Auto Page C3-RS-1000 OLED User manual

C 3 R S 1 0 0 0 O P 3 / 0 8
1
C3-RS-1000OLED
PROFESSIONAL OLED2-WAY915 MHz.FM REMOTE CAR STARTER
&6CHANNELALARMSYSTEM
W i t h
Built-in Temperature Sensor
And Two-way Serial Port Data Link
Compatible
OPERATION MANUAL
THIS PRODUCT IS DESIGNED
FOR PROFESSIONAL INSTALLATION ONLY
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
2
O L E D R E M O T E T R A N S C E I V E R :
A . O L E D R E M O T E D I S P L A Y ……………………………….…..…………………………………..…………………… 4
TheRemoteTransceiver,XT-100OLED
B . C HARG I NG T HE B A TT ER Y ……….………………………………………………………………………….….. 4
C . MAIN PAGE…………………………………………………………………………………………………………… 5
D. S E L E C T T H E T R A N S C E I V E R’ S B U T T O N C O N F I G U R A T I O N …………………………………………. 6
E.S E L E C T TH E T R A N S C E I V E R F E A T U R E S …………………………………………..………………………. 6
P 1 - 1 : E n a b l e / D i s a b l e B i S o u n d W h i l e P r e s s i n g B u t t o n ( 7 )
P 1 - 2 : B u t t o n L o c k S e t t i n g ( 7 )
P 1 - 3 : M e l o d y / V i b r a t i o n M o d e ( 7 )
P 1 - 4 : D e m o M o d e ( 8 )
P 2 - 1 : P o w e r S a v e M o d e ( 8 )
P2-2: Parking Meter Setting (8)
P 2 - 3 : “ L i g h t F o r O L E D ” T i m e r S e t t i n g ( 9 )
P 3 - 1 : T i m e r S e t t i n g ( 9 )
P 3 - 2 : A l e r t A l a r m T i m e r S e t t i n g ( 9 )
P 3 - 3 : C o u n t D o w n T i m e r S e t t i n g ( 1 0 )
P 3 - 4 : D a i l y S t a r t T i m e r S e t t i n g ( 1 0 )
P 4 - 1 : N a m e o f Transceiver Setting(11)
P 5 - 1 : N a m e o f C h a n n e l Setting(11)
P 6 - 1 : L a n g u a g e S e t t i n g ( 1 1 )
P 6 - 4 : S e t T o D e f a u l t s ( 1 2 )
TABLE OF CONTENTS:
A . R E M O T E T R A N S M I T T E R O P E R A T I O N … … … … … … … … … … … … … … … . … … … … … … … . … … … … . … . … 1 2
B. LED DISPLAY .……………..……………………………………………………………………….………………….. 12
C. CHIRP INDICATOR ..………..……………………………………………………………………………….…..……. 12
D. PARKING LIGHT …….……..…………………………………………………………………………..……….….…. 12
E.ACTIVEARMING–ARM&LOCK.……………………………………………………………………….………….13
Ajar Warning
Silent Arming
Sensor By-Pass
HiddenAlarmMode
F.PASSIVEARMING.…………………………………………..…………………….………………………….….…… 13
PassiveArmingwithPassiveDoorLocking
Passive Arming By-Pass
G.ACTIVEDISARMING–UNLOCK&DISARM.…………………………………………………..………………….13
SilentDisarming
Tamper Disarming
Pathway Illumination
Two Steps Door Unlock
Automatic Re-Arm
H. DISARMING WITHOUT A TRANSMITTER .……………..…………………………………………………..…….... 14
Overrides the Alarm without Password Pin Code
Overrides the Alarm with Password Pin Code
I. VALET MODE .……………..…………………………………………………………………….…………………..…... 14
J. CAR LOCA T O R .…………… … … ……………………………… … …………… … … .………… … ……………… ... … 1 5
K. PANIC FUNCTION .……………………………………………………………………………..….……………….…... 15
L.TRIGGERTHESYSTEM.………………………………………..………………………..………….………….….…..15
Stop The Melody Sound
NoiseAbatement Circuit
M . A N T I C A R- J A C K I N G . … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … … . … … . . 1 6
N. SYSTEM’S TRIGGER CHECK ……………………………………………………………….….….…………....……. 16
O.SYSTEM’SSTATUSCHECK……………………………………………………………..……….…….………..…….16
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
3
P.DRIVERPAGING/LOSTANDFOUND………………………….…………..……………………....………………...17
Q.DOMELIGHTCONVENIENCEDELAY&SUPERVISION……………………..……………….….………..……....17
R. IGNITION CONTROL THE DOOR LOCK/UNLOCK. ………..………………….……………………………..…..….17
S.TRUNKRELEASE(CHANNEL3)OUTPUT………..……………………………………………….……………...….17
T.CHANNEL4/ 5 / 6 TIMERCONTROLOUTPUT………..……………………………………………….…………..17
U. MULTI-VEHICLE SECURITY OPERATION: ………..……………………………………………………………….…17
V.OUTOFRANGEINDICATION:………..…………………………….….…………………………………………….…18
W.POWERONMEMORY.………..……………………………………………………………….…….………………....18
REMOTE START OPERATION:
A . T O R E M O T E S T A R T T H E V E H I C L E … … … . . … … … … … … … … … … … … … … … … … … … … … … … . . … … … … . . 1 8
B. TO OPERATE THE VEHICLE WHILE RUNNING ON THE REMOTE START ………………………………..….. 18
C. TEMPORARY STOP FEATURE ……………………………………………….………………….…………………… 19
D. TURBO TIMER MODE ……………………..………………………………….……………….………...………..….… 19
E.TIMERSTART…………………………………………….…………….……………………….…..……………………19
3 (2or 1) Hours Timer Start
Daily Timer Start
Cancel the Timer Start
F. TEMPERATURE CHECK …………….……………………………………………….…...……….…………….….… 20
G.TOTURNOFFTHEREMOTESTART……………………………………………….….…….………………….….…20
H . S H U T - D O W N I N P U T F O R R E M O T E S T A R T E R …………………………….……………………………..………… 20
I. DISABLING THE REMOTE START SYSTEM …………………………….……………………..……………….….…20
T E S T M O D E … … … … … … … . . … … … … … . ……………………………………………….…...……….………..…….…… 20
WarrantyInformation………………………………………………………………………………………………………….21
Congratulations on your purchase of the RS1000 OLED remote start vehicle security system. We sincerely hope the
purchaseoftheRS1000remotestartsecuritysystemgivesyoupeaceofmind.
