Installation Guide
MMD85
8.5" OVERHEAD LCD
VIDEO MONITOR
WITH DVD PLAYER
Installation Guide

2
Installation Guide
Licensed under one or more of the following patents,
Patent NOS. 5,775,762 and 5,927,784
Important Notice
AnLCDpaneland/orvideomonitormaybeinstalledinamotorvehicleandvisibletothe
driver if the LCD panel or video monitor is used for vehicle information, system control,
rear or side observation or navigation. If the LCD panel or video monitor is used for
televisionreception,videoorDVDplay,theLCDpanelorvideomonitormust be installed
sothat these features willonlyfunctionwhen the vehicleisin“park” or when thevehicle’s
parking brake is applied.
An LCD panel or video monitor used for television reception, video or DVD play that
operates when the vehicle is in gear or when the parking brake is not applied must be
installedtotherearof the driver’sseat where it will not be visible,directlyorindirectly,to
the operator of the motor vehicle. It is unlawful in most jurisdictions for a person to drive
a motor vehicle which is equipped with a screen that is located in the motor vehicle at
any point forward of the back of the driver’s seat, or that is visible, directly or indirectly,
to the driver while operating the vehicle. In the interest of safety, the MM850 should
never be installed where it will be visible, directly or indirectly, by the operator of the
motor vehicle.

3
Installation Guide
MATERIALS INCLUDED IN THIS PACKAGE:
1) MMD85VideoMonitorwithDVDplayer(P/N136D3586)(1pc)
2) A/V Adapter Cable (112B3227) (1 pc)
3) 2PinPowerWireHarness withchoke (P/N112B3370) (1pc)
4) HardwarePackage:-
♦#8x3/4” SelfDrilling Screws(4pcs)
♦#8Washers(4 pcs)
5) DomelightHarness (112B3110) (1 pc)
6) RemoteControl(136B3591)(1pc)
TOOLS REQUIRED:
#2 Phillips Screwdriver
#1 Phillips Screwdriver
Utility or Razor Knife or Shears
Wire Strippers
Upholstery hook tool (for removal of panels as necessary)
Electrical Tape
MaskingTape
Multimeter (to verify 12 volt DC and continuity: Do not use a test light or logic probe)
Markerpen – to mark headliner
Scribe (to mark trim ring if used)
Misc. electrical connectors (to connect to vehicle power source). Requirements will vary from vehicle
tovehicle.
3
5
1. 2.
3.
5.
6.
4.
CHOKE
132
465
798
0
ENTER

4
Installation Guide
VEHICLE PREPARATION:
1) Locate an accessory power source (+12v when key is in the ACC. and run positions, and 0v when
key is off). Also find a location that will provide a good grounding point. Generally, this wire can be
found at the ignition switch or fuse-box.
2) The mounting method and location will vary from vehicle to vehicle, so this manual will only focus on
the installation of the video monitor and related accessories.
3) Generally, the best location for the video monitor is where the vehicle'sfactory dome light is installed.
The monitor should be located in such a manner that it can be comfortably viewed by rear seat
passengers. NEVERINSTALLTHE MONITORINAPLACEWITHINTHEDRIVER'S VIEW. THIS IS
NOTONLYDANGEROUS, BUT IT IS ALSO ILLEGAL.
4) Oncethemounting location of the monitor has been determined, there may beadditional preparation
work necessary, depending on the vehicle structure and installation method. Some of the steps that
may be required are:
A) Removal of the vehicle's dome light
B) The headliner may need to be trimmed
VIDEO MONITOR INSTALLATION:
In this installation, the video monitor is mounted directly to the overhead cross-member in the
roof using the mounting screw bosses. These screw bosses should contact the cross-member
directly (i.e.: no gap between the screw boss and the roof structure). Also, be sure that the
screws do not pierce the outer roof skin when fully fastened to the cross-member. It is important
thatthe screws usedinthis installation arenotovertightened, and thatthevideomonitor ismounted
in such a way that the assembly does not distort (or bend) when the mounting screws are tight-
ened. An alternate method is to use a piece of plywood. First secure the plywood block to the
cross-member, then screw the monitor into the plywood. See the drawing on page 5.

