Audiovox 4GHz User manual

2.4GHz HANDSET
For use with Audiovox TL1102 Base Station
COMBINÉ 2.4GHz
Pour poste de base Audiovox TL1102
TELÉFONO DE 2,4GHz
Para usarse con la estación base Audiovox TL1102
OWNER'S MANUAL
MANUEL D'UTILISATION
MANUAL DEL USUARIO

E - 1
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS .............................. 2 - 3
BATTERY CAUTIONARY INSTRUCTIONS .............................. 3
IMPORTANT ELECTRICAL CONSIDERATIONS .................. 4 - 6
• Telephone line problems • FCC Part 15 regulation • Customer information •
Applicable for coin or pay phone only
INSTALLATION ............................................................... 7 - 8
• Handset installation and charging • Placing the battery pack • Install charger
unit in a location
LOCATION OF CONTROLS ................................................. 9
• Handset section • Charger section • Accessories • Icon explanations
SUBSCRIBING HANDSETTO BASE STATION .................. 10 - 11
• Subscribing handset to TL1102 base stations • Deleting a base station •
Selecting base station to be used
TROUBLE SHOOTING GUIDE ............................................. 12
9038_1_ib_e.p65 10/31/03, 12:13 PM1

E - 2
IMPORTANT SAFETY INSTRUCTIONS
Please take a few moments to read the following instructions for your safety and to ensure
that you get the maximum benefit from your product.
When using your telephone equipment, basic safety precautions should always be followed
to reduce the risk of fire, electric shock, and injury to persons, including the following :
1) Read and understand all instructions.
2) Follow all warnings and instructions marked on the product.
3) Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a dry cloth for cleaning.
4) Do not use this product near water, for example, near a bath tub, wash bowl, kitchen
sink, laundry tub, in a wet basement, or near a swimming pool.
5) Do not place this product on an unstable cart, stand, or table. The telephone may fall,
causing serious damage to the telephone.
6) Slots and openings on the sides and back of the base of the phone are provided for
ventilation. These openings must not be blocked or covered. The opening should never
be blocked by a built-in installation unless proper ventilation is provided.
7) This product should be operated only from the type of power source indicated on the
marking label. If you are not sure of the type of power supply to your home, consult your
dealer or local power company.
8) Do not allow anything to rest on the power cord. Do not locate this product where the
cord will be abused by persons walking on it.
9) Do not overload wall outlets and extension cords as this can result in the risk of fire or
electric shock.
10) Never push objects of any kind into this product through phone base slots as they may
touch dangerous voltage points or short out parts that could result in a risk of fire or
electric shock. Never spill liquid of any kind on the product.
11) To reduce the risk of electric shock, do not disassemble this product. Take it to a
qualified service personnel when some service or repair work is required. Opening or
removing covers may expose you to dangerous voltages or other risks. Incorrect
reassembly can cause electric shock when the appliance is subsequently used.
12) Unplug this product from the wall outlet and refer servicing to qualified service
personnel under the following condition.
a) When the power supply cord plug is damaged of frayed.
b) If liquid has been spilled into the product.
c) If the product has been exposed to rain or water.
9038_1_ib_e.p65 10/31/03, 12:13 PM2

E - 3
BATTERY CAUTIONARY INSTRUCTIONS
CAUTION
Risk of explosion if battery is replaced by an incorrect type.
Replace only with the same type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
1) Use only the following type and size battery : type no. SHIDA BATTERY CO. LTD.,
AP55AAAH3NIMH 3.6V 550mAH.
2) Do not dispose of the battery pack in a fire. The cell may explode. Check with state and
local codes for possible special disposal instructions.
3) Do not open and mutilate the battery pack. Released electrolyte is corrosive and may
cause damaged to the eyes or skin. It may be toxic if swallowed.
4) Exercise care in handling the battery to prevent shorting it with conducting materials
such as rings, bracelets, and keys. The battery or conductor may overheat and cause
burns.
5) Charge the battery pack provided with or identified for use with this product only in
accordance with the instructions and limitations specified in the instruction manual
provided for this product.
6) Observe proper polarity orientation between the battery pack and battery charger.
7) Keep batteries out of the reach of children.
d) If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions. Improper
adjustment of other controls may result in damage, and will often require extensive
work by a qualified technician to restore the product to normal operation.
e) If the product has been dropped of the cabinet has been damaged.
f) If the product exhibits a distinct change in performance.
13) Do not use the telephone to report a gas leak in the vicinity of the leak.
14) Avoid using a telephone (other than a cordless type) during an electrical storm. There
may be a remote risk of electric shock from lightning.
USEONLYWITHCLASS 2POWER SOURCE7.5V DC150mA
+
IMPORTANT SAFETY INSTRUCTIONS
!
SAVE THESE INSTRUCTIONS
9038_1_ib_e.p65 10/31/03, 12:13 PM3

