Operating Manual
USER'S INSTRUCTIONS
Vandal-proof Dome
High Resolution
DNR Day/Night
Color Camera
Rev.1

- 2 -
사 용 설 명 서
2
In USA and Canada, Use Class 2 Power Supply Only
USER'S MANUAL

- 3 -
사 용 설 명 서
3
IMPORTANT SAFETY INSTRUCTIONS
1) Read the .snoitcurtsnies
2) Keep these instruct .snoi
3) Heed .sgninrawlla
4) Follow all instructions.
5) Do not use this apparatus nea .retawr
6) Clean only with dry c .htol
7)
Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including
amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet. Consult an electrician for replacement of the obsolute outlet.
-
13 U)nplug this apparatus during lightning storms or when unused for long periods of time.
14 otgnicivresllarefeR) qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been moisture, does not operate normally, or has been dropped.
10)Protect the power cord from being walked on or pinched particularly at plugs, conveniance
repeptacles, and the point where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
11)
12)
USER'S MANUAL

- 4 -
사 용 설 명 서USER'S MANUAL
Contents
Camera Features
Installing & Adjusting
Dimension & Specification
OSD Control Button
On Screen Dispaly (OSD) Menu
Menu Set Up
Lens
Exposure
White Bal
Day&Night
3DNR
Special
Adjust
Reset
Exit
Trouble Shooting
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5
6
7
8
9
10
11
12
15
17
18
19
24
24
24
25

- 5 -
사 용 설 명 서
Camera Features
●
700TV Lines
The combination of a 960H CCD image sensor and New DSP provides an excellent resolution
of 700TV Lines.
●
3D-DNR
Smart 3DNR prevents the image blurring of moving object and activates only if moving objects
are appearing on the scene.
●
DIS(Digital Image Stabilizer) Function
Stabilizes the picture and increases clarity when small amounts of motion due to wind or
climate change may cause the picture to appear out of focus.
●
Smart-IR
The "New DSP" provides a vivid image in darkness due to the control of the IR illumination
sensitivity. The image is never saturated because of close objects.
●
Sens-Up
Despite a limited & low light condition, Sens-Up - Max. x256 helps the viewer to get visible
and clear images.
●
Defog
The "Defog" function improves image clarity in poor conditions such as fog, smoke, rain or
snow.
●
OSD Menu
The On-Screen-Display Menu provides easy control and setting of all functions available in the
set-up of the camera.
USER'S MANUAL

- 6 -
사 용 설 명 서
6
Þ\GGGG[GOPt[GtGGG[GOP
Installing & Components
- Afx the mounting template to the mounting surface.
- Using the L-wrench provied, remove 4 screws and separate the dome cover.
- Drill holes in the celling by matching the holes in the case bed. Fix the case bed on the ceilling by
using tapping screws.
- Pass the power and video cable through the access hole and connect to the camera before mounting
the camera to the base.
- Position and focus the camera to a desired direction and assemble the dome cover to the mounting
base with machine screws using the L wrench provided.
● CAMERA 1piece ● Instruction Manual 1piece ● Mounting Template 1piece
● Service Monitor Cable 1pieces ● Tapping Screw 4pieces ● L-wrench 1piece
1. Installation
2. Components
USER'S MANUAL

- 7 -
사 용 설 명 서
Dimension Connection
Sensor type
Effective pixels
Total pixels
Resolution
Scanning system
Min. illumination
Video Output
S/N Ratio
AGC
Sens-UP
Backlight Compensation
D-WDR
Motion Detection
Privacy Masking
DIS(Digital Image Stabilizer)
Day & Night
White Balance
3DNR(2D or 3D)
Mirror
D-ZOOM
SMART DZOOM
DEFOG
Power Supply
Power Consumption
Lens
Storage Temperature
Operating Temperature
Dimension(W x H x D)
Weight
1/3" Sony 960H CCD
976 (H) X 494 (V) approx. 480K pixels (NTSC)
976 (H) X 582 (V) approx. 570K pixels (PAL)
1020 (H) X 508 (V) approx. 520K pixels (NTSC)
1020 (H) X 596 (V) approx. 610K pixels (PAL)
700TV Lines
2:1 Interlace
0Lux(IR LED ON)
1.0Vp-p Composite. 75 Ohms
52dB
Low / Middle / High
OFF/AUTO (X2 ~ X256)
OFF/BLC/HLC
OFF/INDOOR/OUTDOOR
4 Zone
8 Zone
OFF/ON
Auto(AGC)/Day/Night/Ext
ATW/AWB/AWC->SET/Manual(1,800K ~ 11,000K)
1 ~ 200 Level Selectable
H-Rev / V-Rev / ROTATE/PIP
X32
OFF/ON
OFF/MANUAL/AUTO
DC 12V/AC 24V Dual Voltage
Dome : DC12V 220mA, HEATER ON : 400mA / AC24V 105mA, HEATER ON : 170mA
IR LED Dome : IR LED ON : DC12V 650mA, HEATER ON : 860mA / AC24V 270mA, HEATER ON : 650mA
DC Auto Iris Varifocal Lens(2.8mm-12mm)
IR Distance Max 30M(IR LED 33pieces)
-35º ~ +60º Deg C. RH95% MAX.
-20º ~ +60º Deg C. RH95% MAX.
146mm(W) * 105mm(H) * 146mm(D)
1500g
Dimension & Specication
1. Dimension & Connection
2. Specication
USER'S MANUAL

