Austro Flamm Dexter 2.0 L User manual

Benutzerhandbuch / manual / manuale / manuel
User instructions
Dexter 2.0

Fig. 1
english
open – closed
primary air supply
english
Contents
1. Techn. data 5
2. Important information 5
3. Correct operation
of your stove 6
4. The most important
spare parts - overview 7
5. Special features 8
Guarantee 17
This instruction describes the Dexter left!
Fig. 2

english
5
Dexter
TECHNICAL DATA
Height
955 mm
Width
618 mm
Depth
422 mm
Weight
145 kg
Flue pipe outlet diameter
150 mm
Nominal thermal output (EN 13240)
6,5 kW
Maximum thermal capacity
8 kW
Smallest heating capacity
3,5 kW
Room heating capacity
(depending on building insulation) 65–165 m³
Exhaust values for multiple use of the chimney in
accordance with DIN 4705, Part 3 and for the calculation
of the chimney measurements in accordance with DIN
4705, Part 2
Fluegas mass flow closed 6 g/s
Fluegas temperature closed 326 °C
Minimum feed pressure
Nominal thermal output
closed 12 Pa
at 0.8 times n. ther.
outp.
10 Pa
1. TECHNICAL DATA
As a stove of construction type 1, it is possible to connect it
to the chimney together with an exisiting other stove or
another hearth for solid fuels, as long as the chimney
dimensioning complies with DIN 4705, Part 3.
2. IMPORTANT INFORMATION
The installation and operation information given here is of
general nature. National and European standards, local and
building regulations as well as fire prevention laws must be
observed during the operation of the stove.
General safety instructions for the
operation of your stove
•Thoroughly read the entire manual before starting up
your stove and observe the caution notices.
•Your heating unit may not be moved without approved
means of transport with sufficient load-bearing capacity.
•Your heating unit is not suitable to be used as a stand or
as a ladder.
•Please keep in mind that your
stove’s surface heats up considerably
during operation. We therefore
recommend wearing a safety mitten
when operating your stove.
•Attention – stove varnish is no rust prevention!
•Make your children aware of this particular danger and
keep them at a distance from the heating unit whenever it is
in operation.
•Only burn approved fuels and materials listed in the
chapter “Clean Burning”.
•The burning or placing of flammable or explosive
materials, like empty spray cans and such like into the
firebox as well as the storage of such materials in the
immediate vicinity of your heating unit is strictly forbidden
due the danger of explosion.
•Do not wear loose or flammable clothing when adding
fuel to the fire.
•Placing non-heat-resistant objects on the heating unit or
in the vicinity of the heating unit is forbidden.
•Do not lay laundry onto the stove for drying. Laundry
hung up to dry must be kept at a safe distance from the
stove because of the danger of fire.
•The woodstove DEXTER is no “slow combustion stove”
(must hold embers for at least 4 hours).
•During the operation of your heating unit it is forbidden to
use flammable or explosive materials in the same or an
adjacent room to the one in which your heating unit is
located.
•The appliance must be operated with the stove door
closed.
•The stove door and all fittings for adjusting the stove
must be closed, if the appliance is out of use.
Setting up your stove
Required safety distances (Minimum distances –
see name plate - in Fig. 2)
Make sure that the room in which the stove is set up has at
least one door or window into the outside or is directly
adjacent to such a room. Other fireplaces and extractor
hoods must not be operated in the same room as the stove.
a > 1500 mm
b > 275 / 900 mm
c > 175 mm
(a – toward the front in the radiated area)
(b – to the side steel panel/glass front)
(c – to the back)
Subject to technical and optical modifications. Formatting and printing errors excepted.

