Audiovox Silverline Duo Troubleshooting guide

for select Toyota/Lexus/Scion vehicles
Installation Guide/User manual
OMA-DUO-101-TOY-012012_rev012312.indd 1 1/23/2012 9:01:11 PM

2
Copyrights and Trademarks
Copyright 2012 Audiovox Electronics Corporation
The Audiovox and Audiovox Driven by DICE Electronics logos are trademarks of
Audiovox Electronics Corporation
iPod and iPhone are trademarks of Apple, Inc.
All Trademarks and Logos are the property of their respective owners.
All rights reserved.
Printed in the U.S.A.
OMA-DUO-101-TOY-012012_rev012312.indd 2 1/23/2012 9:01:11 PM

3
Warning and safety
Product registration
Silverline DUO kit contents
Identify your audio system
DIP switch overview
DIP switch settings
Supported iPod models
Note to Installer
Connection diagram
Installation
iPod content browsing
Charging .
iPod locked/unlocked settings and features
Basic operation
Operating the DUO in CDC/MD emulation
Operating the DUO in MP3 emulation
Text display elds in CDC/MD emulation
Operating the DUO iPod source
Operating the DUO in SAT emulation
Text display elds in SAT emulation
Controlling the DUO SIRIUS source
Internet Radio Application support
Data connection requirements
Controlling the Internet Radio App
Text display from the Internet Radio App
Auxiliary audio source
Optional Remote Kit: iPod/App
Optional Remote Kit: SIRIUS
Troubleshooting
Firmware update
Warranty
..........................................................4
.........................................................5
..............................................6
...............................................7
.........................................................8
..........................................................9
.................................................10
..............................................................11
.......................................................12
......................................................................13
...................................................14
.......................................................................14
..................15
..............................................................16
....................17
................................19
...........................20
........................................21
................................22
...................................24
..................................26
.....................................27
...........................................27
.....................................28
............................29
........................................................31
...........................................32
.............................................33
..................................................................34
................................................................37
.............................................................................38
Table of Contents
OMA-DUO-101-TOY-012012_rev012312.indd 3 1/23/2012 9:01:11 PM

4
Please read these instructions carefully before proceeding. Failure to follow instructions may result in
improper operation or injury. Neither Audiovox Electronics Corporation nor Apple Inc., its regional ofces,
distributors or resellers take any responsibility for any damage or injury as a result of using the integration kit.
- Do not open, disassemble or alter the interface in any way.
- Do not insert anything into the casing.
- Do not cut or try to alter cables in any way and always use the correct connections.
- Only operate unit when stationary or ask passengers to operate it for you.
- Do not allow the Apple iPod/iPhone to distract you from driving.
- Exercise good judgement and keep your eyes on the road at all times.
- Do not expose unit to extreme temperatures, humidity or shock.
- Keep the unit and iPod/iPhone away from uids.
- Keep away from children! - Interface components may contain small parts, can be broken or disassembled
and components may become loose from vibration and heat. Small components and packaging materials
may be a choking hazard when handled by children.
Warning and safety!
OMA-DUO-101-TOY-012012_rev012312.indd 4 1/23/2012 9:01:11 PM

5
Thank you for purchasing this integration kit. Please review this booklet before operating the unit. This
interface was designed and manufactured to seamlessly integrate with your vehicle’s factory audio system.
We recommend registering your Audiovox product so you can receive news about important rmware updates
and have unlimited access to our online support system.
To register your Audiovox product, please complete the following steps:
1. Visit http://www.audiovoxproducts.com
2. Look up and save the serial number of the product.
3. Complete the product registration form.
4. Submit the form.
5. Save the registration sheet in a safe place for future reference.
If you are unable to complete the registration via internet, please call Audiovox at 1-800-645-4994.
Congratulations on your purchase!
Product registration
Prior to installation make sure the module’s rmware is up to date to ensure compatibility
with the latest features and enhancements. Please refer to page 37 to update rmware.
OMA-DUO-101-TOY-012012_rev012312.indd 5 1/23/2012 9:01:11 PM

6
Silverline DUO kit contents
Optional accessories (sold separately):
Silverline DUO module
IR Receiver &
Remote controller
AUX connector
user manual Vehicle Interface
Harness
iPod docking
cable
for selected Toyota/Lexus/Scion vehicles
Installation Guide/User manual
Cradle
(A-DCR-50-PTH)
For more accessories, visit www.audiovoxproducts.com
OMA-DUO-101-TOY-012012_rev012312.indd 6 1/23/2012 9:01:12 PM

