. If you
suspect water has frozen within the unit, do not turn it on until you are certain the frozen water has
melted and there are no leaks in the unit. It is recommended to contact a qualied electrician or the
manufacturer for service in this situation.
Leak Detected
If you detect a water leak from the water heater: Turn off the water supply at the shutoff valve on
the unit’s incoming water supply line, shut off power to the heater, and contact your local authorized
distributor for service.

13
Care and Maintenance
01 02
Set the power selector
switch to the OFF position.
03 04
Perform the maintenance
or servicing tasks.
• Washer replacement
• Clean the lter
Open the water tap and allow water
to run through the unit for several
minutes to purge any air from the
heater and water lines.
This step must be performed before
turning on power to the heater.
Failure to perform this step may
cause permanent damage to the
heating elements.
Stopping and restarting the system due to servicing, water
stoppage, or other interruptions of operation
Shut off all power to the unit at the
circuit breaker on the main electrical
panel.
05
Reconnect power to the unit at the
circuit breaker on the main electrical
panel.

14
Before calling for service, check the troubleshooting list of common issues.
If you are unable to resolve a problem, contact customer service.
Problem Possible Cause Solution
Unit is not
heating water.
Incorrect plumbing installation. Make sure the incoming cold water pipe
is connected to the inlet on the right, and
the hot water pipe is connected to the
outlet on the left.
No hot water. Power outage or faulty wiring. Check the power supply. Check the circuit
breaker.
Make sure the unit has the correct
amperage.
If problem persists, contact a qualied
electrician or the manufacturer.
Water is not
hot enough.
The water ow rate exceeds the
heating capacity of the heater.
Temperature setting is too low.
Water pressure is too low.
Reduce the water ow rate by partially
closing the tap.
Switch to the higher temperature setting.
Have a professional check the water
pressure.
Water is too
hot.
The water ow rate through the
heater is too slow.
Temperature setting is too high.
Increase the water ow rate by opening
the tap.
Switch to the lower temperature setting.
Water runs
very hot, then
becomes
cold.
The water ow rate is too high. Reduce the water ow rate by partially
closing the tap.
Water stops
owing.
Blockage in water pipes or
hoses.
No water supply.
Filter is clogged.
Make sure the main water line valve is
fully open and there are no obstructions
in the water supply line.
Check and clean the lter.
Troubleshooting
If you have an issue and need further assistance,
please call: 1-888-783-6082

15

16
LIMITED WARRANTY
The terms of this warranty is solely subject to the original owner and is at no time transferable. A
transfer of ownership will result in an immediate termination of this warranty. This warranty is valid
only if product is purchased from an authorized reseller.
Atmor warrants to the original owner that our instant water heaters will be free from defect in
workmanship and material for a period of TWO YEARS from the date of purchase, and free from
leakage for a period of SEVEN YEARS from the date of purchase. Should any part(s) prove to be
defective during this period, Atmor will be responsible for replacement of the defective part(s) only.
Atmor is not responsible for labor charges or any incidental or consequential expenses. Atmor’s
liability is limited to the cost of the product or $1,000.00, whichever is less. Atmor is not an insurer
and the original owner should purchase insurance to cover damage to property or belongings. The
original owner agrees to waive their right to jury trial or to participate in a class action. In addition,
the original owner agrees to waive subordination to the extent a loss is covered by insurance, so
that their insurance company cannot proceed with action against Atmor for recovery of any claims.
Furthermore, all claims must be arbitrated in the state of New Jersey.
Should the owner wish to return the water heater for repair, the owner must rst secure a written
authorization from Atmor. The owner shall be required to show proof of purchase date and to pay
all transportation costs to return the defective part(s) or water heater for repair or replacement.
Warranty is void if: (a) water heater has been installed or used improperly; (b) design has been
altered in any way; (c) water heater has been installed and/or serviced by someone other than a
licensed electrician; or (d) or if the water heater
has been installed or used in contradiction to
installation instructions, applicable laws and/or
ordinances.
A full and complete version of this warranty is
available on the online, www.atmorusa.com, or
upon request from an Atmor representative.
P.N. 197423B
Distributed by:
PARAGON GROUP USA LLC
Englewood, NJ 07631
USA
Phone: [phone]
Email: [email protected]
Web: www.atmorusa.com

www.atmorusa.com
Agua caliente a petición
Guía de instalación y manejo
Disfrute
Calentador de agua eléctrico sin tanque
Sistema de ducha completo
6kW/240V
El calentador de agua instantáneo proporciona suministro ilimitado de agua caliente
al mismo tiempo que ahorra energía y agua de manera considerable
o