Dexter
6
english
Combustion air
Being the user of the stove you must take care of a sufficient combustion air supply. Sealed-up windows and doors may not allow a
sufficient combustion air supply or disturb the draught behaviour of your stove. Please ensure the additional supply of fresh
combustion air if necessary. For details please consult your specialist retailer. Make sure that the combustion air intakes are not
blocked!
Stove pipe connection
For your own safety stringent laws apply for connecting stove pipes to the chimney. Your professional dealer or distributor
knows these laws. Please have your certified retailer carry out the connection of your stove.
Floor load capacity and Hearth
Make sure that the load capacity of the supporting construction is sufficient to carry the weight of the entire unit, before the
heating unit is installed.
The hearth requirement is minimum 820mm deep x 1120mm wide x 9mm thick fibre cement sheet (Bellis board or similar, with
minimum of 300mm in front of 2 sides of glass.
Flue Connection to Heater
The flue collar fitted to the unit is 5” – Inner diameter is tapered from 137mm and outer diameter is 148mm.
The top flue connection requires either a 5” to 6” adaptor to fit within the top box, or the Austroflamm Flue damper (fits to the
outside of the flue collar (ensure the connection is sealed with fire cement on the inside).
If using the flue damper inside the top box, ensure the damper is set to 30 degrees from the horizontal (assuming a 4.6m
flue height from the hearth).
For rear connection, the rear flue blanking plate is swapped with the flue collar supplied on top of the firebox. Use the top
box with blanking cover to cover the unit. Using the 5’ to 6” adaptor into the flue collar, have holes drilled through the cast
flue collar into the stainless steel active so the flue is mechanically fixed, and seal with fire cement. Connect to a wall
penetration kit or a drop box with triple skin T-piece and flue as per normal with rear wall flue installation. See pics on page
8.
Adaptor to flue inside the top box.

english
7
Dexter
Flue Installation
Flue type: Triple skin flue, 150mm Active /200mm/250mm Double Casing, ie 6”/8”/10”. The Active 150mm flue must be a
tight fit into the heater collar.
The heater must have its own dedicated flue. The active flue must be 8” for the entire length of the flue, and always
less than 45 degrees from the vertical.
Replacement room air from outside equivalent to 160cm2 must be supplied into the room.
Flue Outlet Positions
Minimum Flue Height as per AS/NZS 2918:2018
NOTE: Flue exit MUST also be as high as any nearby structure within a 6m Radius. ( AS 2918:2018 )

Dexter
8
english
Exter External Requirements
Refer to AS/NZS 2918:2018
Note: All external air vents & ceiling penetrations must be bird & rodent proofed with permanently fixed screens
Flue Collar Connection for Rear Flue