TheRS1000LCDisastate-of-the-arttwo-waycommunicationsystem. Pleasetakethetimetoreadoverthismanual
tothoroughlyfamiliarizeyourselfwiththemanyfeaturesandoptionsoftheRS1000.
Auto Page, Inc. has over 25 years of experience in the vehicle security industry in the United States and is a wholly
owned subsidiary of Iwata Electric Co., of Tokyo, Japan. Iwata has been an industry leader for over 50 years,
establishing a reputation for ingenuity in its engineering capability and innovative communication products. Auto
PageandIwatamaintainalongtraditionofprovidingthebestvaluetotheircustomers.
WARNINGS:
As with any product that performs automatic functions, there are certain safety precautions that you must practice and
be awareof.
1. Keep the transmitter out of children’s reach.
2. Do not leave anyone in the vehicle while running on remote control.
3. Alert servicing personnel that the vehicle can be started automatically.
4. Do not start the vehicle by remote while it’s in an enclosed area or garage.
5. Always apply the parking brake and lock the vehicle as you exit the vehicle.
6. The vehicle windows must be rolled up.
7. Should the unit malfunction, disconnect the fuse until the problem is corrected.
8. The use and operations of this system is the sole responsibility of the operator.
9. Some areas may have local ordinances that prohibit leaving a vehicle running on public streets.
10.Itisnotsafetoremotestartthevehicleifthevehicleisparkedonasteepincline.
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
4
REMOTETRANSCEIVER(TX)
A . O L E D D I S P L A Y
Engine
Running
Name of
Transmitter
BatteryLevel
CarJacking
I n – R a n g e I n d i c a t o r
DoorLock
Door Alarm Status
Temperature
Engine
Running
Melody Mode
Timer
Start
Alert Alarm
CountDownTimer
Parking Timer
Clock / Timer
VibrationMode
Bypass Shock
Sensor (Zone 4)
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
5
B . C H A R G E T H E B A T T E R Y
The unit has abuilt-
in 3.7V lithium polymer battery. If the OLED
screen dis play low battery or the i c o n is flashing,
your remote
transceiver needs charging.
Please use the included AC / USB
charger to charge the battery. While the battery is
charging, you can
push the ” ” button to check charging condition.
The battery should
bechargedatleastonceamonthundernormaloperation.
XT -9 0 S : This transmitteruses one(1) 3-volt lithium ion battery (#CR2032) that is placed with the (+) side facing
upward. To replace the battery, you will need to use a small flat blade screwdriver and a small Philips screwdriver.
RemovethesmallPhilipsheadscrew.Thenlocatethesmallnotchonthelowerrightsideofthetransmittercasenext
to the key ring. Using the flat blade screwdriver, carefully pry the top case from the bottomcase. It should snap
apart after breaking the seal. Before removing the battery note the direction of the positive (+) terminal. Place the
new battery in exactly the same manner, being careful not to bend or damage the contact terminal. Snap the cases
back together and then test the transmitter to insure it arms and disarms the alarm. Reinstall the Philips screw to
finalizethebatteryreplacement.
XT-90S Extended Range Sliding Cover remote
s w i t c h
OLEDDisplay
s w i t c h
button
Antenna
s w i t c h
Button
Button 1
Button
Button 3
Button
Button2
Button
Button4
s w i t c h
button
Antenna
ResetHole
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
6
CR2032 3 -V olt Bat ter y
ACPowerSupply:
The remote transceiver equipped AC POWER SUPPLY / AC ADAPTOR (Output Voltage: 4.2VDC – 5.5VDC
and with same USB plug), then you can charge the battery indoors.
This screen will be
displayed
while the battery of the
Remote Transceiver is
charging.
C. MAIN PAGE:
1. Pressthe button, the screen will display the main page.
2. WhenaniconisflashingontheOLEDscreen,pressthe button. The OLED screen will display the
details of the flashing icon. The sequence of flashing icons is as follows: TRIGGERED / ENGINE
RUNNING / COUNT DOWN TIMER / TIMER START / ALART TIMER conditions .
Whilethe
T R I G G E R E D icon
isflashing.
Pushthe
buttontodisplay
thetriggered
area.
or or or
Whilethe icon
flashes Pushthe button
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
7
Whilethe icon
flashes. Pushthe button and the
countdowntimerwillbe
display
ed
.
Pressbutton2to stop the
countdowntime.
or or
While the
icon
flashes. Pushthe button, the OLED screen will display individually i.e. daily start timer
,
timerstartortemperaturestart,dependingonwhichyouhaveselected.
Whilethe iconis
flashing.
Pushthe button, the alert
a l a r m tim e w i l l d i s p l a ye d. Pressbutton2to turnOFF
the alertalarm timer.
