Congratulations
Thank you for purchasing the Audiovox Xpress XM®Satellite Radio Home Kit.
You are one step closer to experiencing the latest innovation in XM
Satellite Radio. XM Satellite Radio will revolutionize your vehicle or
in-homeentertainment.
XM is America’s number one satellite radio service with more than 7 million
subscribers. BroadcastinglivedailyfromstudiosinWashington,DC,NewYork
City, the Country Music Hall of Fame in Nashville, Toronto and Montreal, XM’s
2006 lineup includes more than 170 digital channels of choice from coast to
coast:themostcommercial-freemusicchannels,sports, talk,comedy,children’s
and entertainment programming; and the most advanced traffic and weather
information.
XM, the leader in satellite-delivered entertainment and data services for the
automobile market through partnerships with General Motors, Honda, Toyota,
Hyundai, Nissan, Subaru, Suzuki and Porsche, is available in more than 140
differentvehiclemodelsfor2006. XM’sindustry-leadingproductsareavailable
at consumer electronics retailers nationwide. For more information about XM
hardware,programming and partnerships,pleasevisithttp://www.xmradio.com.
Required subscription for service sold separately. Premium Channels available at
additional monthly costs. Installation costs and other fees and taxes may apply,
including a one-time activation fee. All fees and programming subject to change.
College sports games subject to availability. Subscriptions subject to Customer
Agreement included with the XM Welcome Kit and available at
http://www.xmradio.com. Only available in the 48 contiguous United States.
©2006 XM®Satellite Radio Inc. XM is a trademark of XM Satellite
Radio. All rights reserved. All other trademarks are the property of their
respective owners.
Congratulations

4
FCC Information
The user is cautioned that changes or modifications not expressly approved by
XM®Satellite Radio Inc. can void the user’s authority to operate this device.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the installation instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the antenna of the affected receiver.
- Increase the separation between the XM equipment and the affected receiver.
- Connect the XM equipment into an outlet on a circuit different from that to
which the affected receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Warning: The FCC and FAA have not certified XM Satellite Radio Receivers for use
in any aircraft (neither portable nor permanent installation). Therefore, XM Satellite
Radio, Inc. cannot support this type of application or installation.
FCCInfomation

5
Cautions and Warnings
1. Do not install the Home Cradle in a position that obstructs viewing
of any home entertainment component, such as a television, or
stereo system indicators and displays.
2. This unit complies with the interference limits relative to a Class B
digital device, applicable under Part 15 of the FCC Rules regarding
installation in a residential environment. If the unit is not installed in
accordance with these instructions, it could cause harmful
interference to radio or television reception. If this condition persists
after corrective action, consult your dealer or experienced
installation facility.
3. By adhering to these warnings and safety considerations, serious
accidents and/or personal injury can be avoided.
Cautions and Warnings

6
Install Manual
DC Power Adapter
(P/N 112-3592)
1 pc.
Cradle XMH-10A
(P/N 136-4060)
1 pc.
Antenna
(P/N 118-1134)
1 pc.
Audio Cable
(P/N 112-3599)
1 pc.
Contents XMH-10A
Contents

7
Installation / Wiring Precautions
Installation/Wiring Precautions
1. Make sure the adapter cable is not connected to an AC wall outlet
until all interconnections have been made and verified. The adapter
power cable should be connected last.
2. Do not install the unit in the locations exposed to direct sunlight or
in areas subject to extreme temperatures.
3. Incorrect installation may cause damage to the system.
4. During antenna placement/installation, refer to the Antenna Aiming
procedure outlined in the Xpress XM User Guide.
Setting Up and Installing Your Kit
NOTE: The XM signal can be received and processed virtually
anywhere as long as there are no obvious satellite signal
obstructions such as high terrain, trees, overhangs, etc.
1. Cabling Interconnections
You can begin to enjoy XM Satellite Radio as soon as the Xpress
XMReceiver and home kit installation are complete. Set up your
Xpress home kit using the following installation instructions, or
enlist the help of a professional installer.
2. Installing/Positioning the Antenna
For best reception, the supplied antenna should be placed near a
window; some repositioning may be required to achieve optimum
results. The following guidelines are recommended:

8
AUDIOCABLE
CRADLE
XMH-10A
TO AC WALL
OUTLET
HOME
ANTENNA
DCPOWER
ADAPTER
AUDIOINPUTTO
EXTERNALAMPLIFIER.
a. In a major city, where XMground repeaters are present, you can
usually place the antenna away from a window and still achieve
the desired results. If you experience a loss of signal or audio,
reposition the antenna inside the home or outside as necessary.
b. You can also place the antenna outside (on the roof structure),
provided it is clear of any overhead obstructions.
InterconnectDiagram
Installation / Wiring Precautions

9
16-PINSYSTEM
CONNECTOR
DOCKING
STATION
FRONTVIEW
DOCKING
STATION
TOPVIEW
CONNECTOR
GUIDEPIN
a. Aftermaking suretheconnectorsand guide pinholeare properly
lined up, gently lower the Xpress XMReceiver into the cradle
and gently press down on the Xpress XM Receiver to mate
the connectors together.
3. Installing the Xpress In the Cradle
Install the Xpress XM Receiver in the docking station as follows:
Installation / Wiring Precautions

10
ANTINRF
CONNECTOR
DOCKINGSTATION
REARVIEW
DCINCONNECTOR
AUDIOOUT
CONNECTOR
4.Aiming your XM Home Antenna
If the Xpress display says “NO SIGNAL,” the antenna needs to be
repositioned. In addition, even if you are receiving the XM signal, it is
recommended that you optimize the position of your XM Antenna as
described in this section enabling you to receive the strongest
possible signal and consistent, mute-free reception.
b. The Xpress XM Receiver should now be nestled securely in
the docking station.
Installation / Wiring Precautions