english
9
Dexter
WARNINGS:
A wood burning heater is, by its nature, an appliance that operates at high temperatures, so it is necessary to take into account potential risk factors that
should be avoided at all costs. Children must be kept away from any combustion appliance and supervised in the room at all times.
Installation must be carried out by a licenced and certified installer.
The installation must meet the requirements of the manufacturers instructions, AS2918 and the Building Code of Australia.
The appliance must be installed in such a way as to allow easy maintenance.
Incorrect installation may cause serious damage to the equipment and the safety of people and property.
Before installing your appliance, please ensure the following:
oThe appliance must be installed on a heat resistant surface to 600°C.
oThe floor must be structurally sound, to support the installation weight.
oThe compartment below the heater should not be used to store combustible materials (NM-RS models).
oReplacement outside air must be supplied to the room with the heater, a minimum equivalent to half the cross-sectional area of the flue, ie 160cm2 free
air.
oFollow the clearances to combustible materials as shown on page 9. and 10.
oYour appliance must be non-permanently installed and easily accessible to ensure general maintenance (chimney and equipment).
oThe equipment must not be cemented in its enclosure under any circumstances.
Keep these instructions for future reference
WARNINGS:
oREFER TO COMPLIANCE LABEL – DISREGARD ANY CONTRADICTORY FUEL TYPE INFORMATION IN INSTRUCTION MANUAL
oWARNING: THE APPLIANCE & FLUE SYSTEM SHALL BE INSTALLED IN ACCORDANCE WITH AS/NZS 2918:2001 AND THE APPROPRIATE
REQUIREMENTS OF THE RELEVANT BUILDING CODE OR CODES.
oWARNING: APPLIANCES INSTALLED IN ACCORDANCE WITH THIS STANDARD SHALL COMPLY WITH THE REQUIREMENTS OF AS/NZS
4013:2014 WHERE REQUIRED BY THE REGULATORY AUTHORITY, I.E. THE APPLIANCE SHALL BE IDENTIFIABLE BY A COMPLIANCE
PLATE WITH THE MARKING “TESTED TO AS/NZS 4013:2014”.
oANY MODIFICATION OF THE APPLIANCE THAT HAS NOT BEEN APPROVED IN WRITING BY THE TESTING AUTHORITY IS CONSIDERED TO
BE IN BREACH OF THE APPROVAL GRANTED FOR COMPLIANCE WITH AS/NZS 4013:2014.
WARNINGS:
oCAUTION: MIXING OF APPLIANCE OR FLUE SYSTEM COMPONENTS FROM DIFFERENT SOURCES OR MODIFYING THE DIMENSIONAL SPECIFICATION OF
COMPONENETS MAY RESULT IN HAZARDOUS CONDITIONS. WHERE SUCH ACTION IS CONSIDERED, THE MANUFACTURER SHOULD BE CONSULTED IN THE FIRST
INSTANCE.
oCAUTION: CRACKED AND BROKEN COMPONENTS, e.g. GLASS PANELS OR CERAMIC TILES, MAY RENDER THE INSTALLATION UNSAFE.
oWARNING: ANY MODIFICATION OF THE APPLICANCE THAT HAS NOT BEEN APPROVED IN WRITING BY THE TESTING AUTHORITY IS CONSIDERED AS BREACHING
AS/NZS 4013.
oWARNING: DO NOT USE FLAMMABLE LIQUIDS OR AEROSOLS TO START OR REKINDLE THE FIRE.
oWARNING: DO NOT USE FLAMMABLE LIQUIDS OR AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHEN IT IS OPERATING.
oWARNING: DO NOT STORE FUEL WITHIN THE HEATER INSTALLATION CLEARANCES.
oWARNING: WHEN OPERATING THIS APPLIANCE AS AN OPEN FIRE USE A FIRE SCREEN.
oWARNING: OPEN AIR CONTROL (AND DAMPER WHEN FITTED) BEFORE OPENING FIRING DOOR.
oCAUTION: THIS APPLIANCE SHOULD NOT BE OPERATED WITH A CRACKED GLASS.
oTHIS APPLIANCE SHOULD BE MAINTAINED AND OPERATED AT ALL TIMES IN ACCORDANCE WITH THESE INSTRUCTIONS.
oTHE USE OF SOME TYPES OF PRESERVATIVE-TREATED WOOD AS A FUEL CAN BE HAZARDOUS.
oTHE APPLIANCE OR FLUE SYSTEM SHOULD NOT BE MODIFIED IN ANY WAY WITHOUT THE WRITTEN APPROVAL OF THE MANUFACTURER.
oBURN ONLY HARDWOOD
oPrior to installation check with your state and local authorities regarding any specific regulations that may apply.