- 8 -
사 용 설 명 서
8
TEMP.
SENSOR
HEATE R
HEATER
SETUP
VIDEO
IR LED
VOLUME
UP
FRONT
DOWN
LEFT
OSD Control Button
▲ Up switch : Moves the cursor upwards. Use this button to select an item or adjust the parameters.
▼ Down switch : Moves the cursor downwards. Use this button to select an item or adjust the
parameters.
◀ Left switch : Moves the cursor to the left. Use this button to select or adjust the parameters of the
selected item. The parameter changes each time this button is pressed.
▶ Right switch : Moves the cursor to the right. Use this button to select or adjust the parameters of
the selectd item. The parameter changes each time this button is pressed.
◎ Set switch (Push) : Executes selections and displays a submenu for an item with the mark.
1. The OSD Button is a mini-joy stick control switch used to navigate the OSD Menu.
USER'S MANUAL

- 9 -
사 용 설 명 서
On Screen Display (OSD) Menu
SETUP Menu
On Screen Display (OSD) Menu
Camera functions and settings can be adjusted or changed by activating the OSD menu.
When the OSD menu is activated text will display on the monitor. The user can then move the cursor to
the desired function to change the setting.
LENS
EXPOSURE
WHITE BALANCE
DAY/NIGHT
3DNR
SPECIAL
ADJUST
RESET
EXIT
● DC
● SHUTTER
● BLC
● ATW
● MANUAL
● COLOR
● EXT
● OFF
● CAM TITLE
● PRIVACY
● RETURN
● SHARPNESS
● FACTORY
● MANUAL
● AGC
● D-WDR
● AWB
● B/W
● ON
● D-EFFECT
● DEFECT
● MONITOR
● RETURN
● SENS-UP
● RETURN
● AWC-->SET
● AUTO
● MOTION
● DEFOG
USER'S MANUAL

- 10 -
사 용 설 명 서
USER'S MANUAL
Menu setting can be selected by the OSD Control switch inside the camera.
1. Press the set switch.
* The Set Up menu will be displayed on the monitor.
2. Move and select the required function using the Up and Down switch.
* Move the triangular indicator Up or Down to select the desired feature by moving
the switch Up or Down.
Menu Set Up
SETUP
SETUP
LENS
EXPOSURE
WHITE BAL
DAY&NIGHT
3DNR
SPECIAL
ADJUST
RESET
EXIT
LENS
EXPOSURE
WHITE BAL
DAY&NIGHT
3DNR
SPECIAL
ADJUST
RESET
EXIT
DCAUTO
ATW
COLOR
ON
DCAUTO
ATW
COLOR
ON

- 11 -
사 용 설 명 서
USER'S MANUAL
3. Change menu settings using the Left or Right switch.
* Available values or Status are displayed by moving the switch Left or Right.
Continue to press the switch until desired value / status is displayed.
4. After Changing the setting move the arrow indicator to EXIT and press SET to EXIT.
This function is to adjust the brightness of the scene.
1. Move the triangular indicator to LENS on the Set Up menu screen.
2. Select the desired lens type by moving the switch Left or Right.
NOTE
* Move to the available submenu by moving arrow to desired feature.
* Submenu is not available when this symbol is displayed “---“.
Lens
SETUP
LENS
EXPOSURE
WHITE BAL
DAY&NIGHT
3DNR
SPECIAL
ADJUST
RESET
EXIT
DCAUTO
ATW
COLOR
ON