E - 4
Unplug all electrical appliances when you know an electrical storm is approaching. Light-
ing an pass through your household wiring and damage any device connected to it. This
telephone is no exception.
Warning : Please do not attempt to unplug any appliance during an electrical storm.
Caution : Changes or modifications to this product not expressly approved,or operation of
this product in any way other than as detailed by this Operating Guide, could
void your authority to operate this product as well as void they product’s
warranty.
Telephone Line Problems
The FCC has granted the telephone company the right to disconnect service in the event that
your phone causes problems on the telephone line. Also, the telephone may make changes
in facilities and services which may effect the operation of your unit. However, your
telephone company must give adequate notice in writing prior to such actions to allow you
time for making necessary arrangements to continue uninterrupted service.
If you are having trouble with your telephone service, you must first disconnect your phone
to determine if it is the cause of your problem. If you trouble has been corrected.
FCC Part 15
Warning : Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the
equipment.
Caution : To maintain compliance with the FCC’s RF exposure guidelines place the base
unit at least 20 cm from nearby persons.
Note : This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installa-
tion. If this equipment does cause harmful interference to radio or television reception
which can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures.
IMPORTANT ELECTRICAL CONSIDERATIONS
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is needed.
Consult the dealer or an experienced radio/TV technician for help.
Customer information
This equipment complies with Part 68 of the FCC rules and the requirements adopted by the
ACTA. On the bottom of this equipment is a label that contains, among other information,
a product identifier in the format US:3W4WI03BTL9035, if requested, this number must be
provided to the telephone company.
9038_1_ib_e.p65 10/31/03, 12:13 PM4

E - 5
Anapplicablecertificationjacks Universal Service Order Codes (USOC) fortheequipmentisprovided (i.e.,
RJ11C)in the packaging with eachpieceof approved terminal equipment.
Aplugandjack used to connect this equipment to the premises wiringandtelephonenetworkmust comply
withthe applicable FCC Part68rulesand requirements adopted by theACTA. A compliant telephonecord
andmodularplugisprovidedwiththisproduct. Itisdesignedtobeconnectedtoacompatiblemodularjack
thatis also compliant. See installation instructionsfor details.
TheREN is used to determinethe number of devices thatmay be connected to atelephone line. Excessive
RENson a telephone line mayresultin the devices not ringingin response to an incomingcall. Inmost but
notall areas, the sum ofRENsshould not exceed five (5.0). Tobecertainofthenumberof devices that may
beconnectedtoaline,as determined bythetotalRENs,contactthelocaltelephonecompany. [Forproducts
approved after July 23, 2001, the REN for this product is part of the product identifier that has the format
US:3W4WI03BTL9035. Thedigitsrepresentedby##aretheREN without a decimal point (e.g., 03 isaREN
of 0.3). For earlier products, the REN is separately shown on the label.
IfthisequipmentModelTL1000causesharmtothetelephonenetwork,thetelephonecompanywillnotifyyou
inadvancethat temporary discontinuance of service may berequired. Butif advance notice isn’t practical,
thetelephonecompany will notify the customer assoonas possible. Also, you will be advisedofyour right
tofile a complaint with the FCC ifyou believe it is necessary.
Thetelephonecompanymay make changes in its facilities, equipment, operations or proceduresthatcould
affecttheoperationoftheequipment. Ifthishappensthetelephonecompanywillprovideadvance notice in
orderfor you to make necessary modifications to maintain uninterrupted service.
Pleasefollow instructions for repairingif any (e.g. battery replacementsection); otherwise do notalternate
or repair any parts of device except specified.
Connectiontopartyline service is subject to state tariffs. Contactthestatepublicutility commission, public
servicecommission or corporation commissionfor information.
Theequipment is hearing aid compatible.
NOTICE: If your home has specially wired alarm equipment connected to the telephone line, ensure the
installationofthis[equipmentID]does not disable your alarm equipment. If you have questions about what
willdisable alarm equipment, consult yourtelephone companyor aqualified installer.
Shouldyouexperiencetrouble with this equipment, please contact (AudiovoxElectronicsCorporation,150
MarcusBlvd. Hauppauge,NewYork 11788. Phone: [phone]) for repairorwarrantyinformation. If
the equipment is causing harm to the telephone network, the telephone company may request that you
disconnectthe equipment until the problem isresolved.
NOTICE: Accordingto telephone company reports,AC electrical surges, typicallyresulting from lightning
strikes,are verydestructive to telephone equipmentconnected toACpower sources. To minimizedamage
from these types of surges, a surge arrestor is recommended.
Applicable for Coin or Pay Phone Only
To comply with state tariffs, the telephonecompanymustbe givennotification priorto connection for cus-
tomer-ownedcoin or credit cardphone. In some states, thestate public utility commission,public service
commissionor corporation commission must giveprior approval of connection.
IMPORTANT ELECTRICAL CONSIDERATIONS
9038_1_ib_e.p65 10/31/03, 12:13 PM5

