Auto Page RS-615 User manual

1
RS-615
PROFESSIONAL REMOTE CAR STARTER
&
KEYLESS ENTRY SYSTEM
OPERATIONS MANUAL
THIS PRODUCT IS DESIGNED FOR PROFESIONAL INSTALLATION ONLY

2
SYSTEM OPERATIONS:
WARNINGS:
As with any product that performs automatic functions, there are certain safety
precautions that you must
practice and be aware of.
1. Keep the transmitter out of children’s reach.
2. Do not leave anyone in the vehicle while running on remote control.
3. Alert servicing personnel that the vehicle can be started automatically.
4. Do not start the vehicle by remote while it’s in an enclosed area or garage.
5. Always apply the parking brake and lock the vehicle as you exit the vehicle.
6. The vehicle windows must be rolled up.
7. Should the unit malfunction, disconnect the fuse until the problem is
corrected.
8. The use and operations of this system is the sole responsibility of the
operator.
9. Some areas may have local ordinances that prohibit leaving a vehicle
running on public streets.
10.Do not start the vehicle by remote while the standard transmission vehicle is
parked at a steep place.
Transmitter
Button System Function Remark
Lock Doors
Panic function Press and Hold for 3 seconds
+ Silent Lock / Unlock Ignition in "off" position.
Unlock Doors
-Two Step Door Unlock (Driver’s
door on the first push; Passenger’s
door on the second push Press twice within 3 seconds.
Trunk Release (Channel 3) Press and Hold for 2 seconds
-Car Locator Under locked mode
Activate or Turn Off The Remote
Start
II Switching code For 2nd Car
Operation.For regular remote transmitter Only

3
CHANGING THE BATTERY IN YOUR TRANSMITTERS
XT72S: This transmitter uses two (2) 3-volt lithium ion batteries
(#CR2016) that are sandwiched together with the (+) side facing upward.
To replace the battery, you will need to use a small flat blade screwdriver.
Locate the small notch on the lower right side of the transmitter case next
to the key ring. Using the flat blade screwdriver, carefully pry the top case
from the bottom case. It should snap apart after breaking the seal.
Before removing the batteries note the direction of the positive (+) terminal.
Place the new batteries in exactly the same manner, being careful not to
bend or damage the contact terminal. Snap the cases back together and
then test the transmitter to insure it arms and disarms the alarm.
ACTIVE LOCK:
1. Press button on the transmitter.
2. The horn will chirp once and parking lights will flash once indicating that
the system is now active. The vehicle doors will lock upon activating
when interfaced with the keyless entry system.
SILENT LOCKING / UNLOCKING: Pressing the + buttons
together on the transmitter will lock or unlock your system, No chirp sound
will be heard, lock / unlock confirmation will be through the
vehicle’s parking lights only.
ACTIVE UNLOCK:
1. Press button on the transmitter.
2. The horn will chirp twice and parking light will flash twice to indicating
that the keyless system is now unlocked. The vehicle doors will
unlock and dome lights will turn on for 30 seconds.
PATHWAY ILLUMINATION
(2) CR2016
3-Volt Batteries

4
This feature turns the parking light “ON” for 30 seconds upon a unlock
signal and for 10 seconds upon the lock signal.
TWO STEPS DOOR UNLOCK: This feature will independently unlock the
driver door only when deactivating the system. Pushing the
button a second time within 3 seconds will unlock the entire vehicle.
LED DISPLAY:
LED Function
Off Unlock
Slow
Flash Locked
On (Solid) Valet Mode
CHIRP INDICATOR:
Chirp Function
1 chirp Lock
2 chirps Unlock
6 chirps Car Locator
PARKING LIGHTS:
Parking light Function
1 flash Lock
2 flashes Unlock
12 flashes Car Locator
Constant On Under Remote Start
DEACTIVATING WITHOUT A TRANSMITTER
The Override function may be used if the remote transmitter is lost or
inoperative.
1. Enter the vehicle and turn the ignition switch to ‘ON’ position.
2. Within 10 seconds push and release the valet switch
If starter disable is installed. You can now start and operate the
vehicle normally.
VALET MODE:
The valet switch allows you to temporarily bypass all system function,
eliminating the need to hand your transmitter to parking attendants or
garage mechanics. When the system is in valet mode, and remote start
functions are bypassed, however the remote panic feature and remote
door locks will remain operational. To use the valet mode, the system
must first be deactivated either by using you remote transmitter, or by
operating the Manual override sequence.
Enter Valet Mode:
1. From the Unlock condition, turn the ignition to “ON” position.
2.Push and hold valet switch for 2 seconds until the LED turns on. The