- 12 -
사 용 설 명 서
USER'S MANUAL
1. In the Set Up menu, Select EXPOSURE.
Exposure
NOTE
* When DC is selected, the brightness control range is 1~100.
* When you select the mode setup, you can select INDOOR or OUTDOOR depending on the
installation environment.
DC LENS
BRIGHTNESS
MODE
RETURN
50
INDOOR
RET
IIIIIIIIII IIIIIIIIII|
SETUP
LENS
EXPOSURE
WHITE BAL
DAY&NIGHT
3DNR
SPECIAL
ADJUST
RESET
EXIT
DC
ATW
COLOR
ON
2. Select the desired shutter mode by moving the switch Left or Right.
EXPOSURE
SHUTTER
AGC
SENSE-UP
BLC
D-WDR
RETURN
AUTO
MID
AUTO
OFF
OFF
RET

- 13 -
사 용 설 명 서
USER'S MANUAL
◆ Electronic Shutter : DC lens default is 1/60 and the manual lens default is "Auto Shutter", but the
shutter speed can be adjusted from 1/60 to 1/100,000.
→DIS (Digital Image Stabilizer) : Select the DIS mode when the image appears to have slight movement
due to weather or nearby vibrations. Sense Up mode is disabled when DIS mode is active.
◆ AGC (Auto Gain Control) : The higher the AGC level is, the more noises is introduced into the picture.
→Off : Deactivated.
→ Low : 28dB Gain is applied.
→ Mid : 32dB Gain is applied.
→ High : 36dB Gain is applied.
◆ Sense-Up : A usable image can be displayed in low light conditions when set to "Auto".
→ Off : Deactivated status.
→ Auto : Sense-Up auto mode status, The degree of brightness is decided by the Sense Up setting value
in the low light condition.
NOTE
* Sense-Up mode is disabled when Electronic shutter is selected as Manual or DIS.
SENSE-UP
SENSE-UP
RETURN
x32
RET
NOTE
* Sense Up mode is disabled when AGC mode is set to "Off".

- 14 -
사 용 설 명 서USER'S MANUAL
→ HSBLC (Highlight Suppression Back Light Compensation) : Small areas of very bright lights can be
suppressed so that information in the darker areas of the image can be identified, i.e. car headlights.
Nomarl
BLC
HSBLC
VALUE
AREA
DEFAULT
RETURN
GAIN
MODE
DEFAULT
RETURN
MIDDLE
RET
8
ALL DAY
RET
◆ BLC (Back Light Compensation) : The camera with 3D-DNR provides the intelligent light level control to
overcome strong backlight conditions.
→ Off : Deactivated status.
→ BLC : Select the area of interest and then set the value of the desired amount of compensation.
IIIIIIIIII IIIIIIIIII|
HSBLC

- 15 -
사 용 설 명 서USER'S MANUAL
◆ D-WDR : This camera which is using 3D-DNR DSP provides intelligent light level control in a Wide
Dynamic Range to overcome even strong backlight conditions.
→ Off : Deactivated status.
→ Indoor compensation : Used when the camera is installed indoors.
→ Outdoor compensation : Used when the camera is installed outdoors.
◆ Return : Every function is set up at the EXPOSURE menu, and then return to the previous menu.
WDR OFF WDR ON
White Balance
SETUP
LENS
EXPOSURE
WHITE BAL
DAY&NIGHT
3DNR
SPECIAL
ADJUST
RESET
EXIT
DC
ATW
COLOR
ON
The White Balance options may be set for best color rendition. ATW is the recommended setting.
1. Move the cursor to WHITE BAL on the SETUP menu screen.
2. Select the desired mode by moving the joystick left or right.

- 16 -
사 용 설 명 서USER'S MANUAL
Three white balance modes are available to choose from plus manual.
◆ ATW : Use this mode when the color temperature is from 1,800K to 10,500K.
◆ AWB : This mode is for interior white balance to match ambient lighting. This mode can be used when
the color temperature is from 3,000K to 7,000K.
◆ AWC→SET(Use for well controlled lighting conditions) : After letting camera focus on a blank white
paper to current lighting environment, press the SET button. If the lighting condition changes,
Re-adjustment will be needed.
◆ MANUAL : Manual compensation makes more detailed control possible. First, after setting the
white balance using the ATW or AWB mode, change the mode to manual mode and then press Set
button. While looking at the screen make the necessary adjustments to the Blue and Red values. Select
return when finished.
MANUAL WB
BLUE
RED
RETURN
31
20
RET
IIIIIIIIII IIIIIIIIII|
IIIIIIII IIIIIIIIIIII|
NOTE
The White Balance may not work properly in the following conditions.
* When there is a very high color temperature in the scene.
( for example, clear sky, Sunset)
*▶It is very dark.
*▶If fluorescent light is directly in the scene or if there is a drastic lighting change, The
operation of White balance may become unstable.