Dexter
10
english
3. CORRECT OPERATION OF YOUR STOVE
Approved fuels
Dry, well cured and natural wood (hardwood preferred),
wood briquettes.
Maximum amount of fuel
Maximum amount of fuel to be added: 1,4 kg wood. Larger
amounts of fuel can lead to overheating and thus damage
the stove.
Clean burning
The wood must be dry (relative wood moisture < 15%) and
untreated and the right amount of wood must be burned in
order to ensure a clean fire that releases only small
amounts of emissions.
Startup procedures
During the first 3-4 operations - at nominal heat output -
there may be some odour development and the varnish has
not yet hardened.
Making a fire
For the correct and safe operation of your stove please pay
attention of the chimney developing the necessary feed
pressure. This must especially be considered before the
initial operation (or e.g. after the summer heating break) and
during the mid-season heating periods (e.g. at strong wind,
etc.).
If there is not enough feed pressure, please light only some
paper or small kindling first, in order to “warm up” the stove
and the chimney.
The air inlet must not be covered or closed.
Clean grate, empty ash drawer if necessary (watch out for
ambers!).
Position the lever for the combustion air to the open (“AUF”)
position (see fig. 4).
Place 2-3 logs (approx. 1,0 kg in total) crossways in the
combustion chamber (1) with sufficient distance from each
other (min. 2 cm), on top of that place some softwood
chippings (0,4 kg) (2) and some ignition aid and light (3).
(see fig. 3)
Close the door!
We recommend to let the first load burn down without
changing the air lever position.
As soon as no visible flames are left (only embers left in the
combustion chamber), you can put another load of logs
(approx. 1,4 kg) in the combustion chamber if desired.
When reloading the stove please repeat the procedure as
mentioned under “first lighting”: air lever position on “AUF”
(= open), open door carefully, place logs, close door.
Fig. 4: air knob
After a few minutes, when the logs burn well on all sides
(bright, high flames - see fig. 5), you can adjust the heat
output with the air lever (lever on max. position “AUF” =
maximum heat output), the flames should be yellow and
never look blueish or have black tips (otherwise add more
air) – see fig. 4. Never close air supply completely during
operation. Danger of flash-fire!
The stove door may be opened only for refuelling or
disposing of ashes and is to be closed again afterwards.
Figure 5
Figure 3:ignite the fire
3
2
1
symbol figures
symbol figures
symbol figures

english
11
Dexter
Heating in-between seasons
Heating the stove in between seasons, when the outside
temperatures are higher, the flue gases may not be able to
escape completely and this may lead to disturbances in the
chimney draught, especially if the temperatures are rising
suddenly. The stove has to be charged with less wood and
the primary air has to be increased so that the wood can
burn down faster (with visible flames) and thus the chimney
flue can stabilize.
Chimney fire
A chimney fire may occur, due to sooting and deposits in the
chimney, if impropes or humid fuel is used. In case of a
chimney fire close all air inlets on the fireplace/chimney
immediately and call the fire brigade. Please have an expert
inspect your chimney for cracks and air-tightness after the
burning out of the chimney.
4. THE MOST IMPORTANT SPARES—OVERVIEW
Gaskets
Description
No.
Part
reference
Dexter L
Part
reference
Dexter R
Gasket hollow Ø 6x2260 mm
11
718183
Gasket oval 16x8x2600 mm
12
718763
Keramott
Description
No.
Part
reference
Dexter L
Part
reference
Dexter R
Keramott baffle plate 2
1
720429
720474
Front Keramott base
2
720421
Outside base Keramott corner
l/r
3
720422
720471
Inside base Keramott corner r/l
4
720423
720472
Rear Keramott base
5
720427
Vertical Keramott outside
6
720424
Vertical Keramott corner
7
720425
Vertical Keramott rear
8
720426
Keramott baffle plate 1
9
720428
720473
Grate
-
716408
Other parts
Dexter L Dexter R
Keramott numbering = installation instructions!
Description
No.
Part
number
Dexter L
Part
number
Dexter R
Door complete
13
720430
720476
Door handle
14
361089
Door glass – short side
15
720433
Door glass – long side
16
720432
720477
Stove varnish
-
650002
Glass cleaner ½ litre
-
640070
Accessories
You can obtain floor plates made of glass or steel, care products or the Heat Memory System for heat storage from your
certified dealer.
IMPORTANT: Have defective parts replaced by your certified dealer. This will guarantee that your stove functions
properly and safely.
The fireplae must not be altered.
Maintenance
To clean the glass, please use a specialised product such as Thermohit glass cleaner. Lacquered surfaces are to be
cleaned only with a cloth (may be damp). Special cleaning agents should also be used for stainless steel surfaces.
Only gaskets in good order ensure the proper function of your stove!
Cleaning
The stove, flue outlets and smoke pipes should be cleaned and inspected for deposits every year – if necessary more often,
e.g. after the cleaning of the chimney. The chimney also has to be cleaned regularly by the chimneysweeper. Your
chimneysweeper will inform you of the necessary inspection intervals. An expert should inspect the stove annually.