5
LED will remain on as long as the system is in ‘valet mode’.
Exit Valet Mode:
1. Return to normal operation, turn ignition ‘on’.
2. Push and hold valet switch for 2 seconds, The LED will turn off
indicating the system has exited the valet mode.
PANIC FUNCTION: (IF CAR HORN IS INSTALLED)
The transmitter can be used as a remote panic switch to manually
trigger the vehicle’s horn in case of emergency.
1. Press and hold the button for 3 second. The horn will immediately
sound.
2. During panic mode, the normal function of this transmitter button will
be suspended. The and buttons can be used to lock and
unlock the doors (if the option is installed), however once the button is
pressed, the vehicle’s starter disable device, (where installed) will be
enabled allowing the vehicle to start.
3. To stop the panic, press and hold the or button on the
transmitter again for 3 seconds. Also if any transmitter button other
than the or button is pressed and released, the panic mode will
be turned off immediately.
4. If no buttons are pressed, the panic function will stop automatically in
30 seconds.
DOME LIGHT CONVENIENCE DELAY & SUPERVISION
This system is a unique feature, which will turn on your vehicle dome
light as following: (optional) Additional installation required.
1. Upon unlocking, the interior lights will remain on for 30 seconds.
Note: Turning on the ignition switch or activating the system will turn off
the dome light.
IGNITION CONTROL DOOR LOCKS.
If the vehicle’s door locks have been interfaced to the security system,
the system will automatically lock the vehicle’s doors when the ignition
is turned “ON” and /or unlock the vehicle’s doors when the ignition is
turned “OFF”.
TRUNK RELEASE
Press and hold the button on transmitter for two seconds to remote
control the trunk release or other electric devices.
CAR LOCATOR
Press the button twice with 3 seconds to active car locator function.
The horn will chirp 6 times. The parking light will flash 12 times, for you to
easily locate your car.

6
REMOTE START OPERATION:
WARNINGS:
As with any product that performs automatic functions, there are certain
safety precautions that you must practice and be aware of.
1. Keep the transmitter out of children’s reach.
2. Do not leave anyone in the vehicle while running on remote control.
3. Alert servicing personnel that the vehicle can be started automatically.
4. Do not start the vehicle by remote while it’s in an enclosed area or
garage.
5. Always apply the parking brake and lock the vehicle as you exit the
vehicle.
6. Should the unit malfunction, disconnect the fuse until the problem is
corrected.
7. The use and operations of this system is the sole responsibility of the
operator.
8. Some areas may have local ordinances that prohibit leaving a vehicle
running on public streets.
A. TO REMOTE START THE VEHICLE:
When you want to start your vehicle,
1. Press button once on the transmitter.
2. The parking lights will flash to indicate the remote start received the
signal.
3. The engine will start approximately 5 seconds.
4. Once the engine is running, after a couple of seconds the parking light
will turn on again and climate controls will activate and adjust the
vehicles interior temperature to your preset setting.
5. The vehicle will run for 5 to 30 minute cycle and automatically shut
down.
(SAFTEY START OPERATION:)
The safety start feature allows you to press the button once before the
vehicle will remote start or remote shut down.
NOTE: The Remote Start Unit will not start the vehicle if any one of the
following conditions exists:
1. The hood is opened.
2. The brake pedal is pressed.
3. Move the optional remote start enable toggle switch to OFF position.
(If installed)
4. The gear selector is in any gear other then “PARK” or “NEUTRAL”
TO TURN OFF THE REMOTE START:

7
When the engine is running (by remote start), if you want to stop it,
1. Press button once on the transmitter.
2. Move the optional remote start enable toggle switch to OFF position.
(If installed)
3. Press the brake pedal, the vehicle will shut down and turn off the parking
light to indicate engine stopped.
TO OVERRIDE VEHICLE FROM REMOTE START CONTROL:
To operate the vehicle while running from the remote start.
1. Insert the ignition key and turn it to “ON” (not the start) position.
2. Press the brake pedal.
Note: If the brake pedal is pressed before the key is in the ON
position, the engine will shut down.
TEMPORARY STOP FEATURE:
This feature allows the vehicle to remain running after the key has been
removed from the ignition. This feature is useful for occasions when you
wish to exit and lock the vehicle for short periods of time, but would like to
leave the engine running and the climate control on.
1. Before turning off the engine, press the button once on the
transmitter. The parking lights will come on and the LED will flash 3
times to confirm Temporary Stop feature ‘ON’
2. Turn the ignition key to OFF position. (The engine will stay running.)
3. The engine will run until the pre-programmed time elapsed or shutdown
input is received.
TIMER START:
This unit can be programmed to start and run the engine every 3 hours.
The engine will run for the programmed run time and then shut down.
IMPORTANT: Timer Start should be used only in open areas, Never start
and run the vehicle in on enclosed space as a garage or carport.
3 hours timer start: This feature is design for an extreme cold climate
usage. The system will auto start the vehicle every 3 hours, to prevent
engine freezing and hard to start.
A MAXIMUM OF SIX CYCLES CAN OCCUR.
ENTER:
1. Press the button once to remote start the vehicle. As soon as the
vehicle is running and the parking lights have turned ‘ON’.
2. Immediately press the button then press button. The parking light
will flash (3) times. The horn chirps (3) times. The vehicle is now
programmed to start every (3) hours.
3. Press the brake pedal to stop the vehicle running.