D . S E L E C T T H E T R A N S C E I V E R ’ S B U T T O N C O N F I G U R A T I O N :
1. Spin the jog shuttle up Switch to select the transceiver button configuration. The OLED screen will
display the transceivers button configuration you would like to select.
2. Within 5 seconds, press buttons 1, 2, 3or 4to select the remote controls “button configuration”.
Note: If 5 seconds of inactivity expired, or the buttonis pressed, the transceiver button configuration mode
willexit.
Spin up the switch
topage 1 . Spin up the switch topage 2. Spinupthe switch
topage
3
.
Spinupthe switch
topage4 .
Spinupthe switch
topage5 . Spin up the switch
topage 6 . Spin up the switch
to
r e
turn
to
the
mainpage
.
E . S E L E C T T H E T R A N S C E I V E R F E A T U R E S :
1. Spinthe jog shuttle down Switch to select the transceiver feature you need and the OLED screen will
display the features you have selected.
2. Press buttons 1, 2, 3 or 4 once within 3 seconds after making a selection and the OLED screen will
change to the alternative display.
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
8
Note: If 5 se co nds of in activ ity exp ires or i f t h e button is pressed, the transceiver features program mode
willexit.
Spindownthe
switch
topage 1 . Spindownthe
switch
topage 2. Spindownthe switch topage3. Spindownthe switch topage4 .
Spindownthe
switchtopage5 . Spindownthe
switchtopage6 . Spindownthe
switchto returnto the
mainpage
.
E- P1- 1. “BUTTON BI” SETTING: Example: Set the “Button Bi Disable”.
The unit has a short “bi” sound while pressing the buttons of the remote transceiver
Spindownthe
switch
to page 1.
Pressbutton1and it
willdisplaytheprevious
setting.
Pressbutton2to
changethesetting. Pressthe
buttonand
thesettingiscomplete.
E- P1- 2. “BUTTON LOCK” SETTING: Example:Setthe“ButtonLockEnable”.
Spindownthe
switch
to page 1.
Press button 2and it
willdisplaytheprevious
setting.
Pressbutton1to
changethesetting. Pressthe
buttonand
thesettingiscomplete.
D-P1-3.“MELODY/ VIBRATIONMODE”SETTING: Example: settheVibrationmode.
Spindownthe
switch
to page 1.
Pressbutton3andit
willdisplaytheprevious
setting.
Pressbutton2to
changethesetting. Pressthe
buttonand
thesettingiscomplete
andthe icon will
display
onthe
O
LED
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
9
screen.
E- P1- 4. “DEMO MODE”: To display the units demo mode
Spindownthe
switch
to page 1. Pressbutton4 to start
theDemomovie.
Demo movie playing. PressanyButtontoexit.
E- P2- 1. “POWER SAVE” SETTING: Example set the “Power Save Enable”.
While in the power save mode, the LCD remote transceiver uses “0” current to save the battery power.
Spindownthe
switch
to page 2.
Pressbutton1and it
willdisplaytheprevious
setting.
Pressbutton1to
changethesetting. Press the
buttonand
thesettingis
completed. You can
disablepowersave
modeinthesame
manner.
E- P2- 2.“PARKINGMETER”SETTING:Parkingtimer: Example set the “Parking Meter 30 min..
Note: When the “parking meter” expires, press any button to stop the beeper.
Spindownthe switch
to page 2. Pressbutton2. Pressbutton1three
timestosettheparking
timerto30minutes.
This will toggle between
10/20and30minutes.
Pressthe button to
starttheparkingmeter
andthe icon will
flashonthemainpage.
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
10
D-P2-3.“LIGHTINGFOROLED”SETTINGS: Example: Set theON time for theOLED display from 2
seconds to 3seconds.
Spindownthe
switch
to page 2.
Pressbutton4andit
willdisplaytheprevious
setting.
Pressbutton2to
changethesetting. Pressthe
buttonand
thesettingisdone.
D-P3-1.“T I M E R / C L O C K ” S E T T I N G S : Example: setthe clockto 0 8 : 2 0 P M
Spindownthe
switch
topage 1.
Pressbutton1and
the”hours” digit flashes
for adjusting.
Pressbutton2toset
the”hours”digitto“08
” .
This can also be done
withthejogshuttle.
Pressbutton1and
the ”minutes ” dig it
flashes for adjusting.
Pressbutton2toset
the“minutes”digitto
“20 ”.Thiscanalsobe
donewiththejog
shuttle.
Pressbutton1and
the”A”digitflashesfor
adjusting. AM or PM.
Pressbutton2to set
the“P”. Pressbutton3andthe
settingiscompleted.
D-P3-2.“ALERTALARMTIMER” SETTING: Example set alertalarmtimer to 06:30A
Note: When alert alarm timer trigger press any button to stop the beeper.
Spindownthe
switch
to page 3
Pressbutton2and
the”hours” digit flashes
for adjusting.
Pressbutton2to set
the”hour”digitto“06”.
This can also be done
withthejogshuttle.
Pressthebutton1and
the ”minutes ” dig it
flashes for adjusting.
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
11
Pressbutton2 to set
the”minute”digitto
“30 ”.Thiscanalsobe
donewiththejog
shuttle.
Pressbutton3to set
thealertalarm timer
andthe iconwill
flashonthemain
page.
Pushthe button
Whilethe icon is
flashingorwhenalert
a l a r m ti m e r tr i gg er , t
he
screenwilldisplaythe
a l er t al a r m ti m e r .
Press button 2to turn
OFF the alert alarm
timer or press any
buttontostopthe
alarmwhilealerta
larm
timer is triggered.
C-P3-3.“COUNTDOWNTIMER” SETTING: Example:set the countdowntimer to2 : 3 0
Note: When count down timer is triggered, press any button to stop the beeper.
