ATV IPVD2TRWI User manual

2MP VP Dome
Network Camera:
IPVD2TRWI
Please read this manual thoroughly before use, and keep it handy for future reference.
INSTRUCTION MANUAL

2
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
PROCUCT TO RAIN OR MOISTURE. DO NOT INSERTANY METALLIC OBJECT
THROUGH THE VENTILATION GRILLS OR OTHER OPENNINGS ON THE
EQUIPMENT.
Apparatus shall not be exposed to dripping or splashing and that no objects filled
with liquids, such as vases, shall be placed on the apparatus.
CAUTION
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated "dangerous
voltage" within the product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.

3
FCC COMPLIANCE STATEMENT
INFORMATION TO THE USER:THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO
COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC
RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL
INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS
EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY ENERGY AND IF NOT
INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
CAUTION:CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY
RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER'S AUTHORITY TO OPERATE THE
EQUIPMENT.
THIS CLASS ADIGITALAPPARATUS COMPLIES WITH CANADIAN ICES-003.
CET APPAREIL NUMÉRIQUE DE LA CLASSE A EST CONFORME À LA NORME NMB-003 DU CANADA.
CE COMPLIANCE STATEMENT
WARNING: This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.

4
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused
for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
15. CAUTION – THESE SERVICING INSTRUCTIONS ARE FOR USE BY QUALIFIED
SERVICE PERSONNEL ONLY. TO REDUCE THE RISK OF ELECTRIC SHOCK DO
NOT PERFORM ANY SERVICING OTHER THAN THAT CONTAINED IN THE
OPERATING INSTRUCTIONS UNLESS YOU QRE QUALIFIED TO DO SO.
16. Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed Class 2
power source only.
17. ITE is to be connected only to PoE networks without routing to the outside plant.

5
Contents
1. Description ------------------------------------------------------------------6
1.1 Components - ------------------------------------------------------------------------------------------ 6
1.2 Key Features- ------------------------------------------------------------------------------------------ 7
2. Installation ------------------------------------------------------------------- 8
2.1 Overview----------------------------------------------------------------------------------------------------8
2.2 Connection------------------------------------------------------------------------------------------------14
2.3 Network Connection and IP Assignment ---------------------------------------------------------- 17
3. Operation -------------------------------------------------------------------- 18
3.1 Access from a browser -------------------------------------------------------------------------------- 18
3.2 Access from the internet------------------------------------------------------------------------------ 19
3.3 Setting the admin password over a secure connection------------------------------------------- 19
3.4 Live View Page ----------------------------------------------------------------------------------------- 19
3.5 Network Camera Setup-------------------------------------------------------------------------------- 22
3.5.1 Basic Configuration ---------------------------------------------------------------------------- 22
1) Users------------------------------------------------------------------------------------------ 23
2) Network -------------------------------------------------------------------------------------- 23
3) Video & Image ------------------------------------------------------------------------------ 22
4) Audio-------------------------------------------------------------------------------------------27
5) Date & Time --------------------------------------------------------------------------------- 29
3.5.2 Video & Image---------------------------------------------------------------------------------- 30
3.5.3 Audio---------------------------------------------------------------------------------------------- 36
3.5.4 Event--------------------------------------------------------------------------------------------- 37
1) Event-In-------------------------------------------------------------------------------------- 37
2) Event-Out ----------------------------------------------------------------------------------- 42
3) Event Map----------------------------------------------------------------------------------- 50
3.5.5 System ------------------------------------------------------------------------------------------ 51
1) Information ---------------------------------------------------------------------------------- 51
2) Security--------------------------------------------------------------------------------------- 52
3) Date & Time --------------------------------------------------------------------------------- 55
4) Network -------------------------------------------------------------------------------------- 56
5) Language------------------------------------------------------------------------------------- 65
6) Maintenance --------------------------------------------------------------------------------- 66
7) Support--------------------------------------------------------------------------------------- 67
3.5.7 About---------------------------------------------------------------------------------------------- 67
3.6 Playback------------------------------------------------------------------------------------------------- 68
3.7 Help---- -------------------------------------------------------------------------------------------------- 70
3.8 Resetting to the factory default settings------------------------------------------------------------- 71
4. Appendix -------------------------------------------------------------------- 72
4.1 Troubleshooting ----------------------------------------------------------------------------------------- 72
4.2 Alarm Connection --------------------------------------------------------------------------------------- 73
4.3 Preventive Maintenance -------------------------------------------------------------------------------- 73
4.4 Product Specification ----------------------------------------------------------------------------------- 74