7
Identify your audio system
Select the emulation that best suits your vehicle. The following chart identies the recommended emulation
for the listed radios. Note that your vehicle may support more than one type of emulation.
* Not all radios support MD mode. If an external MD changer is present, it must be disconnected.
** Scrolling text function is available in Satellite emulation, please see page 26 for details.
Note: Years and feature sets listed are shown as a guideline only and do not guarantee compatibility or limit
applicability.
06-11
06-11
OMA-DUO-101-TOY-012012_rev012312.indd 7 1/23/2012 9:01:12 PM

8
DIP switches overview
The conguration switches located on the Silverline DUO module are used to set various operation modes of
the interface. Incorrect DIP switch settings may cause the interface to not work properly or to not operate at all.
Disconnect the vehicle harness from the module and set the ignition to the off position for 60 seconds
after changing the switches then reconnect the module!
Silverline DUO module
OMA-DUO-101-TOY-012012_rev012312.indd 8 1/23/2012 9:01:12 PM

9
The following DIP switch settings are used to congure the Silverline DUO module to interface
with the various vehicle radios. Before installation, set the DIP switch to the position shown for
the corresponding radios.
DIP switch settings
Car conguration switches
Use to retain factory SIRIUS/
XM module, or on radios with
integrated satellite tuner. Also
for radios that do not support
SAT mode. External CDC
(trunk or glove box) must be
disconnected.
CD changer (CDC)
OFF OFF
Mini DISC (MD)
Use with early model
year radios with external
MD changer support. MD
text is available only on a
selected few radios, typically
navigation models.
ON
OFF
Satellite (SAT)
Use this setting for best user
experience. Only available on
SAT capable radios. To enable
use of the SIRIUS Connect
tuner, SAT emulation must
be used. Available on selected
North American radios only.
ON ON
MP3
Use with late model radios
where factory Sirius/XM
module is present (integrated)
and CDC emulation is not
supported (i.e. no text).
OFF
ON
OMA-DUO-101-TOY-012012_rev012312.indd 9 1/23/2012 9:01:12 PM

10
Supported iPod models and rmware version requirements
Model Model
1G nano 160 GB classic
iPod 5G 5G nano
2G nano 3G touch
iPod classic iPhone 4
3G nano
4G touch
iPod touch
6G nano
iPhone
iPhone 3G
4G nano
120 GB classic
2G touch
iPhone 3GS
Firmware / OS Version Firmware / OS Version
1.3.1 2.0.4
1.3 1.0.2
1.1.3 iOS 5
1.1.2 iOS 5
1.1.3
iOS 5
iOS 3.1.3
1.2
iOS 3.1.3
iOS 4.2.1
1.0.4
2.0.1
iOS 4.2.1
iOS 5
iPhone 4S iOS 5
OMA-DUO-101-TOY-012012_rev012312.indd 10 1/23/2012 9:01:12 PM

11
Attention installer! Please read the following!
Audiovox strongly recommends that the unit be installed in an easily accessible place!
DO NOT PLACE IT BEHIND THE RADIO AND DO NOT HIDE UNDER CARPET!
Whether the unit is professionally or self installed, put the module where you, the end user can get to it easily
in the future. (Have the installer show you where the interface module is installed.)
Installing the module behind the radio will make it difcult to:
-Add possible future upgrades, changing software, adding new features, improving operation;
-Access the AUX input on the module to attach any audio device;
-Access the DIP switches located on the module;
-Remove the unit in case of failure.
MAKE SURE THAT THE MODULE IS IN AN ACCESSIBLE PLACE!
OMA-DUO-101-TOY-012012_rev012312.indd 11 1/23/2012 9:01:12 PM

12
Connection diagram
*Do not connect the iPod dock cable under any circumstance to the SIRIUS module
connector! Improper connection can cause permanent damage to iPod/SIRIUS module.
IR receiver
(optional)
Silverline DUO module
(front)
Silverline DUO module
(back)
Update port
(USB to PC) iPod dock cable*
iPod/iPhone
(not included)
Vehicle Inter-
face Cable
SIRIUS SAT radio
(not included)
Auxiliary device
(not included)
AUX connector
(optional)
SIRIUS connector*
OMA-DUO-101-TOY-012012_rev012312.indd 12 1/23/2012 9:01:12 PM

13
Installation
1. Verify compatibility 5. Route kit to glove box or other accessible location
6. Connect battery & test
7. Complete install by re-installing radio
2. Disconnect battery
3. Remove radio from car
4. Install Silverline DUO cable
Some radios will enter an anti-theft security mode and will lock requiring the radio’s security code
to be entered to unlock it. This code can be requested from the vehicle’s dealership.
OMA-DUO-101-TOY-012012_rev012312.indd 13 1/23/2012 9:01:12 PM