- 17 -
사 용 설 명 서
USER'S MANUAL
◆ COLOR : Making the video output color always.
◆ B / W : Making the video output B/W always. (The color burst will also be disabled.)
◆ Auto : Automatically, selects color mode in the bright environment and the B/W mode in low light
conditions. Adjust the delay time, starting brightness and end brightness according to the
ambient conditions by pressing the Set button.
Day&Night
SETUP
LENS
EXPOSURE
WHITE BAL
DAY&NIGHT
3DNR
SPECIAL
ADJUST
RESET
EXIT
DC
ATW
COLOR
ON
1. Select Day&Night on the Set Up menu screen.
2. Select the desired mode by moving the joystick left or right.
DAY&NIGHT B/W
DAY&NIGHT AUTO
BURST
IR SMART
RETURN
DELAY
D → N(AGC)
N → D(AGC)
RETURN
OFF
ON
RET
5
60
20
RET
IIIIIIIIII IIIIIIIIII|
IIIIIIII IIIIIIIIIIII|
IIII IIIIIIIIIIIIIIII|

- 18 -
사 용 설 명 서USER'S MANUAL
◆ EXT : This external contact to ground will change the mode from color to B/W.
3DNR
SETUP
LENS
EXPOSURE
WHITE BAL
DAY&NIGHT
3DNR
SPECIAL
ADJUST
RESET
EXIT
DC
ATW
COLOR
ON
Using the 3D DNR feature of the DSP chip set will reduce the background video noise in low light
conditions.
1. Move the cursor to 3DNR.
2. Select the mode by moving the joystick left or right.
3. Off : Deactivated status.
On : Adjust the 3D DNR level for best reduction of noise in a low light scene.
3DNR
LEVEL
RETURN
200
RET
IIIIIIIIII IIIIIIIIII|
NOTE
* If 3DNR function is used, the cancellation effect of noise is excellent. The higher the
compensation, the better the effect of noise cancellation is, but the ghost effect may occur.

- 19 -
사 용 설 명 서USER'S MANUAL
Special
SETUP
LENS
EXPOSURE
WHITE BAL
DAY&NIGHT
3DNR
SPECIAL
ADJUST
RESET
EXIT
DC
ATW
COLOR
ON
The Special section of the Setup Menu contains seven different functions.
1.When the SETUP menu is displayed, select SPECIAL.
2. Select one of the functions by moving the cursor up or down.
SPECIAL
CAM TITLE
CAM TITLE
D-EFFECT
MOTION
PRIVACY
SYNC
DEFECT
DEFOG
RETURN
0 1 2 3 4 5 6 7 8 9
A B C D E F G H I J K
L M N O P Q R S T U V
W X Y Z ▶ → ← ↑↓ ( )
α - _ ■ / = & : , .
← → CLR POS END
CAMERA 001
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _
OFF
OFF
OFF
L/L
OFF
RET
◆ CAM (Camera) TITLE : Up to 15 alpha numeric characters can be selected for on-screen title display.
Use the cursor to select and position the characters, when finished select "END".

- 20 -
사 용 설 명 서USER'S MANUAL
NOTE
* To erase a letter, move the cursor on the empty space in front of the number 0, and then
letters will be erased by pressing the Set button one by one. Move the cursor on the
“CLR”, press the Set button and all the letters will be erased.
◆ D-EFFECT : The camera is always given the video image effect by this function.
→ FREEZE : The image of the monitor is paused temporarily by this function.
→ MIRROR : The image of the monitor is reversed vertically or horizontally.
→ D-Zoom : Digital zoom with x1 ~ x32 magnification.
The higher the digital zoom magnification, the lower the resolution.
D-EFFECT
D-ZOOM
FREEZE
MIRROR
D-ZOOM
SMART DZOOM
DIS
NEG.IMAGE
RETURN
RANGE
PAN
TILT
RETURN
OFF
OFF
- - -
OFF
- - -
OFF
RET
x2.0
0
0
RET
IIIIIIIIII IIIIIIIIII|
IIIIIIIIII IIIIIIIIII|