6
1. Description
This manual applies to the IPVD2TRWI network camera.
The Network Camera supports the network service for a sensor image with progressive scan, which
can be monitored on a real-time screen regardless of distances and locations. By using its dedicated
program, many users are able to have an access to the Network Camera at once or a single user can
monitor various network cameras at the same time. It also enables users to play, store and retrieve a
monitoring image by using a PC. All the settings and real-time monitoring screens are also provided
through an access to the web.
The Network Camera is fully featured for security surveillance and remote monitoring needs. It is
based on the DSP compression chip, and makes it available on the network as real-time, full frame
rate Motion JPEG and H.264 (or MPEG-4) video streams.
The alarm input and alarm output can be used to connect various third party devices, such as, door
sensors and alarm bells.
1.1 Components
The system comes with the following components:
Check your package to make sure that you received the complete system, including all components
shown above.

7
1.2 Key Features
• Brilliant video quality
The Network Camera offers the highly efficient H.264 video compression, which drastically reduces bandwidth
and storage requirements without compromising image quality. Motion JPEG is also supported for increased
flexibility.
• Wide Dynamic Range
The network camera provides WDR (Wide Dynamic Range) that improves video exposure quality in scenes with
high contrast between bright and dark areas in the video, for example a shady area and a sunny area in the same
scene.
• Dual or triple streams
The Network Camera can deliver dual or triple video streams simultaneously at full frame rate in all resolutions up
to Full HD using Motion JPEG and H.264 (or MPEG-4). This means that several video streams can be configured
with different compression formats, resolutions and frame rates for different needs.
• Image setting adjustment
The Network Camera also enables users to adjust image settings such as contrast, brightness and saturation to
improve images before encoding takes place.
• Intelligent video capabilities
The Network Camera includes intelligent capabilities such as enhanced video motion detection. The network
camera’s external inputs and outputs can be connected to devices such as sensors and relays, enabling the
system to react to alarms and activate lights or open/close doors.
• Easy Focus
Easy Focus will be activated once Day/Night mode switched, and the focus readjusted automatically.
• Focus & Zoom Control via Network
The Network Camera also enables users to adjust focus and zoom remotely via network.
• Resolution
2 Megapixel, 30fps@1920x1080
• Micro-SD Recording support
The Network Camera also supports a micro-SD memory slot for local recording with removable storage.
• Improved Security
The Network Camera logs all user access, and lists currently connected users. Also, its full frame rate video can
be provided over HTTPS.
• Power over Ethernet
Support for Power over Ethernet (IEEE802.3af) enables the unit, as well as the camera module that is connected
to it, to receive power through the same cable as for data transmission. This makes for easy installation since no
power outlet is needed.
• ONVIF
This is a global interface standard that makes it easier for end users, integrators, consultants, and manufacturers
to take advantage of the possibilities offered by network video technology. ONVIF enables interoperability
between different vendor products, increased flexibility, reduced cost, and future-proof systems.

8
2. Installation
For the operation of the Network Camera, it is necessary to connect a network cable for data
transmission, power connection from supplied power adapter. Depending on operation methods, it is
possible to connect an alarm cable additionally. For its fixation on different locations, please consult
with an installer.
2.1 Over View
Parts and Description

9
Camera Dimension
See the diagrams below for the exact dimension of the IPVD2TRWI vandal proof dome network
cameras.
Dimensions Unit: mm
Adjusting the 3-Axis Gimbal
The Gimbal mechanism yields maximum rotation and placement as shown below.
• Z-Axis: Rotation 355°
• Y-Axis: Tilting 70°
• X-Axis: Panning 355°

10
Base Installation
1. Make mounting holes and cable hole in the place (ceiling) to which this dome camera is installed
using the supplied template sheet.
Warning: The total mass of the main unit is approx 1.3kg. Check whether the ceiling to which
the Dome Camera is installed is strong enough to hold the unit mass. If not, the Dome Camera
could fall, causing injury.
2. Attach the safety wire for securing the dome camera to ceiling or structure not to fall.
3. Extract each wire through the cable hole, connect BNC cable and communication lines.
4. Unlock torx screws (4x) the dome cover and fix the dome case firmly with supplied mounting
screws (4x), plastic anchors (4x), O-Rings (4x).
5. Adjust desired focus and scene by turning and moving the hemisphere by hand.
6. Lock the housing cover with torx screws (4x).