14
By default, the interface creates a Playlist having a name that is the same
as the name of the iPod. This Playlist is the very rst on the list of Playlists
shown while browsing in Playlist mode. This Playlist contains all the songs
on the iPod. Once a Playlist is selected an Artist may be selected within
that Playlist using the Artist Mode. Albums by the selected Artist within
the selected Playlist may be selected in Album Mode. “ALL ARTIST” and
“ALL ALBUM” designate all available content in those categories.
The interface automatically charges the battery of the iPod when
connected and your vehicle ignition key is in the ACC/ON position.
Charging may be shown by an
icon that appears on the upper
right corner of the iPod screen.
May vary by model.
Less browsable content
More browsable content
iPod content browsing
Charging
Playlist
Artist
Album
Song
OMA-DUO-101-TOY-012012_rev012312.indd 14 1/23/2012 9:01:13 PM

15
Radio control Limited
iPod control
For iPod touch and iPhone, when the screen is not active (as shown on the left), the
iPod/iPhone is locked (Press the power button to lock the iPhone/iPod Touch).
Before connecting the iPod to the module,
turn the hold switch ON to fully control and
browse the songs from the wireless remote.
The iPod is locked in this state.
Note: Setting the iPod’s hold switch must be done prior to connecting it to the dock cable.
iPod nano 6th generation will always be in locked mode since it does not have a lock switch.
Before connecting the iPod to the
module, turn the hold switch OFF to fully
control and browse the songs from iPod.
Browsing capabilities are limited from the
wireless remote.
iPod locked/unlocked settings and features
slide to unlock
OMA-DUO-101-TOY-012012_rev012312.indd 15 1/23/2012 9:01:13 PM

16
Basic operation
Accessing the DUO as the audio source:
Much like the radio’s AM/FM tuner, satellite radio or CD audio sources, the Silverline DUO is integrated to be
part of the vehicle’s audio system. To access the DUO source, press the SAT button (if SAT emulation is set)
or DISC button (if CDC, MD or MP3 emulation is set) on the radio. Pressing this button repeatedly will cycle
through sources present in the vehicle (CD > DUO).
DUO source selection:
The DUO adds additional audio sources including iPod, SIRIUS Satellite Radio* and/or auxiliary audio
input*. To cycle between these sources, use the SEEK, TRACK or TUNE buttons within the rst 5 seconds of
accessing the DUO as the audio source.
*These sources require additional parts/accessories/service from Audiovox and/or third parties.
Silverline DUO Interface settings (within rst 5 seconds of accessing the DUO as the audio source):
Select DISC/PRESET 1 to apply settings and resume audio playback.
Select DISC/PRESET 3 to change default volume level; use track up/down to adjust between Min and Max.
Select DISC/PRESET 4 to enable/disable scrolling text. (SAT emulation only)
Select DISC/PRESET 6 to view Silverline DUO serial number and rmware version.
DISC 2 and 5 have no settings available.
OMA-DUO-101-TOY-012012_rev012312.indd 16 1/23/2012 9:01:13 PM

17
Press the TEXT button
to cycle betwen display
elds
Press RND to Shufe
songs,
press and hold to shufe
albums
Press to change
DISC
Operating the DUO in CDC/MD emulation mode (non-NAV radio)
Press to change
track
Press RPT to repeat
one,
press and hold to
repeat all
Arrow shows if additional
text information is avail-
able. Hold TEXT button
for more information.
See pg.20
Press to RW or
FFW
Source selector
OMA-DUO-101-TOY-012012_rev012312.indd 17 1/23/2012 9:01:13 PM

18
Press DISC RPT to
repeat all
Press DISC RAND to
shufe albums
Press TITLE to
toggle between
screens A and B
Navigation radio screen A Navigation radio screen B
Press RPT to
repeat one
Press RAND
to shufe
songs
Press to
change track
Note that in MD mode MD1/2 will be displayed instead of CD1/2. Some display types vary and don’t have all available
buttons.
Operating the DUO in CDC/MD emulation mode (NAV radio)
OMA-DUO-101-TOY-012012_rev012312.indd 18 1/23/2012 9:01:13 PM

19
Press to change
track
Press to select
PRESET num-
bers 1-6
Press RPT to
repeat one,
press and hold
to repeat all
Press RAND to shufe
songs, press and hold to
shufe albums
Turn to change
track
Source
selector
Source
indicator
Operating the DUO in MP3 emulation mode
Some display types vary and don’t have all available buttons.
OMA-DUO-101-TOY-012012_rev012312.indd 19 1/23/2012 9:01:13 PM

20
Text display elds in CDC and MD emulation modes (non-NAV radio)
Press the TEXT button to cycle through the available text elds. In CDC and MD modes there are two
available text elds. Please see illustration below for an example of how the text button works in Playlist mode
(DISC 2):
Text is paged in these modes (where supported). Additional text information can be viewed by pressing
the and holding the TEXT button. A little arrow in the right bottom corner indicates additional page of text
information:
OMA-DUO-101-TOY-012012_rev012312.indd 20 1/23/2012 9:01:13 PM