8
Exit the timer start:
Timer start can be exited manually as follows:
1. Repeat the Enter Steps from above.
Or
1. Make sure the remote start system is not operating the engine.
2. Turn the ignition on. The LED and parking light will flash (4) times. The
horn chirps (4) times.
SHUTDOWN INPUT FOR REMOTE STARTER:
If any of the following conditions exist while the system is operating, the
engine will not start or will shut down immediately:
1. The hood is opened.
2. The brake pedal is pressed.
3. Move the optional remote start enable toggle switch to OFF position. (If
installed)
4. Engine is over-revved. {“Tachometer checking type” only}
5. The pre-programmed run time (5 /10 / 20 / 30 minutes) has elapsed.
6. Transmitter button is pressed.
7. The vehicle refused to start running after {3} unsuccessful attempts.
DISABLING THE REMOTE START SYSTEM: (If installed)
This feature allows your system’s remote start unit to be temporarily
disabled to prevent the vehicle from being remote started accidentally. This
feature is useful if the vehicle is being serviced or stored in an enclosed
area. To disable the remote start, move the optional remote start enable
toggle switch to the OFF position.

9
LIMITED LIFETIME WARRANTY PROVISIONS
( U.S. and Continental U.S. Only)
1. AutoPage, Inc. WARRANTS that this new unit has been thoroughly inspected and
tested at the factory prior to delivery. Your AutoPage equipment is guaranteed for
“life” to the original purchaser/user of the equipment under the following conditions:
If the product proves defective (according to AutoPage’s testing) within the first
year, the defective unit may be exchanged or repaired free of charge. “Proof of
Purchase” (dated sales receipt) must accompany all warranty returns; otherwise,
your return will be rejected and sent back. After one (1) year, the purchaser
should ship the unit prepaid to AutoPage with a money order in the amount of
$20.00 to cover shipping and handling charges. Note: The enclosed Warranty Card
may be required to receive warranty services.
2. This WARRANTY will be considered void if the equipment has been misused,
neglected, improperly serviced, altered, dropped or damaged by water, contrary to
the AutoPage OPERATIONS MANUAL. Or, if used with accessories not
approved by AutoPage, which may have contributed to the defect. See note below
regarding product installation.
3. The purchaser’s remedies under this WARRANTY shall be limited to the repair or
replacement of electronic components only. THE FOLLOWING IS NOT
COVERED: Damages or deterioration to cases, batteries, covers and cabinets; the
cost of repairs, replacement and labor of which shall be borne by the purchaser even
if occurring during the WARRANTY period.
4. Any equipment or parts which are claimed to be defective under this WARRANTY
must be sent to the AutoPage Service center with “proof of purchase” at the
purchaser’s expense prior to such return, a Return Authorization Number should be
obtained. AutoPage will return the equipment, charges prepaid. Warranty Service
can be provided through the dealer where the equipment is originally purchased.
5. Any unexpired WARRANTY shall be applicable to equipment and parts in the
possession of the original purchaser only.
6. THIS WARRANTY IS IN LIEU OF ANY AND ALL OTHER WARRANTIES,
EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY

10
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE.
7. AutoPage shall not be liable, under the foregoing WARRANTIES or otherwise, for:
Any personal injury of any kind to the purchaser, its employees or agents or anyone
else whomsoever resulting directly or indirectly from the use or presence of the
equipment or parts; Consequential damages of any kind; any inability of the
purchaser to use the equipment.
IMPORTANT NOTE: Any damages to the alarm system resulting from an
installation performed by anyone other than a professional installation
technician authorized by a dealer of Auto Page will void the product’s
warranty.
This WARRANTY CARD is for your record. However, Auto Page reserves the
right to request you to submit this WARRANTY CARD, which must have
complete information to receive warranty service. Please keep this card in a
secured place.
AUTOPAGE WARRANTY SERVICE CARD
Model: _______________
Serial # _______________
CUSTOMER TO COMPLETE DEALER TO COMPLETE
Mr./Mrs./Ms.
___________________________ ________________________________
Your Name (Please Print) Company Name
___________________________ ________________________________
Address Dealer’s Address
___________________________ ________________________________
City, State, Zip Code City, State, Zip Code
___________________________ ________________________________
Telephone Number Dealer’s Telephone Number
___________________________ ________________________________
Year / Make / Model of Vehicle Date of Installation / Purchase

11
________________________________
Dealer’s Signature
“Proof of Purchase” which includes the store name and date of purchase must
accompany
all warranty returns.
It is the purchaser’s responsibility to keep this card for any future warranty
service.

12

13
1815 W. 205th Street Suite #101 Torrance, CA 90501
Tel: [phone] or [phone] www.autopageusa.com
