Aurora SLF Series User manual
SLF
AR .
EN Please retain these instructions in a safe place for further reference.
2
1
1
2
2
3
3
4
4
Ø:6mm / L:35mm
A
B
C
Volume
3
Volume
1
Volume
2
60cm
60cm
2,25m
60cm
3
2-20min
5
5
6
6
7
7
4
5
6
ENGLISH
INSTALLATION AND OPERATING MANUAL
Before operating the heater, please read these instructions thoroughly to avoid damage and hazardous situa-
tions. Any use of this heater other than that stipulated in this instruction manual may cause re, electric shock
or injury, and voids all warranties.
Warranty does not apply to any defect, deterioration, loss, injury or damage caused by, or as a result of, the misuse or
abuse of this heater. The rights dictated by State law are not prejudiced. None of the terms of this warranty are to be
taken as excluding any conditions or warranties implied by State law, which cannot be excluded or modied.
Before any operation remove the packaging and check product integrity. In case of defects or damages do not try to
repair it yourself but contact your dealer.
Do not let children play with the packaging and protect the environment by disposing of the packaging in accordance
with the national regulations for waste processing.
1.
For your saFety
• This appliance is intended for normal household use and not for
use in vehicles or on board ships or aircrafts.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental ca-
pabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children shall
not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
• Children of less than 3 years should be kept away unless conti-
nuously supervised.
• Children aged from 3 years and less than 8 years shall only switch
on/off the appliance provided that it has been placed or installed
in its intended normal operating position and they have been gi-
ven supervision or instruction concerning use of the appliance in
a safe way and understand the hazards involved. Children aged
from 3 years and less than 8 years shall not plug in, regulate and
clean the appliance or perform user maintenance.
• Make sure that your supply rating corresponds to what specied
on the rating plate: 230V~, 50Hz.
• The appliance must be installed by a professionally qualied elec-
trician.
• This heater is water resistant to IPX4. It can therefore be used
in bathrooms or other areas subject to humidity AS LONG AS IT
IS NOT INSTALLED WITHIN THE PERIMETER OF BATH TUBS
OR SHOWERS. This means that it cannot be installed in the are-
7
as marked as VOLUME 1 in picture 2.
• Do not use the heater in rooms with explosive gas or while using
inammable solvents or varnish or glues.
• Before carrying out any maintenance or cleaning on the applian-
ce, make sure that the mains power supply has been temporarily
disconnected.
• Do not expose this appliance to the weather (snow, rain, sun, etc.).
• Do not immerse the product or parts of it in water; for its cleaning,
see the "cleaning" section.
• Warning ! This fan has been designed for extracting air directly to
the outside or in straight pipes or in pipes with a low air resistance.
Its performance may therefore be lower than its nominal values if
not used in these cases (for example in the case of long pipes or
pipes with sharp bends).
• Always make sure that the air duct is not blocked.
• The appliance must not send exhaust air into pipes where other
fumes or gases have already been conveyed.
• The air to be extracted from the room must be clean (i.e. free of
grease, soot, chemical and corrosive agents, and explosive or
ammable mixtures).
• Keep the appliance’s inlet and outlet grilles free to ensure an op-
timum ow of air.
• Ensure that the fan is switched off from the supply mains before
removing the guard.
• The max operating temperature is 45°C.
2.
Wall mounting
• The appliance must be installed on the wall. Before installation, check if the supplied rawplugs are suitable for
the installation surface.
- Remove the front grille and insert the fan into the duct to mark the location on the wall of the 4 holes (gure
3);
- Drill 4 holes of 6mm diameter in the wall in the marked positions (gure 4);
- Insert the rawplugs (picture 4);
- Reposition the product in the duct and x it with the 4 screws (gure 4).
- Make the electrical connections (gures 5 and 6);
- Close the extractor with its front grille.
3.
electrical connections and Functioning
• This fan is tted with a double electrical insulation circuit (class II) and therefore does not require an earth con-
nection.
• This fan must be correctly installed in compliance with the regulations in force in the country of installation.
• In wet spaces like bathrooms or kitchens, the connection terminal must be installed at least 25 cm above the
oor. The electrical connection to the power supply must also be tted with a two-pole switch with a minimum
gap between the contacts that allows complete disconnection according to excess voltage III category conditions.
• The basic version must be connected following the diagram shown in gure 5.
• The version with timer must be connected following the diagram shown in gure 6.
• The timer version fan turns on automatically after switching on the light and continues to operate
• for the preset time after the light itself was turned off.
• The operating time can be varied from 2 to 20min using the regulator indicated in gure 7.
4.
maintenance and cleaning
• This product does not require any special maintenance.
• Clean the product with a dry cloth once every 6 months.
• If the product requires repairing, contact an authorised technical service centre.
5.
legal notice
Environment and recycling
Please help us to protect the environment by disposing of the packaging in accordance with the national
regulations for waste processing.
Recycling of obsolete appliances
Appliances with this label must not be disposed off with the general waste. They must be
collected separately and disposed off according to local regulations.
ISSLF002_R0
This manual suits for next models