11

12
2.2 Connection
Connection Description
NO Connector Name Description
1 Micro-SD Slot Micro-SD memory slot
2 Service Monitor Port Service Monitor & OSD Controller Communication Port, Stereo Jack
3 Audio In & Out Port Audio Input and Output, Stereo Jack.
4 Alarm In & Out Port Alarm Input and Output, 3pin terminal.
Pin1: Alarm In, Pin2: GND, Pin3: Alarm Out
5 Main Power Main Power, 2 pin terminal,
Pin 1: 12 VDC/24 VAC, Pin2: GND/24 VAC
6 RJ-45 Port Ethernet, RJ-45 port compatible with 10/100Mbps having PoE
functionality.
Micro SD memory slot on the Board
Card Slot for Micro SD memory: Socket “J15”
• Connecting to the RJ-45
Connect a standard RJ-45 cable to the network port of the network camera. Generally a
cross-over cable is used for directly connection to PC, while a direct cable is used for connection
to a hub.
You can also use a router featuring PoE (Power over Ethernet) to supply power to the camera.
• Connecting Alarms
AI(Alarm In) :
You can use external devices to signal the network camera to react on events. Mechanical or
electrical switches can be wired to the AI (Alarm In) and G (Ground) connectors.
G(Ground) :
Connect the ground side of the alarm input and/or alarm output to the G (Ground) connector.
Alarm Out :
The network camera can activate external devices such as buzzers or lights. Connect the device
to the AO (Alarm Out) and G (Ground) connectors.

13
• Connecting the Power
Connect the power of 12 VDC or 24 VAC for the network camera. Connect the positive (+) pole to
the ‘+’ position and the negative (-) pole to the ‘-’ position for the DC power.
Be careful not to reverse the polarity when connecting the power cable.
A router featuring PoE (Power over Ethernet) can also be used to supply power to the
camera.
The heater will operate properly only by the power source of AC 24V.
For the power specifications, refer to the Appendix, Product Specification.
If PoE and 12 VDC are both applied, the camera will be supplied with power from PoE.
• Connecting Service Monitor Port
Service monitor output port (J7) is located on the board of the dome camera, and is used for an
easy OSD setup.
▶ID & IP assignment
To make changes in the OSD menu, please use the OSD controller provided optionally with your
camera purchase. You can set Camera Title and IP Address.
1. Connect the OSD Controller to the Service Monitor port of the network camera.
2. Connect Service Monitor and the Video Output port of the OSD Controller.
3. Press the SET button to access main Menu.
4. Change Camera ID, and IP Address. You can change the Name or Title and IP address of the
camera. Using the ↑↓←→ buttons on the controller, you can change the parameters.
5. Select SAVE or CANCEL to exit the Main Menu.
Video Output is also used for an easy zoom and focus control when installing lens. Video Output
is restricted to 704x480(576) resolution.
Note: You can get the Optional OSD Controller from your installer.
▶Zoom & Focus Control

14
The camera enters Zoom and Focus control mode as soon as connecting OSD Controller to the
Service Monitor port.
-.ZoomControl: ↑(Zoom In), ↓(Zoom Out)
-.FocusControl: ←(Focus Near), →(Focus Far)
-. Smart Focus: Press and hold the SET button for 2 or more seconds. The camera readjusts
focus automatically.
Note: You can get the Optional OSD Controller from your installer.
Heater Kit
This unit is equipped with a 24VAC heater.
• Heater has been placed in the above ‘A’ position
Power Supply 24VAC
Power Consumption 20Watt
Heater On at 41°F (5°C)
Heater Off at 59°F (15°C)
2.3 Network Connection and IP assignment

15
The Network Camera supports the operation through the network. When a camera is first connected
to the network it has no IP address. So, it is necessary to allocate an IP address to the device with the
“Smart Manager” utility on the CD. The factory default IP is “192.168.30.220”.
1. Connect the Network Camera / device to the network and power up.
2. Start SmartManager utility (Start>All Programs>SmartManager>SmartManager), the main
window will be displayed, after a short while any network devices connected to the network will
be displayed in the list.
3. Select the camera on the list and click right button of the mouse. You can see the pop-up menu
below.
4. Select Assign IP. You cam see a Assign IP window. Enter the required IP address.
Note: For more information, refer to the Smart Manger User’s
Manual
3. Operation

16
The Network Camera can be used with Windows operating system and browsers. The recommended
browsers are Internet Explorer, Safari, Firefox, Opera and Google Chrome with Windows.
Note: To view streaming video in Microsoft Internet Explorer, set your browser to allow ActiveX
controls.
3.1 Access from a browser
1. Start a browser (Internet Explorer).
2. Enter the IP address or host name of the Network Camera in the Location/Address field of your
browser.
3. You can see a starting page. Click Live View, Playback or Setup to enter web page.
4. The network camera’s Live View page appears in your browser.
3.2. Access from the internet