Spindownthe
switch
to page 3. Press button 3and
the”hours” digit flashes
for adjusting.
Pressbutton2to set
the”hours”digitto“02 ” .
Thiscanalsobedone
withthejogshuttle.
Pressbutton1and
the ”minutes ” dig it
flashes for adjusting.
Press button 2to set
the”minutes”digitto
“30 ”.Thiscanalsobe
donewiththejog
shuttle.
Pressbutton3to start
th e c ount d o wn
timer and the icon
willflashonthemain
page.
Whilethe iconis
flashingpushthe” ”
buttontodisplay the
countdowntimer.
Pressbutton2to turn
OFF the count down
time.
C-P3-4.“DAILYSTARTT I M E R ” S E T T I N G : Example set the Daily Start Timer to 05:00A. This is to set
the start time. Please refer to daily start timer operations to use the daily timer start. (Page # 19)
Spindownthe
switch
to page 3.
Press button 4
and
the”hours” digit flashes
for adjusting.
Pressbutton2to set
the”hours”digitto“05 ”.
This can also be done
withthejogshuttle.
Pressbutton1and
the”minute”digit
flashesforadjusting.
This can also be
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
12
donewiththejog
shuttle.
Pressbutton2to set
the”minute”digitto
“00 ”.
Pressbutton3and the
setting is done. While the icon is
flashing push the” ”
buttontocheckthedaily
s
ta rt
t
imer
.
D-P4-1.“NAMEOFTX”SETTING: Example Set Name of Transceiver 1 to MIKE
Spindownthe
switchtopage
4 .
Pressbutton1
andthe“-”
flashesfor
setting.
Spindownthe
switchtosetthe
“M ”.
Pressbutton1
and the“-”
flashes for
setting.
Spinupthe ”
switchtoset
the”I”.
Pressbutton1
and the “-”
flashesfor
setting.
Spindownthe
switchtoset
the”K”.
Pressbutton1
and the“-”
flashesfor
setting.
Spinupthe
switchtoset
the”E”.
Pressbutton3
andthesettingis
done.
D-P5-1.“NAMEOFCHANNEL”SETTING: Example Set Name of channel 4 to GARAGE DOOR
Spindownthe
switchtopage5. Pressbutton1
and the“-”
flashesfor
setting.
Spinupthe
switch to set
the”G”.
Pressbutton1
and the“-”
flashes for
setting.
Spindownthe
switchtosetting
the”A”.
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
13
Followingthe
above step to
setting
Alphabeticalto
GARAGEDOOR
Pressbutton1
and the“-”
flashesfor
setting.
Spindownthe
switchtoset
the”R”.
Pressbutton3
andthesettingis
done.
D-P6-1.LANGUAGE SETTING: Example set the Language to English
Spindownthe
switch
to page 6. Pressbutton1to set the Language to ”E N G L I S H ”.
Pressthe button and
the setting is done.
D-P6-2.SET TO DEFAULTS:
Spindownthe
switch
to page 6. Pressbutton4.Pressbuttons1& 2at
sametimetosetthe
defaults.
OPERATION:
A . R E M O T E T R A N S M I T T E R O P E R A T I O N :
Transmitter Button System Function Remark
1
Lock Doors & Arm System
/ Button
1
- Arm and B y p a s s Zone 4. Sh ock S en s or Pres s t wi ce with in 3 s eco nds
then Arm System and Hidden, (Silent) Alarm
Function Press within 3 seconds
Car Locator Upon armed
( 3 - s e c o n d ) Panic function Press and Hold for 3 seconds.
Tocancel.
+ Silent Arming / Disarming Ignition in "off" position.
+ (2-second) Active Anti Car-Jacking Mode. Programming
r e q u i r e d
Ignition in "on" position press and
hold for 2 seconds
2
Unlock Doors & Disarm System / Button 2
-
T w o S t e p s D o o r U n l o c k & D i s a r m S y s t e m P r e s s t w i c e w i t h i n 3 s e c o n d s .
3
(3-second) Trunk Release (Channel 3) Press and Hold for 3 seconds
-
Passive Arming By
-
pass
WhilethesystemDisarmed.
4
Turn ON & Off The Remote Start / Button 4.
-
Safety Start. Programming required Press twice within 3 seconds.
+Channel # 4 Timer Output Programming required
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
14
+
Channel # 5 Timer Output
Programming required
+Channel # 6 Timer Output Programming required
II
Switching code For 2nd Car Operation. For regular remote transmitter
Button Function Selection For Two way Remote transceiver
C o n f i r m
Button/BacktoMainPage
For Two way Remote transceiver
Feature Selection For Two way Remote transceiver
B.LEDdisplay:
LED Function LED Function
O f f D i s a r m e d 1 f l a s h e s . . . p a u s e Z o n e 1 / T r i g g e r o n H o o d
Slow Flash Armed 2 flashes... pause Zone 2 / Trigger on Trunk
Fast Flash
Passive Arming
3 flashes... pause
Zone 3 / Trigger on Door Switch
On (Solid)
ValetMode
4 flashes... pause
Zone 4 / Trigger on Shock Sensor
PauseOn
Password Lock
-
Out
5 flashes... pause
Zone 5 / Trigger on Ignition Switch
C.CHIRPINDICATORS: D.PARKINGLIGHT:
Chirp Function Parking light Function
1chirp Arm 1 flash Arm
2chirps Disarm 2 flashes Disarm
3chirps Ajar Warning 3 flashes Disarm / Triggered
4chirps Disarm /Triggered 12 flashes Car Locator
6chirps CarLocator Constant On Under Remote Start
E. ACTIVE ARMING– LOCK & ARM:
1 . P r e s s t h e button on the transmitter.
