ATN PVS7-3 User manual

ATN PVS7 avalable with numerous image intensifier configurations ranging from High- Resolution Gen 2 to
state-of-the-art thin-film Full Mil Spec Gen3 . The ATN PVS7 is full robust, dependable, high performance
night vision goggle. This model is identical to AN/PVS7 model adopted as a standard issue to US Army
ground troops, designed to assist viewing and provide reliable service in the most unfavorable conditions.
Full U.S.Mil Spec body with goggle assembly, soft carrying case, demist shield, sacrificial filter for objective
lenses, shoulder strap, head-mount assembly with 3 brow pads, lens tissue, neck cord and front lens cap.
ATN pvs7
ATN pvs7
OPTICAL
Field of View (Deg): 40.0
Min. Focus Range: 20cm
Objective:
Focal Length: 26mm
F-Number: 1.17
T-Number: 1.3
Eyepiece:
Diopter Adjustment: +2 to - 6
Eye Relief: 15mm
Interpupillary Adjustment 55 mm to 71 mm
MECHANICAL
(Standard goggle without Afocal)
Weight: (Goggle w/Mask Assy): 650 grams
Dimensions (cm): 14.08 long X 15.56 Wide
ELECTRICAL
Power Source: 2 - AA Batteries (Alkaline) or
1 - BA-5567/U (Lithium)
ENVIRONMENTAL
Operating Temperature: - 51 C to + 45 Deg. C
Storage Temperature: - 51 C to + 85 Deg. C
Humidity: 90% up to +65 C for 240 hours
Immersion: 1 meter for 30 minutes
Adjustable head mount
IR illuminator
Momentary IR-on switch
Automatic high-light cutoff
Flexible carrying case
Operates on two AA alkaline batteries
Two-year factory warranty
American Technologies Network Corp.
20 S. Linden Ave. Unit 1B South San Francisco, CA 94080
800-910-2862, 650-875-0130, FAX [phone]
www.atncorp.com
E-mail: [email protected], [email protected]