17
Access from the internet once connected, the Network Camera is accessible on your local network
(LAN). To access the network camera from the Internet you must configure your broadband router to
allow incoming data traffic to the network camera. To do this, enable the NAT-traversal feature, which
will attempt to automatically configure the router to allow access to the network camera. This is
enabled from Setup > System > Network > NAT.
For more information, please see “3.5.5 System>Network>NAT” of User’s Manual.
3.3 Setting the admin password over a secure connection
T
o
g
ain access to the product, the password for
t
he default administrator user must be set. This
is done in the “Admin Password” dialo
g
, which is
displayed when the network camera is accessed
f
or the setup at the first time. Enter your admin
name and password, set by the administrator.
Note: The default administrator username and
password is “admin”. If the password is lost, the
Network Camera must be reset to the factory
default settin
g
s. See “3.8 Resetting to the Factory
Default Settin
g
s” for more details.
To prevent network eavesdropping when setting the admin password, this can be done via an
encrypted HTTPS connection, which requires an HTTPS certificate (see note below).
To set the password via a standard HTTP connection, enter it directly in the first dialog shown below.
To set the password via an encrypted HTTPS connection, see “3.5.5 System > Security > HTTPS”.
Note: HTTPS (Hypertext Transfer Protocol over SSL) is a protocol used to encrypt the traffic between
web browsers and servers. The HTTPS certificate controls the encrypted exchange of information.
3.4 Live View Page
T
he live view pa
g
e comes in several
screen modes: 1920x1080, 1280x1024,
1280x720, 704x480(576), 640x480,
352x240(288), and 320x240. Users are
allowed to select the most suitable one
out of those modes. Please, ad
j
ust the
mode in accordance with your PC
specifications and monitoring purposes.
1) General controls

18
LiveViewPage Search&PlaybackPage SetupPage HelpPage
The video drop-down list allows you to select a customized or pre-programmed
video stream on the live view page. Stream profiles are configured under Setup > Basic
Configuration > Video & Image. For more information, please see “3.5.1 Basic Configuration >
Video & Image” of User’s Manual.
Theresolutiondrop-downlistallowsyoutoselectthemostsuitableone
out of video resolutions to be displayed on live view page.
Theprotocoldrop-downlistallowsyoutoselectwhichcombinationof
protocols and methods to use depends on your viewing requirements, and on the properties of
your network.
2) Control toolbar
The live viewer toolbar is available in the web browser page only. It displays the following
buttons:
The Stop button stops the video stream being played. Pressing the key again toggles the
start and stop. The Start button connects to the network camera or start playing a
videostream.
The Pause button pause the video stream being played.
The Snapshot button takes a snapshot of the current image. The location where the
image is saved can be specified.
The digital zoom activates a zoom-in or zoom-out function for video image on the live
screen.
The Full Screen button causes the video image to fill the entire screen area. No other
windows will be visible. Press the 'Esc' button on the computer keyboard to cancel full
screenview.
The Manual Trigger button activates a pop-up window to manually start or stop the even
The Smart Focus button readjusts focus automatically.
Use this scale to control the volume of the speakers.
Use this scale to control the volume of the microphone.
Use this scale to control the volume of the speakers and microphones.
3) Video Streams

19
The Network Camera provides several images and video stream formats. Your requirements and
the properties of your network will determine the type you use.
The Live View page in the Network Camera provides access to H.264, MPEG-4 and Motion JPEG
video streams, and to the list of available video streams. Other applications and clients can also
access these video streams/images directly, without going via the Live View page.
4) Focus and Zoom Control
You can control Zoom and Focus in the live screen. Press the button on the left top in the live
screen to activate the Zoom & Focus control panel.
•Adjusting Zoom:
Click “<” button to zoom out and click “>” button to zoom in. The focus is moved slightly after
adjusting zoom; adjust the focus again, as necessary.
•Adjusting Focus:
Click “>” button for far focus and click “<” button to near focus.
•Fine Focus:
Click “Fine Focus” to fine tune and readjust focus automatically.
Note: Click the button in the Live View screen to set the focus to the optimum position.
3.5 Network Camera Setup

20
This section describes how to configure the network camera, and is intended for product
Administrators, who have unrestricted access to all the Setup tools; and Operators, who have access
to the settings for Basic, Live View, Video & Image, Audio, Event, and System Configuration.
You can configure the network camera by clicking Setup in the top right-hand corner of the Live View
page. Click on this page to access the online help that explains the setup tools
When accessing the Network Camera for the first
time, the “Admin Password” dialog appears. Enter
your admin name and password, set by the
administrator.
Note: If the password is lost, the Network Camera
must be reset to the factory default settings. See “3.8
Resetting to the Factory Default Settings”.
3.5.1 Basic Configuration
You can see the device information in this information page.
1) Users