2 . T h e s i r e n w i l l c h i r p o n c e a n d p a r k i n g l i g h t w i l l f l a s h o n c e i n d i c a t i n g t h a t t h e s y s t e m i s n o w a r m e d . T h e
vehicle door will lock upon arming when interfaced with the security system.
AJAR WARNING: If the siren sounds 3 chirps, then you have left a door, trunk, or hood lid ajar.
SILENT ARMING:Spin up the switch to the page1and then press the “Silent Arm” buttonorpress the
transmitter and buttons at the same time to arm your security system, No chirp sound will be heard,
arm confirmation will be through the vehicles parking lights only.
SENSOR BY-PASS:
Bypass The Zone 4: Spin up the switch to the page 2and then
press the button 1or press the bu tto n on
the transmitter two
times within 3 seconds. This will arm the security system and
b y - p a s s t h e z o n e 4 - s h o c k s e n s o r .
The system will chirp one additional time to confirm the sensor bypass mode was
activated. The sensor bypass feature is programmed to activate for one arming cycle
only. The security system will return to normal operation during the next arming cycle.
HIDDEN ALARM FUNCTION (Silent Alarm): Spin up the switch to the page 1 and
then press the “Hidden Alarm” button or press the button first; within 3 seconds
press the button to activate the hidden alarm function. The security system will arm
and with “Hidden Alarm Function” The siren / horn will be silenced even if the unit is
triggered in the armed status. Notification will only be through the hand held two-way
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
15
remote.
F. PASSIVE ARMING (Programming Required)
Active arming / disarming is controlling your security system via the remote transmitter. This security system
is equipped with an optional Passive Arming feature which allows the security system to arm 30 seconds
after the last door is closed. Operation is as follows.
1.Turntheignitiontothe“OFF”positionandexitthevehicle.
2.Afterallentrancesareclosed,thesecuritysystemLEDwillflashfastfor30seconds.Ifyoureopenany
door / hood / trunk, the security system LED will stop flashing. It will begin flashing again once all of the
vehicle entrances are closed.
3.After30-secondtimerhaselapsed,thesecuritysystemwillautomatically“ARM”.Thesirenwillchirp[1]
time and the parking lights will flash [1] time.
PASSIVE ARMING WITH PAS SIVE DOOR LOCKING:
Thevehicledoorswillautomaticallylockafterpassivearmingcyclehasbeencompleted.
PASSIVE ARMING BY-PASS: While the system disarmed, Press the button twice, the security will respond
with [1] chirp and LED will turn “ON”. The security syste m w ill remain in this temporary state for as long as you
w is h . T o e xi t p a ss i ve b y- p a s s , p r e s s t h e t r a n s m i t t e r o r button and the system will return to normal status.
G.ACTIVEDISARMING–UNLOCK&DISARM:
1.Press button on the transmitter.
2.Thesirenwillchirptwiceandparkinglightflashtwicetoindicatingthatthesecuritysystemisnowdisarmed.
The vehicle’s door will unlock and dome light turns on for 30 seconds upon disarming when interfaced with
the security system.
SILENT DISARMING: Spin up the switch to the page 1and
then press the “Silent Disarm” button or press the transmitter
and buttonsat the sametimetodisarmyoursecurity
system, No chirp sound will be heard, arm and disarm
confirmation will be through the vehicles parking lights only.
TAMPER DISARMING: If alarm triggered, upon disarming the system, the siren will chirp 4 times and the
parking light will flash 3 times.
PATHWAY ILLUMINATION: This feature turns the parking lights “ON” for 30 seconds upon an unlock
signal and for 10 seconds upon the lock signal. (Programming required)
TWO STEPS DOOR UNLOCK: This feature will independently unlock the driver’s door only when disarming
the security system. Pushing the button a second time within 3 seconds will unlock the other doors.
(Additional installation is required)
A UT O MA TI C R E - A R M: If this feature is selected, the security system will automatically re-arm itself in 60
seconds after disarming with remote transmitter. Automatic rearm will cancel if the ignition is turned ON
and will pause if any door is opened before the 60 seconds timer has elapsed.
H.DISARMINGWITHOUTATRANSMITTER
OVERRIDES THE ALARM WITHOUT PASSWORD PIN CODE: (Factory Default Setting)
The Override function may be used if the remote transmitter is lost or inoperative.
1 . E n t e r t h e v e h i c l e a n d t u r n t h e i g n i t i o n s w i t c h t o ' O N ’ p o s i t i o n . ( A l a r m w i l l s o u n d . )
2 . W i t h i n 1 0 s e c o n d s p u s h a n d r e l e a s e t h e v a l e t s w i t c h
The alarm will stop sounding and enter the disarmed mode. You can now start and operate the vehicle
n o r m a l l y .
OVERRIDE THE ALARM WITH PASSWORD PIN CODE:
If the valet switch is located in a place that can be easily found, this security system allows the consumer to
program a password pin code offering a higher level of security.
1. Enter the vehicle and turn the ignition switch to the 'ON’ position. (Alarm will sound.)
2. Within 5 seconds, enter your chosen the first digit code by pressing and releasing the Valet Switch.
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
16
(When you are finished with the above procedures, the system's siren stops alarming and the parking
lights stop flashing, but the vehicle cannot be started and driven away.)
3 . I f y o u u s e o n e d i g i t t o b e a p a s s w o r d p i n c o d e , s k i p t o S t e p 6 . I f y o u u s e t w o d i g i t s t o b e a p a s s w o r d p i n c o d e ,
a d v a n c e t o S t e p 4 .