2
Página
Pautas de seguridad......................................................................................................................3
Información técnica .......................................................................................................................4
Tubería de agua ............................................................................................................................5
Montaje..........................................................................................................................................6
Procedimiento de instalación..................................................................................................... 7-8
Conexión de cables.......................................................................................................................9
Puesta en funcionamiento del sistema........................................................................................10
Guía de manejo......................................................................................................................11-12
Cuidado y mantenimiento............................................................................................................13
Solución de problemas................................................................................................................14
Índice

3
Pautas de seguridad importantes
GUARDE ESTAS INSTRUCCIONES
1. Pautas de seguridad
Lea detalladamente este manual antes de intentar instalar el calentador de agua instantáneo.
El hecho de no seguir las instrucciones de seguridad de este manual podría causar daño
a la unidad, y también podría resultar daño a la propiedad, lesiones personales o pérdida
de vidas.
El hecho de no seguir las instrucciones de seguridad, instalación o manejo anula la garantía
del producto.
El fabricante del producto y el distribuidor del producto no serán responsables de ningún
daño o lesión debido al hecho de no seguir las instrucciones de instalación y manejo
especicadas en este manual o debido a un uso inapropiado.
Nunca intente instalar, desensamblar, inspeccionar o reparar, desensamblar o suministrar servicio
de mantenimiento al calentador de agua sin primero apagar toda la energía eléctrica hacia la
unidad por medio del interruptor automático en el panel eléctrico principal.
El calentador de agua debe ser instalado por un electricista con licencia y de acuerdo con todos los
reglamentos de electricidad y construcción nacionales, estatales, provinciales y locales.
Siempre comuníquese con su distribuidor autorizado local para obtener servicio.
2. Seguridad – Notas importantes .
•Para la conexión del suministro de energía eléctrica, utilice alambres de 10 AWG o de mayor
calibre apropiados para 90°C (194°F) como mínimo.
•El calentador debe ser instalado por un técnico profesional y de acuerdo con las instrucciones
de instalación.
•El calentador se debe conectar a tierra.
•El calentador se debe conectar a un interruptor automático dedicado en el panel eléctrico
principal.
•La instalación de la tubería de agua se debe realizar antes de la instalación eléctrica.
•La instalación de la tubería de agua requiere tubos metálicos o mangueras reforzadas que
puedan soportar presión de hasta 101 psi (7 bars).
•Para garantizar un funcionamiento apropiado, el caudal de suministro de agua debe estar a
4.35 psi (0.3 bars) como mínimo.
•No instale el calentador donde este pudiera exponerse a la luz directa del sol, lluvia, salpicaduras
de agua o temperaturas de congelación.
•Esta unidad está diseñada para calentar agua únicamente. No intente utilizar la unidad para
calentar cualquier otro tipo de líquido.
Antes de conectar el producto a una red pública de energía eléctrica, consulte a su autoridad local
de suministro de energía eléctrica para asegurarse que la red eléctrica cumple con los requisitos
indicados.

4
Información técnica
Especicaciones eléctricas
Disfrute
6 kW
Elementos de calentamiento 1
Watts 6.000
Kilowatts 6 kW
Voltaje 240 V
Amperaje del interruptor automático 1 x 30 A
Tamaño de cable (mínimo) 3 x 10 AWG
Especicaciones de la tubería de agua
Flujo de agua mínimo para activar
la unidad 0.47 gpm
Presión de trabajo 4.35 psi - 101 psi
Presión probada 203 psi
Conexiones de agua 1/2" NPT
Dimensiones físicas
Altura Ancho Profundidad Peso
15 pulg. (381 mm) 8½ pulg. (215 mm) 2¼ pulg. (55 mm) 4 lb 3 oz (1.8 kg)
Piezas y accesorios
o
Cabezal de ducha - Flujo de aire
A. Luz indicadora
B. Selector de nivel de
calentamiento: 0/Bajo/
Alto (0/Low/High)
C. Salida de agua caliente
D. Entrada de agua fría
E. Manguera reforzada
resistente a la presión
F. Manguera y manija
del cabezal de ducha
(regadera)
G. Grifo para suministro
de agua al calentador