Dexter
12
english
5. SPECIAL FEATURES Dexter 2.0
Operation with external air supply
The German institute for constructional engineering (DIBT) has given the Dexter 2.0 the general technical approval for
operation with external air supply. If the combustion air is being supplied directly to the furnace by an air-tight pipe including
closing mechanism from the outside, then the stove may be used in residential property with mechanical ventilation.
If the stove in being used like that, a multiple stove installation on the same chimney is forbidden.
This stove has been approved by the German DIBT.
problem
possible reason
solution
door glass gets sooty too fast
bad chimney draught
generally: door glasses must be cleaned with
Austroflamm glass cleaner from time to time
(depending on the frequency of use)
contact your chimney sweep (elongate
chimney/draught metering)
incorrect use of the combustion air
supply lever
please operate air lever according to user's
instructions (if secondary air is closed, the door
glass soots rather fast)
wood logs are too large
keep to the max. fuel quantity according to user's
instruction
operating temperature was not
reached
more fuel, use dry wood (< 15 % residual moisture),
attend air regulation
stove does not get enough
combustion air
chimney draught not sufficient contact your chimney sweep (elongate
chimney/draught metering)
stove is sooted inside more fuel, use dry wood (< 15 % residual moisture),
attend air regulation
stove smells strongly and
there is smoke on the outside
surface
baking phase of the varnish there may be some odour development during the
first operations
stove is dusty/dirty cleaning before the heating season starts!
exhaust gas emission while
putting more wood on the fire
and during operation
chimney draught no sufficient, flue
pipe connection leaky
inspect joints and seal up again if necessary
check chimney draught, examine operating - for info
video follow:
http://www.austroflamm.com/de/Video/index.html
the stove door was opened before
the wood has burnt down to embers
put more fuel wood into the combustion chamber
only if there are only embers left (no more visible
flame)

GUARANTEE
Guarantee
Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure
and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to
have the goods repaired or replaced if the goods fail to
be of acceptable quality and the failure does not
amount to a major failure.
The benefits given under this Limited Warranty are in
addition to other rights and remedies you have under
the Australian Consumer Law that cannot be excluded.
We guarantee full functionality of the stove carcass for 6
years and all stove components made of steel or cast
iron for a full two years from the date of purchase. Steel
and cast-iron components which show defect in materials
or workmanship during the guarantee period shall be
replaced with new components.
We do not guarantee wearable components (such as
Keramott, gaskets, floor grid), surface coatings, lacquer,
glass and ceramics.
Conditions of the Guarantee:
1. Your AUSTROFLAMM stove was installed by a
certified professional and is operated in accordance
with the operator’s manual.
2. Claims to the guarantee shall be subject to a
completely filled-out Guarantee Card and submittal of
the original invoice issued by a certified
AUSTROFLAMM sales agent.
IMPORTANT: Our guarantee includes free shipping
of new components. Work and travel times are not
included. Unwarranted claims shall be re-invoiced to the
operator.

Im Garantiefall herausschneiden und Ihrem AUSTROFLAMM-Fachhändler vorlegen!
In the event of claims to the guarantee, separate here and present this proof of purchase to your certified AUSTROFLAMM dealer.
GARANTIE / GUARANTEE / GARANZIA / GARANTIE
Kaufdatum / date of purchase / data d’acquisto / date d’achat
Modellname / Name of Model / modello / nom du produit
DEXTER L
DEXTER R
Serien No. / serial no. / no. di serie / no. de série
(siehe Typenschild / see manufacturer’s plate /
vedi targhetta / voir plaque signalétique)
angeschlossen von / installed by / installato da / raccordée par
Händlerstempel / dealer’s stamp / Timbro concessionario / tampon
du concessionnaire