4. Within 15 seconds of the last digit code enter (the 1st code), turn the Ignition Switch “Off” and then “On”.
5. Within 15 seconds, enter your chosen of the second digit code by press and release the Valet Switch.
6. Turn the ignition switch to the “OFF” position. [4] Chirps form siren/horn, [3] flash from parking light to
indicate the system was disarmed.
Note: If someone keys-in the wrong password pin code, the system allows him to make 2 mistakes. If the
third code is still wrong, it will automatically shut down for 5 minutes. During this period the system
will not accept any code and the LED will “pause on” (the LED will turn on 1 second
and turn off 0.1 second).
EXAMPLE: To Override The System With The Password Code 83, you would;
1 . E n t e r t h e v e h i c l e a n d t u r n t h e i g n i t i o n s w i t c h t o ' O N ’ p o s i t i o n . ( A l a r m w i l l s o u n d . )
2 . W i t h i n 5 s e c o n d s , P r e s s a n d R e l e a s e t h e V a l e t S w i t c h 8 t i m e s
(When finish the above procedure, the system's siren will stop alarming and the parking lights will stop
flashing, but the vehicle cannot be started and driven away.)
3 . W i t h i n 1 5 s e c o n d s o f t h e l a s t d i g i t c o d e e n t e r ( t h e 1 st code), turn the Ignition Switch “Off” and then “ON”.
4 . W i t h i n 1 5 s e c o n d s , P r e s s a n d R e l e a s e t h e V a l e t S w i t c h 3 t i m e s
5 . T u r n t h e I g n i t i o n S w i t c h t o “ O f f ” p o s i t i o n . [ 4 ] C h i r p s f o r m s i r e n / h o r n a n d [ 3 ] f l a s h e s f r o m t h e p a r k i n g l i g h t
will indicate the system has been disarmed.
I. VALET MODE: (SysteminDisarmorValetmode)
The valet switch allows you to temporarily bypass all alarm functions, eliminating the need to hand your
transmitter to a parking attendants or a garage mechanic.
When the system is in valet mode, all alarm function and remote
start functions
are bypassed, however the remote panic feature
and remote door locks will remain operational. To use the valet
mode, the system must first be disarmed.
Enter Valet Mode:
1.
From the disarmed condition, turn the ignition to the “ON”
position.
2. Push and hold valet switch for 2 seconds until the L
ED turns on
solid. The LED will
remain on as long as the system is in 'valet
mode'.
ExitValetMode:
1. To return to normal operation, turn the ignition 'ON'.
2.
Push and hold valet switch for 2 seconds. The LED will turn off to
indicate the system has exiting the valet mode.
J . C A R L O C A T O R
While the system is armed, press the button to activate
car locator function. The
siren will chirp 6 times. The parking lights
will flash 12 times, for you to easily locate
your vehicle.
K.PANICFUNCTION:
The transmitter can be used as a remote panic switch to manually trigger the alarm in case of an emergency.
1.Pressandholdthe button for 3 second. The alarm will immediately sound and
the
“Panic” icon will display on the OLED screen.
2.Duringpanicmode,thenormalfunctionofthistransmitterbuttonwillbesus
pended.
The transmitter a n d
buttons can be used to lock and unlock the door (if the
option is installed), however once the
button is pressed, the vehicle’s starter
disable device, (where installed) will be enable allowing the vehicle to start.
3. To stop the alarm press the transmitters . The panic mode will be turned off immediately.
4. If the button is not pressed, the alarm will automatically stop after 30 seconds.
L. TRIGGERING THE SYSTEM
When armed, your vehicle is protected as follows:
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
17
1 . L i g h t i m p a c t w i l l t r i g g e r t h e w a r n - a w a y s i g n a l .
2 . H e a v y i m p a c t s / D o o r s o p e n / H o o d o p e n / T r u n k o p e n / T u r n i n g o n t h e i g n i t i o n k e y w i l l t r i g g e r t h e
programmed sequence.
The starter disable relay (if installed) prevents the vehicle’s starter from cranking. The siren, horn, parking
lights, and dome light will turn on to alert of an intrusion for 30 seconds. Then it will stop and automatically
reset and re-arm. If the sensors or detectors are still active, the alarm system will sound a maximum of 6
times of 30 seconds cycles.
Stop The Melody Sound:
While triggering the alarm
the OLE
D screen will alert user through melody
sound and flashing trigger icon, press any button on
the OLED remote transceiver to stop melody sound.
NOISE ABATEMENT CIRCUIT: Your system has “Noise Abatement Circuit”. It can prevent annoying
repetitive trigger sequences due to faulty door pin switches or environmental condition such as thunder,
jackhammers, airport noise, etc.
Here’s how the “Noise Abatement Circuit” work s: If the alarm triggers five times, each time the same sensor
(zone 4) is triggered the “Noise Abatement Circuit” will interpret this pattern of triggers as false alarms. After
the fifth trigger, the “Noise Abatement Circuit” ignores, or bypasses that sensor until any other sensor or
switch is triggered.
“Noise Abatement Circuit” covers doors (Hood/Trunk) differently: If the alarm is triggered by an open door for
sixfullcycles,thedoorswillbebypasseduntilthetriggerceases.
M . A N T I C A R - J A C K I N G ( P r o g r a m m a b l e )
Warning: If you do not need the car jacking function in this alarm system, be sure to set the car jacking
feature “OFF”. This systems default setting is car-jacking feature “OFF”.
ACTIVE ANTI CAR JACKING:
1. Spin up the switch to the page 1and then press and hold the “Car Jacking” button
for 2 seconds or press and ho ld the transmitt er and buttons at the same time
for 2 seconds while the vehicle’s ignition is ON. The parking lights will turn on for 1.5
seconds to indicate the system has entered the car-jacking mode.