E - 6
IMPORTANT ELECTRICAL CONSIDERATIONS
“This product meets the applicable Industry Canada technical specifications.”
Before installing this equipment, users should ensure that it is permissible to be connected
to the facilities of the local telecommunications company. The equipment must also be
installed using an acceptable method of connection. In some cases, the company’s inside
wiring associated with a single line individual service may be extended by means of a
certified connector assembly (telephone extension cord). The customer should be aware
that compliance with the above conditions may not prevent degradation of service in some
situations.
Repairs to certified equipment should be made by an authorized Canadian maintenance
facility designated by the supplier. Any repairs or alternations made by the user to this
equipment, or equipment malfunctions, may give the telecommunications company cause to
request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of the
power utility, telephone lines and internal metallic water pipe system, if present, are
connected together. This precaution may be particularly important in rural areas.
Caution: Users should not attempt to make such connections themselves, but should contact
the appropriate electric inspection authority, or electrician, as appropriate.
“The Ringer Equivalence Number is an indication of the maximum number of terminals
allowed to be connected to a telephone interface. The termination on an interface may
consist of any combination of devices subject only to the requirement that the sum of the
Ringer Equivalence Numbers of all the devices does not exceed five.”
9038_1_ib_e.p65 10/31/03, 12:13 PM6

E - 7
INSTALLATION
Handset Installation and Charging
Plug the AC/DC adaptor jack into the back of
the charger and then plug the AC/DC adaptor
into a compatible wall socket.The rechargeable
batterypack must be charged for approximately
10 hours before first use. The battery pack will
not have been inserted into the handset so
please insert the battery pack into the back of
the handset. Place the handset into the cradle
and the CHARGE LED should light, indicating
the battery pack is being charged. After 10
hours, your telephone will be ready to use.
Placing the Battery Pack
• Remove the battery door to slide downward.
• Connect the new battery pack into the
battery compartment.
• Replace the battery door to slide upward.
NOTE : When the handset is first time power
up, the display will show “REGISTER”, press
YES (3) to start registration and then :
• Press and hold the PAGE button on the new station, (about 6 seconds), until the LED flashes
and release the PAGE button after stops (flashing). This will put the base into subscription
mode for about 5 minutes.
• Enter the PIN code “4321” then press YES (3) to confirm
• Press scroll keys 5/6(6) to select a new base ID number for new base station.
• Press YES (3) to confirm the base number, then handset will start the subscription and
“SEARCHING. . . “ is displayed.
• “REGISTERED x” will be displayed for a few seconds and then “H x” be shown on LCD if
the subscription is successful. Else, “H ?” will be shown for fail subscription.
For detail procedure, please refer page E-10 for registration again.
9038_1_ib_e.p65 10/31/03, 12:13 PM7

E - 8
Install charger unit in a location where:
• Away from electrical appliances, such as computer, TV, microwave ovens, wireless
equipment or another cordless phone.
• In a HIGH and CENTRAL location with no obstructions & barriers,
• Being visible at most of your area.
INSTALLATION
9038_1_ib_e.p65 10/31/03, 12:13 PM8

E - 9
HANDSET SECTION
1) RECEIVER
2) DISPLAY
3) OFF HOOK /YES / FLASH KEY
4) INT/REDIAL / PAUSE KEY
5) ON HOOK/ NO KEY
6) SCROLL KEYS 5 /6
7) DIAL KEYS / ID#’s
8) SPEAKER KEY
9) MICROPHONE
10) STRAP HOLDER
11) SPEAKER
12) BATTERYDOOR
13) HEADSET JACK
LOCATION OF CONTROLS
CHARGER SECTION
14) CHARGE LED
15) ADAPTORSOCKET
ACCESSORIES
16) CHARGERADAPTOR
17) BATTERYPACK
ICON EXPLANATIONS
RECEIVED SIGNAL STRENGTH INDICATOR (RSSI) :
On when registered and in range, flashes when out of range.
RINGER MUTED :
On when ringer volume is set to zero.
LINE INDICATOR :
On when the handset is on line.
BATTERY STRENGTH :
Three segments to indicate state of charge of battery. Flashes when battery needs
recharging.
14 15
12
16
17
9038_1_ib_e.p65 10/31/03, 12:13 PM9