5
Installation Guide
MOUNTING THE VIDEO UNIT
(4)#8x3/4" self tapping
screws( supplied)
Roof
Roofsupport
Headliner
5"x9"x3/4"Plywood Block
orOptional VOHBKT
(4)#8x1" self drilling
screws(not supplied)
Video unit
(4)#8 Flat washers
(supplied)

6
Installation Guide
1) Make the connections to the vehicle for the 2 pin wiring harness.
2) Connect the 2 pin harness to the mating connector on the Video Monitor.
3) Connect power harness to vehicle's electrical system by tapping into an accessory hot line and a
goodground.
4) Verify all functions of the System before final mounting of the finished assembly.
Note: A VCP or other A/V Component can be connected to the video monitor system using
theLINE IN RCA jacks.
A/V Source Definitions :
1 =Built-in DVD
2 =AV1 input ( VCD, Game or future DVD, etc )
3 =AUX input ( VCD, Game or future DVD, etc )
LineOut
RightandLeft
MMD85
CHOKE
Auxillary
video display
12 VDC Power and Ground
INPUT
VIDEO
(Yellow)
Line Out-R (Red)
LINE
OUT
VIDEO Patch Cord
RCA-Female
RCA Male to Male
Line Out-L (White)
Line Out-V (Yellow)
TO
OPTIONAL
ADDITIONAL
MONITOR
To Secondary AV Monitor
Power Harness
Item # 3
Line In-R (Red)
Line In-L (White)
Line In-V (Yellow)
Red/Black (Lamp On)
Violet/Brown (Lamp Auto)
Black/Red (Lamp Common)
LineVideoOut
AudioVideoOutput
AudioVideoInput
DomeLight
PowerSource

7
Installation Guide
Red / black - Lamp on
Black / red - Lamp common
Violet / brown - Lamp Auto
To 3 pin
connector
onMonitor
To
constant
+12vdc
To
constant
+12vdc FactoryDoor ajar
switch or Body
Control computer
Factory Dome light circuit
Positive Switched Dome lighting
CONNECTING THE DOME LIGHTS
The dome lights in the video monitor require three connections to the vehicle's wiring. There are two
common types of dome light circuits used, positive or negative switched. Positive systems supply volt-
age to the interior lights to turn them on, negative switched systems apply ground to illuminate the bulbs.
To determine which system you have you must locate the wires at the dome light. On a positive switched
system, with all the doors closed and the lights out, both wires at the dome light will rest at ground. When
the light is activated, one of these wires will switch to +12 vdc. This is the vehicle's switching wire. On a
negative switched system, with all the doors closed and the lights out, both wires at the dome light will
rest at + 12vdc. When the light is activated, one of these wires will switch to ground. This is the switching
wire.
For positive systems, connect the violet / brown (Lamp auto) wire to the vehicle's switched wire. Then
connect the red / black (lamp on) wire to a fused constant 12 volt source and the black / red (lamp
common) wire to a good ground. Positive systems are commonly found on Ford vehicles.
For negative systems, connect the violet / brown (Lamp auto) wire to the vehicle's switched wire. Then
connect the red / black (lamp on) wire to a good ground and the black / red (lamp common) wire to fused
constant 12 volt source. Negative systems are commonly found on General Motors and import vehicles.
Note:
Some vehicles which incorporate transistorized control of the dome light circuit, such as the 1999
Dodge Caravan, may require that the violet / brown (Lamp auto) wire be connected to the door pin
switch wire, as the additional current draw of the Monitor's lights may not be supported by the output
of the vehicles body control computer.

8
Installation Guide
Troubleshooting:
SYMPTOM:
No power at Video Monitor
Power but no video or
sound
Picture, but no sound
REMEDY:
-Verify +12 VDC on Red wire at 2 pin Power Harness behind video
monitor. Verify ground connection with continuity test from known
good ground to black wire at 2 pin Power Harness
-Verify that the correct source is selected (i.e.: 1 or 2). Verify that the
source is on and playing a known good media (such as a videotape).
Verify connections at both ends of the source component harness.
-Verify that the headphones are turned on; check headphone batter-
ies
-Verifythatpower is available to the FM Modulator;make sure modu-
lator is tuned to the correct FM station
Negative Switched Dome lighting
To 3 pin
connector
To
constant
To
constant
FactoryDoor ajar
switch or Body
Factory Dome light circuit
Red / black - Lamp on
Black / red - Lamp common
Violet / brown - Lamp Auto

9
Installation Guide