2. Once the system is in car-jacking mode and you are forced from the vehicle, the
system will be triggered when the door is opened and closed while the ignition is in
the “ON” position.
PASSIVE ANTI CAR- JACKING: (Programmable)
1. Turn the ignition switch to the “ON” position. The system enters the car-
jacking
mode.
2. Once the system is in car-
jacking mode and you are forced from the vehicle, the
system will trigger when the door is opened and closed while the ignition i
sinthe
“ON” position.
TRIGGER SEQUENCE OF THE ANTI CAR - JACKING MODE:
a). 50 seconds after the system has been triggered. The siren will start chirping for 15 seconds.
b). During this 15 second period of chirping, you will be alerted to push the valet switch once to turn off the
car-jacking feature. If not, it will enter the second timer of the car jacking sequence.
c). 65 seconds after the system has beer triggered the siren starts alarming and the parking lights will start
flashing.
d). 90 seconds after the system has beer triggered
1.Thesirenwillstillbealarmingandtheparkinglightswillcontinueflashing.
2.Thestarterdisablewillactivatetopreventthevehiclefromstartingifstopped.
3.Itwillremainactiveuntilthevehicle'sbatterypowerisexhausted.
OVERRIDE THE SYSTEM TO TURN OFF ANTI CAR- JACKING:
Turn the ignition switch from OFF to ON and within 10 seconds push valet switch, the siren will stop and the
system will be disarmed
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
18
* N o t e : If you use password pin code to double protect the vehicle security, you will need to use it to
completely disarm the system.
N.SYSTEM’STRIGGERCHECK
Spin up the switchtothepage4and then press the “Trigger
Check” button. The remote will respond with one melody sound and
all trigger re cords will immediately be displayed on the OLE D
screen.
Note: It will display the homepage if there were no system’
s
triggered.
O.SYSTEM’SSTATUSCHECK
Spin up the switchtothepage4and then press the “Status
Check” button. The remote will respond with one melody sound and
the vehicles sta t u s w ill i mme dia t ely b e dis pla yed o n the OL ED
screen.
Note: It will display the home page if the car’s status is normal.
P. DRIVER PAGING/ LOST & FOUND
This feature is useful in the event that someone wants to page the driver of the parked vehicle or you cannot
find his OLED remote transceiver.
IndoorDrivingPaging
If the ignition switch is in the “off” position, press and hold the valet switch for 2 seconds
to page the driver. One chirp sound shall
be emitted from the vehicle and the paging
melody will sound from your Remote OLED transceiver. “DRIVER PAGING
” indication
will flash on the OLED screen.
OutdoorDrivingPaging(optional)
If someone tries to page you by tapping the paging (knock) sensor, the paging melody will sound on your
Remote OLED transceiver and “DRIVER PAGING” indication will flash on the OLED screen. The knock
sensor is usually located on the driver’s side of the front windshield.
1. Spin up the switch to the page4and then press the “Driver Pager” button. It will respond with chirps
from the vehicle. A melody sound and “DRIVER PAGING” indication flashes on the OLED screen to
confirm the function has been turned ON.
2 . W h e n t a p p i n g t h e p a g i n g ( k n o c k ) s e n s o r o n t h e v e h i c l e , o n e c h i r p s o u n d w i l l b e e m i t t e d a n d t h e p a g i n g
melody will sound from the Remote OLED transceiver. The “DRIVER PAGING” indication will flash on the
O L E D s c r e e n .
3. Turning ON the ignition switch or pressing the button or button will exit the driver paging mode.
Q.DOMELIGHTCONVENIENCEDELAY&SUPERVISION
The alarm has a unique feature, which will turn on your vehicle’s dome light as follows:
1 . U p o n d i s a r m i n g , t h e i n t e r i o r l i g h t w i l l r e m a i n o n f o r 3 0 s e c o n d s .
2 . I f t h e v e h i c l e i s i n t r u d e d , t h e i n t e r i o r l i g h t w i l l f l a s h f o r t h e s a m e d u r a t i o n a s t h e s i r e n .
Note: Turning ON the ignition switch or arming the alarm will turn off the dome light.
R.IGNITIONCONTROLDOOR LOCK/UNLOCK.
If the vehicles power door locks have been interfaced to the security system, the system will automatically
lock the vehicle's doors in 3 seconds when the ignition is turned “ON” and /or unlock the vehicle’s doors when
the ignition is turned “OFF”. (Programmable)
S. TRUNK RELEASE (CHANNEL 3) OUTPUT.
Press and hold button on the transmitter for three seconds to remotely control the
trunk release or other electric devices.
T. CHANNEL 4/5/6 TIMER CONTROL OUTPUT
Activate The Channel 4:Spin up the switchtothepage3and then press the “Channel 4” button or press
thetransmitter and buttons at the same time to active Channel 4 function.
Activate The Channel 5:Spin up the switchtothepage3and then press the “Channel 5” button or press
the transmitter and buttons at the same time to active Channel 5 function.
Activate The Channe l 6 : Spin up the switchtothepage3and then press the “Channel 6” button or press
the transmitter a n d buttons at the same time to active Channel 6 function.
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
19
U.MULTI-VEHICLESECURITYOPREATION:
Your remote transmitter can be utilized to control multi- vehicle security system, to program the remote
control transmitter to a second vehicle, follow the instructions for Transmitter programming. All programming
parameters will be the same except for the following:
ForRegular Remote Control Transmitter:
1 . P r i o r t o p u s h i n g a n y b u t t o n o n t h e t r a n s m i t t e r . P r e s s t h e S e l e c t II button first on the transmitter.
2 . O n c e II button is pressed the LED on the transmitter will illuminate for 3.5 seconds to indicate the
second transmitter pin code is ON.
3 . W h i l e t h e L E D i s i l l u m i n a t e d , p r e s s a n y b u t t o n o n t h e r e m o t e c o n t r o l t r a n s m i t t e r t o c o n t r o l a s e c o n d
vehicle security system.
For2-way OLED Remote Control Transceiver:
A maximum of
four ve hicl e’ s
security
systemscanbe
controlled by
this transceiver.
TX1 Red Vehicle
TX2 Blue Vehicle TX3 Yellow Vehicle TX4 Green Vehicle
Spin up the switch
To page 6
Thefour transmitters
will bedisplayonthe
OLEDscreen,youcan
choseoneofthefour
transmitterstocontrol
yourvehiclesecurity
system. Pressingbutton3will
settheremote..“TX3”
willbedisplayedonthe
OLED screen
Nowyoucanpress
button to remote control
The“TX3”yellow
vehicle’s security
system.
V.OUTOFRANGEANDTEMPERATUREINDICATION:
If this feature is selected, the system will automatically check the range and update the
temp er a tur e e very 33 m i n u t e s .
1. If the user is within the range, the icon will display on the OLED screen.
2. If the user is out of range, the remote will have five short “bi” sounds and the “Out Of
Range” icon will appear on the OLED screen.
Not e: Programming “Out Of Rangeand Temperature Indication” will decrease the life
e x p e c t a n c y o f t h e b a t t e r y .
W. POWER ON MEMORY:
This security system is equipped with circuitry that will allow the unit to remember its alarm state if the power
is lostandthenreconnected.
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv

C 3 R S 1 0 0 0 O P 3 / 0 8
20
REMOTESTART OPERATION:
A . T O R E M O T E S T A R T T H E V E H I C L E :
1. Press the button on the transmitter. Twice if safety start has been programmed.
2. The parking light will activate to indicate the remote start received the signal. (
A
melody sound from your Remote OLED transceiver and “
” icon will flash on the
O L E D s c r e e n t o c o n f i r m t h e r e m o t e s t a r t w a s a c t i v a t e d . )
3. The engine will start in approximately 5 seconds.
4. Once the engine is running, after the parking lights will turn o
n again and your
climate controls will activate and adjust the vehicles interior temperature to your
Preset setting. (While the vehicle is running, the “Engine Running
” icon and the
“minutes” digit on the OLED screen will flash. It will indicate a count
down timer
based on the 5, 10, 20 or 30 minute run time set up by your installation center.)
5. The vehicle will run for a 5 to 3
0 minute cycle and automatically shut down. (When
the unit shuts off the count down timer will turn off and the transmitter wil
l play a
melody.)
Note: The Remote Start Unit will not start the vehicle if any one of the following
conditions exists:
1. The hood is opened.
2. The brake pedal is pressed.
3. Move the optional remote start enable toggle switch to OFF position. (If installed)
4. The gear selector is in any gear other then “PARK” or “NEUTRAL”
B.TOOPERATETHEVEHICLEWHILERUNNINGONTHEREMOTESTART:
To operate the vehicle while engine running on the remote start.
1 . E n t e r t h e v e h i c l e a n d i n s e r t t h e i g n i t i o n k e y . T u r n i t t o “ O N ” n o t t h e s t a r t p o s i t i o n .
2 . P r e s s t h e b r a k e p e d a l .
Note: If the brake pedal is pressed before the key is in the ON position, the engine will shut down.
C.TEMPORARYSTOPFEATURE:
This feature allows the vehicle to remain running after the key has been removed from the ignition. This
feature is useful for occasions when you wish to exit and lock the vehicle for short periods of time, but would
like to leave the motor running and the climate control on.
1. Before turning off the engine, press the but t o n o n t h e t r a n s m i t t e r . T w i c e i f s a f e t y s t a r t h a s b e e n
programmed. The LED indicator will flash 3 times to confirm.
2.Turn the ignition key to OFF position. (The engine will stay running.)
3.The engine will run until the pre-programmed time elapsed or a shutdown input is received.
D.TURBOTIMERMODE:
T u r b o t i m e r m o d e k e e p s t h e e n g i n e r u n n i n g a f t e r a r r i v i n g a t y o u r
destination for a
programmable period of 1, 3 or 5
minutes. This allows the system time to conveniently
cool down the turbo after you have left the vehicle. To activate the turbo timer:
1. While engine is running, place the transmission gear in the park position and pull up
the hand brake.
2. Before turning off the engine, Spin up the switch to the page 5
and then press the
“Turbo Start” button or press and release and buttons at the same time.
-- The parking light will activate to indicate the remote start has entered turbo timer mode. --
3.Pulloutthe“IgnitionKey”fromthekeycylinder.
-- The engine will continue to run. --
4.Exitandsecurethevehicle.
-- Engine continues running until the pre-programmed time has elapsed. --
If you do not want the vehicle to continue running, simply step on the vehicle's brake, or activate the
button in succession. Any of these will cause the engine to turn off.
E. TIMER START:
Your system has the ability to automatically start the vehicle every 1,2 or 3 hours and run for the
pre-programmed time (5, 10, 20 or 30 minutes), and then shut off. This will continue for 6 cycles. This feature
is especially useful in cold climates where the only means to keep the engine and engine fluids warm is to
periodically start the engine.
If the system is set up to start in temperature mode, the system can be programmed to automatically start
the vehicle’s engine whenever the temperature inside the vehicle reaches or drops below the preprogrammed
temperature level. The system will monitor the air temperature every 3 hours and will only start the engine
SVMASTER -       - http://www.msvmaster.lv
SVMASTER -       - http://www.msvmaster.lv
